Fisher & Paykel ELBA CG905 Series Mounting instructions

GB IE
Installation instructions
and User guide
Gas cooktops
CG604 & CG905 models

1
Contents
Safety and warnings 2
Installation instructions 6
Introduction 18
Using your cooktop 19
Cooking guidelines and cookware 22
Care and cleaning 24
Troubleshooting 29
Warranty and service 31
Important!
SAVE THESE INSTRUCTIONS
The models shown in this document may not be available in all markets and are
subject to change at any time. For current details about model and specification
availability in your country, please visit our local website listed on the back cover
or contact your local Fisher & Paykel dealer.

2
Installation
WARNING!
Cut Hazard
Beware of sharp edges when handling stainless steel appliances.
Failure to use caution could result in injury or cuts.
WARNING!
Electrical Shock Hazard
Before carrying out any work on the electrical section of the appliance, it must
be disconnected from the mains electricity supply.
Connection to a good earth wiring system is absolutely essential and
mandatory.
Alterations to the domestic wiring system must only be made by a qualied
electrician.
Failure to follow this advice may result in electrical shock or death.
Safety and warnings

3
Important safety instructions!
Installation
This appliance shall be installed in accordance with the applicable regulations in force and only
used in a well ventilated space. Read the instructions before installing or using this appliance.
Please make this information available to the person installing the appliance as it could reduce
your installation costs.
This appliance must be installed and serviced only by a suitably qualified and registered person.
In order to avoid a hazard, this appliance must be installed according to these instructions.
Incorrect installation, for which the manufacturer accepts no responsibility, may cause personal
injury or damage and could invalidate any warranty or liability claims.
Prior to installation, ensure that the local distribution conditions (nature of the gas and gas
pressure) and the adjustment of the appliance are compatible.
The adjustment conditions for this appliance are stated on the label.
This appliance is not connected to a combustion products evacuation device. It shall be installed
and connected in accordance with current installation regulations. Particular attention shall be
given to the relevant requirements regarding ventilation.
The flexible hose shall be fitted in such a way that it cannot come into contact with a movable
part (eg drawer) and does not pass through any space susceptible of becoming congested.
If the electrical supply cord is damaged, it must only be replaced by an authorised person.
Ensure that the electrical connection plug is accessible after installation.
This appliance should be connected to a circuit that incorporates an isolating switch
providing full disconnection from the electricity supply.
Do not modify this appliance.
No combustible materials or products should be placed on this appliance at any time.
This appliance should not be sealed into the bench with silicone or glue. Doing so will make
future servicing difficult. Fisher & Paykel will not be liable for costs associated with releasing such
a product, nor for repairing damage that may be incurred in doing this.
Packing elements (eg plastic bags, polystyrene foam, staples, packing straps etc) and tools
should not be left around during and after installation, especially if they are within easy reach of
children, as these may cause serious injuries.
Safety and warnings

4Safety and warningsSafety and warnings
WARNING!
WARNING!
Hot Surface Hazard
This appliance becomes hot during use.
Do not touch the cooktop components, burners, trivets, pan supports or the
base when hot.
Before cleaning, turn the burners o and make sure the whole cooktop is cool.
Failure to follow this advice may result in serious injury.
Fire Hazard
Never leave the appliance unattended when in use. Boilover causes smoking
and greasy spillovers that may ignite.
Never use your appliance for warming or heating the room.
Failure to follow this advice may result in serious injury.
WARNING!
Electrical Shock Hazard
Disconnect the cooktop from the power supply before cleaning or
maintenance.
Failure to follow this advice may result in death or electrical shock.
WARNING!
Explosion Hazard
Do not use or store ammable materials such as gasoline near this
appliance. Do not spray aerosols in the vicinity of this appliance while it is in
operation.
Failure to follow this advice may result in death or serious injury.
Operation

