FONESTAR FO-455M User manual

FO-455M, FO-456MR
HDMI EXTENSION MATRIX
VIA TCP/IP ETHERNET
INSTRUCTION MANUAL
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 1

We take this opportunity to thank you for buying this product.
We recommend you read the instruction manual before switching on the machine and follow the instructions
that are given. eep the manual for future reference.
SECURI Y AND HE ENVIRONMEN
ELECTRICAL SECURITY
Check that the current in the mains connection where the machine is to be installed corresponds to the
power supply of the machine.
To avoid damaging the equipment, electrical shocks, fire or physical injury when you connect or disconnect
the equipment from the power supply, pull the plug firmly out of the mains socket holding the plug, never the
cable.
Always do this with dry hands.
eep the power supply cable far from sources of heat. Do not put heavy objects on top of it or change it.
Clean dust and dirt off the power supply cable regularly.
Do not open the machine; you could get an electric shock.
CAUTION
While installing the machine, make sure it is switched off and unplugged.
Do not open the machine. Touching the internal parts is dangerous and you could receive an electric shock.
The machine must not be splashed or dripped on. Never place recipients with liquid inside on the machine.
Do not place anything inside the machine.
LOCATION
Place the equipment on a horizontal surface with enough space around it to allow ventilation.
Avoid direct sunlight, heat sources and excessive dust.
Do not place the machine near magnetic fields or static electricity.
Do not use surfaces which vibrate or receive impact.
Do not pile machines on top of one another.
VENTILATION
Never block or cover the ventilation slits on the machine.
Do not expose it to direct sunlight or place it near sources of heat.
PERIODS OF INACTIVITY
When the machine is not going to be used for a long period of time, disconnect it from the mains.
If you are using an adapter, take into account that it will continue using electricity even if the machine is
switched off. If it is not going to be used for a long period of time, disconnect it from the mains.
THE ENVIRONMENT
To save energy, switch the machine off when you are not going to use it for a long time. The machine could
contain substances that are harmful to the environment or human health. To minimize the effect of these
substances the machine must be correctly managed and recycled when you decide to dispose of it.
When you dispose of it remember: it cannot be thrown into a conventional rubbish bin.
If it contains or uses batteries, these must be disposed of separately.
The machine (without batteries) must be disposed of correctly. Put it in a container specially intended for the
collection of electronic and electrical appliances, at the dump or hand it over to the dealer when you purchase
similar equipment, so that the dealer can dispose of it correctly (at no added cost).
- 2-
EN
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 2

SIGNIFICANCE OF HE SYMBOLS ON HE MACHINE*
The symbol formed by the expression “Class 1 laser product” written in a rectangle
indicates that visible or invisible laser radiation could be produced. Avoid direct expose to
the laser.
The symbol formed by a ray of lightening inside a triangle shows that the machine has
connection terminals or a circuit with areas with a current which could cause an electric
shock, even in normal working conditions.
The symbol formed by an exclamation mark in a triangle shows that the instruction manual
must be referred to for information on how the machine works and its use.
The symbol formed by one square inside another square shows that the machine has
double electrical insulation.
The European Community symbol shows that the machine complies with the current
European Union legislation, as well as its transposition to local legislation.
The symbol of a rubbish bin crossed out and over a horizontal line shows that when the
product is disposed of it must be done properly, placing it in a special selective electronic
and electrical equipment container or through a dealer when purchasing a similar product,
at no additional cost. It also shows that the machine was put on the market after 13th
August 2005 (European Community Directive 2002/96/CE of Electrical and Electronic
recycling, and its Spanish equivalent R.D.208/2005).
In accordance with what is set out in the aforementioned decree, FONESTAR is registered
in the RAEE (Registro de Aparatos Eléctricos y Electrónicos) in a special section REI
(Registro de establecimientos Industriales), with the entry number 001851.
*It is possible that some of these symbols do not appear on the machine.
EXEMP ION OF LIABILI Y
The characteristics of the equipment and the content of the manual can change without forewarning.
FONES AR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the
information supplied in this instruction manual, and specifically disclaims any implied liability for marketability
or fitness for any other use.
All rights reserved by FONES AR, S.A.
- 3-
EN
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 3

