Fisher & Paykel OR24SDPWGX User manual

1
US CA
OR24SDPWGX model
User guide
Freestanding range
Guide d’utilisation
Cuiseur indépendant

2
✓Do not store or use gasoline or other flammable vapors and liquids
in the vicinity of this or any other appliance.
✓WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• lmmediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
• lf you cannot reach your gas supplier, call the fire department.
✓Installation and service must be performed by a qualified installer,
service agency, or the gas supplier.
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT
FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT
CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR
DEATH.
WARNING
• ALL RANGES CAN TIP
• INJURY TO PERSON COULD RESULT
• INSTALL ANTI-TIP DEVICE PACKED
WITH RANGE
• SEE INSTALLATION INSTRUCTIONS
This appliance is designed and manufactured solely for the cooking of domestic (household)
food and in not suitable for any none domestic application and therefore should not be used
in a commercial environmement.
The appliance guarantee will be void if the appliance is used within a none domestic
environnement i.e. a semi commercial, commercial or communal environment.

3
Dear Customer,
Thank you for having purchased and given your preference to our product.
The safety precautions and recommendations reported below are for your own safety and that of others. They
will also provide a means by which to make full use of the features offered by your appliance.
Please preserve this booklet carefully. It may be useful in future, either to yourself or to others in the event
that doubts should arise relating to its operation.
This appliance must be used only for the task it has explicitly been designed for, that is for cooking foodstuffs.
Any other form of usage is to be considered as inappropriate and therefore dangerous.
The manufacturer declines all responsibility in the event of damage caused by improper, incorrect or illogical
use of the appliance.
IMPORTANT - PLEASE READ AND FOLLOW
✓ Before beginning, please read these instructions completely and carefully.
✓ Do not remove permanently affixed labels, warnings, or plates from the product. This
may void the warranty.
✓ Please observe all local and national codes and ordinances.
✓ Please ensure that this product is properly grounded.
✓ The electrical plug should always be accessible.
✓ The installer should leave these instructions with the consumer who should retain
for local inspector's use and for future reference.
Installation must conform with local codes or in the absence of codes, the National Fuel
Gas Code ANSIZ223.1 - Iatest edition. Electrical installation must be in accordance
with the National Electrical Code, ANSI/NFPA70 - latest edition and/or local codes. IN
CANADA: Installation must be in accordance with the current CAN/CGA-B149.1 National
Gas Installation Code or CAN/CGA-B149.2, Propane Installation Code and/or local codes.
Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical
Codes Part 1 and/or local codes.
INSTALLATION IN MANUFACTURED (MOBILE) HOME: The installation must conform
with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280
[formerly the Federal Standard for Mobile Home Construction and Safety, Title 24, HUD
(Part 280)] or, when such standard is not applicable, the Standard for Manufactured Home
Installations, ANSI/NCSBCS A225.1, or with local codes where applicable.
INSTALLATION IN RECREATIONAL PARK TRAILERS: The installation must conform with
state or other codes or, in the absence of such codes, with the Standard for Recreational
Park Trailers, ANSI A119.5.
Installation of any gas-fired equipment should be made by a Iicensed plumber. A manual
gas shut-off valve must be installed in the gas supply line ahead of the appliance in the gas
stream for safety and ease of service.
If an external electrical source is utilized, the appliance, when installed, must be electri-
cally grounded in accordance with local codes or, in the absence of local codes, with the
national Electrical Code, ANSI/NFPA 70.
This range is supplied with a protective film on steel and aluminium parts.
This film must be removed before installing/using the appliance.
THIS RANGE IS FOR RESIDENTIAL USE ONLY

