FLIR GF300 User manual

User’s manual
FLIR GF3xx series

User’s manual
FLIR GF3xx series
#T559157; r. AH/45951/45951; en-US iii

Table of contents
1 Disclaimers ........................................................................................1
1.1 Legal disclaimer .........................................................................1
1.2 U.S. Government Regulations........................................................1
1.3 Level 1 statement........................................................................1
1.4 Copyright ..................................................................................2
1.5 Quality assurance .......................................................................2
1.6 Patents.....................................................................................2
1.7 EULATerms ..............................................................................2
1.8 EULATerms ..............................................................................3
2 Safety information ...............................................................................5
3 Notice to user ................................................................................... 10
3.1 User-to-user forums .................................................................. 10
3.2 Calibration............................................................................... 10
3.3 Accuracy ................................................................................ 10
3.4 Disposal of electronic waste ........................................................ 10
3.5 Training .................................................................................. 10
3.6 Documentation updates ............................................................. 11
3.7 Note about authoritative versions.................................................. 11
4 Customer help .................................................................................. 12
4.1 General .................................................................................. 12
4.2 Submitting a question ................................................................ 12
4.3 Downloads .............................................................................. 13
5 Important note about training and applications ..................................... 14
5.1 General .................................................................................. 14
6 List of accessories and services ......................................................... 15
7 Introduction......................................................................................17
7.1 FLIR GF300............................................................................. 17
7.1.1 Optical gas imaging of methane and other volatile organic
compounds (VOCs) ........................................................ 17
7.1.2 Benefits ....................................................................... 17
7.2 FLIR GF304............................................................................. 17
7.2.1 Optical gas imaging of refrigerant gases.............................. 17
7.2.2 Benefits ....................................................................... 17
7.3 FLIR GF306............................................................................. 18
7.3.1 Optical gas imaging especially of SF6 and ammonia .............. 18
7.3.2 Benefits ....................................................................... 18
7.4 FLIR GF309............................................................................. 18
7.4.1 IR camera for furnace and high temperature
inspection..................................................................... 18
7.4.2 Benefits ....................................................................... 19
7.5 FLIR GF320............................................................................. 19
7.5.1 Optical gas imaging of methane and other volatile organic
compounds (VOCs) ........................................................ 19
7.5.2 Benefits ....................................................................... 19
7.6 FLIR GF335............................................................................. 20
7.6.1 Benefits ....................................................................... 20
7.7 FLIR GF343............................................................................. 20
7.7.1 The new FLIR GF343 is an optical gas camera for
visualizing carbon dioxide (CO2......................................... 20
7.7.2 Main applications ........................................................... 20
#T559157; r. AH/45951/45951; en-US v

Table of contents
7.8 FLIR GF346............................................................................. 21
7.8.1 Optical gas imaging especially of carbon monoxide (CO)
and other harmful gases .................................................. 21
7.8.2 Benefits ....................................................................... 21
8 Example images................................................................................ 22
8.1 General .................................................................................. 22
8.2 Images ................................................................................... 22
9 Quick Start Guide .............................................................................. 23
9.1 Detecting a temperature............................................................. 23
9.1.1 Procedure .................................................................... 23
9.1.2 Related topics ............................................................... 24
9.2 Detecting a gas leak .................................................................. 24
9.2.1 Procedure .................................................................... 24
9.2.2 Related topics ............................................................... 25
10 FLIR GF3xx series series general instrument check............................... 26
11 A note about ergonomics ................................................................... 27
11.1 General .................................................................................. 27
11.2 Figure .................................................................................... 27
11.3 Related topics .......................................................................... 28
12 Camera parts .................................................................................... 29
12.1 View from the left ...................................................................... 29
12.1.1 Figure.......................................................................... 29
12.1.2 Explanation................................................................... 29
12.2 View from the right .................................................................... 30
12.2.1 Figure.......................................................................... 30
12.2.2 Explanation................................................................... 30
12.3 View from the rear..................................................................... 31
12.3.1 Figure.......................................................................... 31
12.3.2 Explanation................................................................... 31
12.4 Battery condition LED indicator.................................................... 32
12.4.1 Figure.......................................................................... 32
12.4.2 Explanation................................................................... 32
12.5 Power LED indicator.................................................................. 32
12.5.1 Figure.......................................................................... 32
12.5.2 Explanation................................................................... 33
12.6 Laser pointer ........................................................................... 33
12.6.1 General........................................................................ 33
12.6.2 Figure.......................................................................... 33
12.6.3 Laser warning label......................................................... 33
12.6.4 Laser rules and regulations .............................................. 33
13 Screen elements ............................................................................... 34
13.1 Mode selector .......................................................................... 34
13.1.1 Figure.......................................................................... 34
13.1.2 Explanation................................................................... 34
13.2 Result table and measurement tools ............................................. 34
13.2.1 Figure.......................................................................... 34
13.2.2 Explanation................................................................... 34
13.3 Toolbox, indicators, and other objects............................................ 35
13.3.1 Figure.......................................................................... 35
13.3.2 Explanation................................................................... 35
#T559157; r. AH/45951/45951; en-US vi

