Flepcher FLP-ZS9810 User manual

The ZS-9810 comes with a built-in 10 zone selector which can be expanded and deployed for functions that reach up to
a total of 300 zones. This unit ensures that even with paging duty in one zone, users can rest assured that unnecessary
interruption in other sectors of the building is not disrupted. This means paging in certain zones will not interrupt BGM at
other zones if not selected. Connection wise, the ZS-9810 boosts two flexible amplifier connections, one for BGM while
the other amplifier for EMC / Paging usage.
FLP-ZS-9810
10-Channel Uninterrupted Zone Selector
• The power capacity for one zone is 500W, making it
5000W for all 10 zones.
• 10 zone speaker output terminals.
• Volume control over Mic 1-2
• All zone alarm in (A/B 2 channels) and all zone alarm
output (A/B 2 channels).
• Microphone 1-2 inputs, line 1-2 inputs, audio output.
Product Features
Input
Output
Frequency Response
S/N Ratio
Controls
Indicators
Protection
Power Supply
Power Consumption
Communication Protocol
Communication Input
Communication Speed
Weight
Dimension (W x D x H)
Material & Finish
Specifications
Portable Sound System Mixer Amp/ Pre Amp/ Power Amp Paging Microphone
& Zone selector Rack mount equipment
Mic 1,2: 600Ω, 5mV, unbalanced
Line 1,2: 10kΩ, 775mV, unbalanced
80dB
Mic: 100Hz~15kHz; Line: 30Hz~18kHz
Mic input: 60dB; Line input: 80dB
Mic 1,2 gain controls, 10 channel selectors, chime button, power switch
Power LED, 10 paging channel LEDs
AC fuse, 1A
~110V/60Hz or ~230V/50Hz or DC24V
40W
RS422
RJ45
4800bps
4.6 kg
484mm x 350mm x 88mm
Panel: aluminium plate, black
Case: steel plate, black
RJ45
Communication
Port
Alarm in
Alarm out
Line input
Connect to
paging amp
Speaker output zone
Connect to
Page/Alarm AMP
Connect to
BGM AMP
• 3 levels of input priority from high to low: EMC,
Microphone 1, remote paging console (Equivalent priority
to built-in chime).
• Indicators for Zone 1-10 selector, music/paging switch
and all-zone selector.
• 2 RJ45 communication ports for cascading purposes
19

Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
OPERATION MANUAL
PUBLIC ADDRESS SYSTEM
PAGING SELECTOR
FLP-ZS9810
POWER
ON
OFF 12 3 4 5
PAGING ZONES
678910
CHIME MIC 1
MIC 1
5
0
1
2
3
4 6
7
8
9
10
MIC 2
5
0
1
2
3
4 6
7
8
9
10
MUSIC
/ CALL/
ALL
ZONE
FLP-ZS9810
PAGING SELECTOR

TABLE OF CONTENTS
1. SAFETY PRECAUTIONS .......................................................................................3
2. GENERAL DESCRIPTION ....................................................................................5
3. FEATURES ...............................................................................................................5
4. NOMENCLATURE AND FUNCTIONS
4.1 Front Panel .............................................................................................................6
4.2 Rear Panel............................................................................................................. 7
5. ........................................................................................8
6. APPLICATIONS .................................................................................................... 10
7.SPECIFICATIONS .................................................................................................11
8.DIMENSIONAL DIAGRAM .................................................................................. 12
MACHINE OPERATION
2

3
1. SAFETY PRECAUTIONS
Be sure to read the instructions in this section carefully before use.
Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
Do not place cups, bowls, or other containers of
liquid or metallic objects on top of the unit. If they
accidentally spill into the unit, this may cause a
fire or electric shock.
Do not insert nor drop metallic objects or flammable
materials in the ventilation slots of the unit's cover,
as this may result in fire or electric shock.
When Installing the Unit When Installing the Unit
Should the following irregularity be found during
use, immediately switch off the power, disconnect
the power supply plug from the AC outlet and contact
y our nearest dealer. Make no furtherat-
tempt to operate the unit in this condition as this
may cause fire or electric shock.
If you detect smoke or a strange smell coming
from the unit.
If water or any metallic object gets into the unit
If the unit falls, or the unit case breaks
If the power supply cord is damaged (exposure
of the core, disconnection, etc.)
If it is malfunctioning (no tone sounds.)
To prevent a fire or electric shock, never open nor
remove the unit case as there are high voltage
components inside the unit. Refer all servicing
to your nearest dealer.
FLEPCHER
FLEPCHER
Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.
Use the unit only with the voltage specified on
the unit.Using a voltage higher than that which
is specified may result in fire or electric shock.
Do not cut,kink otherwise damage nor modify the
power supply cord. In addition, avoid using the
power cord in close proximity to heaters, and never
place heavy objects - including the unit itself - on
the power cord, as doing so may result in fire or
electric shock.
Be sure to replace the unit's terminal cover after
connection completion. Because high voltage
is applied to the speaker terminals,never touch
these terminals to avoid electric shock.
Be sure to ground to the safety ground (earth)
terminal to avoid electric shock. Never ground
to a gas pipe as a catastrophic disaster mayresult.
Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in theunit falling
down,causing personal injury and / or property
damage.