4
USER INSTRUCTIONS
GENERAL INFORMATION
WARNING!!
1. This appliance shall not be used for space heating. This
information is based on safety considerations.
2. AlI openings in the wall behind the appliance and in the floor
under the appliance shall be sealed.
3. Keep appliance area clear and free from combustible
materials, gasoline, and other flammable vapors.
4. Do not obstruct the flow of combustion and ventilation air.
5. Disconnect the electrical supply to the appliance before
servicing.
6. When removing appliance for cleaning and/or service;
A. Shut off gas at main supply.
B. Disconnect AC power supply.
C. Disconnect gas line to the inlet pipe.
D. Carefully remove the range by pulling outward.
CAUTION: Range is heavy; use care in handling.
7. Electrical Requirement
Electrical installation should comply with national and local
codes.
8. Air Supply and Ventilation
The installer must refers to local/national codes.
9. Gas Manifold Pressure
Natural gas - 4.0” W.C.P.
LP/Propane - 11.0” W.C.P.
10. The misuse of oven door (e.g. stepping, sitting, or leaning
on them) can result in potential hazards and/or injuries.
11. When installing or removing the range for service, a rolling
lift jack should be used. Do not push against any of the
edges of the range in an attempt to slide it into or out of
the installation. Pushing or pulling a range (rather than using
a lift jack) also increases the possibility of bending the leg
spindles or the internal coupling connectors.
WARNING!!
ELECTRICAL GROUNDING INSTRUCTIONS
The range must be electrically grounded in accordance
with local codes or, in the absence of local codes, with
the National Electrical Code, ANSI/NFPA No. 70-latest
edition, in Canada Canadian Electrical Code.
Installation should be made by a Iicensed electrician.
FOR PERSONAL SAFETY, THIS APPLIANCE MUST BE
PROPERLY GROUNDED.
If an external electrical source is utilized, the installation must
be electrically grounded in accordance with local codes or, in
the absence of local codes, with the national Electrical Code,
ANSI/NFPA 70.
This appliance is equipped with a four-prong grounding plug
(NEMA 14-50P) for your protection against shock hazard and
should be plugged directly into a properly grounded socket. Do
not under any circumstances cut or remove the fourth (ground)
prong from the power plug.
REPLACEMENT PARTS
Only authorized replacement parts may be used in performing
service on the range. Replacement parts are available from
factory authorized parts distributors. Contact the nearest parts
distributor in your area.

5
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR
USE OF ELECTRICAL APPLIANCES
Use of any electrical appliance implies the necessity to follow a series of fundamental rules.
In particular:
✓ Never touch the appliance with wet hands or feet;
✓ Do not operate the appliance barefooted;
✓ Do not allow children or disabled people to use the appliance without your supervision.
The manufacturer cannot be held responsible for any damages caused by improper,
incorrect or unreasonable use of the appliance.
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS
After having unpacked the appliance, check to ensure that it is not damaged.
In case of doubt, do not use it and consult your supplier or a professionally qualified techni-
cian.
Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not
be left around within easy reach of children, as these may cause serious injuries.
The packaging material is recyclable and is marked with the recycling symbol
.
✓
Do not attempt to modify the technical characteristics of the appliance as this may
become dangerous to use.
✓ Do not carry out cleaning or maintenance operations on the appliance without having
previously disconnected it from the electric power supply.
✓ After use, ensure that the knobs are in OFF position.
✓ Do not allow children or other incapable people to use the appliance without
supervision.
✓ During and after use of the range, certain parts will become very hot. Do not touch
hot parts.
✓ Keep children away from the range when it is in use.
✓ This range is supplied with a protective film on steel and aluminium parts. This film
must be removed before installing/using the appliance.
✓ Fire risk! Do not store flammable material in the oven and in the warming drawer.
✓ Make sure that electrical cables connecting other appliances in the proximity of the
range cannot come into contact with the hob or become entrapped in the oven
door.
✓ Do not line the oven walls with aluminium foil. Do not place shelves, broiler pan,
pans or other cooking utensils on the base of the oven chamber.
✓ The manufacturer declines all liability for injury to persons or damage to property
caused by incorrect or improper use of the appliance.
✓ To avoid any possible hazard, the appliance must be installed by qualified personnel
only. Any repairs by unqualified persons may result in electric shock or short circuit.
In order to avoid possible injuries to your body or to the appliance, do not attempt
any repairs by yourself. Such work should be carried out by qualified service
personnel only.
✓ Danger of burns! The oven and cooking accessories may become very hot during
operation. Make sure children are kept out of reach and warn them accordingly. To
avoid burns use kitchen clothes and gloves when handling hot parts or utensils.
✓ Stand away from the range when opening oven door. Hot air or steam which
escapes can cause burns to hands, face, and/or eyes.
✓ Never clean the range, oven and the warming drawer with a high-pressure steam
cleaning device, as it may provoke a short circuit.
✓ This appliance is intended for use in your household. Never use the appliance for
any other purpose!
✓ If you should decide not to use this appliance any longer (or decide to substitute an
older model), before disposing of it, it is recommended that it be made inoperative
in an appropriate manner in accordance to health and environmental protection
regulations, ensuring in particular that all potentially hazardous parts be made
harmless, especially in relation to children who could play with old appliances.
Remove the door and the warming drawer before disposal to prevent entrapment.

