Flash Technology OL2A User manual

OL2A
USER MANUAL
©2019 Flash Technology, LLC
Technical Support:
Email:
[e-mail]
Toll Free:
1.800.821.5825
Fax:
1.615.261.2600
Web:
flashtechnology.com/obstruction
70951 Rev C OL2A Manual

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 2
Contents
Regulatory Information .............................................................................................................................................. 3
Safety and Usage Precautions .................................................................................................................................. 3
1. Introduction ...................................................................................................................................................... 3
2. Applications...................................................................................................................................................... 3
3. Installation ........................................................................................................................................................ 3
3.1 2-Hole Flange Mount...................................................................................................................................... 4
3.2 Pole Mount ..................................................................................................................................................... 5
4. Operation .......................................................................................................................................................... 6
4.1 Programming .................................................................................................................................................. 6
4.2 Setting the Flash............................................................................................................................................. 7
4.3 Setting the Intensity........................................................................................................................................ 7
4.4 Turning On/Off................................................................................................................................................ 7
4.5 Checking Battery State of Charge (SOC)....................................................................................................... 8
4.6 Automatic Light Control (ALC)........................................................................................................................ 8
4.7 Battery Charging............................................................................................................................................. 8
4.8 Battery Installation .......................................................................................................................................... 8
4.9 Storage ........................................................................................................................................................... 9
4.10 Troubleshooting.............................................................................................................................................. 9
5. Specifications................................................................................................................................................. 10
6. Flash Codes.................................................................................................................................................... 13
7. Maintenance ................................................................................................................................................... 14
8. Recycling ........................................................................................................................................................ 14
9. Warranty.......................................................................................................................................................... 14

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 3
Regulatory Information
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment. Installation work must be done by a qualified person(s) in accordance with all
applicable local codes and standards.
Safety and Usage Precautions
The lantern's Battery Pack contains lead, lead compounds, and other compounds known to the State of
California to cause cancer and reproductive harm. Please handle with care and wash your hands
thoroughly after handling the Battery Pack.
Charge your lantern's Battery Pack periodically. Permanent damage and reduced capacity will result if
the Battery Pack is not correctly maintained. Refer to Battery Charging on page 8 for details.
Lanterns that have been stored may require a top-up charge before they are put into service. The most
accurate Battery Pack status reading is obtained when the lantern has been in a dark location and in Off
mode for at least 24 hours.
1. Introduction
The OL2A solar hazard marker is:
•Self-contained and solar-powered
•Easy-to-install and low-maintenance with a long-life LED
•Available in red, green, white, yellow and blue
•Easy-to-maintain with replaceable AA NiMH batteries
2-Hole Flange Mount
Pole Mount
Nominal range of a lantern depends on its effective intensity and environmental conditions. For details on how to
calculate range, contact your sales representative.
2. Applications
The OL2A is suitable for ground marking, way finding, perimeter marking and other applications where a hazard
marking light is required.
3. Installation
Year-round, unrestricted solar exposure is critical to long-term performance. Shade dramatically reduces the ability
of the light to charge its battery.
The OL2A has changeable mounts. Either ensure the 2-hole flange or pole mount is attached before lantern
installation.

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 4
3.1 2-Hole Flange Mount
When attaching the 2-hole flange mount, the first 2 steps are handled by manufacturing. Steps 3-5 apply
when a distributor or customer is changing the batteries.
1. Use the alignment keys to align the top cover and flange mount. Press together.
2. Attach the mount to the top cover using the provided 3 screws. Do not over tighten!
3. Apply a thin coat of silicone lubricant to the bottom cover o-ring.
4. Align the bottom cover and press into the top cover. It only fits one way.
5. Secure the bottom cover with the provided 3 screws. Do not over tighten!
Up to four bird deterrents can be installed:
1. Insert the provided screw through the bird deterrent.
2. Drive the screw into one of the four small holes on the top of the mount. Do not over tighten!
3. Bend the bird deterrent as required.

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 5
To install the lantern:
Fix in place with 2x bolts, studs and nuts, nails or screws. Recommended bolt size is 1/4-20 UNC or M6.
3.2 Pole Mount
Install the pole mount:
1. Apply a thin coating of silicone lubricant to the pole-mount o-ring.
2. Use the alignment keys (show on right below) to align the top cover and pole mount.
3. Attach the mount to the top cover using the provided 6 screws. Do not over tighten!
Alignment Keys
Up to 6 bird deterrents can be installed:
1. Insert a mounting screw through the bird deterrent
2. Install the screw. Do not over tighten!
3. Bend bird deterrent as needed