4
SAFETY PRECAUTIONS
An all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in
the electrical installation of the building.
Never plug in nor remove the power supply plug
with wet hands, as doing so may cause electric
shock.
When unplugging the power supply cord, be sure
to grasp the power supply plug; never pull on the
cord itself. Operating the unit with a damaged
power supply cord may cause a fire or electric
shock.
When moving the unit, be sure to remove its power
supply cord from the wall outlet. Moving the unit
with the power cord connected to the outlet may
cause damage to the power cord, resulting in fire or
electric shock. When removing the power cord, be
sure to hold its plug to pull.
Do not block the ventilation slots in the unit's cover.
Doing so may cause heat to build up inside the unit
and result in fire.
Avoid installing the unit in humid or dusty locations,
in locations exposed to the direct sunlight, near the
heaters, or in locations generating sooty smoke or
steam as doing otherwise may result in fire or
electric shock.
Do not place heavy objects on the unit as this may
cause it to fall or break which may result in personal
injury and/or property damage. In addition, the object
itself may fall off and cause injury and/or damage.
Make sure that the volume ontrol is set to minimum
position before power is switched on. Loud noise
produced at high volume when power is switched
on can impair hearing.
Do not operate the unit for an extended period of
time with the sound distorting. Thisis an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
Contact your dealer as to the cleaning.
If dust is allowed to accumulate in the unit over a
long period of time, a fire or damage to the unit
may result.
FLEPCHER
If dust accumulates on the power supply plug or in
the wall AC outlet, a fire may result. Clean it peri-
odically. Inaddition, insert the plug in the wall outlet
securely.
Switch off the power, and unplugthe power supply
plug from the AC outlet for safety purposes when
cleaning or leaving the unit unused for 10 days or
more. Doing otherwise may cause a fire or electric
shock.
Due to product upgrades, while some of the
features and specification in the user manual
does not match the actual functions, sorry for
any inconvenience and thanks for your kind
understanding!
When Installing the Unit When Installing the Unit

3. FEATURES
2. GENERAL DESCRIPTION
Built-in 10groups power zones,can be expanded to 300 zones.
With memory function when power off,can realize the restorationafter electricity be turn on.
10 groups background music amplifier+10 groups alarm signal amplifier input interface to achieve
the access of any number amplifiers(1-10 Units).
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Each Groups Largest Controllable Power Is 500w,the Total Controllable Power Is 5000W.
Two-color zones status display lighs,accurate indicate music,paging or alarm status.
Music zones player control function,to achieve the music broadcast to any zones.
The local and remote(1km)zone paging function,to achieve zone division convenient and flexible.
Built in alarm trggering interface and neighbor floor alarm to achieve smart alarm functions of all
zone,single zone,neighbor floor and so on.
Built-in pre-amplifier with two priority functions,two microphone inputs,and two line i
nput.
Built-in chime with 4 tones.
11. DC interface.
5
The FLP-ZS9810 is a highperformance 10-zone Paging Selector that works with Emergency Panel
and10-zone speaker selector ,Paging microph
one console and Alarm Matrix for emergency notification and
zone paging .The applications can be carride out with an amplifier stepping up the EMC input ,MIC input
and remote paging and then to rigger the speaker selector and Emergency Panel. Features include 10
zones paging and EMC (priority) input,two MIC inputs and two line inputs. Mute function, EMC priority,
remotepaging and built-in chime.
ALARMING SIGNALGENERATOR SPEAKER SELECTOR
PAGING MIC CONSOLE ALARM MATRIX

POWER
ON
OFF 12 3 4 5
PAGING ZONES
678910
CHIME MIC 1
MIC 1
5
0
1
2
3
4 6
7
8
9
10
MIC 2
5
0
1
2
3
4 6
7
8
9
10
MUSIC
/ CALL
ALL
ZONE
FLP-ZS9810
PAGING SELECTOR
4. NOMENCLATURE AND FUNCTIONS
4.1 FRONT PANEL
214356
78
1. POWER
Power indicator
2. POWER SWITCH
On top of the opening Power
Press the end, power shut down
3. PAGING ZONES
(1~10)Paging zones indicator
(1~10)Paging zones button
4. MIC (1~2)
MIC (1~2) volume control
5. CHIME
CHIME Microphone
6. MIC 1
MIC1 input 6.3 Microphone jack input
7. MUSIC/CALL
Music/call button
Music/call button indicator
8. ALL ZONE
All zone button
All zone indicator
6

