Fisher & Paykel CG604DW Mounting instructions

燃气灶
Installation instructions
and User guide
CG604DW & CG905DW models
安装说明
安装说明
和用户指南
用户指南
CG604DW型和CG905DW型
Gas cooktops
HK SG

1EN
Contents
Safety and warnings 2
Installation instructions 6
Introduction 16
Using your cooktop 17
Cooking guidelines and cookware 20
Care and cleaning 22
Troubleshooting 27
Warranty and service 29
Important!
SAVE THESE INSTRUCTIONS
The models shown in this document may not be available in all markets and are
subject to change at any time. For current details about model and specification
availability in your country, please visit our website listed on the back cover
or contact your local Fisher & Paykel dealer.

2
EN
Installation
WARNING!
Cut Hazard
Beware of sharp edges when handling stainless steel appliances.
Failure to use caution could result in injury or cuts.
WARNING!
Electrical Shock Hazard
Before carrying out any work on the electrical section of the appliance, it must
be disconnected from the mains electricity supply.
Connection to a good earth wiring system is absolutely essential and
mandatory.
Alterations to the domestic wiring system must only be made by a qualied
electrician.
Failure to follow this advice may result in electrical shock or death.
Safety and warnings

3EN
Important safety instructions!
Installation
Read these instructions carefully before installing or using this product.
Please make this information available to the person responsible for installing the product as it
could reduce your installation costs.
This appliance shall only be installed and serviced by an authorised person.
Incorrect installation, for which the manufacturer accepts no responsibility, may cause personal
injury or damage and could invalidate any warranty or liability claims.
This appliance must be installed in accordance with these installation instructions, local
gas fitting regulations, municipal building codes, water supply regulations, electrical wiring
regulations and any other relevant statutory regulations.
Do not modify this appliance.
Models without flame failure protection MUST NOT be installed in marine craft, caravans or
mobile homes.
When this appliance is installed, it shall not be used as a space heater.
No combustible materials or products should be placed on this appliance at any time.
Do not spray aerosols in the vicinity of this appliance while it is in operation.
This appliance should not be sealed into the bench with silicone or glue. Doing so will make
future servicing difficult. Fisher & Paykel will not be liable for costs associated with releasing such
a product, nor for repairing damage that may be incurred in doing this.
Packing elements (eg plastic bags, polystyrene foam, staples, packing straps etc) and tools
should not be left around during and after installation, especially if they are within easy reach of
children, as these may cause serious injuries.
Safety and warnings

4
EN Safety and warnings
WARNING!
WARNING!
Hot Surface Hazard
This appliance becomes hot during use.
Do not touch the cooktop components, burners, trivets, pan supports or the
base when hot.
Before cleaning, turn the burners o and make sure the whole cooktop is cool.
Failure to follow this advice may result in serious injury.
Fire Hazard
Never leave the appliance unattended when in use. Boilover causes smoking
and greasy spillovers that may ignite.
Never use your appliance for warming or heating the room.
Failure to follow this advice may result in serious injury.
WARNING!
Electrical Shock Hazard
Switch the power to the cooktop o at the wall before cleaning or
maintenance.
Failure to follow this advice may result in death or electrical shock.
WARNING!
Explosion Hazard
Models with no ame failure protection: If the ame is accidentally
extinguished, turn the control dials and gas supply valve o immediately
and thoroughly ventilate the room. Do not attempt to relight any burner
until you are certain that all gas that may have escaped has dispersed.
Do not use or store ammable materials such as gasoline near this
appliance. Do not spray aerosols in the vicinity of this appliance while it is in
operation.
Failure to follow this advice may result in death or serious injury.
Operation