6
features
1
WARNING - VERY IMPORTANT NOTICE
Never obstruct the slots on the backguard.
CAUTION:
If the burner is accidentally extinguished, turn the gas
off at the control knob and wait at least 1 minute before
attempting to relight.
CAUTION:
Gas appliances produce heat and humidity in the environ-
ment in which they are installed.
Ensure that the cooking area is well ventilated following
national/local codes.
COOKING HOB
1. Auxiliary burner (A) - 3500 BTU/hr
2. Left semi-rapid burner (SR) - 6000 BTU/hr
3. Right semi-rapid burner (SR) - 6000 BTU/hr
4. Triple-ring burner (TR) - 12000 BTU/hr-
Note:
- The electric gas-lighting device is incorporated into the
knobs.
- The appliance has a safety valve system fitted, the flow of
gas will be stopped if and when the flame should acciden-
tally go out.
Fig. 1.1
1
1
23
3
4
1

7
a
CONTROLS DESCRIPTION
1. Front left burner (1) control knob
2. Rear left burner (2) control knob
3. Rear right burner (3) control knob
4. Front right burner (4) control knob
5 6
10 8 9
12347
11
Fig. 1.2
Oven controls:
5. Self cleaning oven control knob
6. Electronic programmer
7. Warming drawer control knob
8. Door locked pilot light
9. Warming drawer on pilot light
10. Oven heating pilot light
11. Oven on pilot light
1

8
how to use the top burners
2
Fig. 2.1
GAS BURNERS
Gas flow to the burners is adjusted by turning the knobs (illustrated in fig. 2.1) which
control the valves.
Turning the knob so that the symbols printed on itself point to the symbol printed on
the control panel achieves the following functions:
Knob
position Function AUXILIARY and SEMI-RAPID burners TRIPLE RING burner
closed
valve
maximum
rate
minimum
rate
Fig. 2.2
2
OFF
HI
LO
OFF
HI
LO
The maximum aperture position permits rapid boiling of liquids, whereas the minimum
aperture position allows simmer warming of food or maintaining boiling conditions of
liquids.
To reduce the gas flow to minimum, rotate the knob further anti-clockwise to point the
indicator towards the LO position.
Other intermediate operating adjustments can be achieved by positioning the indicator
between the maximum and minimum aperture positions, and never between the
maximum aperture and OFF positions.
N.B. When the range is not being used, set the gas knobs to their OFF positions
and also close the gas shut-off valve placed on the main gas supply line.

9
Caution!
The range becomes very hot during operation.
Keep children well out of reach.
b
LIGHTING GAS BURNERS FITTED WITH FLAME FAILURE
SAFETY DEVICE
In order to light the burner, you must:
1 – Push and turn the knob in an anti-clockwise direction up to the HI position
(maximum rate), push in and hold the knob until the flame has been lit.
The sparks produced by the lighter situated inside the relative burner will light the
flame.
In the event that the local gas supply conditions makes it difficult to light the burner
in HI position, try again with the knob in LO position.
If there is no mains electrical supply, bring a lighted match close to the burner.
2 – Wait for about ten seconds after the gas burner has been lit before letting go the
knob (safety device activation delay).
3 – Adjust the gas valve to the desired position.
If the burner flame should go out for some reason, the safety valve will automatically
stop the gas flow.
To re-light the burner, return the knob to the closed OFF position, wait for at least
1 minute and then repeat the lighting procedure.
If your local gas supply makes it difficult to light the burner with the knob set to maxi-
mum, set the knob to minimum and repeat the operation.
2

10
b
Make sure that the handles of
cookware do not stick out over
the edge of the range, to avoid
them being knocked over by
accident. This also makes it more
difficult for children to reach the
cooking vessels.
CORRECT USE OF TRIPLE-RING BURNER (Fig.-2.4a - 2.4b)
The flat-bottomed pans are to be placed directly onto the pan-support.
When using a WOK you need to place the supplied stand in the burner to avoid any
faulty operation of the triple-ring burner (Figs.-2.4a - 2.4b).
IMPORTANT:
The special grille for wok pans (fig. 2.4b) MUST BE PLACED ONLY over the pan-rest
for the triple-ring burner.
CHOICE OF BURNER (fig. 2.3)
The symbols printed on the panel above the gas knobs indicate the correspondence
between the knob and the burner.
The most suitable burner is to be chosen according to the diameter and volume capac-
ity of the container to be warmed.
It is important that the diameter of the pots or pans suitably match the heating potential
of the burners in order not to jeopardise the efficiency of the burners, bringing about a
waste of gas fuel.
A small diameter pot or pan placed on a large burner does not necessarily mean that
boiling conditions are reached quicker.
Fig. 2.3
Fig. 2.4a
WRONG
Fig. 2.4b
CORRECT
DIAMETERS OF PANS WHICH MAY BE USED ON THE HOB BURNERS
BURNER MINIMUM MAX.
Auxiliary 12 cm (4" 23/32 ) 14 cm (5" 1/2)
Semirapid 16 cm (6" 19/64) 24 cm (9" 7/16)
Triple-ring 26 cm (10" 3/16) 28 cm (11" 1/16)
Wok pans min 36 cm (14" 3/16) - max 40 cm (15" 3/4)
Do not use pans with concave or convex bases (apart from wok pans used with the
special pan-support fitted)
2

