Fisher & Paykel CE302C Mounting instructions

Ceramic glass cooktops
Installation instructions
and User guide
CE302C, CE604L, CE604C and CE905C models
NZ AU GB IE

1
Contents
Safety and warnings 2
Installation instructions 6
Introduction 12
Using your cooktop 13
Cooking guidelines 14
Care and cleaning 16
Troubleshooting 18
Warranty and service 19
Important!
SAVE THESE INSTRUCTIONS
The models shown in this user guide may not be available in all markets and are
subject to change at any time. For current details about model and specification
availability in your country, please visit our local website listed on the back cover
or contact your local Fisher & Paykel dealer.

2Safety and warnings
Your safety is important to us. Please read this information before using your cooktop.
Installation
WARNING!
Electrical Shock Hazard
Disconnect the appliance from the mains electricity supply before carrying
out any work or maintenance on it.
Connection to a good earth wiring system is essential and mandatory.
Alterations to the domestic wiring system must only be made by a qualified
electrician.
Failure to follow this advice may result in electrical shock or death.
WARNING!
Cut Hazard
Take care – panel edges are sharp.
Failure to use caution could result in injury or cuts.

3
Safety and warnings
Important safety instructions
Read these instructions carefully before installing or using this appliance.
No combustible material or products should be placed on this appliance at any time.
Please make this information available to the person responsible for installing the appliance as it
could reduce your installation costs.
In order to avoid a hazard, this appliance must be installed according to these instructions for
installation.
This appliance is to be properly installed and earthed only by a suitably qualified person.
This appliance should be connected to a circuit which incorporates an isolating switch providing
full disconnection from the power supply.
Failure to install the appliance correctly could invalidate any warranty or liability claims.

4Safety and warnings
Operation and maintenance
WARNING!
Hot Surface Hazard
During use, accessible parts of this appliance will become hot enough to
cause burns.
Do not let body, clothing or any item other than suitable cookware contact
with the ceramic glass until the surface is cool.
Never leave metal objects on the cooktop as they can become hot very
quickly.
Keep children away.
Handles of saucepans may be hot to touch. Check saucepan handles do not
overhang other cooking zones that are on. Keep handles out of reach of
children.
Failure to follow this advice could result in burns and scalds.
WARNING!
Electrical Shock Hazard
Do not cook on a broken or cracked cooktop. If the cooktop surface should
break or crack, switch the appliance off immediately at the mains power
supply (wall switch) and contact a qualified technician.
Switch the cooktop off at the wall before cleaning or maintenance.
Failure to follow this advice may result in electrical shock or death.
WARNING!
Cut Hazard
The razor-sharp blade of a cooktop scraper is exposed when the safety
cover is retracted. Use with extreme care and always store safely and out
of reach of children.
Failure to use caution could result in injury or cuts.
WARNING!
Fire Hazard
Never leave the appliance unattended when in use. Boilover causes smoking
and greasy spillovers that may ignite.
Never use your appliance for warming or heating the room.
Failure to follow this advice may result in overheating, burning, and injury.

5
Important safety instructions
Never use your appliance as a work or storage surface.
Never leave any objects or utensils other than suitable cookware on the appliance.
Do not allow children to play with the appliance or sit, stand or climb on it.
Do not store items of interest to children in cabinets above the appliance. Children climbing on
the cooktop could be seriously injured.
Do not leave children alone or unattended in the area where the appliance is in use.
Children or persons with a disability which limits their ability to use the appliance should have a
responsible and competent person to instruct them in its use. The instructor should be satisfied
that they can use the appliance without danger to themselves or their surroundings.
Do not repair or replace any part of the appliance unless specifically recommended in the
manual. All other servicing should be done by a qualified technician.
Do not use a steam cleaner to clean your cooktop.
Do not place or drop heavy objects on your cooktop.
Do not stand on your cooktop.
Do not use pans with jagged edges or drag pans across the ceramic glass surface as this can
scratch the glass.
Do not use scourers or any other harsh/abrasive cleaning agents to clean your cooktop, as these
can scratch the ceramic glass.
If the power supply cable is damaged, it must only be replaced by a qualified technician.
Do not operate your cooktop by means of an external timer or separate remote-control system.
Safety and warnings