5
Safety and warnings
Important safety instructions!
Operation
Keep children away from the cooktop when it is in use.
Household appliances are not intended to be played with by children.
Children, or persons with a disability which limits their ability to use the appliance, should
have a responsible person to instruct them in its use. The instructor should be satisfied that
they can use the appliance without danger to themselves or their surroundings.
Do not use an asbestos mat or decorative covers between the flame and the saucepan as
this may cause serious damage to your cooktop.
Do not place aluminium foil or plastic dishes on the cooktop burners.
Do not let large saucepans or frying pans overlap the bench as this can deflect heat onto
your benchtop and damage the surface.
Do not let large saucepans, frying pans or woks push any other pans aside. This could make
them unstable or deflect heat onto your benchtop and damage the surface.
Do not use a steam cleaner for cleaning this cooktop.
Saucepan handles may be hot to touch. Ensure saucepan handles do not overhang other
gas burners that are on. Keep handles out of reach of children.
Do not stand or place heavy objects on this appliance.
After use, ensure that the dials are in the ‘OFF’ position.
This appliance shall not be used as a space heater.
The use of a gas cooking appliance results in the production of heat and moisture in the
room in which it is installed. Ensure the kitchen is well ventilated. Keep natural ventilation
holes open or install a mechanical ventilation device (mechanical extractor hood).
Prolonged intensive use of the appliance may call for additional ventilation, for example
opening of a window, or more effective ventilation, for example increasing the level of
mechanical ventilation where present.
After having unpacked the appliance, check to ensure that it is not damaged.
In case of doubt, do not use it and consult your supplier or a professionally qualified technician.
Some appliances are supplied with a protective film on steel and aluminium parts. This film
must be removed before using the appliance.
Safety and warnings

6Installation instructions
A
B
CDE
F
G
H
I
J
Cooktop and cutout dimensions (mm)
CG604DWFC CG905DWFC
CG905DWAC
Aoverall width of cooktop 578 914 914
Boverall depth of cooktop 511 533 546
Cheight of chassis below top of bench 50 50 76
Dwidth of chassis 554 840 855
Edepth of chassis 480 480 470
Foverall width of cutout 560 870 870
Goverall depth of cutout 490 494 494
Hcorner radius of cutout max. 10 max. 10 max. 10
Idistance from right edge of cutout to
manifold centre line 30 30 30
Jdistance from rear edge of cutout
to gas inlet 40 47 35

7
Installation instructions
Clearances (mm)
CG604DWFC CG905DWFC
CG905DWAC
Aminimum clearance from left or right edge of cutout to:
nearest vertical surface* 140 140 100
Bminimum clearance from rear edge of cutout to:
nearest vertical surface 110 110 115
C
minimum clearance from pan supports to:
rangehood
any other overhead exhaust fan
downward-facing combustible surface (overhead cabinetry)
downward-facing tiled or re-resistant surface
650
800
650
600
650
800
650
600
650
800
650
500
D
minimum clearance below top of benchtop to:
nearest combustible surface
nearest non-combustible surface
60
60
60
60
81
81
EEnsure there is an earthed power outlet within 900 mm of the rear right-hand corner of the
cooktop. The outlet should be accessible with the cooktop installed.
*There may be cabinetry at the minimum clearance ‘A’on one side of the cooktop, but the other side (left or right)
MUST be kept clear.
B
C
A
D
E