11
how to use the warmer drawer
C
USING THE WARMING DRAWER FOR THE FIRST TIME
• Switch on the warming drawer empty at maximum power (HI) for about 2 hours to
remove traces of grease and smells from the components.
• When the warming drawer has cooled down and unplugging the range, clean the
inside of the drawer with a cloth soaked in water and neutral detergent and dry it
perfectly.
WARNING: The drawer is hot during operation, use the handle.
WARNING:
The warming drawer is for keep-
ing hot food hot. Never use it to
warm or heat a room or to warm-
ing plates.
IMPORTANT:
During the self-cleaning cycle the
warming drawer do not operates.
If during self-clening cycle the
warmimg drawer control knob has
been turned ON return the knob
to the OFF position. Otherwise
at the end of the self-cleaning
cycle and after having turned the
oven selector control knob to the
OFF position, the warming drawer
will operates.
CORRECT USE OF THE WARMING DRAWER
• The warming drawer will keep hot cooked foods at serving temperature.
• Always start with hot food.
• DO NOT use to heat cold food other than proofing yeast dough, crisping crackers,
chips, and dry cereal, or warming dishes or plates.
• Use care when opening the drawer. Open door a crack and let hot air or steam
escape before re-moving or replacing food.
• Do not place food in unopened containers in the drawer. Pressure could build up and
cause container to burst.
• Do not touch the interior surface of the drawer while it is in use. The interior of the
drawer could become hot enough to cause burns.
• Use only dry potholders. Moist or damp potholders on hot surfaces may cause burns
from steam. Do not use a towel or other bulky cloth in place of potholders. Do not let
potholders touch hot heating element located upper the drawer.
• Do not use aluminum foil to line the drawer. Foil is an excellent heat insulator and
will trap heat beneath it. This will upset the performance of the drawer and it could
damage the interior finish.
• Do not store flammable materials in the drawer.
• Do not use plastic containers. Do not use no heat resistant containers.
• Do not use the warming drawer as a storage drawer.
GENERAL FEATURES
The warming drawer is fitted with an heating element (500 W) placed on the top.
The heating can be regulated from 86 °F (30 °C) (LO) to 248 °F (120 °C) (HI).
On the top part of the drawer a moisture selector is fitted. For correct use see the
“MOISTURE SELECTOR” chapter.
Fig. 3.1
TO USE THE WARMING DRAWER
• Push and turn the control knob to a temperature setting: (LO), (HI) or between (LO)
and (HI) position.
• Slide the Moisture selector to a Moist or Dry position. Intermediate positions can be
setted (fig. 3.2) (see the “MOISTURE SELECTOR” chapter)
• Allow time for the drawer to be preheated.
• Preheat with rack in place if using that arrangement.
• Preheat empty serving dish while preheating drawer.
• Add cooked, hot food in cooking utensil or to heat-safe serving dishes.
• Food may be kept hot in its cooking container or transferred to a heat-safe serving
dish.
• Aluminum foil may be used to cover food.
CAUTION: Plastic containers or
plastic wrap can melt if in direct
contact with the drawer or a hot
utensil. If it melts onto the drawer,
it may not be removable.
3
OFF
HI
LO

12
c
REVERSIBLE RACK
The rack shall be positioned as per fig-
ures 3.3 and 3.4.
MOISTURE SELECTOR (fig. 3.2)
MOIST position: Vents closed
DRY position: Vents opened
To keep foods moist, slide the moisture
selector to the left. This closes the vents
and the moisture remains inside the
drawer.
In this setting condensation may occur
around the inside edge of the drawer.
To keep foods crisp, slide the moisture
selector to the right. This opens the vents
and allows the moisture to escape. With
the vents open, it is normal for moisture
to collect on surfaces above the warming
drawer.
WARNING LIGHT
The signal light is located above the
control knob and turns “ON’ when the
warming is set. It stays on until the knob
is turned back to the “OFF” position.
DRY
MOIST
Moisture selector
Fig. 3.2
Fig. 3.3
Fig. 3.5
Fig. 3.4
TEMPERATURE SELECTOR
The setting can be anywhere between
LO and HI position.
Knob position °F °C
LO 86 30
between LO and HI from 87 to 247 from 31 to 119
HI 248 120
3

