Fisher & Paykel RS2484VR2K1 User manual

INTEGRATED COLUMNS
WINE CABINET
RS2484VL2K1 & RS2484VR2K1
models
INSTALLATION GUIDE
US CA
86020B11.19

3
CONTENTS
IMPORTANT!
SAVE THESE INSTRUCTIONS
The models shown in this installation guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country,
go to our website fisherpaykel.com or contact your local Fisher & Paykel dealer.
SAFETY AND WARNINGS 4
INTEGRATED COLUMNS — WINE CABINET 5
COMPONENTS 6
DOOR PANEL AND HANDLE SETS 8
WINE DISPLAY ACCESSORIES 9
TOOLS 9
APPLIANCE DIMENSIONS 10
CAVITY DIMENSIONS 11
DOOR PANEL DIMENSIONS 13
TOE KICK PANEL DIMENSIONS 14
CUSTOM DOOR PANEL DIMENSIONS 15
DOOR CLEARANCE 16
ELECTRICAL DIMENSIONS 17
ELECTRICAL SPECIFICATIONS 18
BEFORE INSTALLATION 19
Check your appliance 19
Move your appliance 19
BEFORE INSTALLATION 20
INSTALL ANTI-TIP BRACKET 21
CONNECT TO POWER SUPPLY 22
ATTACH DEPTH ALIGNMENT GAUGES 23
POSITION APPLIANCE INSIDE THE CABINETRY 24
Attach barbed plugs 24
ALIGN APPLIANCE INSIDE THE CABINETRY 25
Align depth gauges with cabinetry 25
Adjusting appliance inside the cabinetry 26
FIX APPLIANCE NSIDE THE CABINETRY 27
INSTALL CARBON FILTER 28
PREPARE FOR DOOR PANEL INSTALLATION 29
Removing hanging bracket 29
Attaching door handle 30
Attaching hanging bracket and side brackets 30
Attaching long glass trims 31
Attaching short glass trims 32
INSTALL DOOR PANEL 33
Hanging door panel 33
Adjusting door panel 34
INSTALL TOE KICK MOUNTING PLATE 35
Adjusting toe kick grille 35
Installing toe kick mounting plate 35
INSTALL TOE KICK AND GRILLES 36
Installing toe kick 36
Attaching top and bottom grilles 36
INSTALL CABINET TRIMS 37
Re-installing top trim 37
Re-installing flow divider 37
The flow divider blocks the air flow from bypassing in front of the bottom grille. 37
Installing side trims 38
Four (4) dual-lock strips are pre-installed along each side trim. 38
INSTALL DOOR TRIMS 39
WINE DISPLAY 40
Installing wine display kit 40
Handle assembly 40
Retainer blocks are pre-assembled at the bottom of both ends of the handle. 40
Installing wine label kit 40
OPTIONAL—CHANGE DOOR HINGES 41
Removing the door 41
Removing top door hinge 42
Removing bottom door hinge 42
Moving the sensor housing 43
Top hinge installation 44
Bottom hinge installation 44
Door brackets 45
Door installation 46
FINAL CHECKLIST 47