8Installation instructions
Before you start
Before starting to install the cooktop, make sure that:
the cooktop has not been damaged during transport. In case of doubt after unpacking and
checking it, contact the retailer
the local distribution conditions (nature of gas and pressure) and the adjustment of the cooktop
(as detailed on the appliance data label and in section ‘Gas supply and gas rate summary’ further
below) are compatible
the installation will comply with the relevant ventilation and electrical requirements detailed
further below
there is an earthed power outlet within the reach of the cooktop’s power supply cable (within
900 mm from the rear right of the cooktop, see dimension E in ‘Clearances’)
the power outlet will be accessible after installation
the power supply cable will not touch any hot metal parts
the benchtop is made of a heat-resistant material
exposed bare edges of the cutout are sealed with an oil-based paint or moisture-proof
polyurethane to prevent possible damage from moisture creeping between the cooktop trim
and the benchtop.
Ventilation requirements
The installer must refer to the current local regulations.
For the United Kingdom and the Republic of Ireland only:
Important!
Regardless of room size, all rooms containing the appliance must have direct access to the outside air
via an openable window or equivalent. Some rooms require permanent ventilation in addition to the
openable window, as detailed below.
The appliance should NOT be installed in a bed-sitting room of volume less than 20 m
3
.
The appliance should be installed in a room or space with an air supply in accordance with BS
5440:2 2000.
For rooms with a volume of less than 5 m
3
, permanent ventilation through a free area of at least
100 cm
2
will be required.
For rooms with a volume between 5 m
3
and 10 m
3
, permanent ventilation through a free area of
at least 50 cm
2
will be required, unless the room has a door which opens directly to the outside
air, in which case no permanent ventilation is required.
For rooms with a volume greater than 10 m
3
, no permanent ventilation is required.
Where there are other fuel-burning appliances in the same room, BS 5440-2: 2000 should be
consulted to determine the correct amount of free area ventilation requirements.
The above requirements also allow for use of a gas oven and grill, but you need to consult a
qualified engineer if there are other gas-burning appliances in the same room.

9
Installation instructions
Electrical connection requirements
This appliance must be connected to a 220-240 V 50 Hz power supply only and earthed via
the power supply cable. In the United Kingdom, the suitably earthed three-pin plug must be
protected by a 3 A fuse.
A suitable isolating switch providing full disconnection from the mains power supply must be
incorporated in the permanent wiring, mounted and positioned to comply with the local wiring
rules and regulations. The isolating switch must be of an approved type and provide a 3 mm air
gap contact separation in all poles (or in all active [phase] conductors if the local wiring rules
allow for this variation of the requirements). The isolating switch MUST be easily accessible to
the customer with the appliance installed.
If the power supply cable is damaged, it must be replaced by a cable of the same type. It can
only be replaced by the manufacturer, its Service Agent or a similarly qualified person in order
to avoid a hazard.
Note: This appliance is supplied with a power supply cable with a plug suited to the country of
sale.
For the United Kingdom and the Republic of Ireland only:
The power supply cable supplied is fitted with a BS1363, 13 A three-pin plug with a 3 A fuse. If
this plug does not fit the power outlet in the house where the appliance is installed, it should be
replaced with a suitable plug as outlined below. Should the fuse require replacement, it must be
replaced with a fuse rated at 3 A and complying with BS1362.
The wires in the power supply cable are coloured as follows:
Green & Yellow = Earth
Blue = Neutral
Brown = Live
As the colours of the wires in the power supply cable may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows:
The green & yellow wire must be connected to the terminal marked E ( Earth) or coloured
green.
The blue wire must be connected to the terminal marked N (Neutral) or coloured black.
The brown wire must be connected to the terminal marked L (Live) or coloured red.

10 Installation instructions
Fastening the cooktop to the bench
This cooktop is suppled with fastening brackets (and screws) that will cope with a
bench thickness of 20-50 mm. For benches thicker than 50 mm, recess the underside
to a thickness of 20-50 mm.
Connecting the cooktop to the gas supply
Important!
This cooktop is supplied factory-set for Natural gas, but is suitable for installation with either
Natural gas or LPG, provided the injectors appropriate for the gas type are installed. Refer to
section ‘Gas supply and gas rate summary’ for nominal ratings and appropriate injector sizes,
and to section ‘Converting to a different gas type’.
Gas products MUST be installed and tested by a suitably qualified and registered person in
accordance with all regulations and standards applicable to the country of installation.
Make sure the connection point will be accessible with the cooktop installed.
To enable the gas supply to be readily shut off, make sure the connection is fitted with an
isolating valve close to the cooktop.
For instructions on converting the cooktop for use with a different gas type, see section
‘Converting to a different gas type’.
20 mm
50 mm recessed to
50 mm
Fig.1 Fastening the cooktop to the bench

