Flyron FNP-702A User manual

Flyron Technology Limited PIR Motion Sensor Activated Audio Player(FNP-702A)
www.flyrontech.com E-mail: [email protected]
1
PIR Motion Sensor Activated Audio Player
User Manual
FNP-702A

Flyron Technology Limited PIR Motion Sensor Activated Audio Player(FNP-702A)
www.flyrontech.com E-mail: [email protected]
2
1 .Features
Adopt passive infrared sensing technology
Can change audio files freely
Support power-off memorizing function
Support to play MP3 audio files with high sound quality
Automatically trigger to play sound back
Load/change audio files through a Micro SD card(TF card), easy to operate
Built-in 4Mbytes internal flash memory
Sound volume is adjustable
Built-in 3W amplifier to ensure loud and beautiful sound output
Auto sleeping circuits design, which can keep long-time standby
Built-in automatic power re-charging circuits
Plug and play type design
Built-in 500mAH lithium battery, time durable
2. Electrical parameters
Power Supply
DC5V Regulated Power Supply
3.7V Lithium battery
Working Current
Standby state(lithium battery)
≤180uA
Playing state(lithium battery)
≤320mA(typical value 150mA)
Charging Current
≤710mA
Audio Format
MP3
Code rate:16~320Kbps
Audio Output Power
8Ω/2W（typical value）
Range of Infrared
induction
≤5m（120°）
3. Product Appearance
3.1 Dimension

Flyron Technology Limited PIR Motion Sensor Activated Audio Player(FNP-702A)
www.flyrontech.com E-mail: [email protected]
3
3.2 Panel
Item No.
Name
Function Description
5
8
7
9
2
3
6
1
4

Flyron Technology Limited PIR Motion Sensor Activated Audio Player(FNP-702A)
www.flyrontech.com E-mail: [email protected]
4
1
Indicator light
Power-on initialization indication / sound updating indication /
playing indication
2
Audio output port
Connect with an external amplifier or an active loudspeaker
3
USB port
For power supply and recharge for the battery
4
TF card slot
Standard TF card socket,used for insert TF card for changing
audio files.
5
Key A
Switch to previous sound/switch to work mode A
6
Key B
Switch to next sound /switch to work mode B
7
PIR detector/sensor
Detect a human body
8
Power switch
ON:working state
OFF:off state
9
Volume wheel
Adjust the sound volume
4. Quick Guide
First install hardware according to installation diagram, ensure every parameters is normal, especial power
supply.
4.1 Installation Operation
There are hanging holes at the back of SmartSound, working with the mounting bracket, which can be easily hung
in the appropriate position. The diagrammatic drawings of the sensor are shown as below.
Top View Side View
Place the product into a predetermined position, and when someone enters the sensitive area, it automatically
plays back the sound. The sensor can be rotated 60 ° both leftward and rightward, so users can turn it to different
sensing areas according to the actual needs.
4.2 Power Supply and Charge

Flyron Technology Limited PIR Motion Sensor Activated Audio Player(FNP-702A)
www.flyrontech.com E-mail: [email protected]
5
This product uses a rechargeable 3.7V lithium battery, and it also can be connected a power
adaptor/charger(DC5V/1A) for power supply. When you connect the device to the power adaptor, the external
power charges the lithium battery and supply power to the host device in the same time. It supports battery
charging at working state and power off state.
Under working state for battery charging, the LED indicator keeps glowing and the host device will not enter into
sleep mode. It can work normally once the sensor is triggered.
Under power off state for battery charging, there is no indication. The lithium battery will be full of power after 4
hours charging.
4.3 Power-on Operation
When the device is switched on(the LED indicator is turned on), it gets into initialization for about 15 secs. During
this, it is normal that there is no any reaction from it. After that it starts to work normally that when the sensor is
triggered, it plays a pre-loaded sound automatically. The interval time is 1-3 secs between each triggering.
4.4 Load / Update Audio Files
Before you load/update new audio file to the device, firstly please prepare a PC and an empty TF card(micro SD
card) with FAT32 file system, and then put the MP3 files to the TF card though PC(any file name is available, but
can not put other files in the TF card). After MP3 files copied completely on PC, insert the TF card to the TF socket
of this product(insert the TF card according to the TF card socket label). At this moment, if you switch on the
player, after being triggered it will play the MP3 files stored in the TF card directly once the inserted TF card is
detected.
If the total time duration of all your audio files(based on 128Kbps of MP3 files) is no more than 4 minutes, you can
copy the audio files to the internal flash to save the cost of a TF card. Please follow the steps below to copy MP3
files from the TF card to the internal flash.
1). Firstly, make sure the player is switched off.
2). Insert the TF card already stored the MP3 files to the player correctly.
3). Use a finger to press Key A and hold, then switch on the player with the other hand. Don’t leave your finger on
Key A until the LED indicator starts to blink.
4). Now release Key A when the indicator starts to blink, which means the device is copying the audio files from