Table of contents
14 Achieving a good image ..................................................................... 36
14.1 General .................................................................................. 36
14.2 Adjusting the infrared camera focus manually ................................. 36
14.2.1 Figure.......................................................................... 36
14.2.2 Procedure .................................................................... 36
14.3 Adjusting the infrared camera focus .............................................. 37
14.3.1 Figure.......................................................................... 37
14.3.2 Procedure .................................................................... 37
14.4 Adjusting an image.................................................................... 37
14.4.1 General........................................................................ 37
14.4.2 Explanation of the adjustment methods............................... 37
14.4.3 Procedure (Auto)............................................................ 37
14.4.4 Figure.......................................................................... 38
14.4.5 Procedure (HSM)........................................................... 38
14.4.6 Procedure (Manual)........................................................ 38
14.5 Selecting a suitable temperature range.......................................... 38
14.5.1 About temperature ranges................................................ 38
14.5.2 Understanding the temperature scale ................................. 39
14.5.3 Changing the temperature range ....................................... 40
14.6 Selecting a suitable color palette .................................................. 40
14.6.1 Procedure .................................................................... 40
14.7 Enabling or disabling histogram mode ........................................... 40
14.7.1 General........................................................................ 40
14.7.2 Procedure .................................................................... 40
14.8 Enabling or disabling inverted color palette..................................... 41
14.8.1 Procedure .................................................................... 41
14.9 Changing object parameters ....................................................... 41
14.9.1 General........................................................................ 41
14.9.2 Types of parameters ....................................................... 41
14.9.3 Recommended values..................................................... 41
14.9.4 Procedure .................................................................... 42
14.9.5 Related topics ............................................................... 42
15 Connecting external devices............................................................... 43
15.1 General .................................................................................. 43
15.2 Related topics .......................................................................... 43
15.3 Connecting devices to the rear connectors ..................................... 43
15.3.1 Figure.......................................................................... 43
15.3.2 Explanation................................................................... 43
15.3.3 Figure.......................................................................... 44
15.3.4 Explanation................................................................... 44
15.4 Inserting SD Memory Cards ........................................................ 44
15.4.1 Figure.......................................................................... 44
15.4.2 Explanation................................................................... 44
15.4.3 Formatting memory cards ................................................ 45
16 Handling the camera.......................................................................... 46
16.1 Charging the camera battery ....................................................... 46
16.1.1 Charging the battery using the power supply cable ................ 46
16.1.2 Charging the battery using the stand-alone battery
charger........................................................................ 46
16.2 Installing and removing the camera battery..................................... 47
16.2.1 Installing the battery........................................................ 47
#T559157; r. AH/45951/45951; en-US vii

