Fisher & Paykel MINIMAL CID834DTB4 User manual

USER GUIDE
AA BI
DOWNDRAFT INDUCTION COOKTOP
MINIMAL
CID84DTB4

CONTENTS
Safety and warnings 5
First use 10
Safety features 12
Cookware 13
Using your induction zones 15
SmartZones 17
PowerBoost 19
GentleHeat 20
Auto RapidHeat 21
Using the timer 23
Cooking guide 25
Using the extractor 27
Care and cleaning 29
Maintenance alerts 32
Troubleshooting 34
Service and warranty 37
Registration
To register your appliance visit our website: fisherpaykel.com/register
3

SAFETY AND WARNINGS
!WARNING!
Hot Surface Hazard
Failure to follow this advice may result in
serious injury.
• DO NOT TOUCH SURFACE UNITS OR AREAS
NEAR UNITS – Surface units may be hot even
though they are dark in color.
• During use, accessible parts of this appliance
will become hot enough to cause burns.
• Never leave metal objects (such as kitchen
utensils) or empty pans on the cooktop as they
can become hot very quickly.
• Magnetisable metal objects worn on the body
may become hot in the vicinity of the cooktop.
Gold or silver jewellery will not be affected.
• Handles of saucepans may be hot to touch.
Check saucepan handles do not overhang other
cooking zones that are on. Keep handles out of
reach of children.
!WARNING!
Electrical Shock Hazard
Failure to follow this advice may result in
electrical shock or death.
• Switch the power to the cooktop off at the wall
before cleaning or maintenance.
• Do not cook on a broken or cracked cooktop.
If the glass should break or crack, switch
the appliance off immediately at the mains
power supply (wall switch) and contact a
qualified technician.
5

SAFETY AND WARNINGS
!WARNING!
Fire Hazard
Failure to follow this advice may result in
serious injury.
• Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire.
• NEVER try to extinguish a fire with water, but
switch off the appliance and cover flame, eg
with a lid or fire blanket, or use dry chemical or
foam-type extinguisher.
• Do not store items on cooking surfaces.
!WARNING!
Health Hazard
Failure to follow this advice may result
in death.
• This appliance complies with electromagnetic
safety standards. However, persons with cardiac
pacemakers or other electrical implants (such
as insulin pumps) must consult with their doctor
or implant manufacturer before using this
appliance to make sure that their implants will
not be affected by the electromagnetic field.
6

SAFETY AND WARNINGS
READ AND SAVE THIS GUIDE
To reduce the risk of fire, injury to persons or damage when using the appliance,
follow the important safety instructions listed below. Read all the guidance before
using the appliance. Ensure your appliance is properly installed and grounded by a
qualified technician.
WARNING — TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO
PERSONS, OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by the manufacturer. If you have questions,
contact the manufacturer.
b) Before servicing or cleaning unit, switch power off at service panel and lock the service
disconnecting means to prevent power from being switched on accidentally. When the
service disconnecting means cannot be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
General Use
zDo not leave the heating elements turned on with empty pots and pans
or with no pans.
zNever heat a tin or can containing foods without opening it first: it might explode!
zThe extracted air must not be conveyed through the same ducts used to extract the
fumes generated by gas combustion or other types of combustion devices. Never use
the device without the grille properly installed!
zWhen the device is used together with other devices powered with non-electrical
energy, the negative pressure of the room must not exceed 4 Pa (4 x 10•5 bar).
zThere shall be adequate ventilation of the room when the range hood is used at the
same time as appliances burning gas or other fuels (not applicable to appliances that
only discharge the air back into the room).
zFor Australia and New Zealand: Range hoods and other cooking fume extractors may
adversely affect the safe operation of appliances burning gas or other fuels (including
those in other rooms) due to back flow of combustion gases. These gases can
potentially result in carbon monoxide poisoning. After installation of a range hood or
other cooking fume extractor, the operation of flued gas appliances should be tested by
a competent person to ensure that back flow of combustion gases does not occur.
zNever leave the appliance unattended when in use. Boilover causes smoking and greasy
spillovers that may ignite.
zNever use your appliance as a work or storage surface.
zWear proper apparel — Loose-fitting or hanging garments should never be worn while
using the appliance.
zDo not leave any magnetic item, e.g. cutlery, roast dish, etc. on your cooktop, including
the cooking zones and user interface.
zDo not place or leave any magnetisable objects (eg credit cards, memory cards) or
electronic devices (eg computers, MP3 players) near the appliance, as they may be
affected by its electromagnetic field.
zWe recommend using plastic or wooden kitchen utensils for cooking with your
induction cooktop.
zStorage in or on appliance — Flammable materials should not be stored in an oven or
near surface units.
zDo not place or leave aluminum foil on the cooktop.
zNever use your appliance for warming or heating the room.
7