Flyron Technology Limited PIR Motion Sensor Activated Audio Player(FNP-702A)
www.flyrontech.com E-mail: [email protected]
6
the TF card to the internal flash memory. When the indicator turns off after a short while(The time duration
depends on the size and quantity of the files in the TF card. Normally 5-15 secs), it means the audio files are
already loaded/updated successfully.(Note:The loaded/updated audio files capacity can not be over the size of the
internal flash memory)
5). Take the TF card out of the player and re-switch on the player, it will play the copied MP3 files in the flash.
6). Use the same TF card to serve other players.
Note: If the TF card and the internal flash are available at the same time, the player always play the MP3 files in
the TF card.
If you need the audio files played according to the playing order you expect, you can follow the steps below to
make it.
1). In the PC side build a new folder, and put all the audio files which need to be loaded in the device in the new
folder.
2). Change the audio file names, beginning with 4 digits such as 0001.mp3, 0002.mp3 or 0001 welcome.mp3, etc.
3). Press "Ctrl + A" on the keyboard to select all.
4). Right click the first audio file, it will pop up a menu, then select“ send to” and select “removable disk”. Like this
way you can put the audio files to the TF card effectively by sequence.
5). The next thing to do is to load the files in the TF card to the device according to the method above.
4.5 Select Mode
This product supports A, B, and C three work modes. Users can choose the right mode according to the actual
requirements.
Mode A: Play the audio files in a loop one by one after each trigger. In another word, when the device get triggered
for the first time, it will play the first audio file, and when the device get triggered again, it will play the second audio
file just like this in a circular way one by one. After trigger to play the last audio file, it will automatically move to the
first one.
Mode B: It's a single playback mode. After each trigger, it will always play the current audio file each time. At this
time you can short press left button(key A) for PREVIOUS and right button(key B) for NEXT to select which audio
file needs to be played.
Mode C: It’s a random playback mode. After each trigger, it plays the sounds in the device randomly.
Mode Selection:1). Long press key A till the indicator light flashes. It means you successfully chose mode A.

Flyron Technology Limited PIR Motion Sensor Activated Audio Player(FNP-702A)
www.flyrontech.com E-mail: [email protected]
7
2). Long press key B till the indicator light flashes. It means you successfully chose mode B.
3). Long press key A and key B simultaneously till the indicator light flashes. It means you
chose mode C successfully.
6. FAQ
Question1: Can this product support to play WAV file ?If not ,how should we do ?
A:It only supports MP3 file, and can not support to play WAV,but can convert the WAV file to MP3 through the
following operations, then use it .
Method1:Install an audio playback software which has MP3 encoding and decoding functions,convert WAV format
to MP3 file .
Method 2: Search the MP3 file you need on the internet.
Question 2: When using this product, I found that it just played half of the voice and stopped. After a short while, it
continued to play. Like this over and over again. What's the problem ?
A: It's a power shortage problem caused by the battery. The problem will be solved after you recharge the battery.
Question 3: After power on, there is a time no response or reaction or insensitive, there are delays and so on.
What does it happen?
A: When the sensor circuit is powered on, there will be 5-15 seconds to activate the sensors, in order to prevent
the spurious triggering or destroying caused by instable voltage. During this time, no induction or very slow
reaction is normal, it will back to normal after this period of time.
Question 4: During updating audio files, sometimes I need to wait very long. what’s the problem?
A:When updating audio files last time, you switched off the power before the updating finished, then the flash
memory of the device was caused some errors. When you update audio files again, the flash memory would be
re-formatted, so time would last longer.