6
Installation instructions
Cooktop and cutout dimensions
Terminal block location:
1 CE604L, CE604C & CE905C models - Middle rear
2 CE302C models - Front left
A
B
2
1
CCI
D
G
F
E
Cooktop and cutout dimensions (mm)
CE302C
CE604L
CE604C CE905C
Aoverall width of cooktop 300 600 600 900
Boverall depth of cooktop 530 530 530 530
Cheight of chassis (below top of bench) 45 45 45 45
CIheight of terminal block (below top of bench) 63 59 59 59
Dwidth of chassis 267 555 555 863
Edepth of chassis 483 483 483 485
Foverall width of cutout 270 560 560 870
Goverall depth of cutout 490 490 490 490
Drawings for illustration purposes only

7
Installation instructions
Clearances
A
B
C
C
E
D
Clearances (mm)
CE302C
CE604L
CE604C CE905C
Aminimum clearance from rear edge of cutout to:
nearest combustible surface 55 55 55 55
Bminimum clearance from glass surface to:
rangehood 650 650 650 650
Cminimum clearance from side edges of cutout to:
nearest combustible surface 65 70 70 65
Dminimum clearance from benchtop to:
overhead cabinet not directly above the cooktop 450 450 450 450
Eminimum clearance below top of benchtop to:
thermal protection barrier 65 65 65 65
Drawings for illustration purposes only

8
Installation instructions
Before you install the cooktop, make sure that
the benchtop is square and level, and no structural members interfere with space requirements
the benchtop is made of a heat-resistant material
the cooktop will not be installed directly above a dishwasher, as the humidity may damage the
cooktop
the installation will comply with all clearance requirements and applicable standards and
regulations
a suitable isolating switch providing full disconnection from the mains power supply is
incorporated in the permanent wiring, mounted and positioned to comply with the local wiring
rules and regulations. The isolating switch must be of an approved type and provide a 3 mm air
gap contact separation in all poles (or in all active [phase] conductors if the local wiring rules
allow for this variation of the requirements)
the isolating switch will be easily accessible to the customer with the cooktop installed
you consult local building authorities and by-laws if in doubt regarding installation
you use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the wall surfaces
surrounding the cooktop.
When you have installed the cooktop, make sure that
the power supply cable is not accessible through cupboard doors or drawers
there is adequate flow of fresh air from outside the cabinetry to the base of the cooktop
if the cooktop is installed directly above an oven or its base is accessible through a cupboard
or drawer space after installation, a thermal protection barrier is installed below the base of the
cooktop (see Fig.1)
the isolating switch is easily accessible by the customer
you complete the ‘Final checklist’ at the end of these installation instructions.
The thermal protection barrier must be:
removable
heat-resistant
made from low thermal conductivity
material
at least 20 mm below the base of the
cooktop to ensure adequate ventilation
20 mm min.
Fig. 1 Thermal protection barrier
< Fresh air from
outside the
cabinetry

9
Installation instructions
Fastening the cooktop to the bench
1 Turn the cooktop upside down and place it on a soft surface.
2 Spread the seal around the edges of the ceramic glass with the adhesive side facing down,
making sure that the whole perimeter is sealed. Cut off any excess material.
3 Mount the supplied clamps (A) and screws (B) onto the cooktop, as shown (without tightening
the screws).
4 Place the cooktop into the cutout, then tighten the screws to clamp the cooktop securely to the
bench.
5 Using a sharp cutter or trimmer knife, trim the excess sealing material around the edge of the
cooktop. Take care not to damage the benchtop.
Note: if your bench is thicker than 40 mm, recess the underside to between 30 and 40 mm.
Fig. 2 Preparing the cooktop before installation(models may vary)
Fig. 3 Fastening the cooktop to the bench
A
A
A
AB
Seal
B
B
B
Adhesive side
CE905C models only:
Choose the most
suitable clamp
position
30 mm min.
40 mm max.
A
B
Seal

