ELITE K2 POWER
Manuel d’utilisation / User manual
Français page 10
English page 13
Deutsch p 16
Italiano p 19
Español p 22
Português p 25
Nederlands p 28
Русский p 31
中文 第34页
日本語 第37页
한국어 페이지 (40)
130.ua — all for cars!
130.ua

2
ELITE K2 POWER
Manuel d’utilisation / User manual
Right output
Left output
Woofer
Tweeter
Woofer
Tweeter
Input
Input
A
Kit connection 2 voies / 2 ways kits connections
ES 100K, ES 130K, ES 165K
Right output
Left output
Woofer
Tweeter
Woofer
Tweeter
Input
Input
B
ES 165K2, ES 165KX2
130.ua — all for cars!
130.ua

3
ELITE K2 POWER
Manuel d’utilisation / User manual
C D
E
INPUT OUTPUT
INPUT OUTPUT
Left
Right
Woofer
Tweeter
Woofer
Tweeter
RCA INPUT SPEAKER OUTPUT
F
ES 165K2, ES 165KX2
ES 165K2, ES 165KX2
Connection kit 2 voies dans le cadre d’une bi-amplification / 2 ways kits connections, bi-amp using
(4 channels amplifier)
130.ua — all for cars!
130.ua

4
ELITE K2 POWER
Manuel d’utilisation / User manual
Right output
Sortie droite
Right output
Sortie gauche
Woofer
Tweeter
Woofer
Input
Entrée
Input
Entrée
Medium/Midrange
Medium/Midrange
Tweeter
G
Kit connection 3 voies / 3 ways kits connections
ES 165KX3
130.ua — all for cars!
130.ua

5
ELITE K2 POWER
Manuel d’utilisation / User manual
J
Left
Right
Woofer
Woofer
Middle
Middle
Tweeter
Tweeter
RCA INPUT SPEAKER OUTPUT
Left
Right
Woofer
Woofer
Middle
Middle
Tweeter
Tweeter
RCA INPUT SPEAKER OUTPUT
K
H I
ES 165KX3
Connection kit 3 voies dans le cadre d’une bi-amplification / 3 ways kits connections, bi-amp using
(4 channels amplifier)
130.ua — all for cars!
130.ua

6
Installation du tweeter / Fitting the tweeter
ES 100K, ES 130K, ES 165K, ES 165K2
ES 165KX2, ES 165KX3
ELITE K2 POWER
Manuel d’utilisation / User manual



L

M
130.ua — all for cars!
130.ua

7
ELITE K2 POWER
Manuel d’utilisation / User manual
Réglage des switch du filtre / Crossover settings - ES 100K
Full
12 dB
Réglage du niveau du tweeter
Tweeter level adjustment
Réglage du woofer
("Pass haut ou "Full")
Woofer high pass / full adjustment
N
Réglage des switch du filtre / Crossover settings - ES 130K, ES 165K
Pente de coupure du Woofer
Woofer low pass slope
12 dB
6 dB
+3
0
-3 dB
Réglage du niveau du tweeter
Tweeter level adjustment
O







130.ua — all for cars!
130.ua

8
ELITE K2 POWER
Manuel d’utilisation / User manual
Réglage des switch du filtre / Crossover settings - ES 165K2
+3
0
-3 dB
1
2
12 dB
6 dB
Réglage du tweeter
Réglage du tweeter (1=Extrême aigu)
Pente de coupure du Woofer
Woofer low pass slope
Pente de coupure du Woofer
Woofer low pass slope
P
Réglage des switch du filtre / Crossover settings - ES 165KX2
18 dB
Réglage du tweeter (1=Extrême aigu)
Tweeter adjustment (1=High treble)
Pente de coupure du tweeter
Tweeter high pass slope
Pente de coupure du Woofer
Woofer low pass slope
Réglage du niveau du tweeter
Tweeter level adjustment
Q


 




 




130.ua — all for cars!
130.ua

9
ELITE K2 POWER
Manuel d’utilisation / User manual
Réglage des switch du filtre / Crossover settings - ES 165KX3
Réglage du niveau tweeter
Tweeter level adjustment
Réglage du passe haut médium
Midrange high pass adjustment
Réglage du tweeter (1=Extrême aigu)
Tweeter adjustment (1=High treble)
Pente de coupure du Woofer
Woofer low pass slope
Réglage du niveau du médium
Midrange level adjustment
R
S



 

 