13
USING THE OVEN FOR THE FIRST TIME
- Put in the shelf and the tray.
- Switch the oven on empty (on a cooking function – NOT SELF CLEANING) at maximum
power for about 2 hours to remove traces of grease and smells from the components.
- When the oven has cooled down and unplugging the range, clean the inside of the oven
with a cloth soaked in water and neutral detergent and dry it perfectly.
WARNING:
The door is hot, use the handle.
Attention: the oven door becomes
very hot during operation.
Keep children away.
VERY IMPORTANT
The oven shall be used always
with the door closed.
how to use the self cleaning oven
NOTES ON OVEN WORKING
A cooling fan starts automatically when selecting a cooking or self cleaning mode.
It stops when turning the selector knob to OFF or light or defrosting position and
th inside oven cavity temperature drops below 100 °C (212 °F).
The purpose of this fan is to reduce the temperature inside/outside the appli-
ance.
Note: The first time the oven is used or after a black-out the programmer must be
started by pressing keys 2 and 3 simultaneously. See the chapter on the use of the
electronic programmer.
4
OPERATING PRINCIPLES
Heating and cooking in the multifunction self cleaning oven takes place as follows:
• by normal convection
The heat is produced by the upper and lower heating elements.
• by forced convection
The heat produced by the circular element is distributed throughout the oven by the
fan.
• by radiation
The heat is radiated by the infra red broil element.
• by radiation and fan
The radiated heat from the infra red broil element is distributed throughout the oven
by the fan.
• by double radiation and fan
The fan distributes the heat radiated by the broil heating element and the upper heat-
ing element in the oven.
• by ventilation
The food is defrosted by using the fan only function without heat.
• by self cleaning
The heat produced by the heating elements cleans the internal oven cavity removing
all residue of grease.
THIS IS NOT A COOKING FUNCTION
GENERAL FEATURES
The ovens have special operating features.
Five different functions can be used to satisfy all cooking needs; it also has a self clean-
ing function which can clean the oven cavity at high temperature, a defrost function and
an oven light function.
These functions are managed by an electronic programmer which keeps the tempera-
ture set constant by means of a probe inside the oven cavity.
The ovens have the following heating elements:
- Lower heating element (double) 500 + 1300 W
- Upper heating element 1000 W
- Grill heating element 2000 W
- Circular heating element 2200 W NEVER USE THE RANGE WHEN
THE OVEN IS OPERATING IN SELF
CLEANING MODE.
DO NOT OPERATE THE TOP
BURNERS.
WHENTHE SELF CLEANING MODE
HAS BEEN COMPLETED:
• do not start immediately a new
self cleaning cycle: LET THE RA
NGE TO COOL DOWN.
IMPORTANT:
DURING THE SELF-CLEANING
CYCLE THE WARMING DRAWER
DO NOT OPERATES.
If during self-cleaning cycle the
warming drawer control knob has
been turned ON return the knob
to the OFF position. Otherwise
at the end of the self-cleaning
cycle and after having turned the
oven selector control knob to the
OFF position, the warming drawer
will operates.
IIIIII
I
I
I
I
I
IIIIIIIIII
I
I
I
I
I
I
III
2 3
4

14
d
OVEN LIGHT (this is not a cooking function)
On turning the knob to this position only the oven lamp lights up.
The lamp is always on in all the cooking functions (not for the self cleaning).
SELECTING THE FUNCTIONS (fig. 4.1)
The cooking function is selected by turning the function selector knob and matching the
mark with the symbol printed on the print.
Fig. 4.1
If the door stays open “door” appears on the programmer dis-
play and after five minutes an audible warning sounds for 30
seconds and “door” flashes.
To silence the audible warning press any programmer pushbutton.
NOTE: The heating elements work even with the door open and this signal just
indicates that energy is being wasted and the control panel/knobs are excessively
heated.
IIIIII
I
I
I
I
I
I
IIIIIIIIII
I
I
I
I
I
I
IIII
DEFROSTING FROZEN FOODS (this is not a cooking function)
Only the fan and the oven lamp switch on. Defrosting takes place by
fan, without heating. The electronic programmer shows dEF
Recommended for:
To rapidly defrost frozen foods; 2.2 lbs (1 kg) requires about one hour.
The defrosting times vary according to the quantity and type of foods to be defrosted.
CONVECTION COOKING WITH VENTILATION
The circular element and the fan switch on. The heat from the back is diffused by fan
convection. The temperature can be set between 120 °F (50 °C) and 480 °F (250 °C).
On selecting this function the electronic programmer starts cooking with a pre-heating
temperature set at 320 °F (180 °C). To vary the temperature see the “Setting the cooking”
chapter.
Recommended for:
For foods of large volume and quantity which require the same internal and external
degree of cooking; for ex: rolled roasts, turkey, legs, cakes, etc.
Important: In all cooking functions the oven must always be used with
the DOOR CLOSED.
4
OFF

