Follett Horizon HCD700RHT User manual

Horizon™
remote air-cooled condensing 700 series Chewblet® ice machine
Horizon remote 700 series ice machine
For use with
1Install/mount Condenser V/Hz/Ph Item number
ice storage bin
top mount
with 115/60/1 HCD700RBT
without 115/60/1 HCD700NBT
RIDE
with 115/60/1 HCD700RBS
without 115/60/1 HCD700NBS
Follett Vision™
undercounter
ice & beverage
dispenser
RIDE
with 115/60/1 HCD700RVS
without 115/60/1 HCD700NVS
Cornelius PR150
undercounter ice &
beverage dispenser
2
RIDE
with 115/60/1 HCD700RPS
without 115/60/1 HCD700NPS
countertop
ice & beverage
dispenser
(by others)
top mount
3
with 115/60/1 HCD700RHT
without 115/60/1 HCD700NHT
RIDE
with 115/60/1 HCD700RHS
without 115/60/1 HCD700NHS
drop-in dispenser
(byothers) RIDE
with 115/60/1 HCD700RJS
without 115/60/1 HCD700NJS
1Ordered separately
2Not compatible with Micro Chewblet ice
3Requires Harmony™top kit (see page 5 for part number)
NOTE: For Micro Chewblet ice, replace second character (C) with an M e.g.
HMD700RBT
801 Church Lane | Easton, PA 18040, USA
1.800.523.9361 | 1.610.252.7301 | follettice.com
Features
Horizon Chewblet ice machine with up to 675lb(306kg)
dailyproduction of popular Chewblet ice
- automatically transport ice through a tube with RIDE®
technology from up to 75' (22.8 m) away
- chewable, compressed nugget ice is preferred over cubes1
- Chewblet ice dispenses reliably from ice and
beveragedispensers
- available with approximately 1.00" (2.54 cm) long
standard Chewblet ice or optional 3/8" (0.95 cm) long
MicroChewblet™ice
- meets 2018 Department of Energy regulations
- water and energy ecient
- quiet production without noisy harvest cycles
Durable, attractive ice machine
- regular bearing inspection or replacement is not required
- easy-to-read LED operating status and diagnostic display
- smooth contours for aesthetically appealing appearance
Designed with sanitation in mind
- Agion® silver-based antimicrobial product protection of
key iceand water contact components
- aluminum-bronze evaporator has antimicrobial properties
- automatic self-flushing reduces water scale buildup
- floatless, sealed design inhibits formation of biofilms
- semi-automatic cleaning and sanitizing system
Certifications
Warranty
- 3 years parts and labor, 5 years compressor parts
Short form specification:
Ice machine to be a Follett® Horizon Chewblet ice machine model
________________ [Insert size/series,condenser type & installation/
mounting, from model number guide] remote 700 without remote
condensing unit (for connection with rack system) with remote air-cooled
condensing unit capable of producing compressed nugget ice using an
ecient, sanitary horizontal evaporator/auger system and delivering ice
by a flexible wire reinforced transport tube to ice storage bin, iceand
water dispenser, ice and beverage dispenser, drop-in dispenser and
provided with a stainless steel frame and exterior, slide-out evaporator
with utility docking station, front-mounted unit status display, automatic
self-flush, and semi-automatic cleaning and sanitizing system, plusall the
featureslisted:
Accessories
Harmony conversion top kit for ice and beverage dispensers
(listed onpage 5)
Water filters (refer to form# 9905)
Wall mount bracket (item# 00997098)
Ice machine stand, height-adjustable (item#00997080)
Timer to control one or two Horizon ice machines
(item#00967265)
Longer ice transport tube (10'/3 m provided as standard
for RIDE models) – Specify length: ____ft/m in 5'/1.5 m
increments
35' (10.7 m) refrigeration lines (item# 00193227 – not
precharged)
SafeCLEAN Plus™ice machine cleaner (item#01050863)
1Independent third party studies. Contact Follett for details.
2Disclaimer: Antimicrobial protection is limited to the treated components and does not treat water or ice.
Job
Item

