FLINQ FQC8208 User manual

FLINQ LED FLOORLAMP XYRO
USER MANUAL FQC8208
V1
ADD NEW PICTURE HERE
Thanks for purchasing this FlinQ product!
To ensure continuous operation and accuracy, please read these operating instructions
carefully before use and save this manual for future use. To skip certain procedures may
result in incorrect reading and use. We hope that you will enjoy using your new product!
If by any chance the item is damaged, defective or broken, you are covered with warranty!
Please do not hesitate to contact us for any questions, concerns or suggestions at the email
address as mentioned in this manual. We deserve the right to make technical and design
modifications in the course of continuous product development. Read and follow the
instructions contained in this manual carefully. Keep these instructions at a safe place for
future reference.
Safety Information:
Please read this manual thoroughly before using the product! Keep it in hand for future
reference. Warnings alert the user to potential serious outcomes, such as injury or adverse
events to the user. Cautions alert the user to exercise care necessary for the safe and
effective use of the product. Notes contain important information that may be overlooked
or missed.
This product can be used indoors (see below for more info).
This appliance may be used by children aged 12 and over, and by persons with reduced
physical, sensory or mental capacities or a lack of sufficient experience and/or knowledge,
provided they are supervised or have been trained in the safe use of the appliance and
understand the potential dangers.
Cleaning and maintenance must not be carried out by children without supervision.
Children must not be allowed to play with the appliance.

Keep the packaging material away from children. There is a risk of suffocation!
Do not allow unsupervised children to clean or maintain this device.
• WARNING! Do not leave packaging material lying around carelessly. This
may become dangerous playing material for children. Risk of suffocation!
• DANGER due to swallowing small parts. Keep these away from children.
Risk of suffocation!
SPECIFICATIONS:
Input voltage: AC 100-240V / 50-60Hz
Rated output/input voltage lamp: DC 5V- 3A (3400mA) max with 2.5MT cable
Rated power: 18W
Energy label: A
Control method: RF433 soft touch wireless remote control with color, speed and dimming
function and much more
Appearance color: full dark black
Product height size: 145cm * 240mm*240mm base foot
Light color: RGB Symphony colors + Cool White + Warm White chosen at any way possible
Display index: CRI>80
Number of lamp LED beads: 225pcs
Product color temperature: warm white (2700-3200K) / white (6000-6500K) / RGB
Symphony Colors
Lumen: 1650 for Warm White and 1800 for White/Cool White
LED life: 25000 hours max.
Working temperature: 0℃~ + 45℃
IP Grade: IP20 (indoor use only)
Shell material: PE White + metal iron spray paint
Net weight: xxx
Lighting Symphony colors mode +/- : 238 lighting effects
REMOTE CONTROL:
Buttons: 10x

Button function: ON/OFF, SYMPHONY START/PAUSE, SPEED +/-, BRIGHTNESS +/-, LIGHT
SWITCH, SYMPHONIC MODE +/-, RING COLOR
Remote control type: RF433 radio frequency remote control
Remote control distance: up to 30 meters (open area)
Remote control power supply: 3x AAA batteries
Control quantity: One remote control can control multiple lights (only for the single colors)
or 1 light selectable for your choice
This product is a lifestyle product.
Read and follow the instructions contained in this manual carefully. Keep these
instructions at a safe place for future reference.
The operating life of the product will be less if the ambient temperature is higher than
45°C or lower than -10°C.
ADD NEW PICTURE HERE TO SHOW LIKE BELOW EXAMPLE
Product general description and contents:
1. Lamp pole
2. Lamp foot base
3. Adapter + connection cable (2.5m) with USB plug
4. RF Remote control
5. Installation bolt + tool and user manual
MAIN USE CAUTIONS BEFORE INSTALLATION:

NOTE:
• Choose a stable, solid and supportive surface and make sure the lamp is set correctly.
• Make sure the cables cannot cause a trip hazard.
• Make sure there is enough ventilation around the device and so not cover it at all times.
• This lamp is intended for inside use and the main power adapter and remote control is not
waterproof! Keep away from water and only use indoors.
WARNING: Keep the external adapter out of reach of children.
Never charge this product in moisture conditions or in the rain. Only charge it indoors, in a
dry place.
• This is not a TOY, keep away from small children below 12 years.
• Do not open or disassemble the lamp or adapter yourself, this will void the warranty at all
times.
•Do not disassemble, repair or modify the product by yourself as this may result into an
electric shock.
•Do not look directly into the lamp beads as it could hurt your eyes.
•The led source is not replaceable.
•If the cable or adapter is damaged or broken please contact your seller for correct
replacement by the manufacturer only.
• Do not stand, sit on, jump or throw with the lamp at all times.
•Do not throw this product in the air as it may cause damage by falling.
• Only use the lamp for its intended designed use as a light.
•Take good care of the product and clean it regularly.
•Never touch the plug contacts with sharp or metal objects.
• Use only the original power supply and original accessories.
• Do not use the device outdoors.
• Protect the device from special liquids and vapors.
NOTE:
•Please note that the power port of the device should not be infiltrated by water.
Otherwise, it will cause a product failure.
•Do not charge or store the product in a place below 0℃or above 40℃, otherwise the
product performance will be reduced.
•It is a normal phenomenon that temperature of the adapter rises during use.

INSTALLATION OF LAMP FOOT BASE WITH LAMP POLE:
NOTE:
Do not connect the power cable nor adapter to the power mains outlet yet!
Please check if the lamp set is complete according the package contents as described.
ADD NEW PICTURE HERE TO SHOW THE POLE LAMP INSTALLATION + FOOT BASE
1. Place the lamp pole carefully on a table that is protected by a soft cloth or towel etc.
2. Take the lamp pole bottom screw side in one hand and bolt it with your other hand on the
lamp foot base hole with the supplied tool and bolt. Fix it firmly but slow, carefully.
3. Insert the USB connector cable end included into the approved adapter power connection
to connect and insert it to the mains power outlet. The power adapter input is AC100-240V
50/60Hz with output from DC 5V-3A (3400mA) max. Keep in mind this adapter is NOT
waterproof and needs to be used only INDOORS.
OPERATION AND REMOTE CONTROL USE:
ADD NEW PICTURE HERE FROM REMOTE AND OPEN WAY OF THE BATTERY COVER