SAFETY AND WARNINGS
zDo not use water on grease fires – Smother fire or flame or use dry chemical or
foam-type extinguisher.
zUse only dry potholders — Moist or damp potholders on hot surfaces may result in
burns from steam. Do not let potholder touch hot heating elements. Do not use a towel
or other bulky cloth.
zUse proper pan size — Always place pans in the centre of the cooking zone.
Select utensils having flat bottoms large enough to cover the surface unit heating
element. The use of undersized utensils will expose a portion of the heating element to
direct contact and may result in ignition of clothing.
zAfter use, always turn off the cooking zones and the cooktop as described in this guide
(ie by using the touch controls). Do not rely on the pan detection feature to turn off the
cooking zones when you remove the pans.
zDo not use a steam cleaner to clean your cooktop.
zDo not place or drop heavy objects on your cooktop.
zDo not stand on your cooktop.
zDo not use pans with jagged edges or drag pans across the ceramic glass surface as
this can scratch the glass.
zDo not use scourers or any other harsh/abrasive cleaning agents to clean your cooktop,
as these can scratch the ceramic glass.
zDo not operate your cooktop by means of an external timer or separate remote-
control system.
zDo not cook on broken cooktop — If cooktop should break, cleaning solutions and
spillovers may penetrate the broken cooktop and create a risk of electric shock.
Contact a qualified technician immediately.
Child Safety
zDo not allow children to play with the appliance or sit, stand, or climb on it.
zDo not store items of interest to children in cabinets above the appliance. Children
climbing on the cooktop could be seriously injured.
zDo not leave children alone or unattended in the area where the appliance is in
use. Children of less than 8 years old must be kept away from the appliance unless
continuously supervised. This appliance can be used by children aged from 8 years
and above, and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, if they have been given supervision or
instruction concerning the use of the appliance in a safe way and they understand
the hazards involved. Cleaning and user maintenance shall not be done by children
without supervision.
zThis appliance is not intended for use by persons (including children) with reduced
physical. Sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety;
zChildren should be supervised to ensure they do not play with the appliance
Cleaning
zClean cooktop with caution — If a wet sponge or cloth is used to wipe spills on a hot
cooking area, be careful to avoid steam burn. Some cleaners can produce noxious
fumes if applied to a hot surface.
zThere is a fire risk if cleaning is not carried out in accordance with the instructions.
8

Servicing
zDo not repair or replace any part of the appliance unless specifically recommended in
the user guide. All other servicing should be undertaken be a Fisher & Paykel trained
and supported service technician or qualified person.
zIf the power supply cable is damaged, it must only be replaced by a
qualified technician.
zIf the appliance is malfunctioning, then contact your Authorized Service Center or
Customer Care to arrange for service. Do not use your appliance until it has been
repaired by a Fisher & Paykel authorized technician.
zCAUTION: The cooking process has to be supervised. A short term cooking process has
to be supervised continuously.
Standard Requirements
zThis induction cooktop generates and uses ISM frequency energy that heats cookware
by using an electromagnetic field. It has been tested and complies with Part 18 of the
FCC Rules for ISM equipment. This induction cooktop meets the FCC requirements to
minimize interference with other devices in residential installation. Induction cooktops
may cause interference with television or radio reception. If interfence occurs, the user
should try to correct the interference by:
zRelocating the receiving antenna of the radio or television
zIncreasing the distance between the cooktop and the receiver
zConnecting the receiver into an outlet different than the receiver.
SAFETY AND WARNINGS
9

FIRST USE
Cooktop overview
Control panel overview
COOKTOP FEATURES
1 Induction zones
2 Extractor
3 Control panel
CONTROL PANEL FEATURES
1 Cooking zone indicator
2 Cooking zone display
3 Zone timer indicator
4 Bridged zone indicator
5 Zone heat selector
6 Gentle heat
7 Gentle heat indicator
8 Product On/Off
9 Keylock / Childlock
!0 Pause / Childlock
!1 Timer control
!2 Main display
!3 Extraction display
!4 Filter indicator
!5 Auto-extraction indicator
!6 Auto-function selector
and filter saturation reset
!7 Extraction speed selector
1 17 7
2 23 34 4
5 5
!6 !7
!3 3
6 689 !0
!1
!2
!4
!5
1 1
1
2
3
1
10