Table of contents
16.2.2 Removing the battery ...................................................... 48
16.3 Turning on the camera ............................................................... 49
16.3.1 Procedure .................................................................... 49
16.4 Turning off the camera ............................................................... 49
16.4.1 Procedure .................................................................... 49
16.5 Adjusting the viewing angle of the viewfinder................................... 49
16.5.1 General........................................................................ 49
16.5.2 Figure.......................................................................... 49
16.5.3 Procedure .................................................................... 49
16.6 Adjusting the viewfinder’s dioptric correction ................................... 50
16.6.1 General........................................................................ 50
16.6.2 Figure.......................................................................... 50
16.6.3 Procedure .................................................................... 50
16.7 Adjusting the camera grip ........................................................... 50
16.7.1 General........................................................................ 50
16.7.2 Figure.......................................................................... 51
16.7.3 Procedure .................................................................... 51
16.8 Opening the display................................................................... 51
16.8.1 Figure.......................................................................... 51
16.9 Adjusting the viewing angle of the display....................................... 52
16.9.1 General........................................................................ 52
16.9.2 Figure.......................................................................... 52
16.9.3 Procedure .................................................................... 52
16.10 Installing an infrared lens ............................................................ 52
16.10.1 Procedure .................................................................... 52
16.11 Removing an infrared lens .......................................................... 53
16.11.1 Procedure .................................................................... 53
16.12 Mounting the heatshield ............................................................. 54
16.12.1 General........................................................................ 54
16.12.2 Procedure .................................................................... 54
16.13 Adjusting the infrared camera focus manually ................................. 56
16.13.1 Figure.......................................................................... 56
16.13.2 Procedure .................................................................... 56
16.14 Adjusting the infrared camera focus .............................................. 57
16.14.1 Figure.......................................................................... 57
16.14.2 Procedure .................................................................... 57
16.15 Autofocusing the infrared camera and the digital camera ................... 58
16.15.1 Figure.......................................................................... 58
16.15.2 Procedure .................................................................... 58
16.16 Operating the laser pointer.......................................................... 59
16.16.1 Figure.......................................................................... 59
16.16.2 Procedure .................................................................... 59
16.16.3 Laser warning label......................................................... 59
16.17 Using the zoom function ............................................................. 59
16.17.1 General........................................................................ 59
16.17.2 Procedure .................................................................... 59
17 Working with views and images........................................................... 60
17.1 Saving infrared images............................................................... 60
17.1.1 General........................................................................ 60
17.1.2 Image capacity .............................................................. 60
#T559157; r. AH/45951/45951; en-US viii

Table of contents
17.1.3 Saving an infrared image directly to an SD Memory
Card............................................................................ 60
17.1.4 Previewing and saving an infrared image to an SD
Memory Card ................................................................ 60
17.2 Opening an image..................................................................... 61
17.2.1 General........................................................................ 61
17.2.2 Procedure .................................................................... 61
17.3 Changing settings related to image presentation.............................. 61
17.3.1 General........................................................................ 61
17.3.2 Procedure .................................................................... 62
17.4 Editing a saved image................................................................ 62
17.4.1 General........................................................................ 62
17.4.2 Procedure .................................................................... 62
17.5 Deleting a file........................................................................... 63
17.5.1 Procedure .................................................................... 63
18 Working with measurement tools ........................................................ 64
18.1 Laying out a measurement tool .................................................... 64
18.1.1 General........................................................................ 64
18.1.2 Procedure .................................................................... 64
18.2 Moving or resizing a measurement tool.......................................... 64
18.2.1 General........................................................................ 64
18.2.2 Procedure .................................................................... 64
18.3 Creating & setting up a difference calculation .................................. 64
18.3.1 General........................................................................ 64
18.3.2 Procedure .................................................................... 65
18.4 Changing object parameters ....................................................... 65
18.4.1 General........................................................................ 65
18.4.2 Types of parameters ....................................................... 65
18.4.3 Recommended values..................................................... 66
18.4.4 Procedure .................................................................... 66
18.4.5 Related topics ............................................................... 67
19 Programming the camera ................................................................... 68
19.1 General .................................................................................. 68
19.2 Procedure ............................................................................... 68
20 Recording video clips ........................................................................ 69
20.1 General .................................................................................. 69
20.2 Procedure ............................................................................... 69
21 Changing settings ............................................................................. 70
21.1 General .................................................................................. 70
21.2 Procedure ............................................................................... 70
21.3 Connecting the camera using a peer-to-peer (ad hoc) WLAN
network .................................................................................. 70
21.3.1 General........................................................................ 70
21.3.2 Procedure .................................................................... 70
21.3.3 Related topics ............................................................... 71
21.4 Connecting the camera using a infrastructure WLAN network ............. 71
21.4.1 General........................................................................ 71
21.4.2 Procedure .................................................................... 71
21.4.3 Related topics ............................................................... 71
21.5 Changing Wi-Fi settings ............................................................. 71
21.5.1 General........................................................................ 71
#T559157; r. AH/45951/45951; en-US ix