2
Form# 6190 Remote 700 series ice machine
Evaporator specification
W1 Width 22.70" (57.7 cm)
Fits 22.00" wide dispensers
D1 Depth 24.25" (61.6 cm)
H1 Height 21.25" (54.0 cm)
C1 Electrical
115 V /60/1
1.2 amps, requires dedicated
15amp circuit,
6.5' (2 m) cord, NEMA 5-15 plug
C2 Ice transport tube see page 6 for details
C3 Water inlet 3/8" OD push-in water inlet
C4 Drain 3/4" MPT, vented T required
C5 Ice bin signal cord for Vision applications only
C6 Suction line 5/8"
C7 Liquid line 3/8"
Water temperature 45 - 90 F (7 - 32 C)
Potable water pressure 10 - 70 psi (69 - 483 kpa)
Ice production see ice production charts on page 8
Energy consumption
90 F (32 C) air,
70 F (21C) water
air-cooled models – 5.2 kWh
per 100lb(45.4 kg) ice
Water consumption 12 gal (45.4 L) of potable water per
100lb (45.4 kg) of ice (per AHRI
test standards. 12.5 gal (47.3 L)
including periodic flushing.
Approximate ship weight 125 lb (57 kg)
NOTE: For indoor use only
Evaporator dimensional drawing
W1
D1
H1
G
C1
C2
C5
C3
C4
C6 C7
9.00"
(22.86 cm)
2.56"
(6.50 cm)
3.29"
(8.36 cm) 7.12"
(18.08 cm)
9.12"
(23.16 cm)
2.75"
(6.98 cm)

3
Form# 6190
Remote 700 series ice machine Remote 700 series ice machine
Condenser specification
W1 Width 36.25" (92.1 cm)
D1 Depth 25.50" (64.8 cm)
H1 Height 26.10" (66.3 cm)
Electrical 208-230 V, 60 Hz
Maximum circuit HVACR break size 15 A
Minimum circuit ampacity 10.7 A
Air temperature -20 - 120 F (29 - 49 C)
Maximum refrigerant line
run length
100' (30.5 m)
Maximum line rise above
evaporator
35' (10.7 m)
Evaporator mounting above
condenser
15' (4.6 m)
Evaporator mounting maximum
refrigeration line drop
15' (4.6 m)
Cooling capacity for ice machines
connected to ride systems
5200 BTU/hr
Rack systems (EPR valve to be
supplied by installer)
set to 0 F (-18 C)
Ice production see ice production charts on page 8
Approximate ship weight 225 lb (102.0 kg)
NOTE: For outdoor use only
1. Condensing units have a liquid suction line heat exchanger. The entire
liquid line should be insulated separately from the suction line.
2. Outdoor installation of low side is not recommended and will void
warranty.
Condenser dimensional drawing
W1
D1
H1

4
Form# 6190 Remote 700 series ice machine
1 – Locating the ice machine
Horizon self-contained Chewblet ice machines allow top-mounting or mounting in a base cabinet, on a wall or on a floor stand up to
75' (22.9 m) from the dispenser or ice bin with RIDE technology. In-cabinet mounting (RIDE applications) require special attention to
service access and ice tube runs (see pages 5-6).
Top mounting – ice and beverage
dispensers (by others)
RIDE model – Follett low-profile
Vision and Cornelius PR150 ice and
beverage dispensers
Top mount on
Follett ice storage bins
Important specifier notes: Important specifier notes: Important specifier notes:
1. Dispenser must be compatible with
nugget ice. See page 5 for compatible ice
and beverage dispenser models and top
kitnumbers.
2. Verify ceiling or soffit height to ensure
sufficient top clearance.
1. See page 5-6 for critical clearance
requirements.
2. Ice transport tube ships with Vision ice and
beverage dispenser (Vision applications only).
3. Ice transport tube ships with Horizon series
ice machine for Cornelius dispensers.
1. See form# B300 for bin sizing.
2. Verify ceiling or soffit height to ensure
topclearance.
3. Locate floor sink or grate and drains in front
of storage bin.
4. Do not position bin drain lines to block
Ice•DevIce™bin cart.
RIDE model – ice and beverage
dispensers (by others)
RIDE model – drop-in beverage
dispensers (by others)
RIDE model –
Follett ice storage bins
Important specifier notes: Important specifier notes: Important specifier notes:
1. See page 5-6 for critical clearance
requirements.
2. Dispenser must be compatible with nugget
ice. Compatible dispensers include Servend
MD150/175/200/250, SV175/200/250,
MDH-402 and Follett Symphony Plus™
110CM, as well as the dispensers listed on
page 5.
3. Top kit MSF30SC required with Coca-Cola
Freestyle 7000. Top adapter 46412 and ice
kit 46430 must also be ordered from Coca-
Cola. Consult with Coca-Cola and Follett to
qualify application prior to ordering.
4. RIDE application is approved only for Pepsi
Spire 3.0 and 5.0 designed for top mount
ice machines and requires MSP24SC for 3.0
and MSP30SC for 5.0, ordered separately. For
manual fill versions of PepsiSpire 3.0 and 5.0,
contact factory.
1. See page 5-6 for critical clearance
requirements.
2. Compatible with the following dispensers:
Cornelius 1522, 1722, 2323 and Lancer 2200,
2300, 23300.
3. Requires 12.00" (30.5 cm) of access space for
installation on transport tubeside.
1. See form# B300 for bin sizing.
2. Locate floor sink or grate and drains in front
of storage bin.
3. Do not position bin drain lines to block
Ice•DevIce bin cart.

