HOW TO USE THE AUTOMATIC
TERRAIN ADJUSTMENT:
FMR R-Series, V-Series with
Terracing Option
SOP-FMR-Oct19-13

Manual Height Adjustment
1. Visio must be powered ON
2. Use the Bravo height adjust keys to
manually raise and lower each arm
The Automatic Terrain Adjustment (ATA) is
controlled using the “Visio” controller.
IMPORTANT: The VISIO must be powered on
for any sprayer hydraulic functions to work.
The Visio will indicate the arms are in
manual mode (M – red arrows) and will also
indicate the height of the sumps from the
ground (green arrows)
Automatic Height Adjustment
1. Turn the Visio ON
2. Press for 2 seconds to enter
Auto mode (Note both arms must be in
manual mode to enter Automatic)
The Visio will indicate the arms are in
automatic mode (A)
To revert to Manual Mode
1. Either use the Bravo to manually adjust
the arm heights or
2. Press to enter Manual mode

Adjusting the Target Height
1. Press and hold the OK button for 2
seconds. This screen is then displayed.
2. Press OK again to display this screen.
3. Use the Arrow key to select the digit to
change, then use the
key to change the digit. Press OK when
correct, then ESC multiple times to return
to the main screen.
NOTE: Note the new tracking height will
not be stored / held in the memory. It is
recommended to power down the Visio by
holding down the ESC button for 3 seconds.
Once the monitor has turned off hold the
ESC button for 3 seconds to turn on the
Visio. The tracking height will now be stored
in the memory.
