Flash Furniture BR-DDIA-3058-GG User manual

Customer Service Email:[email protected] | Phone:[phone]
BR-DDIA-3058-GG/BR-DDIA-4558-GG/BR-DDIA-30119-GG/BR-DDIA-45119-GG
BR-DDIA-30139-GG/BR-DDIA-45139-GG/BR-DDIA-30152-GG/BR-DDIA-45152-GG
ASSEMBLY INSTRUCTIONS
Before YouB :egin
Please identify all component parts and hardware pieces required before you begin. Carefully remove all of the
components from the packaging and set aside for assembly. Assemble on a soft surface to prevent scratching
during assembly.
Caution:
Tighten all components securely before use. Failure to do so may result in personal injury.
DO NOT use any sharp objects to open plastic wrapped components as damage to product or components may
result.
Warning:
CHOKING HAZARD - Small Parts. Adult Assembly Required.
DO NOT ALLOW CHILDREN TO CLIMB ON FURNITURE
Serious or fatal injuries can occur from furniture tipping over. You must install Tipping Restraint Hardware (where
included) to help prevent the unit from tipping and causing accidental injury, instability, death or damage. The
tipping restraint is intended only as a safety measure, it is not a substitute for proper adult supervision.
To help prevent furniture from tipping over it must be permanently attached to the wall. Anti-Tip Safety Wall
Straps suitable for the unit weight and wall materials (if not included) should be purchased and installed.
Online Assembly Instructions: http://ftp.flashfurniture.com/AssemblyInstructions/BR-DDIA-45152-GG.pdf

Have a Question/Concern?
Quality products and first-class customer service are the cornerstone of long-
lasting consumer relationships. We strive toward excellence in all we do and
want you to be completely satisfied with your purchase.
Please contact our exceptional Customer Experience Agents at the email
address or phone number shown below to assist you with any product
questions or issues before requesting a return.
We look forward to serving you in a friendly, efficient manner to resolve any
issues you may have.
Customer Service Email: [e-mail]
Customer Service Phone: [phone]
Our Warranty Statement
This warranty covers manufacturing defects associated with your new product. The product is
warranted from the original purchase date and to the original purchaser for normal usage,
according to the below-referenced specifications and limitations.
•Non-moving metal parts are warranted for 5 years.
•Component parts including pneumatic cylinder, control mechanism, base and casters
are warranted for 2 years.
•All other items are warranted for 1 year.
Normal usage means use in compliance with the restrictions and weight limits specified for the
product. In the absence of product-specific restrictions and weight limits, normal usage means
use for no more than forty hours per week by persons weighing 250 lbs. or less. Coverage
terminates if the product is sold or otherwise transferred. Repairs made by parties other than
Belnick also void this warranty.
This warranty will not cover: (1) labor, freight, or damage from misuse, abuse, negligence,
alteration, assembly, installation, attachments, accident, vandalism, acts of nature or any other
event beyond the control of Belnick; (2) tearing, scratching, scuffing, or blemishing of leather or
fabric; (3) cosmetic damage that may result from normal usage; (4) damage attributable to use
by persons exceeding specified weight limits or commercial use exceeding forty hours per
week; or (5) rust or other damage caused by exposure to moisture. The user assumes all risk of
injury resulting from use of this product. Liability for incidental or consequential damage is
excluded. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.

X1 X2 X4 X2 X2
X1 X2
X1
Product Installation
STEP 1: Insert Tension Knob (Part E) into
underside of Mounting Bracket (Part B) and
attach Tension Cup Assembly (Part F) using
Phillips Screwdriver (Part H)
Table top
Table top
Acrylic Partition
A Acrylic Partition
B Mounting Bracket C Partition Grips D Allen Wrench
E Tension Knob
F Tension Cup
Assembly
G Mounting
Bracket Screw
E Tension Knob
H Phillips
Screwdriver
Tension Knob
E
Tension Cup Assembly
F
B Mounting Bracket
H Philips Screwdriver
STEP 2: Pull apart two halves of Mounting Bracket
(Part B) and insert Partition Grips (Part C). Insert
Mounting Bracket Screw (Part G) but do not tighten
completely.
Partition Grips
C G
Mounting Bracket Screw
STEP 3: Fit Mounting Brackets (Part B) to the edge of the table
top and turn Tension Knob clockwise to tighten.
STEP 3: Fit Acrylic Partition (Part A) into the Mounting Brackets then tighten
Mounting Bracket Screws using Allen Wrench (Part D).
A
D Allen Wrench
