ACTIVESMART™
INTEGRATED REFRIGERATOR
RS36W and RS91W Models
FRAMED AND FRAMELESS CABINETRY
DUAL INSTALLATION GUIDE
NZ AU GB IE HK SG IN US CA

1
FOLLOW THE INSTALLATION SEQUENCE
1 Safety and warnings 3
2 Dual Installation 3
3 Components list 4
4 Alcove dimensions 5
5 Attaching foam pads 5
6 Removing hinge bracket and fitting alcove bracket 6
7 Attaching top joiner bracket and alcove fixing bracket to alcove 7
8 Location of products into alcove — Right product 8
9 Location of products into alcove — Left product 9
!0 Preparing for centre trim 10
!1 Attaching the centre trim and toe kick 11

3
1SAFETY AND WARNINGS
Dual installation refers to the joining of 1 x RS91WR model with 1 x RS91WL model or
1 x RS36WR model with 1 x RS36WL model.
2DUAL INSTALLATION
RS91WR MODELS RS91WL MODELS
RS91WRJ FP RS91WLJ FP
RS91WRU FP
RS36WR MODELS RS36WL MODELS
RS36W80RJ FP RS36W80LJ FP
RS36W80RU FP
RS36WRJC DCS RS36WLJC DCS
RS36WRUC DCS
This booklet refers to left hinge and right hinge products.
IMPORTANT!
 Each refrigerator requires a water supply and shut off valve. Use a solid brass type splitter
if both refrigerators are supplied from the one water supply.
 Ensure the dual power outlet is suitable for two right angled plugs.
 Extension cords should not be used in the dual installation.
IMPORTANT!
For correct and complete installation of your refrigerator(s) follow the ‘Installation
guide’ booklet supplied with your refrigerator. This booklet is supplementary providing
instructions which are unique to dual installation.
!WARNING!
This appliance is top-heavy and must
be secured to prevent the possibility of
tippingforward.
To ensure that the appliance is stable under
all loading conditions, theanti-tip bracket and
fittings supplied must be installed according
tothe following installation instructions by a
professional installer.
IMPORTANT!
SAVE THESE INSTRUCTIONS
The models shown in this installation guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to
our website www.fisherpaykel.com or www.dcsappliances.com or contact your local Fisher & Paykel dealer.

4
3COMPONENTS LIST
Included with the Dual Install kit.
Alcove fixing bracket
(1)
Joiner bracket
(1)
Left hinge refrigerator
alcove bracket
(1)
Right hinge refrigerator
alcove bracket
(1)
Foam pads
(6)
Spring clips (provided with
the appliance)
(6)
Centre trim
(1)
Bottom joiner bracket
(1)
M8 nut
(1)
M8 Nut
M8 Nut
M8 set screw
(1)
M8 Screw Set
M8 Screw Set
M5 x 12 Socket head cap screw
(11)
M5 x 12 SHCS
(Socket Head Cap Screw)
M5 x 12 SHCS
(Socket Head Cap Screw)
#8 x 16 mush
washer screw
(5)
#8 x 16
Mush Washer
Twin Thread
Philips Screw
#8 x 16
Mush Washer
Twin Thread
Philips Screw
Toe kick
(1)

5
4ALCOVE DIMENSIONS
1Measure and attach foam pads to three locations down the right side of the left hinge
refrigerator. (Align the top of the foam pad to your measurement mark. Align the side of the
foam pad with the front edge of the cabinet).
 2” (50mm) from the cabinet top.
 35” (890mm) from the cabinet top.
 13” (50mm) from the floor.
Repeat on the left side of the right hinge product.
IMPORTANT!
Foam pads should be placed at identical heights on left and right hinge refrigerators to
ensure good fit of joiner trim.
2” (50mm)
35” (890mm) 13” (50mm)
ALCOVE DIMENSIONS inches (mm)
AOverall height of alcove 84” (2134)
BOverall width of alcove 72” (1829)
B
A
5ATTACHING FOAM PADS

