Flash Furniture TLH-007-TAN-GG User manual

Online Assembly Instructions: http://ftp.flashfurniture.com/AssemblyInstructions/TLH-007-TAN-GG.pdf
TLH-007-BK-GG / TLH-007-TAN-GG / TLH-007-MRN-GG

Have a Question/Concern?
Quality products and first-class customer service are the cornerstone of long-
lasting consumer relationships. We strive toward excellence in all we do and
want you to be completely satisfied with your purchase.
Please contact our exceptional Customer Experience Agents at the email
address or phone number shown below to assist you with any product
questions or issues before requesting a return.
We look forward to serving you in a friendly, efficient manner to resolve any
issues you may have.
Customer Service Email: [e-mail]
Customer Service Phone: [phone]
Our Warranty Statement
This warranty covers manufacturing defects associated with your new product. The product is
warranted from the original purchase date and to the original purchaser for normal usage,
according to the below-referenced specifications and limitations.
•Non-moving metal parts are warranted for 5 years.
•Component parts including pneumatic cylinder, control mechanism, base and casters
are warranted for 2 years.
•All other items are warranted for 1 year.
Normal usage means use in compliance with the restrictions and weight limits specified for the
product. In the absence of product-specific restrictions and weight limits, normal usage means
use for no more than forty hours per week by persons weighing 250 lbs. or less. Coverage
terminates if the product is sold or otherwise transferred. Repairs made by parties other than
Belnick also void this warranty.
This warranty will not cover: (1) labor, freight, or damage from misuse, abuse, negligence,
alteration, assembly, installation, attachments, accident, vandalism, acts of nature or any other
event beyond the control of Belnick; (2) tearing, scratching, scuffing, or blemishing of leather or
fabric; (3) cosmetic damage that may result from normal usage; (4) damage attributable to use
by persons exceeding specified weight limits or commercial use exceeding forty hours per
week; or (5) rust or other damage caused by exposure to moisture. The user assumes all risk of
injury resulting from use of this product. Liability for incidental or consequential damage is
excluded. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.

Left Side Top Frame Post Right Side Top Frame Post
Front Legs
Back Legs
Left & Right Leg Bottom Braces Left Side Upper Stabilizing Bar Right Side Upper Stabilizing Bar
Left Side Lower Stabilizing Bar Right Side Lower Stabilizing Bar Swing Attachment Bars
Left & Right Arms
Front Seat Attachment Bar
Swing Seat Fabric Canopy
Left & Right Canopy Frame
Seat
Cushions
Rear Seat Bracket Note: Install
with open side facing outward
Swing Attachment Springs Bolt/Nut/Cap To Attach
Legs To Upper Frame Posts Front Seat Attachment Bar Bolts
Bolt/Nut/Cap For Swing
Attachment Bars
Bolt/Nut/Cap For Upper Stabilizing
Bar, Left & Right Bottom Leg Braces
& Left & Right Side Top Frame Posts
Bolt and Wing Nut Set for Left
and Right Side Upper Seat
Back Attachment to Arms
Bolt/Nut/Cap for Rear Seat
Bracket
Bolt/Nut/Cap for Left and Right
Side Lower Seat Back
Attachment to Arms
Bolt/Nut/Cap To Attach Left & Right
Upper Stabilizing Bar &To Attach Left
& Right Lower Stabilizing Bar To Legs
Bolt/Nut/Cap for Left & Right Lower
Stabilizing Bar
Canopy Tilt Tension KnobS
Spacer for Lower Seat Back
Attachment To Arms

STEP 1: Attach Left Side Top Frame
Post (Part A) to Right Side Top Frame
Post (Part B) using (2) M6x55mm Bolt/
Nut/Cap Sets (Part 6)
STEP 2A: Attach Left & Right Front Legs (Part C) and Left & Right Rear Legs (Part D) to
Top Frame using (8) M8x105mm Bolt/Nut/Cap Sets (Part 2).
STEP 2B: Attach Left & Right Bottom
Braces (Part E) to Front & Rear Legs
using (4) M6x55mm Bolt/Nut/Cap Sets
(Part 6)
STEP 3A: Attach Left Side Upper Stabilizing
Bar (Part F) to Right Side Upper Stabilizing
Bar (Part G) using (1) M6x30mm Bolt/Nut/Cap
Set (Part 10) STEP 3B: Attach Upper Stabilizing Bar to
Rear Legs using (4) M6x60mm Bolt/Nut/Cap
Sets (Part 7)
STEP 3C: Attach Left Side Lower Stabilizing
Bar (Part H) to Right Side Lower Stabilizing
Bar (Part I) using (1) M6x30mm Bolt/Nut/Cap
Set (Part 10)
STEP 3D: Attach Lower
Stabilizing Bar to Left & Right
Side Braces using (2) M6x30mm
Bolt/Nut/Cap Sets (Part 10)
STEP 5: Attach Swing Attachment Springs
(Part 1) to Left and Right Swing Attachment
Bars then hang on Left & Right Top Frame
Posts
STEP 4C: Attach Swing Attachment
Bars (Parts J & J1) to Left & Right Swing
Arms using (4) M6x35mm Bolt/Nut/Cap
Sets (Part 9)STEP 4D: Attach Rear Seat Bracket (Part Q) to
Upper Seat Back using (1) M6x45mm Bolt/Nut/
Cap Set (Part 7) Note: Attach Facing Outward
STEP 4A: Attach Front Seat
Attachment Bar (Part L) to Left & Right
Arms using (2) M8x40mm Front Bar
Attachment Bolts (Part 3) STEP 4B: Attach Upper Seat Frame to Left & Right
Upper Arms using (2) M6x75mm Bolt and Wing Nut
Set (Part 5). Attach Lower Seat Frame to Lower Arms
using (2) M6x75mm Bolt/Nut/Cap Sets (Part 4) and (2)
Spacers (Part 13)
STEP 6: STEP 6: Attach Left & Right Canopy Frames (Part O)
Attach Left & Right Canopy Frames (Part O)
using (2) Canopy Tilt Tension Knobs (Part 13)using (2) Canopy Tilt Tension Knobs (Part 12)

STEP 7: Attach Fabric Canopy
to Left & Right Canopy Frames
using Attached Hook and Loop
Fasteners
STEP 8: Position Seat and Back Cushions (Part P)
STEP 9 (When Reclined):
Insert Locking Pin (Part 11)
through Rear Seat Bracket Holes
and Fasten Closed. Remove to
return seat back to the upright
position
LOOSEN CANOPY TENSION KNOBS TO ADJUST THE AMOUNT OF
TILT. TIGHTEN WHEN PREFERRED ANGLE IS ACHIEVED
