84606—Instruction-English 1 of 5 Printed in China
Portable Unit Heater
Model 84606 240V~60Hz 4000 WATTS
INSTRUCTION MANUAL
READANDSAVETHESEINSTRUCTIONS
Please read these instructions carefully and keep for
future reference IMPORTANT SAFETY
INSTRUCTIONS
Read Carefully-These instructions contain vital
information for the proper installation, use and
efficient operation of the heater. Carefully read
these instructions before installation, operation,
or cleaning of the heater. User should always
following this instruction to reduce the risk of fire,
electric shock, and injury to persons.
WARNING! When using electrical
appliances, basic precautions should always be followed to reduce the risk of
fire, electric shock, and injury to persons, including the following.
1．Read all instruction before using this heater.
2．Connect to property grounded outlets only. Check heater voltage
and amperage on back of heater to make sure it agree with the
electric service supplied.
3．Do not use outdoors.
4．This heater is not intended for user in wet or damp locations, never
locate heater where it may fall into a bathtub or other water
container
5．This heater is hot when in use. To avoid burns, do not let bare skin
touch hot surfaces. Always use handles when moving this heater.
Keep combustible materials, such as furniture, pillows, bedding,
For Model No: EH - 4606 (4000W)
NEMA # 6 - 20P
20 amp 240V
PLUG TYPE

84606—Instruction-English 2 of 5 Printed in China
papers, clothes, and curtains at least 3 feet (0.9m) from the front of
the heater and away from the sides and rear.
6．Extreme caution is necessary when any heater is used by or near
children or invalid and whenever the heater is left operating and
unattended.
7．Do not insert or allow foreign objects to enter any ventilation or
exhaust opening as this may cause an electric shock, fire, or
damage the heater.
8．To prevent a possible fire, do not block air intake or exhaust in any
manner. Do not use soft surface, like a bed, where openings may
become blocked. Clean as often as necessary to prevent dust from
clogging the grilles or element fins. Keep all electrical cords,
drapes, paper, plastics and other combustibles away from heater.
9．To disconnect heater, turn selector knob to off position, then
remove plug from outlet.
10．Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, etc. To prevent entanglement or damage, route cord away
from high traffic areas.
11．A heater has hot and arcing or sparking parts insides. Do not use it
in areas where gasoline, paint, or flammable liquids are used or
stored.
12．If this heater or its power cord become damaged or malfunction in
any way, unplug heater discontinue use, and have unite repaired
by a reputable repair service.
13．Do not operate heater without stand.
14．Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock.
or injure to persons.
15．Avoid the use of an extension cord because the extension cord
may overheat and cause a risk of fire. If you have to use an
extension cord, the cord shall be No. 12 AWG minimum size and
rated minimum 4000W.
16．Always unplug heater when not in use.
ASSEMBLY
This Heater has been pre-assembly in factory.
FEATURES
LIVE POWER SIGNAL LIGHT ( POWER ON LIGHT)—Glows amber
when unit is plugged in.
Thermostat Control: Off, Low, High

84606—Instruction-English 3 of 5 Printed in China
Safety Features:
Plug-- The cord has a 3-prong plug as
shown in Figure 1. No adapter is
available, and none should be used.
Prior to operating heater, make sure the
electrical outlet is of the configuration
and capacity appropriate for the heater.
See outlet configuration show at the
right. This heater is for use on 240
volts. The type outlet is a 240 volt
grounding outlet. When properly
installed, it provides a ground
connection through the cord to the
heater to protect operator from
electric shock. If you are unable to
insert the plug into the outlet, contact
an electrician.
ELECTRICAL RATINGS
This product is rated 16.7 amps (4000W) at 240 Volt AC, 60 Hz.
OPERATION
WARNING: Be careful not to direct the airstream at draperies, furniture,
or other objects that could be damaged by heat. Do not place the heater
where a small child maybe may fall over the heater. Do not place the
heater where the power cord may be walked on, tripped over or otherwise
subjected to hard usage.
1.The heater is for floor mounting. Place the heater on floor or other flat
surface free from obstructions, and at least 3 ft. (0.9m) away from any
wall or combustible material.
2. With the Thermostat Switch in the OFF position, Insert plug firmly into
proper wall outlet. Be sure plug fits tightly. A loose fit will cause
overheating and damage to the plug. Plug and cord may feel warm
during normal usage. Do not use an extension cord. Always operate
heater on its feet in the normal upright position.
3. Turn the “ THERMOSTAT” Control clockwise(right) to the “HIGH” setting
until the knob stops. The heater should begin heating and the fan should
start to blow warm air.
For Model No: EH - 4606 (4000W)
NEMA # 6 - 20P
20 amp 240V
PLUG TYPE
Figure 1
Grounding Pin

84606—Instruction-English 4 of 5 Printed in China
4. Allow the heater to operate until the room temperature reaches the
desired level, then slowly rotate the “THERMOSTAT” Control
counter-clockwise(left) until the heater cycles off. At this setting, the
heater will cycle on and off automatically to maintain this comfort level.
NOTE: Do not force knob beyond its normal stop position. It may be
necessary to make minor adjustments to the thermostat to maintain
the desired comfort level. Clockwise movement will increase the
room temperature. Counter-clockwise movement will decrease
room temperature.
5.When heater is not needed, rotate control knob to the “OFF” position,
remove the plug from outlet, and move heater to safe place for storage.
NOTE: Each time heater is used, be sure to turn knob full “On”
before turning it back to approximate setting established as most
comfortable. (Design of the thermostat requires this operation every
time heater is used).
IMPORTANT NOTE: Do not expect the heating coils on your heater
to glow. Coil elements are normally dark. Air movement over these
coils prevents glowing yet provides convection heat, similar to a
forced-air furnace. Some glow may occur where the moving air does
not directly touch the coils.
IF YOUR HEATER FAILS TO OPERATE:
Be sure it is plugged in and that the electrical outlet is working.
Check that the thermostat is not set too low, turn the thermostat up
(clockwise) until the heater restarts.
If you still notice the same malfunction mentioned above, remove the
plug from the socket and have the appliance serviced by authorized
service personnel only.
CLEANING AND STORAGE
We recommend that the heater be cleaned at least once a month and
before off-season storage.
Turn the heater OFF and unplug it. Allow it to cool.
Use a dry cloth to clean the external surfaces of the heater.
If heater is used in very dusty location, use a vacuum cleaner dust brush
or high pressure air to remove dust and other foreign material from the
grilles

84606—Instruction-English 5 of 5 Printed in China
DO NOT USEWATER, WAX, POLISHORANYCHEMICALSOLUTION.
Clean your heater using the above mentioned steps, then pack the
heater in its original container and store it in a cool dry place.
This heater does not disassemble.
•The motor is factory lubricated for life, and will require no further
lubrication.
SPECIFICATIONS
If you should have any questions regarding operation,
contact us toll-free at 1-800-295-4448
WARNING
OPERATION OF THE SAFETY THERMAL LIMIT INDICATES THE
HEATER HAS BEEN SUBJECTED TO SOME ABNORMAL
CONDITIONS. IT IS RECOMMENDED THAT THE HEATER BE
CHECKED BY A REPUTABLE ELECTRICAL OR REPAIR SERVICE TO
INSURE THE HAS NOT BEEN DAMAGED.
Model NO.
84606
Voltage /Frequency
240V ~ 60 Hz
Output Power (W) & Electric Current (A)
4000W / 16.7A
NEMA Code Receptacle
6-20P
Dimensions
280x 270x340 (mm)
Net Weight
5.7Kgs
