FLO-DYNAMICS BrakeMate Programming manual

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 941523
QUICK START
INSTRUCTIONS
R
BRAKE FLUSH MACHINE
CONNECTION
CONNECTION TO M.C. RESERVOIR
SELECTING THE FLUSHING SEQUENCE
CONNECTION TO BLEEDER VALVES
PRIMING THE UNIT
Connect to a battery. Do not use jump pack or booster packs.
Remove the cap from the master cylinder reservoir. Connect the
wand adapter to the ABS line and insert into reservoir. Open the
ball valve. Press the “REMOVE FLUID” button on the control panel
and drain the master cylinder reservoir about 3/4 of the way down.
Do not drain completely! Press “STOP” when complete.
To select the sequence, press the “SELECT” button until the light is
on the wheel you want to ush rst, and press “ENTER”.
Press “SELECT” until the light is on the wheel you want to ush
second, and press “ENTER”.
Press “SELECT” until the light is on the wheel you want to ush
third, and press “ENTER”.
Press “START” to begin the ushing process.
Raise the vehicle, attach the appropriate color coded lines and
open the bleeder valves a quarter of a turn until uid begins to run
into the yellow hoses.
Connect all the suction lines and the yellow supply line to the
manifold in the front of the machine. Open the ball valve and
press “PRIME”on the control panel. Once you see uid in all of
the sight glasses, press “STOP”. The machine is ready for use.
Connect the appropriate adapter to the master cylinder reservoir.
Turn the black o-ring compressor and check to see if it is tight.
Connect the yellow supply line, open the ball valve and press the
“M/C/ PRESSURE” button. Check for leaks.
NOTE: It is normal to see air bubbles in the suction lines. This is air be-
ing drawn in around the bleeder valves.
The unit will beep and the light in front of the unit will ash when
complete.

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 941523
QUICK START
INSTRUCTIONS
R
BRAKE FLUSH MACHINE
DISCONNECT
ADD FLUID
COMPLETION
DRAIN THE WASTE TANK
REMOVE FLUID
Close the bleeder valves. Hold the “REMOVE FLUID” button down
until all 4 wheel lights come on. Remove the suction lines from the
vehicle and return them to the machine. Press “STOP”.
Lower the vehicle.
To add uid, connect the wand adapter to the supply line and
press “ADD FLUID”. Place wand into reservoir and open the ball
valve slowly to add the appropriate amount. When nished, close
the ball valve and press “STOP”.
Replace the master cylinder cap and step on the brake pedal to
assure rmness.
To drain the waste tank, connect the wand adapter to the end of
the black hose. Place in an appropriate waste container, open ball
valve, and press “DRAIN WASTE TANK”.
If you need to remove uid, connect the wand adapter to the ABS
line and place wand into reservoir. Press“REMOVE FLUID” and drain
to the appropriate level. When nished, press “STOP”.
Close the ball valve on the yellow hose. While holding a rag around
the connection, disconnect the supply line from adapter. Remove
the adapter. Check the uid level.
