Follett Maestro Chewblet 400 Series Supplement

Follett®Maestro™Chewblet®400 Series
Ice Machine and Top Kit
for Lancer countertop ice and beverage dispensers
208264
U
L
R
U
L
R
C
NSF
Installation, Operation and Service Manual
00117267R02
801 Church Lane • Easton, PA 18040, USA
Toll free [phone] • [phone]
www.follettice.com
Following installation, please forward this manual
to the appropriate operations person.
Order parts online
www.follettice.com

Welcome to Follett Corporation
Important cautions
Specications
Installation
Operation
Cleaning
Replacement Parts
Models MTL22SC, MSL22SC
Models MTL30SC, MSL30SC
2
Table of contents
3
3
4
7
15
15
17
17
18

Welcome to Follett
Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and
outstanding after-the-sale support. To ensure that this equipment delivers that same degree of service, we
ask that you review the installation portion of this manual before beginning to install the unit. Our installation
instructions are designed to help you achieve a trouble-free installation. Should you have any questions or
require technical help at any point, please call our technical service group at [phone] or [phone].
Before you begin
After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If
damage is found, notify the shipper immediately and contact Follett Corporation so that we can help in the ling
of a claim, if necessary.
Check your paperwork to determine which model you have. Follett model numbers are designed to provide
information about the type and capacity of Follett equipment. Following is an explanation of the different model
numbers in the series.
3
Important cautions
Dispenser bin area contains mechanical, moving parts. Keep hands and arms clear of this
area at all times. If access to this area is required, power to unit must be disconnected rst.
Follett recommends a Follett water lter system (part# 00130229 for the 400 series) be
installed in the ice machine inlet water line.
Ice is slippery. Maintain counters and oors around dispenser in a clean and ice-free condition.
Ice is food. Follow recommended cleaning instructions to maintain cleanliness of delivered ice.
!
MSL22SC
Ice machine configuration
SC = self-contained
Dispenser size
22 = 22" wide
24 = 24" wide
30 = 30" wide
44 = 44" wide
Dispenser manufacturer
C = Cornelius
L = Lancer
S = SerVend
Ice machine mounting
MT = Maestro top mount
MS = Maestro RIDE™ model

Specications
4
Electrical
Model number Full load amps Max. fuse size
MC400 series ice machine 115/60/1 11.0 amps 20 amps
Ambient specications
Air temperature 100 F/38 C max. 50 F/10 C min. (best performance below 80 F/27 C)
Water temperature 90 F/32 C max. 40 F/4 C min. (best performance below 70 F/21 C)
Water pressure 70 P.S.I. max. (482kPA) 10 P.S.I min. (89kPA)
Plumbing
Your new ice machine is equipped with a drain line to simplify draining the evaporator and oat reservoir. The
tube labeled “oat/evap drain” is for SERVICE USE ONLY and must NOT be connected to the ice machine drain.
Water line sizes Make up water (inlet to oat) 1/4" min.
Condenser (water-cooled only) 3/8" min.
Drain line sizes Ice machine drain 3/4" min.
Condenser (water-cooled only) 1/2" min.
Slope to drain 1/4" per foot (6mm per 30.4cm run) 1/2" min.
• Water shut-off recommended within 10 feet (3m), drain to be hard-piped and insulated
• Separate drains for ice machine and condenser. To prevent back ow, do NOT connect drains.
• Follett recommends installation of a Follett water lter system (part# 00130229) in ice machine inlet water line
Field Wiring: countertop and wall mount dispensers with RIDE™ remote
ice delivery model ice machines
Consult enclosed D400A/W, R400A/W, MCD400A/W manual.