11
Installation instructions
Special requirements for CG604DWFC and CG905DWFC models
Gas connection to these cooktops MUST use the elbow supplied. Where a regulator is required
to satisfy local market regulations, it must be connected to the elbow to prevent gas leakage.
In some countries, the supplied elbow has a 1/2” taper male thread (Fig. 2a). In other countries,
the supplied elbow has a 1/2” parallel male thread and a conical adaptor (1/2” taper male
thread) may be supplied as well (Fig.2b).
Important!
The conical adaptor (if supplied) must be used only in the countries where it is required by the applicable
local regulations. Note: if installing the conical adaptor, remember to fit the fibre washer supplied between
the adaptor and the elbow.
Ensure the fibre washer (supplied) is located between the elbow (supplied) and cooktop gas
inlet (Figs. 2a and 2b). Failure to use this washer will cause the connection to leak. Tighten the
floating nut to firm finger tight, plus an additional ¼ turn (90
o
).
Gas connection with a flexible hose
Use a 900-1125 mm long flexible hose and ensure that all pipework is of correct rating for both
size and temperature.
The flexible hose shall be fitted in such a way that it cannot come into contact with a movable
part (eg drawer) and does not pass through any space susceptible of becoming congested.
Ensure that the appliance is restrained or secured so that the flexible hose cannot be strained.
The hose assembly must be as short as practicable and comply with relevant standards
requirements.
The hose must not be kinked, subjected to abrasion or permanently deformed.
The hose must not be near or in contact with any hot surfaces (eg base of metal hotplate, flue or
chassis of underbench oven etc).
For Natural gas (G20, G25, or G20/G25 depending on gas category):
In the United Kingdom, the flexible hose should comply with BS669. Parts of the appliance likely
to come in contact with a flexible hose have a temperature of less than 70
o
C.
In all other countries, the flexible hose should comply with local regulations and standards.
For LPG (G30 G31):
In the United Kingdom, use a bayonet-type hose suitable for use on LPG up to 50 mbar pressure
rise. The flexible hose must be certified for LPG and comply with local regulations and standards.
In all other countries, the flexible hose should comply with local regulations and standards.

12 Installation instructions
Gas inlet (BS 21/ ISO 7-1 Rp 1/2”)
Fibre washer
Fibre washer Fibre washer
Elbow
Elbow Conical adaptor for elbow
(use only if required)
BS 21/ISO 7-1 R 1/2”
ISO 228-1 G 1/2”
BS 21/ ISO 7-1 R 1/2”
Fig.2a Gas connection to the cooktop:
elbow with 1/2” taper male thread (CG604DWFC and CG905DWFC models)
Fig.2b Gas connection to the cooktop:
elbow with 1/2” parallel male thread and conical
adaptor (if required) (CG604 DWFC and CG905DWFC models)
Fig.3 Gas connection to the cooktop
(CG905DWAC models)

13
Installation instructions
Leak-testing and flame-testing the cooktop
Important!
The operation of the cooktop, including the ignition system, must be tested before installation is complete.
If, after following the instructions below, satisfactory performance cannot be obtained, contact the local
gas authority or your local Authorised Service Centre for advice and assistance.
Checking the connections for leaks
After installation and making all connections, check thoroughly for possible leaks and make sure
all connections are gas-tight.
1 Turn all control dials to O (OFF).
2 Open the valve on the gas supply.
3 Check each connection one at a time by brushing a soap and water solution or a suitable leak
detection fluid over it.
Important!
Do not use any naked flames to check for leaks.
The presence of bubbles indicates a leak. Tighten or replace connections as appropriate, then
leak-test all connections again. For CG604DWFC and CG905DWFC models, ensure a fibre washer
(supplied) is located between the elbow and the cooktop’s gas inlet and---if the conical adaptor
is installed---between the adaptor and the elbow.
Checking the burner flames
1 Light each burner.
2 Check for a well-defined blue flame without any yellow tipping. See Fig.4.
If any abnormality is evident, check that:
- the burner cap is located properly
- the injector nipple is correctly aligned
- the correct size injectors are installed.
Incorrect: flame
‘lifting off’ the burner
Incorrect:
yellow tipping
Good flame: well-defined blue flame
without yellow tipping
Fig.4 Incorrect and good flame patterns