10
Installation instructions
Connecting the cooktop to the mains power supply
Important!
This cooktop must be connected to the mains power supply only by a suitably qualified person.
This cooktop must be earthed.
Before connecting the cooktop to the mains power supply, check that:
1 the domestic wiring system is suitable for the power drawn by the cooktop
2 the voltage corresponds to the value given on the rating plate
3 the power supply cable sections can withstand the load specified on the rating plate.
To connect the cooktop to the mains power supply, do not use adapters, reducers, or branching
devices, as they can cause overheating and fire.
The power supply cable must not touch any hot parts and must be positioned so that its
temperature will not exceed 75
o
C at any point.
Power supply
CE302C 2900W @ 220-240V~ (12.6 A)
CE604L 6000W @ 220-240/380-415V 3N~ (26 A)
CE604C 6400W @ 220-240/380-415V 3N~ (27.8 A)
CE905C 8400W @ 220-240/380-415V 3N~ (36.5 A)
Important!
Check with an electrician whether the domestic wiring system is suitable without alterations. Any
alterations must only be made by a qualified electrician.
Connection diagrams
Single-phase connection
CE604L, CE604C, CE905C
CE302C
Two-phase connection Three-phase connection
PE
1
2
3
4
5
N (L2)L1
220 - 240 V
PE
1
2
3
4
5
380 - 415 V 3N
N
L3L1L2
PE
1
2
3
4
5
380 - 415 V 2N
N
L1L2
PE
N(L )
L12

11
Final checklist
TO BE COMPLETED BY THE INSTALLER
Is the cooktop earthed?
Check that the power supply cable is NOT touching the base of the cooktop. This will ensure that
the cable is not damaged by heat from the cooktop.
Check that the power supply cable is not accessible via cupboard doors or drawers.
Is the cooktop clamped down securely?
Check that all the cooking zones function correctly. Turn on all of them to a high setting and
leave them on for at least one minute.
Are all elements glowing?
Are all ‘Hot surface’ indicators glowing?
Have you shown the customer how to use the cooktop? Make sure you explain to the customer
about the ‘Hot surface’ indicators. Encourage them to read the full user guide before using the
cooktop.
Installer’s name:
Installer’s signature:
Installation company:
Date of installation:
LEAVE THESE INSTRUCTIONS WITH THE CUSTOMER
Installation instructions

12
About your new cooktop
Thank you for buying a Fisher & Paykel ceramic glass cooktop. This guide introduces you to all its
special features. We recommend you read the whole guide before using your new cooktop, for
both safety and cooking success.
For more information, visit our local website listed on the back cover.
Before using your new cooktop
Read this user guide, taking special note of the ‘Safety and warnings’ section.
Remove any protective film that may still be on your cooktop.
1 Single cooking zone
2 Dual cooking zone
3 Cooking zone with SuperSimmer feature
4 ‘Hot surface’ indicators
5 Control dials
Fig.4 CE302C model
Fig.6 CE604L model Fig.7 CE604C model
Fig.5 CE905C model
Introduction
1
1
11
11
1
2
2
2
3
1
1
14
44
4
2
55
55

13
To start cooking
Turn the control dial of the cooking zone you
wish to use to the High setting, then adjust as
necessary.
When using dual cooking zones, you may
choose to use the inner zone only ( ) or the
full dual cooking zone ( ). See Fig. 9 below.
Some models have a cooking zone with a
unique SuperSimmer feature (see Fig. 10).
This special, low turndown range is excellent
for the most delicate cooking tasks, like
melting chocolate or simmering soups and
stews.
For further advice on cooking and using
the SuperSimmer feature, see ‘Cooking
guidelines’ following.
‘Hot surface’ indicators
As soon as you turn a cooking zone on, its
‘Hot surface’ indicator will start glowing.
It will continue to glow even after you have
turned the cooking zone off, until the glass
becomes cool enough to be safely touched.
When you have finished cooking
When you have finished using a cooking
zone, turn its dial to the off (
O ) position.
When you have finished using your cooktop,
check that all dials are turned off.
Fig.8 Single cooking zone control
Fig.9 Dual cooking zone control (some
models only)
Fig.10 Cooking zone with SuperSimmer
(some models only)
Using your cooktop
High Low
SuperSimmer range
High
Inner zone
Full dual zone
Low High
Low
High Low
Medium