20.75" (527 mm)
22.75" (578 mm)
13.00"
(331 mm)
4.875"
(124 mm)
2.375"
(61 mm)
1.875" (48 mm)
7.00" (178 mm)
A
A
B
B
F
F
D
E
C
A
B
C
C
17.00"
(432mm)
20.75" (527 mm)
17.00"
(432 mm)
L
U
L
U
RR
NSF
NSF
Front view — air-cooled
remote mount
Side view — air-cooled
remote mount
Top back view — air-cooled
top mount
Front view — water-cooled Side view — water-cooled
12.875"
(327 mm)
4.75"
(121 mm)
8.375"
(213 mm)
2.25"
(57 mm)
1.875" (48 mm)
6.875"
(175 mm)
2"
(51 mm)
5
Dimensions and clearances
Required clearances – MCD400 series
Entire front of ice machine clear of obstruction/connections to allow removal.
12" (305 mm) above ice machine for service
6" (153 mm) minimum between louvered (exhaust) side of ice machine and any adjacent equipment.
MCD400AHS – 18" (457 mm) minimum, 10 ft (3 m) maximum between discharge and air intake grilles.
A– 3/4" MPT drain
B– 3/8" OD push-in water inlet
C– Electrical cord
D– 3/8" FPT condenser inlet
E– 1/2" FPT condenser drain
F– Bin signal cord

Installation
1. Install Lancer ice dispenser according to manufacturer’s specications.
Note: We recommend that the dispenser back be mounted at least 1" (26mm) from wall to allow water, drain
and electric lines from top mount ice machines to be concealed behind dispenser.
2. Disconnect power to dispenser.
3. Remove front panel/merchandiser from the dispenser.
4. Adjust the agitation timer located on Lancer PC board to 1 second on (Fig. 1.1) – 2 1/2 hours off (Fig. 1.2).
6
PRESS IN ON
THIS SIDE TO
TURN SWITCH
ON.
SWITCH
ON
SWITCH
OFF
PRESS IN ON
THIS SIDE TO
TURN SWITCH
OFF.
ROCKER
SWITCHES
(VIEW LOOKING
DOWN)
SIDE VIEW
SIDE VIEW
1 2 3 4 5 6 7 8
OFF
SWITCH
NUMBER
AGITATION FREQUENCY
NO AGITATION
10 MINUTES
20 MINUTES
30 MINUTES
40 MINUTES
50 MINUTES
60 MINUTES
70 MINUTES
80 MINUTES
90 MINUTES
100 MINUTES
110 MINUTES
120 MINUTES
130 MINUTES
140 MINUTES
150 MINUTES
5
6
7
8
O
O
O
O
O
O
O
X
O
O
X
O
O
O
X
X
O
X
O
O
O
X
O
X
O
X
X
O
O
X
X
X
X
O
O
O
X
O
O
X
X
O
X
O
X
O
X
X
X
X
O
O
X
X
O
X
X
X
X
O
X
X
X
X
SWITCH
NUMBER
AGITATION TIME
1 SECOND
2 SECONDS
3SECONDS
4SECONDS
3
4
O
O
O
X
X
O
X
X
X = ON
O = OFF
1
2
Fig. 1

7
Agitation adjustments - Lancer FS Series
Major/Minor
FS-16 Setup
Config Bonus Key
Soda/Plain Water
Config Dispense Only
PC Mode
PC Time
Ice Stir Off
Ice Stir On
Sold Out
Carb Sensors
Ice Bin Sensors
Valve Code Version
Number Of Valves
Reset Defaults No Yes
Reload Defaults?
1 2 3 4
12 0.104 0.104
1000
Ice Bin Optic
Upper Lower
Sold Out #1
Selection Sold Out
05000
On Time (MSEC)
Off On
Set PC Mode Menu
V:1 B1 DLY1
Dispense Delay
V:2 1:S 2:W 3:S 4:W
V:1 T:F M:S B:W
Bonus Key Setup
Brands Per Side
V:1 L:2 R:1
FS-16 Setup
FS-16 Setup
FS-16 Setup
FS-16 Setup
FS-16 Setup
FS-16 Setup
FS-16 Setup
FS-16 Setup
FS-16 Setup
FS-16 Setup
FS-16 Setup
FS-16 Setup
FS-16 Setup
Soda/Plain Water
OFF Time (MIN)
00150
On Time (MSEC)
01000
1000 500
34 0.104 0.104
On On On On
V:1 B:1
Sold Out #1
Off
Sold Out #1
Ver. 0.200
Lancer FS-16
Sub-CatagoryMain Menu
Initialization Screen
2nd Sub-Catagory
(Boot Up Only)
Cancel Enter
Scrolls through Main Menu
Press "Enter" to enter sub-catagory
Moves curser to right or left
Changes value (number/letter)
Press "Enter" to enter save changes
Press "Cancel" to exit menu
➊
Lancer FS series only
1. Hold down "cancel" and "left button" to get to hidden menu ➊.
2. Type in code 6655.
3. Type in 150 minutes of off time and 1000 milliseconds (1 second of time) as the preferred setting.
Note: See Lancer manual for more information.