8 Product On/Off
9 Keylock / Childlock
!0 Pause / Childlock
!1 Timer control
!2 Main display
!3 Extraction display
!4 Filter indicator
!5 Auto-extraction indicator
!6 Auto-function selector
and filter saturation reset
!7 Extraction speed selector
ZONE DISPLAY DESCRIPTION
Cooking zone off
(not activated)
Cooking zone on
(activated but not operating)
Power levels
PowerBoost function
Hot Surface indicator
Pan detection indicator
Gentle heat indicator
Childlock indicator
Pause function
Auto RapidHeat function
Touch display
Your cooktop is operated using
an intuitive touch display. Use the
control panel to navigate cooking
settings.
Using the touch controls
Use the ball of your finger, not its
tip. The controls respond to touch,
so pressure is not needed.
FIRST USE
Display overview
11

SAFETY FEATURES
The cooktop controls can be locked for cleaning and to prevent unintended use. When the
cooktop is locked the controls and cooktop display will remain unresponsive.
Ensure all cooking zones have been turned
to OFF. Touch and hold the keylock control
. The indicator above the keylock control
will illuminate indicating that the controls
are locked.
Ensure cooktop is OFF and all cookware is
removed. Touch and hold and . Lwill
illuminate in the display indicating that the
controls are locked.
To unlock the cooktop, touch and hold
the keylock control . The indicator light
above the control will dim. Your cooktop
is now unlocked.
To unlock the cooktop, touch and hold
and . The indicator will dim. Your
cooktop is now unlocked.
ACTIVATING KEYLOCK
ACTIVATING CHILDLOCK
DISABLING KEYLOCK
DISABLING CHILDLOCK
Keylock
Childlock
LL
12

COOKWARE
Cookware size
For optimal performance, ensure the size of the cookware is suitable for the zone in use.
1 1
1 1
Cooking zone Min. pan size* Power** Powerboost
1 Smartzone
unbridged 110mm 2100 W 3000 W
bridged 230mm 3700 W n/a
* Recommended
**Total max power 7400 W
13

COOKWARE
Quickest heating Performance
High content of ferromagnetic material. Heating area is
consistent across the base and up the sides of pan.
Average heating Performance
Reduced area of ferromagnetic material. Reduced zone of
heating, results in poor performance and slower heating.
Slow heating Performance
Very limited area of ferromagnetic material. Results in very
slow heating performance.
Note: This type of pot is good for very delicate tasks such
as melting chocolate, as heating is very slow.
The quality of your cookware can affect cooking performance. Only use
induction-compatible cookware that has been specifically designed for induction cooking.
Look for the induction symbol on the packaging or the bottom of the pan.
Ensure the base of your cookware is smooth, sits flat against the glass, and is similar in size
as the cooking zone. A small pot on a large cooking zone may not be detected. Always
centre your pan on the cooking zone and lift pans off the cooktop – do not slide, or they
may scratch the glass.
Suitable cookware material:
zstainless steel –
with a magnetic base or core
zaluminium and copper –
with a magnetic base or core
zcast iron
zsteel
zenamelled steel.
Unsuitable cookware material:
zaluminium or copper –
without a magnetic base
zglass
zwood
zporcelain
zceramic or earthenware.
To check if cookware material is suitable for induction use, carry out a magnet test:
Move a magnet across the base of the pan. If the magnet is attracted, the pan is induction
suitable. Ensure attraction is consistent across the base of the pan. If there are gaps, such
as an indented manufacturer’s logo, then the performance will be impaired.
If you do not have a magnet, fill the pan with some water and refer to section 'Using your
induction zones'. If does not flash and the water is heating, pan is suitable.
Induction cookware
14

USING YOUR INDUCTION ZONES
To begin cooking
Press the ON/OFF control. The indicator light
above the control will glow.
Place a suitable pan on the desired cooking
zone. Ensure the bottom of the pan and
the surface of the cooking zone are clean
and dry.
Always place small pans in the centre of the
cooking zone.
Select a heat setting by touching or sliding
the setting selector with your finger.
zIf you don’t select a heat setting
within 10 seconds, the cooktop will
automatically turn off.
zYou can modify the heat setting at any
time during cooking.
1
2
3
15