14 Cooking guidelines
Cookware
Use heavy-gauge, flat, smooth-based cookware that matches the diameter of the cooking zone.
This will provide good contact with the glass and help reduce cooking times. Low heat or slow
cooking is often due to incorrect cookware size.
Cookware with a stainless steel sandwich base or enamelled cast iron will give you the best
results.
Saucepans or heavy frying pans with jagged edges or a rough base will scratch the glass.
Always lift pans off the cooktop - do not slide, or they may scratch the glass.
Never use plastic or aluminium foil dishes on the cooktop.
Aluminium and copper-based cookware will leave metallic stains on the cooktop. To prevent
these building up, clean the cooktop after every use following the instructions in ‘Care and
cleaning’. If the metallic stains are allowed to burn onto the surface, they may react with the
glass and may no longer be removable. They don’t, however, affect performance.
It is safe to place hot cookware from the oven, or another cooking zone, on the glass surface
when the surface is cool.
Avoid placing anything on a hot cooking zone until it has cooled completely.

15
Cooking guidelines
Important!
Never leave the appliance unattended when in use. Boilover causes smoking and greasy
spillovers that may ignite.
Take care when deep-frying: oil or fat can overheat very quickly, particularly on a high setting.
General cooking tips
Using a lid will reduce cooking times through retaining the heat.
Minimise the amount of liquid or fat to reduce cooking times.
Start cooking on a high setting and reduce it when the food has come to the boil or heated
through.
Even after a cooking zone has been turned off, its glass surface retains enough heat to continue
cooking. To avoid overcooking, remove pans from hot cooking zones when the food is cooked.
Cooking rice, simmering
Some tasks, including cooking rice by the absorption method, may require a setting higher than
the lowest setting to ensure the food is cooked properly in the time recommended.
Simmering occurs below boiling point, when bubbles are just rising occasionally to the surface
of the cooking liquid. It’s the key to delicious soups and tender stews because the flavours
develop without overcooking the food. Egg-based sauces are best kept below boiling point
throughout cooking, and flour-based sauces should also be gently simmered after they have
reached boiling point.
Using the SuperSimmer feature (some models only)
The front right cooking zone on some models has a unique SuperSimmer feature. This allows the
cooking zone to be turned down to very low and even heat settings. These are ideal for melting
chocolate and butter, cooking rice and delicate sauces, simmering soups and stews, and keeping
cooked food hot.
The high settings of the SuperSimmer cooking zone are just as powerful as those of the other
cooking zones, allowing food to be browned, seared, sautéed, or boiled before simmering, all on
the same cooking zones.
Searing steak
1 Stand the meat at room temperature for about 20 minutes before cooking.
2 Heat up a heavy-based frying pan.
3 Brush both sides of the steak with oil and season it to taste.
4 Lower the meat onto the hot pan.
5 Turn the steak only once during cooking. The exact cooking time will depend on the thickness
of the steak and how cooked you want it. Times vary between 2 to 8 minutes per side. Press the
steak to gauge how cooked it is: the firmer it feels, the more ‘well done’ it will be.
6 Leave the steak to rest on a warm plate for a few minutes to allow it to relax and become tender
before serving.

