Flash Furniture UL-A074-RD-GG User manual

Office Computer Chair
Adjustable Ergonomic
Swivel Gaming Chair
Customer Service Email: [email protected] | Phone: [phone]
UL-A074-RD-GG
ASSEMBLY INSTRUCTIONS
Before You Begin:
Please identify all component parts and hardware pieces required before you begin. Carefully remove all of the
components from the packaging and set aside for assembly. Assemble on a soft surface to prevent scratching
during assembly.
Caution:
Tighten all components securely before use. Failure to do so may result in personal injury.
DO NOT use any sharp objects to open plastic wrapped components as damage to product or components may
result.
Warning:
CHOKING HAZARD - Small Parts. Adult Assembly Required.
DO NOT ALLOW CHILDREN TO CLIMB ON FURNITURE
Serious or fatal injuries can occur from furniture tipping over. You must install Tipping Restraint Hardware (where
included) to help prevent the unit from tipping and causing accidental injury, instability, death or damage. The
tipping restraint is intended only as a safety measure, it is not a substitute for proper adult supervision.
To help prevent furniture from tipping over it must be permanently attached to the wall. Anti-Tip Safety Wall
Straps suitable for the unit weight and wall materials (if not included) should be purchased and installed.

Have a Question/Concern?
Quality products and first-class customer service are the cornerstone of long-
lasting consumer relationships. We strive toward excellence in all we do and
want you to be completely satisfied with your purchase.
Please contact our exceptional Customer Experience Agents at the email
address or phone number shown below to assist you with any product
questions or issues before requesting a return.
We look forward to serving you in a friendly, efficient manner to resolve any
issues you may have.
Customer Service Email: [e-mail]
Customer Service Phone: [phone]
Our Warranty Statement
This warranty covers manufacturing defects associated with your new product. The product
is warranted from the original purchase date and to the original purchaser for normal usage,
according to the below-referenced specifications and limitations.
Non-moving metal parts are warranted for 5 years.
Component parts including pneumatic cylinder, control mechanism, base and casters
are warranted for 2 years.
All other items are warranted for 1 year.
Normal usage means use in compliance with the restrictions and weight limits specified for
the product. In the absence of product-specific restrictions and weight limits, normal usage
means use for no more than forty hours per week by persons weighing 250 lbs. or less.
Coverage terminates if the product is sold or otherwise transferred. Repairs made by
parties other than Belnick also void this warranty.
This warranty will not cover: (1) labor, freight, or damage from misuse, abuse, negligence,
alteration, assembly, installation, attachments, accident, vandalism, acts of nature or any
other event beyond the control of Belnick; (2) tearing, scratching, scuffing, or blemishing of
leather or fabric; (3) cosmetic damage that may result from normal usage; (4) damage
attributable to use by persons exceeding specified weight limits or commercial use
exceeding forty hours per week; or (5) rust or other damage caused by exposure to
moisture. The user assumes all risk of injury resulting from use of this product. Liability for
incidental or consequential damage is excluded. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation or exclusion may
not apply to you.

Screw Caps Allen Wrench
STEP 1: Turn Base Center (Part 3) upside
down and insert (5) Base Arms (Part 3B)
into the base center. Attach arms to the
center using (10) M6x10mm screws.
Tighten with Allen Wrench (Part 14).
Base Center
Base Arms
STEP 2: Insert (5) Casters (Part 8) into the base arms and return assembled base
to the upright position. Insert the wide end of the Gas Lift (Part 5) into the base
center. Slide the Gas Lift Cover (Part 7) downwards over the Gas Lift.
Gas Lift Cover
Gas Lift
Caster
Base
Center
Base Arms
Allen Wrench
M6x10mm Screws
STEP 3: Lay the Seat (Part 2) face down
on a smooth clean surface. Attach the
Control Unit (Part 6) to the underside
of the Seat using (4) M6x18mm
Washers and (4) M6x20mm Screws.
Tighten with Allen Wrench (Part 14).
M6x20mm Screws
Allen Wrench
M6x18mm Washers
Seat
Control Unit
STEP 4A: Place the Control
Unit onto the Gas Lift and
press down to seat.
STEP 4B: Attach the lower
Armrests (Part 4) to the Seat
using (4) M6x25mm Screws.
Tighten loosely with Allen
Wrench (Part 14).
Armrests
M6x25mm Screws Allen Wrench
NOTE: DO NOT
TIGHTEN SCREWS
COMPLETELY
STEP 8: Using (4)
M6x25mm Screws,
attach Backrest (Part 1)
to Armrests. Securely
tighten all Screws.
Backrest
M6x25mm
Bolt
STEP 6: Cover Screws
with (8) Screw Caps
(Part 13).
Screw Caps
Screw Caps