15
d
TRADITIONAL CONVECTION COOKING
The upper and lower heating elements switch on.
The heat is diffused by natural convection and the temperature must be set between
120-°F (50 °C) and 480 °F (250 °C). On selecting this function the electronic program-
mer starts cooking with a pre-heating temperature set at 350 °F (200 °C). To vary the
temperature see the “Setting the cooking” chapter.
Recommended for:
For foods which require the same cooking temperature both internally and externally, i.
e. roasts, spare ribs, meringue, etc.
VENTILATED COOKING WITH DOUBLE BROIL
The infrared element, the upper heating element and the fan switch on. The heat is
mainly diffused by radiation and the fan distributes it in the whole oven. The temperature
can be set between 120 °F (50 °C) and 480 °F (250 °C).
On selecting this function the electronic programmer starts cooking with a pre-heating
temperature set at 480 °F (240 °C).
To vary the temperature see the “SETTING THE COOKING” chapter.
For correct use see the “VENTILATED BROILING AND AU GRATIN” chapter.
Recommended for:
Meats which are to be cooked at a high temperature but which must remain tender. Fish
remains more tender; turn it once during cooking.
BROILING
The infrared heating element switches on.
The heat is diffused by radiation. The temperature can be set between 120 °F (50 °C)
and 480-°F (250 °C). On selecting this function the electronic programmer starts cooking
with a pre-heating temperature set at 480 °F (210 °C).
To vary the temperature see the “SETTING THE COOKING” chapter.
For correct use see the “BROILING” chapter.
Recommended for:
Intense broiling action for cooking with the broiler; browning, crisping, “au gratin”, toasting,
etc.
For correct use see the “GRILLING” chapter.
VENTILATED BROILING
The infrared heating element and the fan switch on. The heat is mainly diffused by radia-
tion and the fan distributes it in the whole oven.
The temperature can be set between 120 °F (50 °C) and 480-°F (250 °C). On selecting
this function the electronic programmer starts cooking with a pre-heating temperature set
at 480 °F (220 °C). To vary the temperature see the “SETTING THE COOKING” chap-
ter.
Recommended for:
For grill cooking when a fast outside browning is necessary to keep the juices in, i. e. veal
steak, steak, hamburger,
etc. For correct use see the “VENTILATED BROILING AND AU
GRATIN” chapter.
4

16
d
IMPORTANT NOTES:
This is not a cooking function but is only used to
clean the oven.
Before starting the self cleaning cycle:
- Take all the accessories out of the oven (drip tray
and shelves).
- Clean any traces of liquid which have over-
flowed.
- Close the oven door and make sure that it is
closed properly.
If there are cracks or flaws on the oven door glass
(inside/outside) or if the gaskets are ruined or worn
or if the door does not close perfectly, unplug the
appliance and contact the Service Centre.
GENERAL INFORMATION
• In this function the residual cooking greases on the inside walls of the oven cavity
are pulverised by the high temperature. The fumes produced during this process are
filtered by a special catalyst in the upper part of the appliance.
• Smells and fumes produced during self cleaning are not a cause of alarm. Adequate
ventilation should however be provided in the room where the range is installed, e.g.
by opening a window.
• Do not wait for the oven to be very greasy before performing this cleaning. It should
not be performed after every cooking, either, but only when the level of dirt justifies it
(on average 1 – 2 times a month depending on oven use).
• For safety reasons (high temperature of the oven cavity), when the self cleaning starts
the oven door is automatically locked by an electronic device (after about 30 seconds
on the control panel the door locked pilot light lights up). The door can no longer be
opened and is only unlocked at the end of the cleaning cycle or, stopping the cycle,
when the oven cavity has cooled to a temperature lower than 570 °F (300 °C).
• When the self cleaning function starts an internal fan starts automatically to cool the
oven walls. It only stops at the end of the cycle, when the oven cavity temperature has
dropped below 212 °F (100 °C).
• The procedures for starting, stopping and completing the self cleaning cycle and deal-
ing with any problems are described in the following chapters:
- “How to start the self cleaning cycle”
- “Problems on starting and during the self cleaning cycle”
- “How to stop the self cleaning cycle”
- “What to do when the self cleaning cycle has finished”
- “Abnormal situations and/or operating problems”
CAUTION: During the self clean-
ing cycle the accessible parts
may become hot. Keep children
away.
SELF CLEANING FUNCTION (this is not a cooking function)
NEVER USE THE RANGE WHEN
THE OVEN IS OPERATING IN SELF
CLEANING MODE.
DO NOT OPERATE THE TOP
BURNERS
IMPORTANT:
The health of some birds is
extremely sensitive to the fumes
given off during the self-cleaning
cycle.
Exposure to the fumes may result
in death to certain birds.
Always move birds to another
closed and well ventilated room.
WHENTHE SELF CLEANING MODE
HAS BEEN COMPLETED:
• do not start immediately a new
self cleaning cycle on the same
oven: LET THE RANGE TO COO
L DOWN.
IMPORTANT:
DURING THE SELF-CLEANING
CYCLE THE WARMING DRAWER
DO NOT OPERATES.
If during self-cleaning cycle the
warming drawer control knob has
been turned ON return the knob
to the OFF position. Otherwise
at the end of the self-cleaning
cycle and after having turned the
oven selector control knob to the
OFF position, the warming drawer
will operates.
4

