Fisher & Paykel OR60SDBSX2 Guide

Using your gas cooktop
Details how to use the cooktop of your Seven-Function cooker.
Fig. 44 Cooktop layout
1. Auxiliary burner
2. Semi-rapid burner
3. Triple-ring wok burner
Gas burners
The knob controls the flow of gas through the safety valve.
•0= closed valve (OFF)
•
https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Electric/OR60SDBSX2/User_Guide_OR60SDBSX2_(59…
Updated: Mon, 20 Mar 2023 17:44:50 GMT
Powered by
1

= maximum flow
• = minimum flow
You can choose to cook at any heat between
and
, but never between
and 0(OFF).
Fig. 45 Burner control knob
Before using your cooktop
Before using your new cooktop, please:
• Read this user guide, taking special note of the ‘Safety and warnings’ section.
https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Electric/OR60SDBSX2/User_Guide_OR60SDBSX2_(59…
Updated: Mon, 20 Mar 2023 17:44:50 GMT
Powered by
2

• Turn the power to the cooker on at the wall.
• Make sure all controls are turned off.
Using the gas burners
1. Choose the control knob for the burner you want to use.
2. Press the knob down gently and turn it anticlockwise to the
position. The ignitors on all the burners will spark.
3. Hold down the knob for approximately 10 seconds after the burner has lit. Releasing the knob too soon will
extinguish the flame.
4. Adjust the flame anywhere between the
and
positions. Do not adjust the flame between
and 0(OFF).
If the burner does not light within 15 seconds, turn the control knob off and wait at least one
minute before trying again.
5. To turn the burner off, turn the knob clockwise to 0(OFF) until you hear the safety click. After use, always turn
the knobs to the 0(OFF) position.
Flame failure safety feature
• The flame failure probe cuts off the gas supply to the burner if the flame is blown out.
• When lighting the burner on flame failure models, hold down the knob for approximately 10 seconds after the
burner has lit. Releasing the knob too soon will extinguish the flame.
• If the flames are accidentally extinguished, turn off the burner and do not try to light it again for at least one
minute (to allow the gas to disperse).
https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Electric/OR60SDBSX2/User_Guide_OR60SDBSX2_(59…
Updated: Mon, 20 Mar 2023 17:44:50 GMT
Powered by
3

If a burner does not light
Check that:
• The cooktop is plugged in and the electricity is switched on.
• The gas is turned on.
• The gas bottle is not empty (if you are using bottled gas).
• You have held down the knob for at least 10 seconds.
• The ignitors are sparking. If the ignitors are not sparking, they may be dirty or wet. Clean them with a toothbrush
and methylated spirits, as shown in Fig. 46.
Fig. 46 Cleaning the ignitor and probe
If the flame is irregular
If the flame is yellow or irregular, check that the burner parts, including the burner cap, are:
• clean and dry.
• positioned correctly. See ‘Care and cleaning’.
• See also ‘Cooktop troubleshooting’.
Matching cookware to burner
Use flat-bottomed pans, and make sure they match the size of the burner, as shown in the following table. A
small pot on a large burner is not efficient.
Diameters of pans which may be used on the cooktop
Burners Minimum Maximum
Auxiliary 12 cm (6 cm with small pan support) 14 cm
https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Electric/OR60SDBSX2/User_Guide_OR60SDBSX2_(59…
Updated: Mon, 20 Mar 2023 17:44:50 GMT
Powered by
4

Burners Minimum Maximum
Semi-rapid 16 cm 24 cm
Triple-ring wok
26 cm 28 cm
Maximum diameter for woks 36 cm
Fig. 47a Correct and incorrect matching of cookware
and burner size
Fig. 47b Efficient and inefficient saucepan bottoms
Small pan support
Fig. 48a Small pan support
This pan support is to be placed on top of the auxiliary burner when
using small diameter pans, in order to prevent them from tipping over.
Wok stand
The wok stand fits over the triple-ring wok burner trivet.
https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Electric/OR60SDBSX2/User_Guide_OR60SDBSX2_(59…
Updated: Mon, 20 Mar 2023 17:44:50 GMT
Powered by
5

Fig. 48b Correct placement of wok stand
• Using a wok without the stand may cause the wok to tip or the wok burner to operate incorrectly.
Do not use the stand for ordinary, flat-bottomed saucepans.
• The wok stand MUST BE PLACED ONLY over the trivet for the triple-ring wok burner.
• The cooktop becomes very hot during operation. Keep children well out of reach.
