Fluke 323 User manual

PN 4045153
May 2012
© 2012 Fluke Corporation. All rights reserved. Printed in China.
Specifications are subject to change without notice.
All product names are trademarks of their respective companies.
323/324/325
Clamp Meter
Users Manual

LIMITED WARRANTY AND LIMITATION OF LIABILITY
This Fluke product will be free from defects in material and workmanship for two
years from the date of purchase. This warranty does not cover fuses, disposable
batteries, or damage from accident, neglect, misuse, alteration, contamination, or
abnormal conditions of operation or handling. Resellers are not authorized to
extend any other warranty on Fluke’s behalf. To obtain service during the warranty
period, contact your nearest Fluke authorized service center to obtain return
authorization information, then send the product to that Service Center with a
description of the problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH
AS FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED.
FLUKE IS NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR
THEORY. Since some states or countries do not allow the exclusion or limitation of
an implied warranty or of incidental or consequential damages, this limitation of
liability may not apply to you.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
11/99

i
Table of Contents
Title Page
Introduction.................................................................................................................1
How to Contact Fluke ................................................................................................. 1
Safety Information ...................................................................................................... 2
How to Clean the Product .......................................................................................... 9
Specifications .............................................................................................................10
Electrical Specifications.......................................................................................... 10
Mechanical Specifications ......................................................................................12
Environmental Specifications .................................................................................12
The Meter ................................................................................................................... 14

323/324/325
Users Manual
ii

1
Introduction
The Fluke 323/324/325 Clamp Meters (the Product) measure ac and dc voltage, ac current,
resistance, and continuity. The 324 and 325 can also measure capacitance and contact
temperature. The 325 can also measure dc current and frequency. Note that the 325 is shown
in all of the illustrations. For temperature measurement, you must use the included K-Type
Thermocouple.
XWWarning
Read "Safety Information" before you use the Product.
How to Contact Fluke
To contact Fluke, call one of the following telephone numbers:
•Technical Support USA: 1-800-44-FLUKE (1-800-443-5853)
•Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853)
•Canada: 1-800-36-FLUKE (1-800-363-5853)
•Europe: [phone]

323/324/325
Users Manual
2
•Japan: [phone]
•Singapore: [phone]
•Anywhere in the world: [phone]
Or, visit Fluke's website at www.fluke.com.
To register your product, visit http://register.fluke.com.
To see, print, or download the latest manual supplement, visit
http://us.fluke.com/usen/support/manuals.
Safety Information
A Warning identifies conditions and procedures that are dangerous to the user. A
Caution identifies conditions and procedures that can cause damage to the Product or the
equipment under test.
Table 1 tells you about symbols used on the Product and in this manual.
XWWarning
To prevent personal injury, use the Product only as specified, or the
protection supplied by the Product can be compromised.

Clamp Meter
Safety Information
3
To prevent possible electrical shock, fire, or personal injury:
•Use only correct measurement category (CAT), voltage, and amperage
rated probes, test leads, and adapters for the measurement.
•Do not touch voltages > 30 V ac rms, 42 V ac peak, or 60 V dc.
•Carefully read all instructions.
•Hold the Product behind the tactile barrier. See The Clamp Meter, item
.
•Do not exceed the Measurement Category (CAT) rating of the lowest
rated individual component of a Product, probe, or accessory.
•Do not measure current while the test leads are in the input jacks.
•Do not use the Product around explosive gas, vapor, or in damp or wet
environments.
•Limit operation to the specified measurement category, voltage, or
amperage ratings.
•Do not work alone.
•Do not apply more than the rated voltage, between the terminals or
between each terminal and earth ground.

323/324/325
Users Manual
4
•Comply with local and national safety codes. Use personal protective
equipment (approved rubber gloves, face protection, and flame-
resistant clothes) to prevent shock and arc blast injury where
hazardous live conductors are exposed.
•Replace the batteries when the low battery indicator shows to prevent
incorrect measurements.
•The battery door must be closed and locked before you operate the
Product.
•Measure a known voltage first to make sure that the Product operates
correctly.
•Remove all probes, test leads, and accessories that are not necessary
for the measurement.
•Only use probes, test leads, and accessories that have the same
measurement category and voltage rating as the Product.
•Keep fingers behind the finger guards on the probes.

Clamp Meter
Safety Information
5
•Connect the common test lead before the live test lead and remove the
live test lead before the common test lead.
•Remove all probes, test leads, and accessories before the battery door
is opened.
•Do not use and disable the Product if it is damaged.
•Do not use the Product if it operates incorrectly.
•Do not use test leads if they are damaged. Examine the test leads for
damaged insulation, exposed metal. Check test lead continuity.
•Before each use, examine the Product. Look for cracks or missing
pieces of the clamp housing. Also look for loose or weakened
components. Carefully examine the insulation around the jaws. See The
Clamp Meter, item .
•Examine the case before you use the Product. Look for cracks or
missing plastic. Carefully look at the insulation around the terminals.
•Read all safety Information before you use the Product.

323/324/325
Users Manual
6
•Remove batteries to prevent battery leakage and damage to the Product
if it is not used for an extended period.
•Remove batteries to prevent battery leakage and damage to the Product
if is to be stored above its operating temperature.
WCaution
To avoid possible damage to the Product or to equipment under test, use a
thermocouple rated for the temperatures to be measured. The Product is
rated for -10.0 °C to +400.0 °C and 14 °F to 752 °F. The included type-K
thermocouple is rated to 260 °C.