5EN
Safety and warnings
Important safety instructions!
Operation
Keep children away from the cooktop when it is in use.
Household appliances are not intended to be played with by children.
Children, or persons with a disability which limits their ability to use the appliance, should have a
responsible person to instruct them in its use. The instructor should be satisfied that they can use
the appliance without danger to themselves or their surroundings.
If the electrical supply cord is damaged, it must only be replaced by an authorised person. Ensure
that the electrical connection plug is accessible after installation.
This appliance should be connected to a circuit that incorporates an isolating switch providing
full disconnection from the electricity supply.
Do not use an asbestos mat or decorative covers between the flame and the saucepan as this may
cause serious damage to your cooktop.
Do not place aluminium foil or plastic dishes on the cooktop burners.
Do not let large saucepans or frying pans overlap the bench as this can deflect heat onto your
benchtop and damage the surface.
Do not let large saucepans, frying pans or woks push any other pans aside. This could make them
unstable or deflect heat onto your benchtop and damage the surface.
Do not use a steam cleaner for cleaning this cooktop.
Saucepan handles may be hot to touch. Ensure saucepan handles do not overhang other gas
burners that are on. Keep handles out of reach of children.
Do not stand or place heavy objects on this appliance.
After use, ensure that the control dials are in the ‘OFF’ position.
This appliance shall not be used as a space heater, especially if installed in marine craft or
caravans.
The use of a gas cooking appliance results in the production of heat and moisture in the room
in which it is installed. Ensure the kitchen is well ventilated. Keep natural ventilation holes open
or install a mechanical ventilation device (mechanical extractor hood). Prolonged intensive use
of the appliance may call for additional ventilation, for example opening of a window, or more
effective ventilation, for example increasing the level of mechanical ventilation where present.
After having unpacked the appliance, check to ensure that it is not damaged.
In case of doubt, do not use it and consult your supplier or a professionally qualified technician.
Packing elements (eg plastic bags, polystyrene foam, nails, packing straps, etc.) should not be left
around within easy reach of children, as these may cause serious injuries.
Some appliances are supplied with a protective film on steel and aluminium parts. This film must
be removed before using the appliance.

6
EN Installation instructions
A
B
CDE
F
G
H
I
J
Cooktop and cutout dimensions (mm)
CG604 CG905
Aoverall width of cooktop 578 914
Boverall depth of cooktop 511 533
Cheight of chassis below top of bench 50 50
Dwidth of chassis 554 840
Edepth of chassis 480 480
Foverall width of cutout 560 870
Goverall depth of cutout 490 494
Hcorner radius of cutout max. 10 max. 10
Idistance from right edge of cutout to
manifold centre line 30 30
Jdistance from rear edge of cutout
to gas inlet 40 47

7EN
Installation instructions
Clearances (mm)
CG604 CG905
Aminimum clearance from left edge of cutout to:
nearest combustible surface 140 140
Bminimum clearance from right edge of cutout to:
nearest combustible surface 140 140
C
minimum clearance from rear edge of cutout to:
nearest combustible surface
nearest non-combustible surface
110
20
110
30
D* minimum height of non-combustible material when used on
adjacent walls 150 150
E
minimum clearance from pan supports to:
rangehood
any other overhead exhaust fan
downward-facing combustible surface (overhead cabinetry)
downward-facing tiled or re-resistant surface
650
800
650
500
650
800
650
500
F
minimum clearance below top of benchtop to:
nearest combustible surface
F&P oven or nearest non-combustible surface
60
60
60
60
GEnsure there is an earthed power outlet within 900 mm of the rear right-hand corner of the
cooktop. The outlet should be accessible with the cooktop installed.
H
If connecting the cooktop to the gas supply with a exible hose, the connector on the wall
should be between 800-850 mm above the oor and to a distance of at least 250 mm outside
the width of the cooktop. The connector should be accessible with the cooktop installed.
*See section ‘Standards requirements’following.
C
E
A
FB
GH
D