5
Form# 6190
Remote 700 series ice machine Remote 700 series ice machine
1 – Locating the ice machine (continued)
Top mounting – compatible ice and beverage dispensers1
Manufacturer Model Number Width in (cm) Depth2 in (cm) Height3 in (cm) Harmony top kit
Coca-Cola
dispensers
Freestyle 7000 30.10 ( 76.5) 33.11 ( 79.0) 47.00 (119.4) HTF30SC-7F 4, 5
Freestyle 9000 25.50 ( 64.8) 35.50 ( 90.2) 73.75 (187.3) HTF24SC-7F 4, 6
Cornelius
dispensers
DB/ED/DF 150 series 22.00 (55.9) 30.75 (78.1) 35.63 (90.5) HTC22SC-7F
DB/ED/DF 175 series 24.50 (62.2) 30.00 (76.2) 35.63 (90.5) HTC24SC-7F
DB/ED/DF 200 series 30.00 (76.2) 30.95 (78.6) 35.63 (90.5) HTC30SC-7F
DB/ED/DF 250 series 30.00 (76.2) 30.95 (78.6) 39.63 (100.7) HTC30SC-7F
DB/ED/DF 300 series 44.38 (112.7) 30.00 (76.2) 39.63 (100.7) HTC44SC-7 (F or B) 7
FlavorFusion / Overload 30.00 (76.2) 33.00 (83.82) 41.00 (104.1) HTC30SC-7F-FF
IDC215 30.00 (76.2) 29.88 (75.9) 36.69 (93.2) HTC30SC-7F-IDC
IDC255 and Pro Fast Gate 30.00 (76.2) 33.13 (84.2) 39.75 (101.0) HTC30SC-7F-IDC 8
Lancer
dispensers
4500-22N 22.00 (55.9) 30.50 (77.5) 36.66 (93.1) HTL22SC-7F
4500-30N / Chewable ice dispenser 30.00 (76.2) 30.50 (77.5) 36.66 (93.1) HTL30SC-7F
FS-22N 22.00 (55.9) 30.50 (77.5) 41.28 (104.8) HTL22SC-7F
FS-30N 30.00 (76.2) 30.50 (77.5) 41.28 (104.8) HTL30SC-7F
FS-44N 44.75 (113.7) 30.38 (77.2) 42.72 (108.5) HTL22SC-7F 9
Sensation 30" 30.00 ( 76.2) 31.00 ( 78.7) 38.25 ( 97.2) HTL30SC-7F-STP
Touchpoint 32.50 ( 82.6) 33.70 ( 85.6) 40.00 (101.6) HTL30SC-7F-STP
Pepsi
dispensers
Spire 3.0 27.00 ( 68.6) 35.00 ( 88.9) 38.12 ( 96.8) HTP24SC-7F
Spire 5.0 30.50 ( 77.5) 36.00 ( 91.4) 42.75 (108.6) HTP30SC-7F
Servend
dispensers MDH-302 42.75 (108.6) 30.50 (77.5) 35.16 (89.3) HTS44SC-7 (F or B) 7
1All approved dispensers can be filled with a RIDE model Horizon ice machine without a top kit except Coca-Cola Freestyle 7000 and Pepsi Spire 3.0 and 5.0, see page 4 for details.
2Requires minimum 1.00" (2.54 cm) clearance between back of dispenser and wall.
3Net height after installation of top kit (excluding height of ice machine).
4Consult with Coca-Cola and Follett to qualify application prior to ordering.
5 Top adapter 46412 and ice kit 46430 must also be ordered from Coca-Cola.
6Adapter must also be ordered from Coca-Cola. KO IC Code: 46010 (Silver), 46011 (Red) or 46012 (Black).
7Specify “F” for front facing, or ”B“ for backward facing units.
8Contact factory regarding IDC Pro.
9FS-44N consists of 2 separate 22.00” (55.9 cm) dispensers. A top kit is needed for each Horizon ice machine ordered.
2 – Undercounter/in-cabinet mounting
Cabinet details
Important specifier notes
Cabinet base
must be flat & free of obstructions
(no lip or utilities to block removal)
Cabinet door opening
24.00"W x 22.25"H
(60.9 cm x 56.5 cm) minimum
slides
out
1. Cabinet door opening
must meet minimum size
requirements shown and be
free of obstructions to allow ice
machine to slide out (no lip or
utilities to block removal).
2. Cabinet base must be capable
of supporting ice machine and
allow ice machine to rest flat on
cabinet bottom.
3. No counter supports, electric or
plumbing can run in front of the
ice machine.