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 6
Install the lantern:
1. If required, insert the reducing sleeve into the pole mount. Note that it aligns only one way.
2. Slide the lantern and sleeve over the pole; press down to ensure lantern is well seated.
3. Secure with the provided 3 screws; if required, drill 1/8 - 9/64 in. [3.2 - 3.6 mm] pilot holes and then install
the screws.
4. Operation
The solar panel charges the battery in daylight using the Energy Management System (EMS). The capacity of the
battery ensures that even with poor levels of sunlight over an extended period, the lantern has enough reserve
power to continue to perform reliably. Stored battery energy then powers the LED during the night.
The change from night-to-day or day-to-night is called a transition. To avoid false transitions and ensure stable
operation, the transition time is 2 minutes. For example, 2 minutes of darkness is needed for the lantern to switch to
night operation.
4.1 Programming
The OL2A is configured using the IR programmer. The lantern’s mating IR receiver is on an energy-saving sleep
cycle.
Press and hold for 2 seconds to awaken the IR receiver and begin communication with the lantern:
The lantern is now ready to accept programming. Note that the lantern will quickly flash after every key it receives.
All programming codes follow the same sequence:
3 quick flashes
Command accepted
2 slow flashes
Command rejected
The number symbol # represents 0 - 9. Commands can be rejected if they are unsupported, contain an incorrect
key sequence or have an effective intensity too high for the programmed flash code.

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 7
4.2 Setting the Flash
To set the flash pattern, enter its flash code using the IR programmer. See the Flash Codes on page 13 for details.
Example: Enter
For quick flash Q 1s 0.3 (flash code 129)
4.3 Setting the Intensity
The OL2A is programmed using effective intensity. Effective intensity is the brightness of a flashing light as
perceived by the human eye (as opposed to peak intensity, which is the actual intensity of a light during a flash).
Effective intensity is calculated using the following equation:
Effective Intensity (cd) =
Peak Intensity (cd) x Flash Duration (sec)
0.2 (sec) + Flash Duration (sec)
The OL2A makes this calculation automatically based on your programmed flash code and effective intensity
selected. Note that for a fixed/steady-burning light (code 001), effective intensity equals peak intensity. The range
of intensity codes are:
600 0.1-0.4 effective candela
601 1 effective candela
602 2 effective candela
6## Maximum values vary by flash code and LED color
Example: Enter
For intensity of 5 effective candela
Product performance varies by installation location. Contact your sales representative for further
details.
4.4 Turning On/Off
In “on” mode, the OL2A LED turns on at night and off during the day. The lantern charges in sunlight, but the LED
remains off when in “off” mode. When turned on again, the lantern activates at its last programmed settings (1
minute preview for daytime activations).
Option 1: Switched Models
Set the switch to on or off position
Option 2: IR Programmer
Point programmer at OL2A from a distance of one foot, press and hold for 4 seconds. The lantern LED will
brighten to on or fade to off to confirm your setting change.

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 8
4.5 Checking Battery State of Charge (SOC)
Using the IR programmer, enter: or
Good Battery
SOC >70%
Charge Battery
SOC 14-70%
Low Battery
SOC ≤14%, LVD Active
If the battery is ≤14%, Low Voltage Disconnect (LVD) disables the LED and attempts to charge the battery to a
sustainable SOC. The LED is re-enabled once SOC is >75%.
4.6 Automatic Light Control (ALC)
During periods of sustained poor solar charging, Automatic Light Control (ALC) may decrease LED intensity based
on battery SOC and recent charging trends. When solar charging returns to a sustainable level, ALC increases
intensity back to the user setting. ALC may be disabled to keep the lantern at a constant intensity.
Enable ALC:
Disable ALC:
4.7 Battery Charging
The batteries are best charged inside the lantern. The OL2A can recharge 0 V or 0% SOC batteries back to 100%
SOC:
Summer sunlight 8-12 hours
Winter sunlight 18-36 hours
60 W incandescent lamp 15-36 hours
A commercial charger designed for 1.2 V AA batteries can also be used.
Do not use a battery charger with >370 mA charge rate. High charge rates will overheat the batteries
and cause internal damage.
Take care when charging using a lamp. Provide air circulation or a fan so that the lantern and batteries
do not exceed maximum temperature.
4.8 Battery Installation
The OL2A comes with 3x AA industrial-grade, high-temperature NiMH batteries. The OL2A will only operate with all
3x batteries installed correctly. The lantern remembers its settings even when the batteries are removed.
Other rechargeable AA NiMH batteries will not void your warranty. Shock, vibration, temperature and
optical performance may be limited.

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 9
To install batteries:
1. Install batteries, noting their polarity.
2. Apply a thin coat of silicone lubricant to the large sealing o-ring.
3. Align top cover and assembly components; secure with the provided screws. Do not over tighten!
4.9 Storage
Turn the lantern off to store. In switched models, set the switch to the “off” position. To turn off using the IR
programmer, press and hold for 4 seconds.
If a lantern detects continuous darkness for 24 hours, like when it’s inside packaging for shipping or storage
purposes, it will disable the LED. Upon sensing light, it will enable the LED and continue normal operation.
Check the battery state of charge every 1-2 months and charge if required.
High-grade NiMH batteries shipped with the OL2A can be stored without any charging for up to 12 months
with no battery damage.
4.10Troubleshooting
LED is off during
the night
Batteries are low and lantern cannot turn on
Charge the lantern or replace the batteries
Batteries are low and LVD is active
•Confirm with code 810 using IR
programmer.
•Charge lantern or replace batteries.
•Decrease effective intensity to a
sustainable level.
Switch is off
Switch to on.
Night not yet detected
Wait for the lantern to detect 2 minutes of
consistent “dark”.
Nearby light source is illuminating the
lantern
Move away from light source, turn off
unneeded light or shield lanterns
Solar panel is not charging the battery well
during the day
Under bright sunlight, enter code 815 using
the IR programmer:
•1x flash= too low for charging
•2x flashes = solar panel is fine
No response to IR
programmer
Batteries are very low and lantern cannot
turn on
Charge the lantern or replace the batteries
Sunlight is obscuring IR signal
Move the IR programmer closer to the
lantern
Moisture inside
Condensation
Ensure the vent on the bottom cover is not
dirty or obstructed
Seal failure
•Ensure the bottom cover o-ring is dry
(no water) and lubricated.