8
EN Installation instructions
Before you start
Before starting to install the cooktop, make sure that:
the cooktop has not been damaged during transport. In case of doubt after unpacking and
checking it, contact the retailer
the local distribution conditions (nature of gas and pressure) and the adjustment of the cooktop
(as detailed on the appliance data label and in the ‘Gas rate and injector size table’ further
below) are compatible
the cooktop will be connected to a 220-240 V 50 Hz power supply and earthed via the power
supply cable
there is an earthed power outlet within the reach of the cooktop’s power supply cable (within
900 mm from the rear right of the cooktop, see dimension G in ‘Clearances’)
the power outlet will be accessible after installation
the power supply cable will not touch any hot metal parts
a suitable isolating switch providing full disconnection from the mains power supply is
incorporated in the permanent wiring, mounted and positioned to comply with local wiring
rules and regulations. The isolating switch must be of an approved type and provide a 3 mm air
gap contact separation in all poles (or in all active [phase] conductors if the local wiring rules
allow for this variation of the requirements)
the isolating switch will be accessible after installation
the benchtop is made of a heat-resistant material
exposed bare edges of the cutout are sealed with an oil-based paint or moistureproof
polyurethane to prevent possible damage from moisture creeping between the cooktop trim
and the benchtop.

9EN
Installation instructions
Fastening the cooktop to the bench
This cooktop is suppled with fastening brackets (and screws) that will cope with a
bench thickness of 20-50 mm. For benches thicker than 50 mm, recess the underside
to a thickness of 20-50 mm.
Connecting the cooktop to the gas supply
Important!
This cooktop is supplied factory-set for Town Gas, but is suitable for installation with either Town
Gas or LPG, provided the injectors appropriate for the gas type are installed. Refer to the ‘Gas
rate and injector size table’ for nominal ratings and appropriate injector sizes, and to section
‘Converting to a different gas type’.
The gas connection must be carried out by a suitably qualified person according to the relevant
standards.
For Town Gas, connect the gas supply to the gas pressure regulator supplied with the cooktop.
(Bromic; model BM-WF-1A). Ensure the gas supply is regulated to 8 mbar (3.2”W.C).
For LPG, connect the the gas supply to the test point adaptor supplied with the cooktop.
Ensure that the supply pressure is regulated to 27.5 mbar (11”W.C.) See section ‘Converting to a
different gas type’.
Make sure the connection point will be accessible with the cooktop installed.
To enable the gas supply to be readily shut off, make sure the connection is fitted with an
isolating valve close to the cooktop.
Attach the duplicate appliance data label on a surface adjacent to the cooktop, so that it will be
easily read with the cooktop installed.
For instructions on converting the cooktop for use with a different gas type, see section
‘Converting to a different gas type’.
20 mm
50 mm recessed to
50 mm
Fig.1 Fastening the cooktop to the bench

10
EN Installation instructions
Special requirements for CG604 and CG905DWFC models
Gas connection to these cooktops MUST use the elbow supplied. The regulator will not seal if
installed without it.
Ensure the fibre washer (supplied) is located between the elbow (supplied) and cooktop gas
inlet (Fig.2). Failure to use this washer will cause the connection to leak. Tighten the floating
nut to firm finger tight, plus an additional ¼ turn (90
o
).
Gas connection with a flexible hose
If the gas is connected with a flexible hose, the connector on the wall should be between 800-
850 mm above the floor and to a distance of at least 250 mm outside the width of the cooktop.
The connector should be accessible with the cooktop installed.
Flexible hose assemblies should be certified. The thread connection shall be Rp ½” (ISO 7-1)
female. See Fig. 2.
The hose assembly must be as short as practicable and comply with relevant requirements.
The hose must not be kinked, subjected to abrasion or permanently deformed.
The hose must not be near or in contact with any hot surfaces (eg base of metal hotplate, flue or
chassis of underbench oven etc).
Fibre washer Elbow (1/2” BSP external thread)
Fig.2 Gas connection to the cooktop
(CG604 and CG905DWFC models)