6
6REMOVING HINGE BRACKET AND FITTING ALCOVE BRACKET
Fitting alcove bracket
4Screw the front two M5x8 countersunk Phillips screws (refer to C). Check that the top face
of the front trim is parallel to the refrigerator.
5Shift M5x10 pan head Phillips trim attachment screws into the slots in the alcove bracket,
(refer to D).
–If the front trim is not parallel to the refrigerator, screw the jacking screw supplied:
M5x12 Socket head cap screw (refer to E) to adjust the trim position.
6When the front trim is parallel to the refrigerator, secure the alcove bracket with the third
countersunk screw (refer to F).
B
A
E
F
C
D
Removing hinge bracket
Follow the steps below to remove the hinge bracket (non hinged side) and fit the alcove
bracket. This process is required for both left and right hinge refrigerators.
<1/4” (<6mm)
Top trim
1Ensure the distance between the end of the top trim and the side of the cabinet is not
greater than 1/4” (6mm). If distance is greater than 1/4” (6mm), loosen the pan head Phillips
screws at the back of the trim and shift the trim sideways to suit.
2On the right hand side (when facing the front side of the refrigerator), loosen the M5 x 10
pan head Phillips top trim attachment screws. Shift screws towards the centre of the trim,
(refer to A).
3Remove the right hinge bracket from the left hinge refrigerator by unscrewing the
countersunk Phillips head screws with a Phillips head screwdriver (refer to B).
Repeat process of removing hinge bracket and fitting alcove bracket on the right
hinge refrigerator.
Start with the left hinge refrigerator and repeat the process on the right hinge refrigerator.
Refrigerator front side

7
7ATTACHING TOP JOINER BRACKET AND ALCOVE FIXING BRACKET TO ALCOVE
1Use M5x12 Socket head cap screws to connect the top joiner bracket to the alcove
fixingbracket.
– For 80” (2032mm) installation, use the upper slots of the alcove fixing bracket (refer to A).
– For 84” (2134mm) installation, use the lower slots of the alcove fixing bracket (refer to B).
A
B
2Measure the width of your alcove. Mark a line in the centre of the cavity, on the ceiling.
3For flush installation measure 11/4” (108mm) back from the front face of the adjacent
cabinetry doors (refer to C).
– Face1 should be 41/4” (108mm) back.
– Face 2 should be lined up with the centre of the alcove.
For proud installation, the joiner bracket should sit forward. Measure 11/4” (108mm) - x
back from the front face of the adjacent cabinetry doors (refer to C).
– Face 1 should be 11/4” (108mm) - x (x = distance the product sits proud).
– Face 2 should be lined up with the centre of the alcove.
Using #8 x 16 mush washer screws (4), align and fix the joiner bracket to the centre of the
alcove (refer to D). (Loosely fix the screws the centre of each slot to enable adjustment in
the joiner bracket).
WARNING!
Ensure anti tip brackets are fitted at this stage (refer to separate ‘Installation guide’
booklet supplied with your refrigerator).
IMPORTANT!
Door panels must be fitted to doors at this stage (refer to separate ‘Installation guide’
booklet supplied with your refrigerator).
WARNING!
Do not open doors.
SCALE 1:10
84” (2134mm)
72” (1829mm)
At this stage, connect to water and electrical supply as per the ‘Installation guide’ booklet
supplied with your refrigerator.
WARNING!
Failure to follow the instructions can lead to serious injury or death.
41/4” (108mm) = flush installation
41/4” (108mm) - x = proud installation
x
C
D
Face 1
Face 2
41/4” (108mm) = flush installation
41/4” (108mm) - x = proud installation

8
8LOCATION OF PRODUCTS INTO ALCOVE — RIGHT PRODUCT
1Roll the right hinge refrigerator into the right hand side of the alcove until the refrigerator
makes contact with the joiner bracket.
IMPORTANT!
For flush installation: check for flushness of the refrigerator with the surrounding
cabinetry (refer to separate ‘Installation guide’ booklet supplied with your refrigerator)
on how to achieve flushness.
2Adjust the refrigerator height (refer to separate ‘Installation guide’ booklet supplied with
your refrigerator).
3Screw two M5 x 12 Socket head cap screws to connect the alcove bracket to the joiner
bracket (refer to A).
4If the refrigerator is not flush, further loosen the top screws of the alcove attachment
bracket if required and move the bracket in a forward to back motion to suit (refer to B).
5Recheck refrigerator flushness (refer to separate ‘Installation guide’ booklet supplied with
your refrigerator). Once satisfied with flushness, tighten top screws fix an additional
#8 x 16 mush washer screw (refer to C).
SCALE 1:10
SCALE 2:5
A
SCALE 2:5
C
B