16 Care and cleaning
What?
soiling examples
How? Important!
Light soiling on
glass after every use
fingerprints and
marks
stains left by
non-sugary
liquids (eg water,
soup, oil)
1 Wipe with a soft, damp cloth and
mild detergent. A microfibre or
‘glass’ cloth is ideal for this.
2 Wipe dry with a clean cloth or
paper towel.
Before cleaning, make sure that
the glass is a safe temperature
to touch.
Non-sugary
boilovers, spills
and food stains on
glass
burnt-on food or
grease
pasta water, milk,
soup
1 Remove the soiling with ceramic
cooktop cleaner using a sponge or
non-abrasive scourer suitable for
ceramic glass.
2 Remove any excess cleaner and
wipe dry with a clean cloth or
paper towel.
3 Apply ceramic cooktop
conditioner or protector following
the instructions on the dispenser.
A microfibre or ‘glass’ cloth is ideal
for this.
Heavy-duty scourers, some
nylon scourers and harsh/
abrasive cleaning agents
may scratch the glass. Always
read the label to check if your
cleaner or scourer is suitable.
Never leave cleaner residue
on the cooktop: the glass may
become stained.
Important!
For your safety, switch the power to the cooktop off at the wall before any cleaning. In this case,
there will be no ‘Hot surface’ indication, but the cooking zones may still be hot! Take extreme
care.
Do not use a steam cleaner to clean your cooktop.
Do not use scourers or any harsh/abrasive cleaning agents to clean your cooktop, as these can
scratch the ceramic glass or stainless steel.

17
Care and cleaning
What?
soiling examples
How? Important!
Hot sugary spills,
melted plastic or
metal on glass
sugar, sugary
syrups
jams and jellies
vegetables or
vegetable water
with high sugar
content (peas,
sweetcorn,
beetroot)
melted
aluminium foil or
plastic wrap
Remove these immediately with a
spatula or razor blade scraper suitable
for ceramic glass cooktops, but beware
of hot spills and surfaces:
1 Hold the blade or utensil at a 30
o
angle and scrape the soiling or
spill to a cool area of the cooktop.
2 Immediately clean the soiling up
with a dish cloth or paper towel.
3 Follow the instructions for ‘Light
soiling on glass after every use’
above.
Remove stains left by melts
and sugary food or spillovers
immediately. If left to cool on
the glass, they may be difficult
to remove or even permanently
damage the glass surface.
Cut hazard: the blade in a
scraper is razor-sharp when the
safety cover is retracted. Use
with extreme care and always
store safely out of reach of
children.
Metallic stains on
glass caused by
cookware with
copper base
aluminium base
Follow the instructions for ‘Non-
sugary boilovers, spills and food
stains on glass’ above.
For stubborn metallic stains,
try using a razor blade scraper
suitable for ceramic glass
cooktops, holding it at a 30
o
angle.
If the cooktop is not cleaned
after every use and copper or
aluminium stains are allowed
to burn onto the surface,
they may react with the glass
and no longer be removable.
They don’t, however, affect
performance.
Stainless steel strip
food stains
fingerprints and
marks
1 Wipe the soiling off with a cloth
using a mild household detergent
or stainless steel cleaner.
2 Wipe the surface dry using a
microfibre cloth.
3 For extra shine, use a suitable
stainless steel polish.
Immediately wipe off any
stainless steel cleaner if it is
spilled onto the control dials.
Commercial stainless steel
cleaners containing chlorine
compounds are corrosive and
may damage the appearance
of your cooktop. Always read
the label to check if your
cleaner contains chlorine.
Control dials
food stains
fingerprints and
marks
1 Wipe with a damp cloth and mild
detergent.
2 Dry thoroughly with a soft cloth.
Do not use stainless steel
cleaner on the dials, as doing
so may damage their coating.

18 Troubleshooting
Troubleshooting chart
Problem Possible causes What to do
Cooking zones cannot be
turned on.
No power. Make sure the cooktop is
connected to the power supply
and that it is switched on at the
wall. Check whether there is
a power outage in your home
or area. If you’ve checked
everything and the problem
persists, call your Authorised
Repairer or Customer Care.
Cooking zones seem to
turn themselves off and
on during use.
They cycle off and on to maintain
the selected setting or prevent the
glass from overheating.
This is normal and needs no
action.
There is a metal sheen on
the glass.
Cookware with copper or
aluminium base.
See ‘Care and cleaning’.
The glass is being
scratched.
Rough-edged cookware.
Unsuitable, abrasive scourer
being used.
Use cookware with flat and
smooth bases. See ‘Cooking
guidelines’.
See ‘Care and cleaning’.
Cooking zones cannot be
turned off.
Technical fault. Switch the power to the
cooktop off at the wall and call
your Authorised Repairer or
Customer Care.