6
Form# 6190 Remote 700 series ice machine
4 – Horizon ice machine mounting accessories
Optional wall mount bracket Optional machine stand Important specifier notes:
22.00"
(55.9 cm)
25.50"
(64.8 cm)
23.00"
(58.4 cm)
13.00"
(33.0 cm)
18.70"
(47.5 cm)
22.25"
(56.5 cm) 16.50"
(41.9 cm)
6.88"
(17.48 cm)
1. For secure wall mounting, specify
optional wall mount bracket.
2. Wall and fasteners must support the
weight of the ice machine, bracket,
supply water and ice. Use of a backing
board may be required with hollow wall
construction.
3. Machine stand mounting adds 6.88"
(17.48 cm) to height of ice machine.
4. No dips in tube routing allowed.
5. Ice transport tube needs minimum 1/4"
per foot (2 cm per meter) pitch toward
ice machine and should be secured to
prevent dips and traps from forming.
5 – Horizon ice tube runs - specifier guidelines
Long tube runs for RIDE remote ice delivery equipment
1/4"
1'
maximum
2' (60.9 cm)
beverage
dispenser
wall-mounted
ice machine
support
straps
transport tube slope
(toward ice machine)
(2 cm per meter)
minimum of
6.00" (15.24 cm)
turn/corner
radius
ice transport tube –
1 3/16" OD,
2 1/8" OD with insulation
Important specifier notes:
1. 75' (22.8 m) maximum ice transport
tuberun.
2. Tubing routing bends must have a
6.00"(15.24 cm) radius or larger.
3. Dips and traps are not allowed. If not
supported from underneath, secure
insulated ice transport tube at least
every2' (60.9 cm) to prevent drips
andtraps.
4. Relative humidity levels above 80%
in areas where the ice machine or ice
transport tube is located may produce
excessive condensation that will cause
water damage.
5.
Contact factory for recommendations
on running tubing through a decorative
soffit orchase.

7
Form# 6190
Remote 700 series ice machine Remote 700 series ice machine
Remote condensing unit
Condensing unit installation specifications
Important specifier notes:
48.00"
(121.9 cm)
24.00"
(61.0 cm)
48.00"
(121.9 cm)
24.00"
(61.0 cm)
air in
exhaust
1. Provide front, back and side clearances
asshown.
2. The maximum refrigerant line run length is
100' (30.5 m). Installations with up to 50'
(15.2 m) line run require:
700 Series – 8 lb (4 kg) of refrigerant
Consult installation manual for correct
refrigerant charge if line run exceeds
50ft(15.2 m).
3. The maximum line rise above the evaporator
is 35 ft (10.7 m). Condensing unit above
evaporator unit – 35ft(10.7m) (installations
with rise over 20ft (6.1 m) require additional
suction line s-trap at midpoint rise).
4. The evaporator can only be mounted
a maximum of 15' (4.6 m) above the
condensing unit.
Note: The service loop is not included
when calculating length, rise or drop in
thetubingrun.
Note: To connect evaporator/ice machine to rack systems, see page 3.

Remote 700 series ice machine
801 Church Lane | Easton, PA 18040, USA
1.800.523.9361 | 1.610.252.7301 | follettice.com
Form #6190 02/18
© Follett LLC
Ice production – Horizon 700R/N series
Inlet water
temperature
F (C)
Ambient air temperature F (C)
60 (16) 70 (21) 80 (27) 90 (32) 100 (38)
lb/kg production in 24 hr
50 F (10 C) 747 (339) 678 (308) 644 (292) 586 (266) 565 (256)
60 F (16 C) 714 (324) 673 (305) 618 (280) 559 (254) 529 (240)
70 F (21 C) 671 (304) 643 (292) 589 (267) 528 (239) 512 (232)
80 F (27 C) 649 (294) 609 (276) 561 (254) 506 (230) 478 (217)
90 F (32 C) 600 (272) 583 (264) 535 (243) 499 (226) 441 (200)
Agion is a registered trademark of Sciessent LLC.
Harmony, Horizon, Ice•DevIce, Micro Chewblet, SafeCLEAN Plus, Symphony Plus, and Vision are trademarks of Follett LLC.
Chewblet, Follett and RIDE are registered trademarks of Follett LLC, registered in the US.
Follett reserves the right to change specifications at any time without obligation. Certifications may vary depending on country of origin.