11 EN
Installation instructions
Leak-testing and flame-testing the cooktop
Important!
The operation of the cooktop, including the ignition system, must be tested before installation is complete.
If, after following the instructions below, satisfactory performance cannot be obtained, contact the local
gas authority or your local Authorised Repairer for advice and assistance.
Checking the connections for leaks
After installation and making all connections, check thoroughly for possible leaks and make sure
all connections are gas-tight.
1 Turn all control dials to O (OFF).
2 Open the valve on the gas supply.
3 Check each connection one at a time by brushing a soap and water solution or a suitable leak
detection fluid over it.
Important!
Do not use any naked flames to check for leaks.
The presence of bubbles indicates a leak. Tighten or replace connections as appropriate, then
leak-test all connections again. For CG604 and CG905DWFC models, ensure the fibre washer
(supplied) is located between the elbow and the cooktop’s gas inlet.
Checking the burner flames
1 Light each burner.
2 Check for a well-defined blue flame without any yellow tipping. See Fig.3.
If any abnormality is evident, check that:
- the burner cap is located properly
- the injector nipple is correctly aligned
- the correct size injectors are installed.
Incorrect: flame
‘lifting off’ the burner
Incorrect:
yellow tipping
Good flame: well-defined blue flame
without yellow tipping
Fig.3 Incorrect and good flame patterns

12
EN Installation instructions
Converting to a different gas type
Important!
Gas conversion may only be carried out by a suitably qualified person.
To convert from one gas type to another, you need to replace the injectors and adjust the
minimum burner setting.
To replace the injectors, you will need a 7 mm box spanner (not supplied).
1 Switch the power supply to the cooktop off at at the wall.
Important!
Disconnect cooktop from the power supply before continuing.
2 Make sure each control dial is turned to O (OFF).
3 Remove all the pan supports and burner heads.
4 Pull off the control dials.
5 Using a 7 mm box spanner, remove the injectors and replace them with the correct ones
(size numbers are stamped on the inside, eg 70=0.70 mm). Hold on to the card housing the
replacement injectors for later use.
6
Check insulation resistance and earth continuity.
7
Switch the power supply to the cooktop back on at the wall.
8
Refit the control dials.
9
Adjust the minimum burner setting. See section ‘Adjusting the minimum burner setting’
following.
10
Check that all burners have a good flame (Fig.3).
11
To indicate the gas type change, peel the adhesive label off the replacement injector card and
stick it into the framed ‘gas type’ area on the appliance data label (on the underside of the
cooktop). A second conversion label should also be affixed to the duplicate appliance data label.

13 EN
Installation instructions
Adjusting the minimum burner setting
This has been adjusted at the factory for Town Gas but may need adjusting for local conditions.
When converting to LPG, the minimum setting MUST be re-adjusted for each burner.
To adjust the minimum setting, you will need a Ø 2.5 x 45 mm screwdriver.
1
Light the burner and set the control dial to its minimum.
2
Remove the dial.
3
Slowly turn the adjustment screw inside the valve shaft until a minimum regular flame is
achieved. Note:
The flame will diminish when the screw is turned clockwise, and increase when turned
anti-clockwise.
4
Refit the dial.
5
Check the minimum burner setting: quickly turn the dial from maximum to minimum. The flame
must not go out. If it does, repeat the steps above.
Repeat the steps above for each burner.
Fig.4 Adjusting the minimum burner setting

14
EN Installation instructions
Gas rate and injector size table
CG604DWFCX & CG905DWFCX Gas Cooktop
This product has been set either for Singapore LPG or Town Gas (this is marked on the
product) but the minimum setting may need adjusting for a particular installation.
The gas rates and injectors are noted in the table below;
BURNER TYPE
AUX SR TR
NOMINAL POWER (W) 1000 1750 3600
REDUCED POWER (W) 350 450 1500
Additional
marking
Additional
marking
Additional
marking
INJECTOR
(1/100mm
or marking)
Natural gas
LPG
Town Gas
20mbar
29mbar
8mbar
72 X 97 Z 140 -
50 - 65 - 95 -
145 1 190 2 320 -
SR SR
AUX
TR
TR
SR SR
TR AUX

