Fluke 568 EX User manual

PN 4326622
June 2013
© 2013 Fluke Corporation. All rights reserved.
Specifications are subject to change without notice.
All product names are trademarks of their respective companies.
568 EX
Infrared Thermometer
Users Manual
Please visit our website
www.alpine-components.co.uk

LIMITED WARRANTY AND LIMITATION OF LIABILITY
This Fluke product will be free from defects in material and
workmanship for two years from the date of purchase. This
warranty does not cover fuses, disposable batteries, or
damage from accident, neglect, misuse, alteration,
contamination, or abnormal conditions of operation or
handling. Resellers are not authorized to extend any other
warranty on Fluke’s behalf. To obtain service during the
warranty period, contact your nearest Fluke authorized
service center to obtain return authorization information,
then send the product to that Service Center with a
description of the problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER
WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR
PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS
NOT LIABLE FOR ANY SPECIAL, INDIRECT,
INCIDENTAL OR CONSEQUENTIAL DAMAGES OR
LOSSES, ARISING FROM ANY CAUSE OR THEORY.
Since some states or countries do not allow the exclusion
or limitation of an implied warranty or of incidental or
consequential damages, this limitation of liability may not
apply to you.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
11/99

i
Table of Contents
Title Page
Introduction ................................................................ 1
Safety Information...................................................... 2
Features..................................................................... 5
Display ....................................................................... 5
Menu Overview ....................................................... 6
Save........................................................................ 7
Light......................................................................... 7
Memory ................................................................... 7
Emissivity Menu ...................................................... 7
°C and °F................................................................. 9
Min, Max, Avg, Differential ...................................... 9
Alarm....................................................................... 9
Trigger Lock ............................................................ 10
Laser ....................................................................... 10
Setup....................................................................... 11
Language.............................................................. 11
Backlight............................................................... 11
Time/Date............................................................. 12
Delete Data ............................................................. 13
How the Product Works............................................. 13
Product Operation...................................................... 14
Temperature Measurement..................................... 14
Find a Hot or Cold Spot........................................... 14
Distance and Spot Size........................................... 15

568 EX
Users Manual
ii
Field of View........................................................... 16
HOLD...................................................................... 17
External Contact Probe........................................... 18
Troubleshooting...................................................... 18
Maintenance.............................................................. 19
Battery Replacement.............................................. 19
Clean the Lens........................................................ 19
Clean the Case....................................................... 19
Replacement Parts................................................. 19
Specifications ............................................................ 20
General Specifications............................................ 20
KTC Specifications ................................................. 21

1
Introduction
The 568 EX Infrared Thermometer (the Product) is designed for
operation in potentially explosive areas of Zones 2 and 1 in
accordance with Directive 1999/92/EC respectively 94/9/EC
(ATEX).
Contact Fluke
To contact Fluke, call one of the following telephone numbers:
•Technical Support USA: 1-800-44-FLUKE (1-800-443-5853)
•Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853)
•Canada: 1-800-36-FLUKE (1-800-363-5853)
•Europe: [phone]
•Japan: [phone]
•Singapore: [phone]
•Anywhere in the world: [phone]
Or, visit Fluke's website at www.fluke.com.
To register your product, visit http://register.fluke.com.
To see, print, or download the latest manual supplement, visit
http://us.fluke.com/usen/support/manuals.

568 EX
Users Manual
2
Safety Information
The current operating instructions, EC Declaration of Conformity
and the Ex-certificate are available for download from the relevant
product page under http://www.fluke.com; alternatively they can be
requested directly from the manufacturer.
A Warning identifies conditions and procedures that are
dangerous to the user.
Symbols used on the Product and in this manual are explained in
Table 1. Laser safety markings are shown in Figure 1.
Note
For special safety information for use in ex-hazardous
areas, please see the additional Safety Instructions.
Warning
To prevent possible electrical shock, fire, eye
damage, or personal injury:
•Read all safety information before you use the
Product.
•Use the Product only as specified, or the
protection supplied by the Product can be
compromised.
•Do not use the product if it operates incorrectly.
•See emissivity information for actual
temperatures. Reflective objects result in lower
than actual temperature measurements. These
objects pose a burn hazard.

Infrared Thermometer
Safety Information
3
•Do not look directly into the laser with optical
tools (for example, binoculars, telescopes,
microscopes). Optical tools can focus the laser
and be dangerous to the eye.
•Do not look into the laser. Do not point laser
directly at persons or animals or indirectly off
reflective surfaces.
•Use the Product only as specified or hazardous
laser radiation exposure can occur.

568 EX
Users Manual
4
Table 1. Symbols
Symbol Explanation
Hazardous voltage. Risk of electrical shock.
Risk of danger. Important information. See manual.
Warning. Laser.
Conforms to European Union directives.
°C Celsius
°F Fahrenheit
Battery

This product complies with the WEEE Directive (2002/96/EC)
marking requirements. The affixed label indicates that you must not
discard this electrical/electronic product in domestic household
waste. Product Category: With reference to the equipment types in
the WEEE Directive Annex I, this product is classed as category 9
"Monitoring and Control Instrumentation” product. Do not dispose
of this product as unsorted municipal waste. Go to Fluke’s website
for recycling information.
Battery
Laser
Aperture
eyl08b.eps
Figure 1. Laser Safety Markings

Infrared Thermometer
Features
5
Features
•Single-spot laser sighting
•Backlight display
•MAX, MIN, DIF, and AVG temperature display
•80PK-1 K-type thermocouple (KTC) probe
•Adjustable emissivity and predefined emissivity table
•Infrared and thermocouple temperature display
•Celsius or Fahrenheit temperature display
•Tripod mount
•Standard miniature KTC connector input
•12 or 24 hour clock
•Last reading Hold (20 seconds) and auto off
•Multi-language interface
•High and low temperature alarm
•Data storage and review
•Trigger lock
Display
The Product display can show data in these languages:
•English
•German
•French
•Portuguese
•Simplified Chinese

568 EX
Users Manual
6
Menu Overview
Figure 2 shows the LCD and menu interface. Table 2 is a top-level
description of the menu.
eyl01a.eps
Figure 2. Menu Navigation
Table 2. Top-Level Menu Description
Level Softke
y
Descri
p
tion
1 Left Save Save readin
g
to memor
y
2 Left Mem Review/delete memory entries
3 Left MnMx Enable Min/Max
4 Left °C/°FToggle between C and F
5 Left (Lock) Lock the Product on
6 Left Setup Turn off/on backlight
1 Right Light Adjust backlight brightness
2 Right Set emissivity
3 Right Avg Enable Avg/Diff
4 Right Alarm Set and enable alarms
5 Right Laser Toggle the laser on/off
All Center Menu Advance the menu to the next level