NOMENCLATURE AND FUNCTIONS
4.2 REAR PANEL
1. MIC2 IN
MIC2 input 6.3 Microphone jack input
2. CHIME VOL
CHIME volume control
3. LINE 1/LINE 2 IN
Line 1 Access alarm signal
4. AUDIO OUT
MIC1/MIC2/LINE1/LINE2/CHIME/TEL
signal ouput
5. ADRESS
Adress code switch
6. COM
Network Communication Port
7. MUSIC IN(CH1~CH10)
Background music input
8. ALARM IN (CH1~CH10)
Zoning alarm signal
9. AC POWER INPUT
10. OUT(CH1~CH10)
11. ALARM OUT A / B
Short-circuit the signal region output
12. ALARM IN A / B
Short-circuit the signal region input
1234567 8 9
101112
7
MIC 2
IN
CHIME
VOL
LINE1
IN
LINE2
IN
AUDIO
OUT
+ - + - + - + -
ALARM IN ALARM OUT
+ A - + B - + A - + B -
ADDRESS COM
------------------------------
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10
+ + + + + + + + + + + + + + + + + + + + + + + + + + + + + +
MUSIC IN ALARM IN OUTPUT MUSIC IN ALARM IN OUTPUT MUSIC IN ALARM IN OUTPUT MUSIC IN ALARM IN OUTPUT MUSIC IN ALARM IN OUTPUT MUSIC IN ALARM IN OUTPUT MUSIC IN ALARM IN OUTPUT MUSIC IN ALARM IN OUTPUT MUSIC IN ALARM IN OUTPUT MUSIC IN ALARM IN OUTPUT
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10
~240V 50Hz
T1AL 250V
ON
12345678
USE ONLYWITHA 250W FUSE
BATT SUPPLY
24V 2A
RISQUE DE CHOC ELECTRIQUE
-NE PASOUVRIR
AVIS:
RISK OF ELECTRIC SHOCK
DO NOT OPEN

5. MACHINE OPERATION
Signal from MIC 2 and LINE 2 are automatically muted by signal from MIC 1 (MIC 1input overrides
MIC 2 and LINE 2 signals).
Signal from MIC1, MIC2 and line2 are automatically muted by signal from LINE 1(LINE 1 input
overrides the other input signals).
MUTING FUNCTION
OPERATION
4. Adress setting
01
from 1~10
from 11~20
03
from 21~30
04
from 31~40
05
from41~50
06
from 51~60
07
from 61~70
08
from 71~80
02
09
from 81~90
10
from 91~100
11
from 101~110
12
from 111~120
13
from 121~130
14
from 131~140
15
from 141~150
16
from 151~160
12345
55
5
5
5
5
5
55
5
5
5
5
5
5
55
1234
1234
1234
1234
1234
1234
1234
1234
1234
1234
1234
1234
1234
1234
1234
Adress codo
drawing Difinition Adress codo
drawing Difinition
8
2. pin 1~10 of ALARM IN to be connected to fire center are the live terminals of CH1~CH10 respectively.
And,+12V~ high level or 0V-low level is available for alarm activating . While ACTIVE LEVEL set at
HIGH, high level is valid; while ACTIVE LEVEL set at LOW , low level (grounded signal)is valid.
3. Witch address is for Remote only. If there are more than one in Remote
System , they must be addressed with different priority each other.
10 Zones Speaker Selector
1. While press don any switch of CH1~CH10 on front panel with its indicatorlit,the paging channel will be
switching on respectively.Press the switch the switch again with the indicator getting off forresetting.

MACHINE OPERATION
1236
47
558
1
1
2
2
3
3
4
4
1
1
2
2
3
3
4
4
1
1
2
2
3
3
4
4
1
1
2
2
3
3
4
4
1
1
2
2
3
3
4
4
1
1
2
2
3
3
4
4
1234
1234
5
5
5
5
5
5
5
5
5
5
5
5
5
55
Address code
drawing
Address code
drawing
Definition Definition
from 161~170
from 171~180
from 181~190
from 191~200
from 201~210
from 211~220
from 221~230
from 231~240
from 291~300
from 281~290
from 271~280
from 261~270
from 251~260
from 241~250
17
18
19
20
21
22
23
24
25
26
27
28
29
30
9
NOTE:1. 6.8 two address switch does not work.
2. White points indicate the direction of pull Address Code.
3. When the seventh bit address switch pulling in the 0 (down) position, saying that
this function of the fire alarm interface short-circuit signal has reply, as with the fire
alarm interface connected to 10 channel 24V DC supply and FLP-ZS9810 there
are any models of the fire alarm interface short-circuit signal has reply, fire alarm
interface light does not flash, the two models are not on the fire alarm interface
short-circuit signal reply,the fire alarm interface panel lights flash.When the
seventh bit address switch pulling in 1 (up) position, does not have this feature.