4
!WARNING!
Electric Shock Hazard
Read and follow the safety and warnings
outlined in this installation guide before
operating this appliance.
Failure to do so can result in death, electric
shock, fire or injury topersons.
!WARNING!
Cut Hazard
Take care—panel edges are sharp.
Failure to use caution could result in injury
or cuts.
!WARNING!
This appliance is top-heavy and must
be secured to prevent the possibility of
tippingforward.
To ensure that the appliance is stable under
all loading conditions, theanti-tip bracket
and fittings supplied must be installed
according tothe following installation steps
by a professional installer.
SAFETY AND WARNINGS
IMPORTANT SAFETY INSTRUCTIONS
BEFORE INSTALLATION
zThe appliance has front and rear rollers for moving the appliance forward and backward.
Do not move the appliance sideways to avoid damaging the rollers or the floor
covering/surface.
zEnsure your appliance is not exposed to any heat generating appliance eg cooktop,
oven or dishwasher.
zThe appliance must be installed by a qualified installer, or Fisher & Paykel trained and
supported service technician to avoid faulty electrical connection.
zAll connections for electrical power and earthing must comply with local codes and
ordinances and be made by licensed personnel when required.
zAvoid installation of the appliance/s under a ground fault circuit interrupter (GFCI).
zEnsure the appliance is installed properly. Improper installation that results in appliance
failure is not covered under the appliance warranty.
UNPACKING
zThe appliance is heavy (including packaging — 302lb/137kg) and requires at least
twopersons to move and install. Avoid scratching the surface of your appliance when
moving or installing.
zKeep the appliance stable and door closed to prevent tipping over when moving to
installation location.
zEnsure feet of the appliance are retracted before moving to installation location.
zIf appliance is damaged, contact your Fisher & Paykel dealer.
zCheck all components and accessories are complete. Refer to 'Components' page.
zRecord the model and registration numbers for future servicing or repair of
your appliance.
ELECTRICAL
zElectrical connection for these appliances must be located in an adjacent area or unit
(cabinet or cupboard) that is easily accessible in case of repair or disconnection.
zOnce installed, the service technician will NOT remove the appliance from the cavity to
gain access for repair.
WARNING!
zElectric shock hazard! Assume all parts live.
zDisconnect supply before servicing and installation.

5
SAFETY AND WARNINGS INTEGRATED COLUMNS — WINE CABINET
INSTALLATION
Cavity preparation
zThe anti-tip bracket and fittings supplied must be fitted tothe wall of the finished
enclosure to withstand a 225lb/100kg load.
zEnsure that the anti-tip bracket is installed correctly to prevent the possibility of the
appliance tipping forward when the door is open.
Positioning inside the cabinetry
zDO NOT attempt to open the door until the appliance is fully installed.
zEnsure the door of the appliance is closed when rolling into thecabinetry.
zEnsure the power cord is not run over or damaged when rolling the product
into the cabinetry.
Aligning inside the cabinetry
zEnsure the doors are in line with the cabinetry front and the appliance iscentred.
zAll four corners of the appliance must be supported firmly onto the floor to eliminate any
movement. Installing the appliance on a soft, uneven, or not level floor may cause twisting
and poor door sealing.
Fixing inside the cabinetry
zUse low speed, low torque setting when using a powered driver for the screws when fixing
or aligning the product.
zMake sure to remove the depth alignment brackets before fixing theappliance inside
the cabinetry.
zOpen the appliance door to remove the alignment brackets from both sides of the
appliance, and then re-tighten the screws.
Door panel installation
Stainless steel
zProtect the finish of the Fisher & Paykel Stainless Steel door panels from any
scratch or damage.
zLeave the protective film on the panels when hanging and remove the film only when the
installation is complete.
Custom
zIf using Custom door panels, ensure they are prepared as per 'Custom door panel
dimensions' section.
zEnsure the screw pilot holes do not penetrate the full depth of the panel.
zDo not place the handle holes in marked areas to avoid clashing with panel
attachment brackets.
zMinimum panel thickness where screw hole is drilled must be 16mm.
Door hinge change
zDoor hinges are interchangeable for each model. A hinge change kit is available
and can be purchased separately if you prefer to change from ‘right hand hinge’ to
‘left hand hinge’ or vise versa.
RS2484VL2K1
RS2484VR2K1

6
Installation kit (Internal box)
Supplied with appliance
Door panel attachmentkit
Side bracket
(6)
Bracket slider
(6)
Side spacer bracket
(6)
For SS door panels:
8Gx16 Mush washer screw (30)
For Custom door panels:
M5x12 Cross-head screw (30)
Install fasteners kit
Depth alignment gauge
(4)
Barbed plug
(2)
8Gx16 Countersunk screw
(7)
Anti-tip bracket assemblykit
Anti-tip bracket
(1)
Masonry plug
(4)
10-12x35mm cross-head screw
(5)
Miscellaneous components
Hinge limiting pin
(3)
Air toe kick seal
(1)
Flow divider cap
(1)
Locking clip
(2)
COMPONENTS