130.ua — all for cars!
130.ua

English
ELITE K2 POWER
User manual
Warning
Listening for a prolonged period at a high volume level over 110 dB may result in hearing loss. Exposure, even brief,
to sound at over 130 dB may result in irreparable hearing loss.
Important recommendations
First of all, check the space available for the loudspeakers (see the plans on the packaging) and then start cutting.
If the loudspeakers are to be mounted in their original place, check whether there is enough space between the
loudspeaker and the protective grating.
• Keep the loudspeakers away from metal chips and dust.
• Clean carefully prior to mounting the loudspeakers.
Warranty conditions
If you encounter problems, contact your Focal distributor first. For all Focal equipment, the warranty applicable to
France covers a 2-year period as of the purchase date and is non-transmissible in case of resale. In the event of faulty
equipment, it should be sent, at your own expense, in its original packaging to your distributor, who will then check
the equipment and determine the nature of the problem. If it is under warranty, the equipment will be returned to
you or replaced “postage paid”. Otherwise, a quote for repair will be sent to you. The warranty does not cover damage
arising from improper use or incorrect connection (e.g. burned voice coils...)
Environmental information
Your Focal-JMlab product has been designed and manufactured using high quality materials and components, which
can be recycled and reused. This symbol signifies that the electrical and electronic devices, at the end of their life,
should be disposed of separately from household waste. Please take this device to the local collection point or to a
recycling centre. You will thus contribute to environmental conservation.
Register your product online at www.focal.com/garantie and get your certificate of guaranty.
130.ua — all for cars!
130.ua

14
ELITE K2 POWER
User manual
2-channel connection Kit (Fig A)
- ES 100K, ES 130K, ES 165K
2-channel connection Kit (Fig B)
- ES 165K2, ES 165KX2
These filters have been designed for use in "bi amplification".
For "conventional" use, with the help of 2 short wires, connect the "input" terminals (IN W+ to IN T+ & IN W- to IN T-)
(Fig C & E)
2-channel Kit connections in the case of bi amplification / BI AMP using (4-channel amp): (Fig F)
- ES 165K2, ES 165KX2
3-channel connection Kit
- ES 165KX3
3-channel Kit connections in the case of bi amplification (Fig K)
- ES 165KX3
These filters have been designed for use in "bi amplification".
For "conventional" use, with the help of 2 short wires, connect the "input" terminals (IN W+ to IN T+ & IN W- to IN
T-) (Fig H & J)
Mounting of the filter
- ES 100K, ES 130K, ES 165K,
- ES 165KX, ES165KX2, ES 165KX3
The filters should be mounted (using the screws provided or with the help of double sided tape), preferably in a dry
and ventilated area.
To open the casing, unclip the cover (ES100/130/165K models) or unscrew the 4 screws (ES165K2/165KX2/165KX3
models) (Fig D & I): Warning: for this filter model please keep the 4 aluminium spacers.
Note: If access to the filters is difficult, please implement the cabling and adjustments prior to final mounting.
Installation of the tweeter (ES100K/130K/165K/165K2 kits)
There are three mounting options
1 - Mounting on the inclined pod: choose the desired tilt according to the selected place. (Fig L1)
Make a hole for the cables and screws, mount the stand with the help of the screws
included in the kit, thread the 2 wires and then mount the tweeter in its housing
(adjusted mounting). These tasks can be performed when the grating is assembled.
Warning: To remove the tweeter from this accessory, please act on the edge and, using a fine-blade tool as a
lever, remove the tweeter/plastic collar/grille assembly.
2 - Mounting in the original place: Remove the grating, disassemble the plastic collar exerting pressure in
order to remove this spare part from the tweeter body, remount the dome protective washer. (Fig L2)
The dome of the tweeter should not enter into contact with a surface or a spare part of the vehicle: Respect the
mounting of this important protective washer; this is required for all mountings without a grating in original places.
3 - Flush mounting: cut out a 40 mm in diameter hole. “Tight” adjustment (Fig L3)
Note: To mount the plastic collar, please respect the guide that ensures sound assembly of the 2 parts.
130.ua — all for cars!
130.ua

15
ELITE K2 POWER
User manual
Installation of the tweeter (Kits ES165KX2 and 165KX3)
There are two mounting options:
1 - Mounting on the inclined pod: choose the desired tilt according to the selected place. (Fig M1)
Mount the stand using the screws provided, thread the wires and then mount the tweeter in its housing (adjusted
mounting). Reinstall the grille.
2 - Flush mounting: cut out a 51 mm in diameter hole: “Tight” adjustment. (Fig M2)
The serrated steel washer (provided) maintains the pressure of the tweeter after it has been mounted in its housing.
Coaxial kit EC165 K (Fig S)
This coaxial kit is equipped with an integrated tweeter crossover (6 db/oct); please observe the general
recommendations for installation.
Warning: The tweeter post is not adjustable or rotative: it has been designed to be as compact as possible and
thus compatible with as many spaces as possible.