14 Installation instructions
Converting to a different gas type
Important!
Gas conversion may only be carried out by a suitably qualified and registered person.
To convert from one gas type to another, you need to replace the injectors and adjust the
minimum burner setting.
To replace the injectors, you will need a 7 mm box spanner (and a 10 mm ring spanner for
CG905DWAC models). These are not supplied.
1 Disconnect the cooktop from the power supply.
Important!
Disconnect cooktop from the power supply before continuing.
2 Make sure each control dial is turned to O (OFF).
3 Remove all the pan supports and burner heads.
4 Pull off the control dials.
5 Using a 7 mm box spanner, remove the injectors and replace them with the correct ones
(size numbers are stamped on the inside, eg 70=0.70 mm). Hold on to the card housing the
replacement injectors for later use.
CG905DWAC only
6 Remove all the screws holding the burners in place.
7 Carefully lift the hob tray off the cooktop.
Important!
Beware of sharp edges.
8 Replace the wok burner injector with the correct one using a 10 mm ring spanner.
9
Reset the venturi. Loosen the venturi screw, move the venturi towards the injector approx.
2 mm.
10
Refit the hob tray on the cooktop, repeating steps 6 and 7 in reverse.
11
Check insulation resistance and earth continuity.
12
Reconnect the cooktop to the power supply.
13
Refit the control dials.
14
Adjust the minimum burner setting. See section ‘Adjusting the minimum burner setting’
following.
15
Check that all burners have a good flame (Fig.4).
16
To indicate the gas type change, peel the adhesive label off the replacement injector card and
apply it over the existing gas type label (on the underside of the cooktop).

15
Installation instructions
Adjusting the minimum burner setting
This has been adjusted at the factory for Natural gas but may need adjusting for local
conditions.
When converting to LPG, the minimum setting MUST be re-adjusted for each burner.
To adjust the minimum setting, you will need a Ø 2.5 x 45 mm screwdriver.
1
Light the burner and set the control dial to its minimum.
2
Remove the dial.
3a
For Natural gas
(G20, G25, or G20/G25 depending on gas category)
Slowly turn the adjustment screw inside the valve shaft until a minimum regular flame is
achieved.The flame will diminish when the screw is turned clockwise, and increase when turned
anti-clockwise.
3b
For LPG (G30 G31)
Turn the adjustment screw inside the valve shaft clockwise until it comes to a stop. This is the
fixed minimum burner setting for LP gas.
The brass wok burner in the centre of CG905DWAC models may require progressive
venturi adjustment (Fig. 6) until a good flame (Fig.4) is achieved:
- If the flame is ‘lifting off’ the burner, move the venturi closer to the injector.
- If there is yellow tipping, move the venturi away from the injector.
4
Refit the dial.
5
Check the minimum burner setting: quickly turn the dial from maximum to minimum. The flame
must not go out. If it does, repeat the steps above.
Repeat the steps above for each burner.
Venturi
NG venturi position
LPG venturi position
Fig.5 Adjusting the minimum burner setting Fig.6 Progressive venturi adjustment for the
brass wok burner on CG905DWAC models