Table of contents
21.5.2 Procedure .................................................................... 71
21.5.3 Related topics ............................................................... 72
22 Technical data................................................................................... 73
22.1 Online field-of-view calculator...................................................... 73
22.2 Note about technical data ........................................................... 73
22.3 Note about authoritative versions.................................................. 74
22.4 FLIR GF300 14.5°..................................................................... 75
22.5 FLIR GF300 14.5° Fixed lens....................................................... 80
22.6 FLIR GF300 24° ....................................................................... 85
22.7 FLIR GF300 24° Fixed lens ......................................................... 90
22.8 FLIR GF304 14.5°..................................................................... 95
22.9 FLIR GF304 14.5° Fixed lens..................................................... 101
22.10 FLIR GF304 24° ..................................................................... 106
22.11 FLIR GF304 24° Fixed lens ....................................................... 112
22.12 FLIR GF306 14.5°................................................................... 117
22.13 FLIR GF306 14.5° Fixed lens..................................................... 123
22.14 FLIR GF306 24° ..................................................................... 129
22.15 FLIR GF306 24° Fixed lens ....................................................... 135
22.16 FLIR GF309 14.5°................................................................... 141
22.17 FLIR GF309 14.5° Fixed lens..................................................... 147
22.18 FLIR GF309 24° ..................................................................... 152
22.19 FLIR GF309 24° Fixed lens ....................................................... 158
22.20 FLIR GF320 14.5°................................................................... 163
22.21 FLIR GF320 14.5° Fixed lens..................................................... 169
22.22 FLIR GF320 24° ..................................................................... 175
22.23 FLIR GF320 24° Fixed lens ....................................................... 181
22.24 FLIR GF335 24° ..................................................................... 187
22.25 FLIR GF343 24° Fixed lens ....................................................... 192
22.26 FLIR GF346 14.5°................................................................... 197
22.27 FLIR GF346 14.5° Fixed lens..................................................... 203
22.28 FLIR GF346 24° ..................................................................... 209
22.29 FLIR GF346 24° Fixed lens ....................................................... 215
23 Mechanical drawings ....................................................................... 221
24 CE Declaration of conformity ............................................................ 227
25 Cleaning the camera ........................................................................ 229
25.1 Camera housing, cables, and other items..................................... 229
25.1.1 Liquids....................................................................... 229
25.1.2 Equipment.................................................................. 229
25.1.3 Procedure .................................................................. 229
25.2 Infrared lens .......................................................................... 229
25.2.1 Liquids....................................................................... 229
25.2.2 Equipment.................................................................. 229
25.2.3 Procedure .................................................................. 229
26 Cooler maintenance......................................................................... 231
26.1 General ................................................................................ 231
26.2 Signs to watch for ................................................................... 231
27 Detectable gases............................................................................. 232
27.1 General ................................................................................ 232
27.2 Gases that can be detected by FLIR GF300.................................. 232
27.3 Coolants that can be detected by FLIR GF304 .............................. 235
#T559157; r. AH/45951/45951; en-US x

Table of contents
27.4 Gases that can be detected by FLIR GF306.................................. 235
27.5 Gases that can be detected by FLIR GF320.................................. 239
27.6 Gases that can be detected by FLIR GF343.................................. 242
27.7 Gases that can be detected by FLIR GF346.................................. 242
28 Why do some gases absorb infrared energy? ..................................... 246
29 About FLIR Systems ........................................................................ 249
29.1 More than just an infrared camera .............................................. 250
29.2 Sharing our knowledge ............................................................ 251
29.3 Supporting our customers......................................................... 251
30 Terms, laws, and definitions.............................................................. 252
31 About calibration............................................................................. 254
31.1 Introduction ........................................................................... 254
31.2 Definition—what is calibration? .................................................. 254
31.3 Camera calibration at FLIR Systems ........................................... 254
31.4 The differences between a calibration performed by a user and
that performed directly at FLIR Systems....................................... 255
31.5 Calibration, verification and adjustment........................................ 255
31.6 Non-uniformity correction.......................................................... 256
31.7 Thermal image adjustment (thermal tuning) .................................. 256
32 Thermographic measurement techniques .......................................... 257
32.1 Introduction .......................................................................... 257
32.2 Emissivity.............................................................................. 257
32.2.1 Finding the emissivity of a sample.................................... 257
32.3 Reflected apparent temperature................................................. 261
32.4 Distance ............................................................................... 261
32.5 Relative humidity .................................................................... 261
32.6 Other parameters.................................................................... 261
33 History of infrared technology........................................................... 262
34 Theory of thermography................................................................... 265
34.1 Introduction ........................................................................... 265
34.2 The electromagnetic spectrum................................................... 265
34.3 Blackbody radiation................................................................. 266
34.3.1 Planck’s law ................................................................ 267
34.3.2 Wien’s displacement law................................................ 268
34.3.3 Stefan-Boltzmann's law ................................................. 269
34.3.4 Non-blackbody emitters................................................. 270
34.4 Infrared semi-transparent materials............................................. 272
35 The measurement formula................................................................ 273
36 Emissivity tables ............................................................................. 277
36.1 References............................................................................ 277
36.2 Tables .................................................................................. 277
#T559157; r. AH/45951/45951; en-US xi

