Horizon Elite™Ice Machine Models with RIDE®Technology
Installation Instructions for Ice Manager™Diverter Valve
HCD/HCF1010RMS, HCD/HCF1410RMS,
HCD1010NMS, HCD1410NMS
(See model number congurator on page 2 for details.)
01113372R00
801 Church Lane • Easton, PA 18040, USA
Toll free [phone] • [phone]
www.follettice.com
Ice Manager
Diverter Valve
(1) Horizon™
Chewblet®Ice Machine
(purchased separately)
(2) ice storage units
(purchased separately)
Any combination of bins or dispensers
Ice Manager
Control Panel
Lane 1
Lane 2
remote condensing

2remote condensing ICE MANAGER
ConfigurationApplication
S RIDE™
(RIDE remote
ice delivery
equipment)
T Top-mount
400 up to
454 lbs
(206kg)
1000/1010
up to
1036 lbs
(471kg)
1400/1410
up to
1450 lbs
(658kg)
1650 up to
1580 lbs
(717kg)
V Vision™
H Harmony™
B Ice storage bin
J Drop-in
M Ice Manager
diverter valve
system
CondenserSeriesVoltageIcemaker
C 208-230/60/1 (icemaking head)
Self-contained only.
D 115/60/1 (icemaking head)
Self-contained and remote. If remote
unit, high side is 208-230/60/1.
E 230/50/1 (icemaking head)
Self-contained only.
F 115/60/1 (icemaking head)
Remote only. High side is
208-230/60/3.
MC Maestro™
Chewblet®
(400 Series)
HC Horizon
Chewblet
(1000, 1400,
1650 Series)
HM Horizon
Micro Chewblet
HC 1400C SVA
A Air-cooled, self-contained
W Water-cooled, self-contained
R Air-cooled, remote condensing unit
N Air-cooled, no condensing unit for
connection to parallel rack system
Chewblet
®
Ice Machine Model Number Configurations

3
ICE MANAGER remote condensing
Front cover
7
Internal connection
6
External connection
5
Louvered docking assembly
3
Site preparation
2
Unpack
1
After thorough review of Ice Manager site survey, read and complete
Horizon ice machine installation sections 1 through 6.
For connection to Ice Manager diverter valve system
refer to Ice Manager installation guide.
Horizon ice machine for use with Ice Manager diverter valve system
The Ice Manager diverter valve system delivers ice to two ice storage units enabling a single Follett
Horizon ice machine to meet demand for ice at two locations. The system’s sensors monitor ice levels
in each storage unit and automatically switch ice delivery to the appropriate location.
Ice transport tube
4

4remote condensing ICE MANAGER
Carefully unpack and inspect the contents of your Follett ice machine. 1
Unpack
7/16"
7/16"
➊ ➋
➌➍
➎ ➏
Unpack ice machine
1. 1

5
ICE MANAGER remote condensing
Prepare the installation site. 2
Site preparation
2.1
Provide drainage, water supply and electrical power to within 6 feet (2m) of ice
machine in accordance with local and national codes. Outdoor installation is
not recommended and will void warranty.
Electrical ➊
• 120/60/1-5 amps
Potable water supply ➋ (3/8” push-in internal connection, 3/8” OD tubing required)
• 10-70 psi (69-483kpa)
• 45-90 F (7-32 C)
• Follett recommends the use of an in-line water ltration system (item# 00130286)
• This equipment is to be installed with adequate backow protection to comply with applicable
federal, state, and local codes
Drain ➌ (3/4” MPT)
• The drain line from the ice machine must have at least 1/4” per foot pitch (6,4 mm/0,3 m)
Refrigeration lines ➍
• 5/8” ∅ (15,8 mm) diameter suction line (insulated) ➍
• 3/8” ∅ (9,5 mm) liquid line ➎
Installation site requirements
2.1
➎
➍
3/8" ∅ (9,5mm)
NEMA
5-15
➋
➊
➋
➌
1'
1/4" per foot
(6,4 mm per 0,3 m)
5/8" ∅ (15,8 mm)

6remote condensing ICE MANAGER
Install the louvered docking assembly.
Louvered docking assembly 3
Machine stand accessory
Wall bracket accessory
3/8˝ ∅
high pressure
line
1010, 1410:
5/8" ∅ low pressure line
1" (25,4 mm)
Stub Typ
1.88" (47,8 mm)
3.38" (86 mm)
2" (50,8 mm)
➋
➊
➊
• Mount louvered docking assembly ➊
• “Rough-in” the refrigerant piping ➋
2.1 Louvered docking assembly
3.1
• Mount louvered docking assembly to wall
bracket accessory
• Mount louvered docking assembly to
machine stand accessory

7
ICE MANAGER remote condensing
No Lip
➋
Access panel/
door on counter
3.25" (83 mm) min.
➊
➌
24" min.
(609 mm
22.25" min.
(656 mm)
CROSSBRACE
Top View
DOCKING STATION
• Position and screw louvered docking assembly to the bottom of counter inside of access panel/
door min. of 3.25" (83 mm) from the front edge of the cross brace ➊
• The mounting surface for the louvered docking assembly must be solid.
Do not mount directly onto runners or channels.
• There must be no lip or edge that would hinder the ice machine from sliding in or out of the
louvered docking station ➋
• Ice machine must be installed facing forward as shown for service accessibility ➌
Undercounter installation requirements
4.2

8remote condensing ICE MANAGER
Ice transport tube
Install the ice transport tube. 4
1/4"
1'
➍
➏
➐
➊
➋
➌
➎
Hot Water
160 F (71 C)
Ice transport tube tips
• Insulate entire length of ice transport tube ➊
• Secure ice transport tube ➋as needed to prevent dips and traps from forming.
For long tube runs see guide on page 15.
• Pitch ice transport tube at least 1/4" per foot (6,4mm/.3m) ➌
• Ice transport tube must drain towards ice machine
Ice transport tube to Ice machine
• Be sure tube ends are square ➍
• Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with pliers ➎
before making connection to ease assembly
• Push ice transport tube onto ice machine nipple ➏
• Install hose clamp ➐
Ice transport tube installation.
4.2

9
ICE MANAGER remote condensing
Connect utilities to louvered docking assembly. 5
External connections
CAUTION
• Plug must be accessible after nal installation.
➋
➊
➌
• Remove access panel if necessary.
• Install drain line ➊.
The rigid drain line from the ice machine
must have at least 1/4" per foot pitch
(6,4mm/0,3m).
 • Rough-in ice machine potable water
supply ➋.
3/8” push-in connection will be made at
shut-off valve inside machine.
• Apply Petrogel to barbed drain tting ➌
• Replace access panel.
Water and drain
5.1
➊
• Braze supplied expandable refrigerant
lines in place ➊
Refrigerant
5.2

10 remote condensing ICE MANAGER
Connect louvered docking assembly to ice machine. 6
Internal connections
➊
• Braze refrigerant lines ➊
Refrigeration lines
6.3
➊
➋
• Slide ice machine into louvered docking
assembly ensuring that drain tube is fully
seated on barbed drain tting ➊
• Insert ice transport tube all the way into
coupling and tighten nut rmly ➋
Ice transport tube installation
6.1
➋
➊
• Insert potable water line into valve ➊
Water line
6.2
• Remove twist tie
• Carefully pass cord thru opening and plug
into wall outlet
Power cord
6.4
