Fluke 732C Configuration guide

Manual Supplement
© 2021 Fluke Corporation. All rights reserved. ®
Manual Title: 732C/734C Operators Supplement Issue: 1
Part Number: Web Only Issue Date: 10/21
Print Date: August 2018 Page Count: 2
Revision/Date:
This supplement contains information necessary to ensure the accuracy of
the above manual.

732C/734C Manual Supplement
10/21
1
Change #1
On page 11, under Selecting Line Voltage and Accessing the Fuse, replace steps 3 and 4 with:
3. Use the screwdriver to pry the fuse holder tab and slide out the fuse holder. The spare fuse
is on the left side of the fuse holder and is not an active part of the protection circuit.
4. Replace the fuse that is on the right side of the fuse holder. See the data on the rear panel
or Figure 2 to check for the correct fuse type and rating.
On page 14, replace the figure with:
Figure 2. Line Power Label and Fuse Location

Manual Supplement 732C/734C
2 10/21
On page 27, replace both figures:
Figure 10. 732C MONITOR/EXT BAT IN Connector Pinout
Figure 11. 732C-7001 BAT OUT Connector Pinout
On page 53, in Table 13, in the WF1 row, change the Qty to 2.