Disclaimers
1
1.1 Legal disclaimer
All products manufactured by FLIR Systems are warranted against defective materials
and workmanship for a period of one (1) year from the delivery date of the original pur-
chase, provided such products have been under normal storage, use and service, and in
accordance with FLIR Systems instruction.
Uncooled handheld infrared cameras manufactured by FLIR Systems are warranted
against defective materials and workmanship for a period of two (2) years from the delivery
date of the original purchase, provided such products have been under normal storage,
use and service, and in accordance with FLIR Systems instruction, and provided that the
camera has been registered within 60 days of original purchase.
Detectors for uncooled handheld infrared cameras manufactured by FLIR Systems are
warranted against defective materials and workmanship for a period of ten (10) years from
the delivery date of the original purchase, provided such products have been under normal
storage, use and service, and in accordance with FLIR Systems instruction, and provided
that the camera has been registered within 60 days of original purchase.
Products which are not manufactured by FLIR Systems but included in systems delivered
by FLIR Systems to the original purchaser, carry the warranty, if any, of the particular sup-
plier only. FLIR Systems has no responsibility whatsoever for such products.
The warranty extends only to the original purchaser and is not transferable. It is not appli-
cable to any product which has been subjected to misuse, neglect, accident or abnormal
conditions of operation. Expendable parts are excluded from the warranty.
In the case of a defect in a product covered by this warranty the product must not be fur-
ther used in order to prevent additional damage. The purchaser shall promptly report any
defect to FLIR Systems or this warranty will not apply.
FLIR Systems will, at its option, repair or replace any such defective product free of charge
if, upon inspection, it proves to be defective in material or workmanship and provided that
it is returned to FLIR Systems within the said one-year period.
FLIR Systems has no other obligation or liability for defects than those set forth above.
No other warranty is expressed or implied. FLIR Systems specifically disclaims the implied
warranties of merchantability and fitness for a particular purpose.
FLIR Systems shall not be liable for any direct, indirect, special, incidental or consequen-
tial loss or damage, whether based on contract, tort or any other legal theory.
This warranty shall be governed by Swedish law.
Any dispute, controversy or claim arising out of or in connection with this warranty, shall be
finally settled by arbitration in accordance with the Rules of the Arbitration Institute of the
Stockholm Chamber of Commerce. The place of arbitration shall be Stockholm. The lan-
guage to be used in the arbitral proceedings shall be English.
1.2 U.S. Government Regulations
This product may be subject to U.S. Export Regulations. Please send any inquiries to ex-
[e-mail].
1.3 Level 1 statement
Applicability: Flir GF3xx.
This document is controlled to Flir Technology Level 1. The information contained in this
document pertains to a defense article controlled for export by the International Traffic in
#T559157; r. AH/45951/45951; en-US 1