17
The temperature set is shown on the electronic programmer display and can be varied,
with 5 °F (5 °C) intervals, by means of the programmer keys.
During the cooking the oven temperature (°F or °C) is measured by a sensor inside the
cavity and is shown on the programmer display until setted temperature is reached. If
setted temperature is less than inside oven temperature, the display shows the setted
temperature.
1. SELECTING THE COOKING FUNCTION
Turn the selector knob to the cooking function required
The pre-set temperature appears on the programmer display. °F or °Cflashes on the
display for 3 seconds. The heating elements start cooking immediately.
2. SETTING THE COOKING TEMPERATURE
The temperature can be changed when °F or °Cis flashing on the display
2a. If °F or °Cis not flashing press key 4 of the programmer.
2b. Press key 6 to increase the temperature or key 5 to reduce it.
The maximum temperature which can be set is 480 °F (250 °C) while the minimum
temperature is 120 °F (50 °C).
Note: When °F or °Cbecomes steady the value shown on the display indicates the oven
cavity temperature until setted temperature is reached. If setted temperature is less than
inside oven temperature, the display shows the setted temperature.
Caution: If a temperature below the minimum value (120 °F or 50 °C) is set the system
switches off automatically and OFF appears.
In this case repeat the procedure from point 2.
3. SWITCHING OFF
Turn the selector knob to position OFF (oven OFF). The programmer display shows
the time.
SETTING THE COOKING (ONLY FOR THE COOKING FUNCTIONS)
SELECTING °F/°C ON THE DISPLAY
1. Turn the oven selector knob to a cooking function (i.e. BAKE).
2. Press key 5 on the programmer to reduce the temperature until you reach the
minimum value (120 °F/50 °C).
3. With °F/°C flashing on the display press key 5 again (if °F/°C is not flashing press key
4 before pressing key 5) until OFF appears on the display.
4. Keep key 4 pressed for about 3/5 seconds until the display changes from °C to °F or
vice versa. During selection °C or °F is flashing.
5. When OFF apears again on the display turn the selector knob to OFF position; the
selection to °C or °F has been completed.
d
I
I
I
I
I
I
I
I
I
I
I
4 5 6
Oven function selector knob
Oven programmer
➀
➀
➁
2a 2b
I
I
I
I
I
I
I
I
I
I
I
5
5
➂
4
➃
➄
➁
4

18
d
HOW TO START THE SELF CLEANING CYCLE
Important: the self cleaning cycle must only be performed with the oven empty;
so, before starting the cycle take all the accessories (shelves, drip tray, ...) out of
the oven cavity and dry any traces of overflowed liquid.
Do not use any degreasing products (e.g. degreasing sprays, detergents, etc.).
1. Close the oven door (if it is open or not closed properly the self cleaning cycle will
not start).
2. Turn the oven selector knob to the self cleaning position ; P0•00 appears
on the electronic programmer display with the letter Pflashing.
3. Press pushbutton 3 on the programmer to start the cycle.
This combined confirmation operation offers greater safety when there are children;
in fact turning the knob to the self cleaning function has no effect if key 3 of the
programmer is not then pressed.
• P1•30 (self cleaning time, 1 hour and 30 minutes) appears and the door is locked
after about 30 seconds;
• On the control panel the door locked pilot light lights up to indicate that the door is
locked.
4. To increase the self cleaning cycle time (max 5 hours) press key 2 of the programmer
then key 6. To go backwards to the minimum of 1 hour and 30 minutes press key 2
then key 5.
• During the setting AUTO flashes and Pdisappears.
5. The self cleaning cycle starts immediately and is completed in the programmed
time.
• Throughout the self cleaning cycle the programmer displays the time (hours and
minutes) remaining until the cycle is finished.
VERY IMPORTANT:
The self cleaning cycle only starts with the oven door closed. If the door is open or
not closed properly the oven CANNOT perform the self cleaning cycle; electronic
safety devices prevent the self cleaning cycle from starting.
I
I
I
I
I
I
I
I
II
I
I
I
I
I
I
➁
3
➂
I
I
I
I
I
I
I
I
I
25 6
➃
➄
4