USING YOUR INDUCTION ZONES
Turn the cooking zone off:
touch or slide the setting selector until 0 shows in the
zone display.
Turn the product off:
touch the ON/OFF control.
Pause cooking:
touch to pause all cooking functions, will show in
the main display. To unpause, press again followed
by the desired setting selector.
If Hflashes in the display:
Hwill flash in the cooking zone display of any zone
that is too hot to touch. It will remain illuminated until
it has cooled to a safe temperature.
If flashes alternately with the heat setting:
the pan may not be located on the correct cooking
zone, it may not be centred correctly or it may not
suitable for induction cooking.
No heating will take place until a suitable pan is
detected. The cooktop will turn off after 10 minutes if
no suitable pan is used.
16

SMARTZONES
The SmartZones can accommodate several small pots. These
small pots will be detected as one large pot.
The entire SmartZone is activated when a pot is detected. This
means that other magnetic items (such as cutlery) sitting in the
cooking zone will heat up. Do not leave cutlery or other magnetic
items on your cooktop.
Bridging Zones
The bridging zone function allows you to use two SmartZones together.
zYou can only bridge a cooking zone with the one directly behind it.
zThere may be a cooler area in the centre of the combined cookng zones. You may need
to move food around the pan to ensure even cooking.
zWhen using bridging zones, it is not possible to use the PowerBoost function.
Place the pan over the two zones
you wish to use, ensuring both zones
are covered.
1
2
3
Touch anywhere on the setting
selectors of both cooking zones at the
same time.
will illuminate in both zones to
indicate the bridge-status. will show
in the display of the rear cooking zone
to indicate it is now controlled by the
front control.
Use the front setting selector to set the
heat setting for the combined zone.
The heat setting will be displayed
in both bridged zones. The setting
indicator will glow on both zones.
17

SMARTZONES
If no pan is detected on one cooking zone:
The left hand display will still show the selected temperature and the right hand display will
still show .
If after 10 minutes no pan is detected:
zThe bridging function will switch off.
zThe cooking zone without a detectable pan will turn off.
zThe remaining cooking zone will continue cooking at the selected heat setting.
Using the timer in bridged mode:
You may only set one timer for the bridged cooking zone. See 'Using the timer'. The timer
indicator will show in both displays.
Cancelling bridging will also cancel the timer for those cooking zones.
To cancel bridging
Touch the setting selectors of both
bridged cooking zones at the same time.
The bridging indicator lights will dim.
Sliding the scale down to 0will not turn
off bridging.
18

POWERBOOST
Using PowerBoost
This feature enables you to sear meat or bring liquid to boil very quickly. When a cooking
zone is set to PowerBoost, it uses more than 100% of the power of that particular cooking
zone, resulting in a boost of intense heat. PowerBoost heats food and liquids very quickly.
Do not leave the cooktop unattended when using this feature.
Setting PowerBoost
1
2
3
Once PowerBoost is set, the cooking zone
will heat more than 100% for 10 minutes.
Pwill flash for a few seconds before the
cooking zone automatically reduces the heat
to setting 8.
Slide the setting selector to set the
cooking zone to the highest heat level.
Hold until Pdisplayed.
You can set two cooking zones for
PowerBoost, as long as one is not behind
the other.
zIf one cooking zone is set to PowerBoost and a second cooking zone in front or behind
the first cooking zone is accidentlly set to PowerBoost, Pwill flash on the first cooking
zone to alert that the configuration is not possible and power is automatically decreased.
zWhen a cooking zone is set for PowerBoost, the other cooking zone in front of or behind
may automatically reduce its power level.
zPowerBoost is not available if cooking zones are bridged.
To cancel PowerBoost
Slide the setting selector to a new heat setting or to 0to turn off the zone.
19

GENTLEHEAT
Using GentleHeat
There are two GentleHeat settings.
zThe Low setting is ideal for the most delicate cooking tasks (such as melting
chocolate), as the cooking zone will provide a very low continuous gentle heat.
zThe Medium setting is ideal for keeping cooked food warm and the gentle warming
of delicate foods.
Setting up a cooking zone for GentleHeat
For Medium setting
With Low GentleHeat active, touch the
GentleHeat control again to select the
Medium setting.
zThe Medium setting indicator above
will glow and the Low setting
indicator goes out.
zTouching the GentleHeat control a third
time will switch off the cooking zone.
2
To exit the GentleHeat setting
Touch or slide the setting selector to a new setting or to 0to turn the cooking zone off.
For Low setting
Touch and hold the GentleHeat control on the
setting selector.
The Low setting indicator above will glow and
will show in the display.
1
20