Disclaimers1
Arms Regulations (ITAR). Flir trade secrets contained herein are subject to disclosure re-
strictions as a matter of law. Diversion contrary to US law is prohibited. US Government
authorization for public release has been obtained from the Office of Security Review, au-
thorization No. 10-S-2672. Additional US Department of State authorization is not required
prior to export or transfer to foreign persons or parties, unless otherwise prohibited.
1.4 Copyright
© 2016, FLIR Systems, Inc. All rights reserved worldwide. No parts of the software includ-
ing source code may be reproduced, transmitted, transcribed or translated into any lan-
guage or computer language in any form or by any means, electronic, magnetic, optical,
manual or otherwise, without the prior written permission of FLIR Systems.
The documentation must not, in whole or part, be copied, photocopied, reproduced, trans-
lated or transmitted to any electronic medium or machine readable form without prior con-
sent, in writing, from FLIR Systems.
Names and marks appearing on the products herein are either registered trademarks or
trademarks of FLIR Systems and/or its subsidiaries. All other trademarks, trade names or
company names referenced herein are used for identification only and are the property of
their respective owners.
1.5 Quality assurance
The Quality Management System under which these products are developed and manu-
factured has been certified in accordance with the ISO 9001 standard.
FLIR Systems is committed to a policy of continuous development; therefore we reserve
the right to make changes and improvements on any of the products without prior notice.
1.6 Patents
000439161; 000653423; 000726344; 000859020; 001707738; 001707746; 001707787;
001776519; 001954074; 002021543; 002021543-0002; 002058180; 002249953;
002531178; 002816785; 002816793; 011200326; 014347553; 057692; 061609;
07002405; 100414275; 101796816; 101796817; 101796818; 102334141; 1062100;
11063060001; 11517895; 1226865; 12300216; 12300224; 1285345; 1299699; 1325808;
1336775; 1391114; 1402918; 1404291; 1411581; 1415075; 1421497; 1458284;
1678485; 1732314; 17399650; 1880950; 1886650; 2007301511414; 2007303395047;
2008301285812; 2009301900619; 20100060357; 2010301761271; 2010301761303;
2010301761572; 2010305959313; 2011304423549; 2012304717443; 2012306207318;
2013302676195; 2015202354035; 2015304259171; 204465713; 204967995; 2106017;
2107799; 2115696; 2172004; 2315433; 2381417; 2794760001; 3006596; 3006597;
303330211; 4358936; 483782; 484155; 4889913; 4937897; 4995790001; 5177595;
540838; 579475; 584755; 599392; 60122153; 6020040116815; 602006006500.0;
6020080347796; 6020110003453; 615113; 615116; 664580; 664581; 665004; 665440;
67023029; 6707044; 677298; 68657; 69036179; 70022216; 70028915; 70028923;
70057990; 7034300; 710424; 7110035; 7154093; 7157705; 718801; 723605; 7237946;
7312822; 7332716; 7336823; 734803; 7544944; 7606484; 7634157; 7667198; 7809258;
7826736; 8018649; 8153971; 8212210; 8289372; 8340414; 8354639; 8384783;
8520970; 8565547; 8595689; 8599262; 8654239; 8680468; 8803093; 8823803;
8853631; 8933403; 9171361; 9191583; 9279728; 9280812; 9338352; 9423940;
9471970; 9595087; D549758.
1.7 EULA Terms
• You have acquired a device (“INFRARED CAMERA”) that includes software licensed by
FLIR Systems AB from Microsoft Licensing, GP or its affiliates (“MS”). Those installed
software products of MS origin, as well as associated media, printed materials, and
#T559157; r. AH/45951/45951; en-US 2