7
Miscellaneous items (MI) pack
Supplied with appliance
USERGUIDE
USCA NZ AU GB IE SG HK
8602A09.19
INTEGRATED COLUMN
WINE CABINET
RS2484VL2K1, RS2484VR2K1,
RS6121VL2K1, RS6121VR2K1
models
SERVICE& WARRANTY
SERVICEET GARANTIE
ΣΈΡΒΙΣΚΑΙ ΕΓΓΎΗΣΗ
SERVIZIOE GARANZIA
SERVICE& GARANTIE
HUOLTOJA TAKUU
SERVICEOG GARANTI
保修和维修
݉ଡ଼ڸߴঔ
INTEGRATED COLUMNS
WINE CABINET
RS2484VL2K1, RS2484VR2K1,
RS6121VL2K1, RS6121VR2K1
models
INSTALLATIONGUIDE
USCA NZ AU GB IE SG HK
86020A09.19
User guide
(1)
Service & Warranty
(1)
Installation guide
(1)
Air carbon filters
#862755
(2)
Install parts (External box)
Supplied with appliance
Door panel side extrusion
(2)
Cabinet side trim assembly
(1)
Long glass trim (2) Short glass trim (2)
Toe kick install kit
Not supplied and must be purchased separately
Toe kick
(1)
OStandard toe kick height is 102mm forstandard stainless steel door panel.
OFor Custom door panel installation, atoe kick 2"–6" (50-152mm) must be fitted
andadjusted accordingly.
OAn extra bottom grille is required for a2" (50mm) toe kick installation. You can purchase
the extra bottom grille (Part No. 847542P) online at fisherpaykel.com.
Top grille assembly
Top (fixed) grille
(1)
Hinge change kit (Optional)
Not supplied and must be purchased separately
MODEL LEFT HINGE TO RIGHT HINGE RIGHT HINGE TO LEFT HINGE
RS61 848188 848187
Each kit includes: Hinge change assembly (1x), Top (fixed) grille assembly (1x)
Hinge change assembly
Hinge top
pocket RH (2)
Hinge top
pocket LH (2)
K05 top adaptor
bracket RH (1)
K05 top adaptor
bracket LH (1)
Bottom adaptor
bracket RH (1)
Bottom adaptor
bracket LH (1)
Bottom hinge
bracket RH(1)
Bottom hinge
bracket LH (1)
COMPONENTS

8
Door panel set
Not supplied and must be purchased separately
Stainless steel door panel set:
(Fisher & Paykel)
Custom door panel set:
Supplied by customers to match their cabinetry.
Custom Door Panel must leave glass pane visible.
A full custom panel sheathing over the glass pane
does not meet the specifications of this appliance.
Door handle set
Not supplied and must be purchased separately. Select between the options below:
Professional round
handle kit (CA:24980)
Professional square
handle kit (CA:24982)
Contemporary round
handle kit (CA:24981)
Contemporary square
handle kit (CA:24979)
Professional round
door handle (1)
Professional square
door handle (1)
Contemporary round
door handle (1)
Contemporary square
door handle (1)
M5x25 Hex screw
(4)
M5x25 Hex screw
(4)
M5x25 Hex screw
(4)
M5x25 Hex screw
(4)
DOOR PANEL AND HANDLE SETS

9
TOOLSWINE DISPLAY ACCESSORIES
2x 1x
Handle assembly (1)
Cradle assembly (4)
Spacer (1)
Required tools
Not supplied
Powered driver Flathead screwdriver Ruler
Hacksaw Cross-head screwdriver Pencil
Cutter T2 star-head screwdriver Hand truck
Supplied tools
Included in installation kit
Spanner 13mm
(1)
Hex key
(1)
IMPORTANT!
Wine display accessories are not supplied with the appliance. A wine display kit and a label
kit are sold separately and can be purchased online at fisherpaykel.com.
Wine display kit
Label (14) Pencil (1)
Wine label kit

10
APPLIANCE DIMENSIONS
A
B
C
PRODUCT DIMENSIONS INCHES MM
AOverall height of product 84" 2134
BOverall width of product 233/4" 603
COverall depth of product (excluding front door panel) 24" 610
Weight (including packaging) 380lbs 172kg

11
CAVITY DIMENSIONS
A
B
C
CAVITY DIMENSIONS INCHES MM
AOverall height of cavity 84" 2134
bOverall width of cavity 24" 610
cOverall depth* (including door panel) if power plug is located in adjacent cabinet 25" 635
Overall depth* (including door panel) if power plug is located behind appliance 25 9/16" 650
* Cavity depth assumes door panel thickness of 19mm.