9
9LOCATION OF PRODUCTS INTO ALCOVE — LEFT PRODUCT
A
IMPORTANT!
Open the door of the right hinge refrigerator.
1Roll the left hinge refrigerator into the left hand side of the alcove until the refrigerator
makes contact with the joiner bracket (refer to A).
IMPORTANT!
For flush installation: check for flushness of the refrigerator with the adjacent refrigerator
(refer to separate ‘Installation guide’ booklet supplied with your refrigerator on how to
achieve flushness).
2Open the left hinge refrigerator door to access the brackets (refer to B).
3Adjust the refrigerator height (as per the separate ‘Installation guide’ booklet supplied with
your refrigerator), so holes in the top trim are in line with the holes in the joiner bracket
(refer to C).
– Note: for clarity of drawing, top trims are not shown.
4Screw two M5 x 12 Socket head cap screws to fix left hand top trim to the joiner bracket
(refer to C).
B
C

10
!0 PREPARING FOR CENTRE TRIM
1Remove the centre* M10 x 65 Socket head cap screws from the base of the refrigerators
(refer toA)
*Remove the right screw from the left hinge refrigerator.
*Remove the left screw from the right hinge refrigerator.
2Attach the bottom joiner bracket using M10 x 65 Socket head cap screws (refer to B).
A B
3For 80” (2032mm) refrigerators, cut centre trim using the same method as instructed for
side trims (refer to separate ‘Installation guide’ booklet supplied with your refrigerator).
4Mark out three locations for the spring clips along the centre trim to match foam pad
locations on cabinet.
5Insert right hand spring clip into the centre trim channel (refer to C).
IMPORTANT!
Ensure the bottom of the right hand spring clip is located on the right hand side of the
channel.
6Insert the left hand spring clip into the centre trim channel (refer to D).
7Before pushing the left hand spring clip all the way into the trim, squeeze the two spring
clips together and push home. You will hear the spring clips engage into the trim (refer to E).
Repeat for the remaining two locations on the centre trim.
CD E
CLICK!

11
!1 ATTACHING THE CENTRE TRIM AND TOE KICK
IMPORTANT!
Open both refrigerator doors.
1Bring the centre trim in front of the
gap between the two refrigerators
(refer to A).
2Starting from the upper spring clips, squeeze the clips to
slot between the two refrigerators (refer to B).
3Repeat on the middle and then the lower clips.
4Using the palm of your hand, push trim all the way down
the length of the refrigerator.
C
B
6Installing toe kick
Unscrew the toe kick bracket screws mid-way, and bring forward (refer to Dand E).
Repeat this process for both refrigerators.
5Screw the M8 set screw into the threaded hole of the
bottom joiner bracket to support the middle trim. This
maintains the height position of the trim. Once you are
satisfied with the location of the middle trim, use the M8
nut to lock the set screw into location (refer to C).
7Place toe kick over the brackets and position
the outer brackets until flush with surrounding
cabinetry. Use the folded edge of the supplied
toe kick or another suitable straight edge to
align the inner brackets. Once aligned, remove
the toe kick.
8Tighten the toe kick bracket screws to lock brackets into position and remove the backing
from the Velcro strip (refer to F). Attach the toe kick to the adhesive surfaces.
A
F
D
E

NZ AU GB IE HK SG IN US CA
845689 B 07.17
© Fisher & Paykel Appliances 2017. All rights reserved.
The product specifications in this booklet apply to the specific products
and models described at the date of issue. Under our policy of continuous
product improvement, these specifications may change at any time. You
should therefore check with your Dealer to ensure this booklet correctly
describes the product currently available.