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 10
•Ensure o-ring is not pinched and all
screws are fully installed.
•Ensure bottom cover is fully seated to
ensure O-ring seals properly
5. Specifications
Optical
29 cd peak intensity; see below
High-power LED, >100,000 hours lifetime
Red, green, white, yellow and blue chromaticity
Proprietary optical design
40 flash patterns
Divergence
>8° FWHM vertical divergence
Solar Panel
Best-in-class high-efficiency solar cells 0.6 W
Battery
3 AA high-temperature nickel-metal hydride (NiMH) batteries
1.2 V nominal each
-40 to 185 ºF (-40 to 85 ºC) ambient
5-year battery life; Replaceable and recyclable
Energy Management System
Intelligent, microprocessor EMS
Automatic Light Control (ALC)
2.0
When enabled, ALC adjusts output intensity in response to unusually low
amounts of sunlight to ensure continued operation
Programming
Programmable with optional IR programmer
Construction
Premium-grade UV-resistant, polycarbonate body and lens
Waterproof battery compartment with Gore® vent
Color indicator matches LED color
Temperature
-22 to 122 ºF (-30 to 50 ºC) optimal
-40 to 176 ºF (-40 to 80 ºC) maximum
Weight
Flange mount: 0.8 lbs (0.4 kg)
Pole mount: 0.9 lbs (0.4 kg)
Mounting
Flange or pole-mount options
Wind Loading
161 mph (72 m/s)
Ice Loading
0.03 psi (22 kg/m2)
Shock & Vibration
MIL-STD-202G
Compliance
RoHS - Restriction of Hazardous Substances Directive 2002/95/EC (RoHS)
CE - EN 60945, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3
FCC - Part 15 of the FCC Rules (see 15.109)
ICES - Class [B] digital apparatus complies with Canadian ICES-003
Ingress
EN 60529 IP 68 immersion, 24 hrs at 3’ (1 m)
MIL-STD-202G immersion & damp heat cycling
MIL-STD-810G rain & salt fog
Patents US and international patents apply

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 11
Peak Intensity
Color
Intensity
Red
18 cd
Green
23 cd
White
29 cd
Yellow
25 cd
Blue
8 cd
OL2A Red: Typical Performance
Flash Code 001: Steady-on Dusk-to-Dawn, 6 days autonomy min.
Effective Intensity
Intensity Code
Effective Intensity
Intensity Code
0.4 cd
600
2 cd
602
1 cd
601
3 cd
603

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 12
Dimensions
Flange Mount
Pole Mount
With sleeve: 1.9” (48 mm) pole ID
Without sleeve: 2.4” (61 mm) pole ID
Over-top mount: 2.8” (71 mm) pole OD

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 13
6. Flash Codes
Maximum effective intensity varies by flash code and color. “FL” is the flash duration (seconds) and “EC” is an
eclipse (seconds). Intensities are IALA values (10th percentile) over a 360° horizontal measurement.

OL2A
USER MANUAL
©2019 Flash Technology, LLC Page 14
7. Maintenance
Although the OL2A is maintenance-free, performance gains can be made. Clean with water and a soft sponge or
cloth. A mild, non-abrasive cleanser can be used for more stubborn residue. Clean more frequently during drier
months as dust accumulates more quickly. Check the exterior and o-rings for cracks and missing or broken
hardware.
8. Recycling
This product may contain substances that could be harmful to the environment or human health if improperly
handled at the product’s end of life. Check your local municipality for electronics recyclers.
The batteries are rechargeable nickel-metal hydride (NiMH). Consult your local laws for information on
recycling.
This product complies with the European Union’s requirements according to Directive 2002/96/EC on waste
electrical and electronic equipment (WEEE).
9. Warranty
This product is covered by the Flash Technology warranty. Visit solarobstructionlights.com for additional
information. Failure to comply with the use, storage, maintenance or installation instructions detailed in this manual
could void the warranty. Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Before contacting Flash Technology’s customer service department, please have the serial number of your light
available, a brief description of the problem and all details of installation and recharging efforts.
To contact Customer Service:
Mail: Flash Technology
332 Nichol Mill Lane
Franklin, TN 37067 USA
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Website: flashtechnology.com/obstruction