12
CAVITY DIMENSIONS
Frameless Cabinetry
Aligns appliance flush with the cabinetry
Framed Cabinetry
Aligns appliance flush with the frame of cabinetry
CAVITY DIMENSIONS INCHES MM
AMinimum required finished return (cavity sides and top) 4" 102
bMinimum cabinetry gap clearance from edge of door panels 1/8" 3
B
A
B
A

13
STAINLESS STEEL/CUSTOM DOOR PANEL
A
C
B
DOOR PANEL DIMENSIONS (STAINLESS STEEL) INCHES MM
AHeight of door panel 79 7/8" 2029
BWidth of door panel 23 3/4" 603
CDepth of door panel (excluding door handle) 3/4" (19)
DOOR PANEL DIMENSIONS (CUSTOM)*
AHeight of door panel 77 7/8"–81 7/8" 1978–2080
BWidth of door panel 23 3/4" 603
CDepth of door panel min 5/8"–max 1" 16–25
DOOR PANEL WEIGHT LB (KG)
Maximum weight of Stainless steel/Custom door panel
(including handle/brackets)† 55lb (25kg)
† Door handle kit is available as an optional accessory for both Stainless Steel door panels and Custom door panels and
must be purchased separately.
DOOR PANEL DIMENSIONS

14
TOE KICK PANEL DIMENSIONS
Standard toe kick height is 4" (102mm)
with Stainless steel door panel
2" (50mm) toe kick height*
(with extra lower grille attached)
27/8"–4" (73–102mm) toe kick depth
measured from from rearof door panel
6" (152mm) toe kick
height**
A
B
C
TOE KICK DIMENSIONS INCHES MM
AWidth of toe kick
Stainless steel panel/Custom panel 23 7/8" 607
BHeight of toe kick#
Stainless steel panel 4" 102
Custom panel** 2"– 6" 50–152
CDepth of toe kick (measured from front of door)
Stainless steel panel/Custom panel 27/8"–4" 73–102
#Standard toe kick height is 4" (102mm) with the optional Stainless door panel. For Custom door panel installation, a custom toe kick 2–6" (50–152mm) can be
manufactured and fitted by cabinetmaker. The Custom door panel height needs to be adjusted accordingly.
** Extra bottom grilles are required for a 2" (50mm) toe kick installation. You can purchase the extra bottom grille (Part No. 847542P) online at fisherpaykel.com.

15
CUSTOM DOOR PANEL DIMENSIONS
Custom door panel dimensions
Dimensions apply for the preparation
and installation of Custom door panels.
For Dwg and Dxf files of the below
panel preparation download the folder
on thekitchentools.fisherpaykel.com.
IMPORTANT!
zThe thickness of the custom door
panel can vary as long as the screws
do not penetrate beyond the full
depth of the door panel, and as long
as the overall weight of the panel
does not exceed 55lb/25kg.
zMeasurements of screw hole
locations can vary depending on the
height of toe kick 2–6"/50–152mm.
23 3/4" (603mm)
1 5/16" (33mm)
2" (50mm) 2" (50mm) 2’ (50mm) 2" (50mm)
79 7/8" (2029mm)
70" (1778mm)
50 3/16 (1274mm)
19 3/4" (502mm)
5" (127mm)
Do not place handle holes in
marked areas to avoid clashing
with panel attachment brackets
2" (51mm)
8" (203mm)
11 7/8" (302mm)
2 3/8" (60mm)
13/16" (20mm)
3 9/16" (90mm)
7/8" (22mm) x Ø1/16" (Ø2mm)
16 5/16" (415mm)
62 9/16 (1589mm)
7 7/8" (200mm)
For 6" toe kick, make door
length 2" shorter
For 2" toe kick, make door
length 2" longer