208264
UL
R
UL
R
C
NSF
Fig. 4
Top mounted ice machine installation
9. Position Follett MCD400AHT ice machine on perimeter
gasket of stainless steel top. Ice machine should be
oriented with A/C condenser facing front (Fig. 4).
8
8. Install supplied stainless steel top with access opening
toward front of dispenser (Fig. 3).
For dispensers with top mounted ice machines
Proceed with steps 9 through 17.
For dispensers with RIDE model ice machines
Go directly to step 18.
Fig. 3
5. Reinstall front panel.
6. Remove existing plastic top from dispenser and install
supplied gasket around perimeter of dispenser top
(Fig. 2).
7. Sanitize dispenser before proceeding.
gasket
Fig. 2

Fig. 5
10. Use pliers to compress and remove cage nut at front
of condenser on ice machine base (Fig. 5.1).
11. Install lter and grille. Lock in place using four
mounting screws (Fig. 5.2).
Fig. 6
9
ModuleNo.
ModuleNo.
Product
Product
StockModuleIdentification Plate
StockModuleIdentificationPlate
208264
208264
ServiceNo.
ServiceNo.
MIN.BRANCHCIRCUITAMPACITY
MIN.BRANCHCIRCUITAMPACITY
DESIGNPRESSUREHIGHSIDE
DESIGNPRESSUREHIGHSIDE
MAX.BRANCHCIRCUITFUSESIZE
MAX.BRANCHCIRCUITFUSESIZE
AIROUT
AIROUT
VOLTS
VOLTS
EastonPennsylvania
EastonPennsylvania
MOTORCOMPRESSORTHERMALLY PROTECTED
MOTORCOMPRESSORTHERMALLYPROTECTED
THEUSA
THEUSA
MADEIN
MADEIN
SINGLE
SINGLE
LOWSIDE
LOWSIDE
CHARGE
CHARGE
OZ
OZ
PSIG
PSIG
C
C
R
R
R
R
PHASE
PHASE
AMPS
AMPS
HZ
HZ
PARTNO
PARTNO
AMPS
AMPS
FULLLOADAMPS
FULLLOADAMPS
CORPORATION
CORPORATION
REFRIGERANT
REFRIGERANT
SERIALNO
SERIALNO
MODEL
MODEL
AIRIN
AIRIN
U
U
U
U
L
L
L
L
NSF
NSF
1
filter
grille
2
2
Power
A
B
C
Top back view – air-cooled
top mount
3/8" OD
water inlet
Drain
3/4" MPT
12. Make water, drain and electric connections to
ice machine (Fig. 6).
Note: Water connection accepts 3/8" OD
copper or plastic tubing. Push tubing in
until it stops. Use supplied 90˚ push-in
water inlet tting if there is not enough
clearance behind ice machine to install
water tubing without kinking tubing or
putting stress on tting.
Note: Follett recommends the installation
of a Follett water lter system (part#
00130229) on supply water inlet.

Fig. 7
10
13. Remove ice machine top panel and louvered side
panel.
14. Insert ice transport tube to a 1/2" (13mm) depth
through mounting bracket (Fig. 7 and 8.1) and
secure transport tube away from condenser fan
under oat reservoir bracket
(Fig. 8.2).
15. Tighten clamp screw on ice machine base securely
(Fig. 8.3).
16. Uncoil capillary tube from bin thermostat and route
through hole in gasket to mounting bracket and
secure as shown (Fig. 7).
17. Reinstall ice machine louvered side panel and top
panel.
GO TO STARTUP – STEP 27.
ice transport tube
bin thermostat
1/2"
2"
Fig. 8
2
1
3tighten
clamp
screw
insert ice
transport
tube