Disclaimers1
“online” or electronic documentation (“SOFTWARE”) are protected by international in-
tellectual property laws and treaties. The SOFTWARE is licensed, not sold. All rights
reserved.
• IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT (“EULA”), DO
NOT USE THE DEVICE OR COPY THE SOFTWARE. INSTEAD, PROMPTLY CON-
TACT FLIR Systems AB FOR INSTRUCTIONS ON RETURN OF THE UNUSED DE-
VICE(S) FOR A REFUND. ANY USE OF THE SOFTWARE, INCLUDING BUT NOT
LIMITED TO USE ON THE DEVICE, WILL CONSTITUTE YOUR AGREEMENT TO
THIS EULA (OR RATIFICATION OF ANY PREVIOUS CONSENT).
•GRANT OF SOFTWARE LICENSE. This EULA grants you the following license:
◦ You may use the SOFTWARE only on the DEVICE.
◦NOT FAULT TOLERANT. THE SOFTWARE IS NOT FAULT TOLERANT. FLIR Sys-
tems AB HAS INDEPENDENTLY DETERMINED HOW TO USE THE SOFTWARE
IN THE DEVICE, AND MS HAS RELIED UPON FLIR Systems AB TO CONDUCT
SUFFICIENT TESTING TO DETERMINE THAT THE SOFTWARE IS SUITABLE
FOR SUCH USE.
◦NO WARRANTIES FOR THE SOFTWARE. THE SOFTWARE is provided “AS IS”
and with all faults. THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PER-
FORMANCE, ACCURACY, AND EFFORT (INCLUDING LACK OF NEGLIGENCE)
IS WITH YOU. ALSO, THERE IS NO WARRANTY AGAINST INTERFERENCE
WITH YOUR ENJOYMENT OF THE SOFTWARE OR AGAINST INFRINGEMENT.
IF YOU HAVE RECEIVED ANY WARRANTIES REGARDING THE DEVICE OR
THE SOFTWARE, THOSE WARRANTIES DO NOT ORIGINATE FROM, AND ARE
NOT BINDING ON, MS.
◦ No Liability for Certain Damages. EXCEPT AS PROHIBITED BY LAW, MS SHALL
HAVE NO LIABILITY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL OR IN-
CIDENTAL DAMAGES ARISING FROM OR IN CONNECTION WITH THE USE
OR PERFORMANCE OF THE SOFTWARE. THIS LIMITATION SHALL APPLY
EVEN IF ANY REMEDY FAILS OF ITS ESSENTIAL PURPOSE. IN NO EVENT
SHALL MS BE LIABLE FOR ANY AMOUNT IN EXCESS OF U.S. TWO HUNDRED
FIFTY DOLLARS (U.S.$250.00).
◦Limitations on Reverse Engineering, Decompilation, and Disassembly. You
may not reverse engineer, decompile, or disassemble the SOFTWARE, except and
only to the extent that such activity is expressly permitted by applicable law notwith-
standing this limitation.
◦SOFTWARE TRANSFER ALLOWED BUT WITH RESTRICTIONS. You may perma-
nently transfer rights under this EULA only as part of a permanent sale or transfer of
the Device, and only if the recipient agrees to this EULA. If the SOFTWARE is an up-
grade, any transfer must also include all prior versions of the SOFTWARE.
◦EXPORT RESTRICTIONS. You acknowledge that SOFTWARE is subject to U.S. ex-
port jurisdiction. You agree to comply with all applicable international and national
laws that apply to the SOFTWARE, including the U.S. Export Administration Regula-
tions, as well as end-user, end-use and destination restrictions issued by U.S. and
other governments. For additional information see http://www.microsoft.com/export-
ing/.
1.8 EULA Terms
Qt4 Core and Qt4 GUI, Copyright ©2013 Nokia Corporation and FLIR Systems AB. This
Qt library is a free software; you can redistribute it and/or modify it under the terms of the
GNU Lesser General Public License as published by the Free Software Foundation; either
version 2.1 of the License, or (at your option) any later version. This library is distributed in
the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied
warranty of MERCHANTABILITYor FITNESS FOR A PARTICULAR PURPOSE. See the
GNU Lesser General Public License, http://www.gnu.org/licenses/lgpl-2.1.html. The
#T559157; r. AH/45951/45951; en-US 3

Disclaimers1
source code for the libraries Qt4 Core and Qt4 GUI may be requested from FLIR Systems
AB.
#T559157; r. AH/45951/45951; en-US 4

Safety information
2
WARNING
Applicability: Class A digital devices.
This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in
accordance with the instruction manual, may cause interference to radio communications. It has been
tested and found to comply with the limits for a Class A computing device pursuant to Subpart J of Part
15 of FCC Rules, which are designed to provide reasonable protection against such interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever measures may
be required to correct the interference.
WARNING
Applicability: Class B digital devices.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular in-
stallation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING
Applicability: Digital devices subject to 15.19/RSS-210.
NOTICE: This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Op-
eration is subject to the following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause undesired
operation.
WARNING
Applicability: Digital devices subject to 15.21.
NOTICE: Changes or modifications made to this equipment not expressly approved by FLIR Systems
may void the FCC authorization to operate this equipment.
WARNING
Applicability: Digital devices subject to 2.1091/2.1093/OET Bulletin 65.
Radiofrequency radiation exposure Information: The radiated output power of the device is below
the FCC/IC radio frequency exposure limits. Nevertheless, the device shall be used in such a manner that
the potential for human contact during normal operation is minimized.
WARNING
Applicability: Cameras with one or more laser pointers.
Do not look directly into the laser beam. The laser beam can cause eye irritation.
#T559157; r. AH/45951/45951; en-US 5