16
DOOR CLEARANCE
CLEARANCE DIMENSIONS INCHES MM
ADepth of door (90° open) measured from front of door 26" 660
bMinimum door clearance* to adjacent wall (115°—full internal access) 14" 356
cMinimum door clearance* to adjacent wall (90°—reduced internal access) 4 5/16" 110
DMinimum cabinetry gap clearance from edge of door panels 1/8" 3
Note: Door clearance measured from front cabinetry edge.
A
B
Wall
D
Wall
A
C
Insert hinge limiting pin (supplied)
to limit door swing to 90°.
IMPORTANT!
Ensure the appliance is stable before opening the door.
115° DOOR OPENING
(FULL INTERNAL ACCESS)
90° DOOR OPENING
IMPORTANT!
zEnsure the hinge limiting pin
is inserted before pushing the
appliance into the cabinetry.
zThe pin fits in the boreholes
of the top hinge.

17
ELECTRICAL DIMENSIONS
WARNING!
zElectric shock hazard! Assume all parts live.
zDisconnect power supply before servicing and installation.
Floor
Electrical connection must be within this space if located behind the
appliance and must not protrude from the back wall.
REAR OF CAVITY
C
B
1
1
2
D
C
A
ELECTRICAL DIMENSIONS INCHES MM
AOverall height of supply area 9" 229
BOverall depth of supply area 1" 25
CWidth of notch in supply area (both sides) 1/2" 13
DHeight of sides of supply area (both sides) 5" 127
Note: Dimensions are based on minimum depth of cavity.
ELECTRICAL AND PLUMBING CONNECTIONS
1Recommended location for connections in adjacent area or unit
2Alternative location for connections at rear of cavity

18
ELECTRICAL SPECIFICATIONS
Power cord (excluding plug)Power cord (excluding plug)
AB
ELECTRICAL SPECIFICATIONS
Supply 115 VAC, 60 Hz
Service 10 amp circuit
Socket 3-prong grounding-type
Power cord (total length) 2000mm
MAXIMUM DISTANCE OF POWER CORD AND WATER HOSE INCHES MM
aPower cord length from left side edge of appliance (excluding plug) 71 1/4 1809
bPower cord length from right side edge of appliance (excluding plug) 72 1/4 1835

19
BEFORE INSTALLATION
Follow the steps below to move your appliance to installation location. Be careful when tilting the appliance forward/backward.
Remove external box.
1
Move your appliance
Check your appliance
Remove brackets from one side of pallet.
3Tilt slightly forward and Insert hand truck.
Hand truck
4Restrain with strap and remove remaining brackets.
Strap
5Tilt backward to load appliance onto hand truck.
6
IMPORTANT!
zEnsure that your appliance is the
correct model as per your order.
zCheck that the components and
install kits are complete.
zKeep the detached parts to
reinstall later.
zair flow divider
ztop door panel extrusion
ztop trim
ztoe kick mounting plate
ztop grille
zbottom grille
Installation kit
Air flow divider
INTEGRATEDCOLUMNS
RS4621F,RS6121F,RS7621F,
RS6121S&RS7621S models
INSTALLATIONGUIDE
NZAUGBEU
849164B 10.18
Miscellaneous items
(MI) pack
Top door panel
extrusion
Top grille
Top trim
Bottom grille
Toe kick mounting plate
2Remove installation kit, MI pack and pre-installed parts.
Keep all components to use later.

20
Check the installation location
Check the cabinetry
zCheck the dimensions of the cabinetry: height, width, depth, floor level, finished
alcove returns.
Check the power supply connection
zEnsure that there is a separate power socket for each appliance.
zAvoid sharing the power point with other appliances to prevent accidental switching off
of the appliance.
zFor power requirements, refer to the information on the serial plate.
zEnsure your appliance is properly grounded (earthed).
zConnect your appliance to an electrical supply with the fitted plug and lead.
zIf power connection is located behind the appliance, we recommend to install an isolating
switch to a location that is easily accessible to the user for repair or disconnection.
zFollow local codes and ordinances when installing the appliance.
BEFORE INSTALLATION