15 EN
Final checklist
TO BE COMPLETED BY THE INSTALLER
Have you securely fastened the cooktop to the bench with the supplied brackets?
Have you used the supplied elbow and fibre washer to connect the gas to the inlet on the
cooktop?
Have you leak-tested all connections?
Are the injector sizes correct for the gas type?
Is the shut-off valve on the gas supply accessible to the customer?
Is the power supply isolating switch accessible to the customer?
Is the cooktop power supply cable plugged into an earthed outlet?
Check the entire length of the power supply cable: it should not touch any hot metal parts.
Have you removed all protective film from the stainless steel surfaces?
Have you disposed of all packaging elements?
OPERATION:
Do all burners light individually and in combination?
Do the burners remain lit when turned quickly from maximum to minimum?
Are the flames consistent, free from any yellow tipping and appropriately sized?
Have you demonstrated the basic operation to the customer?
Installer’s name:
Installer’s signature:
Installation company:
Date of installation:
LEAVE THESE INSTRUCTIONS WITH THE CUSTOMER
Installation instructions

16
EN Introduction
About your new cooktop
Thank you for buying a Fisher & Paykel gas cooktop. Once it is installed and ready to use, you
will want to know everything about it to make sure you get excellent results right from the start.
We recommend you read the whole guide before using your new cooktop, for both safety and
cooking success.
For more information, visit our local website listed on the back cover.
Before using your new cooktop
Read this user guide, taking special note of the ‘Safety and warnings’ section.
Ensure the power supply to the cooktop is turned on.
1 Semi-rapid burner
2 Rapid burner
3 Wok burner
4 Auxiliary burner
5 Control dials
Fig.6 Cooktop layout - CG905DWFC
(with flame failure protection)
Fig.5 Cooktop layout - CG604DWFC (with
flame failure protection)
1
11
5
5
4
3
3
1
43

17 EN
Control dials
The dials control the flow of gas through the valve.
Using the burners
Models with flame failure protection
1
Press the selected burner’s dial down gently and
turn it anti-clockwise to HIGH.
The ignitors on all the burners will spark.
2
Hold down the dial for about 5 seconds after the burner
has lit. Releasing the dial too soon will extinguish the flame.
3
Adjust the flame anywhere between HIGH and LOW.
Do not adjust between HIGH and O (OFF).
4
After use, always turn the dials to O (OFF).
Using your cooktop
Fig. 8 Pressing down then
turning the control dial
Fig. 7 Control dial for CG604 & CG905DWFC models
NEVER cook or
leave the dial
between HIGH
and O(OFF)
LOW
OFF (closed valve)
HIGH
Burner
indicator

18
EN Using your cooktop
If a burner does not light
Turn the control dial to O (OFF) and wait at least 1 minute before trying again. This
is to allow the gas to disperse. If after trying again the burner still does not light, check that:
the cooktop is plugged in and the power supply is switched on
there is no power failure in your home or neighborhood
the gas is turned on
the gas bottle is not empty (if you use bottled gas)
the ignitors are sparking. If they are not sparking, they may be dirty or wet. Clean them with
a toothbrush and methylated spirits, as shown in Fig. 9 below. See ‘Care and cleaning’ for
instructions on removing and replacing the burner parts.
If the flame is irregular
Check that the burner parts (flame spreader and burner cap) are:
clean and dry
positioned correctly, as shown in Figs. 10 and 11.
For further advice, see sections ‘Care and cleaning’ and ‘Troubleshooting’.
Fig.9 Cleaning the ignitor and probe
Ignitor
Flame failure probe
(models with flame failure protection only)
Ignitor Flame spreader
Burner cap
Fig.10 Burner parts Fig.11 Correct assembly
of burner parts
Fig.12 Incorrect assembly
of burner parts, resulting in
irregular flames