Clamp Meter
Safety Information
7
Table 1. Symbols
Symbol Meaning Symbol Meaning
AC (Alternating Current) JEarth ground
DC (Direct Current) ~
Do not dispose of this product as
unsorted municipal waste. Go to
Fluke’s website for recycling
information.
AC and DC Current PConforms to European Union
directives.
WRisk of Danger. Important
information. See Manual. TDouble insulated
XHazardous voltage. Risk of
electric shock. Æ
This product has been tested to the
requirements of CAN/CSA-C22.2
No. 61010-1, second edition, including
Amendment 1, or a later version of the
same standard incorporating the same
level of testing requirements.
Conforms to relevant
Australian standards. ®German certifying body.

323/324/325
Users Manual
8
Table 1. Symbols (cont.)
Symbol Meaning Symbol Meaning
MBattery ,
Application around and removal
from HAZARDOUS LIVE
conductors is permitted.
CAT III
CAT III equipment is designed to
protect against transients in
equipment in fixed equipment
installations, such as distribution
panels, feeders and short branch
circuits, and lighting systems in
large buildings.
CAT IV
CAT IV equipment is designed
to protect against transients
from the primary supply level,
such as an electricity meter or
an overhead or underground
utility service.
Note
The Measurement Category (CAT) and voltage rating of combinations of test
probes, test probe accessories, current clamp accessories, and the Product is the
LOWEST rating of individual components.

Clamp Meter
How to Clean the Product
9
How to Clean the Product
Regularly wipe the case with a damp cloth and weak detergent.
WCaution
To prevent damage to the Product, do not use abrasives or solvents to clean
the Product case.
To clean the Product Jaw:
1. Examine the jaw mating surface to make sure it is clean. If there is unwanted material
(including rust), jaw closure will not be correct and there will be measurement errors.
2. Open the jaws and clean the clamp metal ends with a lightly oiled cloth.

323/324/325
Users Manual
10
Specifications
Electrical Specifications
AC Current (Jaw)
Range
323.....................................................400.0 A
324, 325.............................................(40.00, 400.0) A
Resolution
323.....................................................0.1 A
324, 325.............................................(0.01, 0.1) A
Accuracy ................................................2.0 % ±5 digits (45 – 65 Hz)
2.5 % ±5 digits (65 – 400 Hz)
DC Current with Jaw (325)
Range......................................................(40.00, 400.0) A
Resolution ...............................................(0.01, 0.1) A
Accuracy .................................................2.0 % ±5 digits
AC Voltage
Range......................................................600.0 V
Resolution ...............................................0.1 V
Accuracy (45 – 400 Hz) ..........................1.5 % ±5 digits

Clamp Meter
Specifications
11
DC Voltage
Range ....................................................600.0 V
Resolution ...............................................0.1 V
Accuracy .................................................1 % ±5 digits
Resistance
Range
323, 324.............................................(400.0, 4000) Ω
325.....................................................(400.0, 4000, 40000) Ω
Resolution ...............................................(0.1, 1, 10) Ω
Accuracy .................................................1 % ±5 digits
Continuity Beeper
323 ....................................................≤70 Ω
324/325 .............................................≤30 Ω
Capacitance (324, 325)
Range .....................................................(100.0, 1000) μF
Resolution ...............................................(0.1, 1) μF
Accuracy .................................................1 % ±4 digits
Frequency (325)
Range .....................................................5.0 to 500.0 Hz

323/324/325
Users Manual
12
Resolution ...............................................0.1 Hz
Accuracy .................................................0.5 % ±4 digits
Trigger Level ...........................................5 to 10 Hz, ≥10 A
10 to 100 Hz, ≥5 A
100 to 500 Hz, ≥10 A
Contact Temperature (324, 325)
Range......................................................-10.0 °C to 400.0 °C
Resolution ...............................................0.1 °C
Accuracy .................................................1 % ±8 digits
Note: Temperature uncertainty (accuracy) does not include error of the thermocouple probe.
Mechanical Specifications
Size (L x W x H) .....................................(207 x 75 x 34) mm
Weight
323.....................................................265 g
324.....................................................208 g
325.....................................................283 g
Environmental Specifications
Operating Temperature...........................-10 °C to +50 °C
Storage Temp .........................................-30 °C to +60 °C

Clamp Meter
Specifications
13
Operating Humidity .................................Non Condensing (≤10 °C)
≤90 % RH (at 10 °C to 30 °C)
≤75 % RH (at 30 °C to 40 °C)
≤45 % RH (at 40 °C to 50 °C)
(Without Condensation)
Operating Altitude ...................................2000 meters
Storage Altitude ......................................12,000 meters
EMI, EMC................................................Meets all applicable requirements in EN/IEC 61326-1
Temperature Coefficients........................Add 0.1 x specified accuracy for each degree C
above 28 °C or below 18 °C
Over Voltage Category ...........................CAT IV 300 V, CAT III 600 V
Safety Compliance..................................EN/IEC 61010-1, Pollution Degree 2
EN/IEC 61010-2-032
EN/IEC 61010-031:2002/A1:2008
P
Agency Approvals ...................................ÆComplies with CAN/CSA-C22.2 No. 61010-1,
2nd edition, including Amendment 1., , ®
IP Rating .................................................IP 30 Per IEC 60529:2001; Non-operating
Batteries..................................................2 AAA, NEDA 24A, IEC LR03

323/324/325
Users Manual
14
The Meter
1
2
300V
CAT
600V
CAT
300V
CAT 600VCAT
325
TRUE RMS CLAMP METER
gtq008.eps

Clamp Meter
The Meter
15
20
OFF
ON V
Hz
AC
DC
A
k
MAXMIN
F
F
C
ON
323
324/325
gtq001.eps

323/324/325
Users Manual
16
ON
2:00
2:00
MIN
MAX
gtq002.eps