Safety information
2
WARNING
Applicability: Cameras with one or more batteries.
Do not disassemble or do a modification to the battery. The battery contains safety and protection devices
which, if damage occurs, can cause the battery to become hot, or cause an explosion or an ignition.
WARNING
Applicability: Cameras with one or more batteries.
If there is a leak from the battery and you get the fluid in your eyes, do not rub your eyes. Flush well with
water and immediately get medical care. The battery fluid can cause injury to your eyes if you do not do
this.
WARNING
Applicability: Cameras with one or more batteries.
Do not continue to charge the battery if it does not become charged in the specified charging time. If you
continue to charge the battery, it can become hot and cause an explosion or ignition. Injury to persons
can occur.
WARNING
Applicability: Cameras with one or more batteries.
Only use the correct equipment to remove the electrical power from the battery. If you do not use the cor-
rect equipment, you can decrease the performance or the life cycle of the battery. If you do not use the
correct equipment, an incorrect flow of current to the battery can occur. This can cause the battery to be-
come hot, or cause an explosion. Injury to persons can occur.
WARNING
Make sure that you read all applicable MSDS (Material Safety Data Sheets) and warning labels on con-
tainers before you use a liquid. The liquids can be dangerous. Injury to persons can occur.
CAUTION
Do not point the infrared camera (with or without the lens cover) at strong energy sources, for example,
devices that cause laser radiation, or the sun. This can have an unwanted effect on the accuracy of the
camera. It can also cause damage to the detector in the camera.
CAUTION
Do not use the camera in temperatures more than +50°C (+122°F), unless other information is specified
in the user documentation or technical data. High temperatures can cause damage to the camera.
CAUTION
Applicability: Cameras with one or more laser pointers.
To prevent damage, put the protective cap on the laser pointer when you do not operate the laser pointer.
Damage to the laser pointer can occur if you do not do this.
CAUTION
Applicability: Cameras with one or more batteries.
Do not attach the batteries directly to a car’s cigarette lighter socket, unless FLIR Systems supplies a spe-
cific adapter to connect the batteries to a cigarette lighter socket. Damage to the batteries can occur.
#T559157; r. AH/45951/45951; en-US 6

Safety information
2
CAUTION
Applicability: Cameras with one or more batteries.
Do not connect the positive terminal and the negative terminal of the battery to each other with a metal
object (such as wire). Damage to the batteries can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not get water or salt water on the battery, or permit the battery to become wet. Damage to the batteries
can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not make holes in the battery with objects. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not hit the battery with a hammer. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put your foot on the battery, hit it or cause shocks to it. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the batteries in or near a fire, or into direct sunlight. When the battery becomes hot, the built-in
safety equipment becomes energized and can stop the battery charging procedure. If the battery be-
comes hot, damage can occur to the safety equipment and this can cause more heat, damage or ignition
of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the battery on a fire or increase the temperature of the battery with heat. Damage to the battery
and injury to persons can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the battery on or near fires, stoves, or other high-temperature locations. Damage to the battery
and injury to persons can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not solder directly onto the battery. Damage to the battery can occur.
#T559157; r. AH/45951/45951; en-US 7

Safety information
2
CAUTION
Applicability: Cameras with one or more batteries.
Do not use the battery if, when you use, charge, or put the battery in storage, there is an unusual smell
from the battery, the battery feels hot, changes color, changes shape, or is in an unusual condition. Speak
with your sales office if one or more of these problems occurs. Damage to the battery and injury to per-
sons can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Only use a specified battery charger when you charge the battery. Damage to the battery can occur if you
do not do this.
CAUTION
Applicability: Cameras with one or more batteries.
Only use a specified battery for the camera. Damage to the camera and the battery can occur if you do
not do this.
CAUTION
Applicability: Cameras with one or more batteries.
The temperature range through which you can charge the battery is 0°C to +45°C (+32°F to +113°F). If
you charge the battery at temperatures out of this range, it can cause the battery to become hot or to
break. It can also decrease the performance or the life cycle of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
The temperature range through which you can remove the electrical power from the battery is -15°C to
+50°C (+5°F to +122°F), unless other information is specified in the user documentation or technical data.
If you operate the battery out of this temperature range, it can decrease the performance or the life cycle
of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
When the battery is worn, apply insulation to the terminals with adhesive tape or equivalent materials be-
fore you discard it. Damage to the battery and injury to persons can occur if you do not do this.
CAUTION
Applicability: Cameras with one or more batteries.
Remove any water or moisture on the battery before you install it. Damage to the battery can occur if you
do not do this.
CAUTION
Do not apply solvents or equivalent liquids to the camera, the cables, or other items. Damage to the bat-
tery and injury to persons can occur.
CAUTION
Be careful when you clean the infrared lens. The lens has an anti-reflective coating which is easily dam-
aged. Damage to the infrared lens can occur.
#T559157; r. AH/45951/45951; en-US 8