19
PROBLEMS ON STARTING AND DURING THE SELF CLEANING
1. Steady door
The function selector has been turned to the self cleaning position with the oven
door open or not perfectly closed. Or the door has been opened before the cycle
has been started with confirmation from key 3
What to do:
Close the door and repeat previous cycle.
. If after 5 minutes the door has not been closed door flashes and an audible signal
sounds for 30”.
What to do:
Close the door, press any programmer key to silence the audible signal and repeat the
operations to start the cycle.
2. door with AUTO flashing
The oven door has been opened after the self cleaning cycle has started (before
locking the door). The self cleaning cycle is zeroed.
What to do:
1. Close the door. P0•00 appears on the electronic programmer display with the letter
Pand AUTO flashing.
2. Turn the function selector to OFF and repeat the operations to start the cycle.
. If after 5 minutes the door has not been closed door flashes and an audible signal
sounds for 30”.
What to do:
Close the door, press any programmer key to silence the audible signal and repeat the
operations to start the cycle.
3. F0.00 with AUTO flashing
The self cleaning cycle has been stopped and then started again when it was quite a
way through. The message is displayed after about 10 minutes and the self cleaning
cycle is zeroed.
What to do:
1. Put the switch to OFF.
2. Wait for at least 15 minutes.
3. Repeat the operations to start the self cleaning cycle.
4. If after several attempts the message continues contact the Service Centre.
Caution: It is advisable not to stop the self cleaning cycle and then start it again
when it is quite a way through.
IIIIII
I
I
I
I
I
I
IIIIIIIIII
I
I
I
I
I
I
IIII
I
I
I
I
I
I
I
I
I
I
I
IIIIII
I
I
I
I
I
I
I
IIIIIIIIII
I
I
I
I
I
I
I
IIII
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
d
4

20
d
HOW TO STOP THE SELF CLEANING CYCLE
1. Turn the function selector to OFF (oven OFF)
-If the oven cavity temperature is higher than 570 °F (300 °C)
1a. The time of day appears steadily on the programmer display.
1b. When the oven cavity temperature drops below 570 °F (300 °C):
-
OFF appears on the programmer display again
- the door locked pilot light goes out
- the door unlocks and can be opened
-If the oven cavity temperature is lower than 570 °F
1c. The time appears on the programmer display
1d. After a technical time:
- the door locked pilot light goes out
- the door unlocks and can be opened
IMPORTANT: Wait for the oven to cool down completely before starting a cooking
function.
ACCIDENTAL INTERRUPTION OF THE SELF CLEANING CYCLE
2. The function selector has been turned to any cooking function
-If the oven cavity temperature is higher than 570 °F (300 °C)
2a. The time of day appears steadily on the programmer display.
2b. When the oven cavity temperature drops below 570 °F (300 °C):
-
OFF appears on the programmer display
- when door locked pilot light goes out (after some minutes) the door unlocks and
can be opened
2c. To reset normal conditions turn the function selector to OFF (oven OFF). The time
appears on the programmer display.
-If the oven cavity temperature is lower than 570 °F (300 °C)
2d. Pre-set temperature of the selected function appears on the programmer display.
2e. After a technical time:
- the door locked pilot light goes out
- the door unlocks and can be opened
2f. To reset normal conditions turn the function selector to OFF (oven OFF). The time
appears on the programmer display.
IMPORTANT: Wait for the oven to cool down completely before starting a cooking
function.
WHAT TO DO WHEN THE SELF CLEANING CYCLE HAS FINISHED
1. P0.00 with AUTO flashing.
Wait for the oven to cool down and the door to unlock.
The self cleaning cycle has finished. P0.00 will remain until the door is unlocked.
The door remains locked until the cavity temperature has dropped below 570
°F (300°C).
2. The door locked light goes out (when the temperature has dropped below
570 °F - 300 °C).
AUTO and the letter Pflash.
The door is unlocked and can be opened.
3. Turn the function selector knob to OFF (oven OFF).
The time appears on the programmer display.
4. Wait for the oven to cool down completely.
5. Remove the pulverised dirt.
Open the oven door and remove the residue of pulverised dirt inside the oven with a
damp cloth.
IMPORTANT: Before switching the oven on again in any function wait for the
appliance to cool down completely.
➀
➁
1a 1b
2a 2b
3d
I
I
I
I
I
I
I
I
I
I
I
➀
➁
➂
4