16 Installation instructions
Gas supply and gas rate summary
Gas supply: These products are factory-set for Natural gas (G20, G25, or G20/G25 depending on gas category). For conversion to LPG (G30/G31), see section ‘Converting to a dierent gas type’.
Classication: Class 3 – Appliance for building into a kitchen unit or worktop.
Injector marking
Nominal rating (kW)
Injector marking
Nominal rating (kW)
Gas rate (g/h)
Injector marking
Nominal rating (kW)
Injector marking
Nominal rating (kW)
Gas rate (g/h)
Injector marking
Nominal rating (kW)
Injector marking
Nominal rating (kW)
Gas rate (g/h)
Injector marking
Nominal rating (kW)
Injector marking
Nominal rating (kW)
Gas rate (g/h)
Burner DIPARKOWDIPAR-IMESYRAILIXUA
Gas type NG LPG NG LPG NG LPG NG LPG
CG905DWAC
II2H3+ 75 S 1.0
050 1.1 80 97 Z 1.9 058 M 1.7 124 169 5.5 114 5.5 401 100 Z 2.0 065 2.0 146
II2H3B/P 75 S 1.0 II2E+3+ 75 S 1.0
050 1.1 80 97 Z 1.9 058 M 1.7 124 169 5.5 114 5.5 401 100 Z 2.0 065 2.0 146 050 1.1 80 97 Z 1.9 058 M 1.7 124 169 5.5 114 5.5 401 100 Z 2.0 065 2.0 146
II2L3B/P 75 S 1.0 050 1.1 80 97 Z 1.75 058 M 1.7 124 169 5.0 114 5.5 401 103 F2 2.0 065 2.0 146
CG604DWFC, CG905DWFC
IE, IT, GB, GR, PT, ESII2H3+ (G20 20 mbar; G30/G31 28-30/37 mbar)
II2H3+ 72 X 1.0 50 1.0 73 97 Z 1.75 65 1.75 127 140 3.6 95 3.6 262 II2H3B/P 72 X 1.0 50 1.0 73 97 Z 1.75 65 1.75 127 140 3.6 95 3.6 262 II2E+3+ 72 X 1.0 50 1.0 73 97 Z 1.75 65 1.75 127 140 3.6 95 3.6 262 II2L3B/P 72 F1 1.0 50 1.0 73 94 Y 1.75 65 1.75 127 140 F3 3.6 95 3.6 262 I3B/P - - 50 1.0 73 - - 65 1.75 127 - - 95 3.6 262 II2H3B/P (G20 20 mbar; G30/G31 30/30 mbar) I3B/P (G30/G31 30/30 mbar) II2E+3+ (G20/G25 20/25 mbar; G30/G31 28-30/37 mbar) II2L3B/P (G25 25 mbar; G30/G31 30/30 mbar)
DK, FI, SE NO FR, BE, LU NL
Country codeGas type

17
Installation instructions
Final checklist
TO BE COMPLETED BY THE INSTALLER
Have you securely fastened the cooktop to the bench with the supplied brackets?
All models except CG905DWAC: Have you used the supplied elbow (and conical adaptor if
required) and fibre washer(s) to connect the gas to the inlet on the cooktop?
Have you leak-tested all connections?
Are the injector sizes correct for the gas type?
Is the shut-off valve on the gas supply accessible to the customer?
Is the power supply isolating switch accessible to the customer?
Is the cooktop power supply cable plugged into an earthed outlet?
Check the entire length of the power supply cable: it should not touch any hot metal parts.
Have you removed all protective film from the stainless steel surfaces?
Have you disposed of all packaging elements?
OPERATION:
Do all burners light individually and in combination?
Do the burners remain lit when turned quickly from maximum to minimum?
Are the flames consistent, free from any yellow tipping and appropriately sized?
Have you demonstrated the basic operation to the customer?
Installer’s name:
Installer’s signature:
Installation company:
Date of installation:
LEAVE THESE INSTRUCTIONS WITH THE CUSTOMER

18 Introduction
About your new cooktop
Thank you for buying a Fisher & Paykel gas cooktop. Once it is installed and ready to use, you
will want to know everything about it to make sure you get excellent results right from the start.
We recommend you read the whole guide before using your new cooktop, for both safety and
cooking success.
For more information, visit our local website listed on the back cover.
Before using your new cooktop
Read this user guide, taking special note of the ‘Safety and warnings’ section.
Ensure the power supply to the cooktop is turned on.
1 Semi-rapid burner
2 Rapid burner
3 Wok burner
4 Auxiliary burner
5 Control dials
Fig.8 Cooktop layout - CG905DWFC
(with flame failure protection)
Fig.7 Cooktop layout - CG604DWFC
(with flame failure protection)
Fig.9 Cooktop layout - CG905DWAC
(with auto-reignition)
1
11
5
55
4
3
3
1
3
2
4
2
1
43
