FLO-DYNAMICS TSD650 DUAL Programming manual

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 942006
TS D 650 DUAL
R
TRANSMISSION
FLUID X-CHANGER
w/ DUAL TANKS
Quick Start Instructions
Press for Dipstick Exchange
ADDITIONAL FEATURES
OPERATION
CONNECTION
Check the uid level.
Press or to add or remove uid in 2/10 of a quart increments.
Use Option 3 in the main menu to add a full quart & Option 4 to remove a full quart.
Press to return to the main menu.
With the engine o, use the arrow keys to select
the desired amount to be exchanged.
Press to proceed. Press again to begin exchange.
Start the vehicle’s engine when display prompts you to do so. Press .
Once exchange is nished the screen will beep and display “Complete”.
If needed, while running, pressing once will pause the machine.
Press to resume from pause, or press a second time to cancel exchange.
Connect battery cables
to vehicle’s battery.
Connect red and gray service hoses to chrome manifold.
Insert nylon tube down dipstick tube the same length as the dipstick,
being cautious not to insert too far.
DIPSTICK Exchange
Make sure the correct tank is
selected (see Additional Functions
on other sheet).

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 942006
TS D 650 DUAL
R
TRANSMISSION
FLUID X-CHANGER
w/ DUAL TANKS
Quick Start Instructions
Check the uid level.
Press or to add or remove uid in 2/10 of a quart increments.
Use Option 3 in the main menu to add a full quart & Option 4 to remove a full quart.
Press to return to the main menu.
Once exchange is nished the screen will beep and display “Complete”.
Use the arrow keys to select the desired amount to be exchanged.
Press to proceed. Turn vehicle’s engine on.
Press to begin the exchange.
Connect appropriate adapters to vehicle’s cooler line ttings.
Connect red and black service hoses to quick disconnect adapters on the end of the
cooler line adapters.
If needed, while running, pressing once will pause the machine.
Press to resume from pause, or press a second time to cancel the exchange
CONNECTION
Press for Inline Exchange
Connect battery cables
to vehicle’s battery.
Make sure the correct tank is
selected (see Additional Functions
on other sheet).
ADDITIONAL FEATURES
OPERATION
INLINE Exchange

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 942007
R
Quick Start Instructions: Additional Functions
TS D 650 DUAL
TRANSMISSION
FLUID X-CHANGER
w/ DUAL TANKS
From the Main Menu, press to proceed to the next menu.
Press to drain the New Fluid Tank. Press to drain the Used Fluid Tank.
Press to begin the process. The unit will shut o when complete.
From the Main Menu, press to proceed to the next menu.
Press to display the voltage.
From the Main Menu, press to proceed to the next menu.
Press . Press or to select tank to be used.
DRAINING THE TANKS
Connect any open end adapter to red hose & insert
into appropriate disposal container.
Make sure all other hoses are disconnected!
Press . Press to begin the process.
The unit will shut o when complete.
PRIMING THE MACHINE
Make sure there is uid in the New Fluid Tank.
Connect the Red & Black service hoses together using any two mating adapters.
MAIN MENU
Press for Main Menu
Connect battery cables
to vehicle’s battery.
VOLTAGE MONITOR
SELECT NEW FLUID TANK

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 942007
R
Quick Start Instructions: Additional Functions
TS D 650 DUAL
TRANSMISSION
FLUID X-CHANGER
w/ DUAL TANKS
If the exchange stops and the display reads “Reverse Hoses”, turn vehicle o, switch
the red and black service hoses, restart vehicle, and press .
If the exchange stops and the display reads “Shift to Neutral”, set the vehicle’s
parking brake, shift to Neutral, and press .
From the Main Menu, press twice.
Press to display the total lter use. Press to reset.
If there is a power failure during a transmission uid exchange, the procedure can be
continuted seamlessly.
Simply reconnect the battery cables, and press .
The exchange will resume where it left o.
The machine will indicate when the canister lters need to be replaced.
Remove service panel on back of machine. Use a standard lter band clamp tool to
unscrew old lters, & replace them with new lters. Make sure new lters are on tight.
IMPORTANT: Machine must be primed after lter change.
HALTED: REVERSE HOSES
HALTED: SHIFT TO NEUTRAL
TOTAL FILTER USE
POWER FAILURE MEMORY
CYCLE VALVES
FILTER CHANGE DUE
From the Main Menu, press to proceed to the next menu.
Press to cycle the valves.

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com
Cleaning Feature
RTSD650 DUAL
TRANSMISSION
FLUID X-CHANGER
w/ DUAL TANKS
Press for No Cleaning, for 5 Minute Cleaning, or for
10 Minute Cleaning.
CLEANING OPERATION
CLEANING OPERATION
Use the arrow keys to select the desired amount to be exchanged.
Press to begin exchange.
When cleaning process is complete, shut o engine and press to continue!
Press to proceed.
Start the vehicle’s engine when display prompts you to do so. Press .
Once exchange is nished the screen will beep and display “Complete”.
Start the vehicle’s engine when display prompts you to do so. Press .
Once exchange is nished the screen will beep and display “Complete”.
Connect red and gray service hoses to chrome manifold. Insert nylon tube down
dipstick tube the same length as the dipstick, being cautious not to insert too far.
NOTE: This machine is fully interactive. Always follow the on-screen instructions.
DIPSTICK Exchange
INLINE Exchange
Connect appropriate adapters to vehicle’s cooler line ttings. Connect red & black
service hoses to quick disconnect adapters on the end of the cooler line adapters
Press for No Cleaning, for 5 Minute Cleaning, or for
10 Minute Cleaning.
Use the arrow keys to select the desired amount to be exchanged.
Press to begin exchange.
NOTE: This machine is fully interactive. Always follow the on-screen instructions.
Press to proceed.