DESCRIP ION
THIS MANUAL CORRESPONDS TO THE FOLLOWING MODELS:
FO-455M HDMI extension through TCP/IP ethernet (transmitter + receiver).
Increases the HDMI signals transmission distance up to 120 m for a resolution of 1080p,
through switch with IGMP function or direct connection with cat 5e/6 cable.
FO-456MR HDMI matrix receiver through TCP/IP ethernet.
For extension or replacement of mod. FO-455M.
CON ROLS AND FUNC IONS
RANSMI ER (mod. FO-455M)
1.- Power supply input for the mains adapter provided.
2.- INPU : AV digital input, HDMI connector.
3.- Reset button. Press and hold this button for 5 seconds to restore the transmitter’s IP and MAC addresses
to the factory settings.
4.- IR IN: remote control IR receiver connection input. Connect the IR extension cable to be able to change
the transmission channel remotely. This is the only way to change channel using the remote control.
Below the channel ratio is shown depending on the value which appears in the transmitter display:
5.- Transmitter output, RJ-45 output.
6.- CHANNEL: transmission channel selection button. Press this button several times to select the required
transmission channel.
Note: if this button is pressed and held for 3 seconds, the device restarts. This restart does not alter the
value of the transmitter’s IP and MAC addresses.
- 4-
EN
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 4

RECEIVER (mods. FO-455M and FO-456MR)
1.- Power supply input for the mains adapter provided.
2.- OU PU : A/V digital output, HDMI connector.
3.- Reset button. Press and hold this button for 5 seconds to restore the transmitter’s IP and MAC addresses
to the factory settings.
4.- IR IN: remote control IR receiver connection input. Connect the IR extension cable to be able to change
the transmission channel remotely. This is the only way to change channel using the remote control.
Below the channel ratio is shown depending on the value which appears in the receiver display.
5.- Receiver input, RJ-45 connector.
6.- CHANNEL: transmission channel selection button. Press this button several times to select the required
transmission channel.
Note: if this button is pressed and held for 3 seconds, the device restarts. This restart does not alter the
value of the transmitter’s IP and MAC addresses.
- 5-
EN
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 5

EN
- 6-
CONNEC ION AND OPERA ING
DIREC CONNEC ION WI H CA 5e/6 CABLE
- Connect the AV digital source to the transmitter INPUT using the HDMI cable.
-Connect the receiver OUTPUT to the television using the HDMI cable.
- Use cable Cat 5e/6 up to 120 m to connect the transmitter and the receiver with cable according to the
IEEE-568B standard.
- Power the transmitter and the receiver of the FO-455M with the mains adapters provided.
- Switch on the A/V digital source and the television.
Note: select the same channel in the receiver as in the transmitter.
CONNEC ION VIA CP/IP E HERNE
- Connect the A/V digital source to the transmitter INPUT using the HDMI cable.
- Connect the receiver OUTPUT to the television using the HDMI cable.
- Connect the transmitter output to the switch input using the Cat 5e/6 cable according to standard
IEEE-568B.
- Use the Cat 5e/6 cable up to 120 m to connect the switch and the receiver with cable according to
IEEE-568B standard.
- Power the transmitters FO-455M and the receivers FO-456MR with the mains adapters provided.
- Switch on the A/V digital source and the televisions.
Note: this configuration allows the connection of up to 16 transmitters and 237 receivers. Select in each
receiver the channel corresponding to the transmitter with the audio/video source required.
INS RUC IONS FOR USE
The transmitters and the receivers come with the IP and MAC default addresses assigned, as follows:
To assign or change the IP and MAC addresses of the transmitters and receivers take the following
instructions into consideration:
1.- CHANGE HE COMPU ER’S IP ADDRESS
In order to make any changes to the IP and MAC addresses of mods. FO-455M and FO-456MR, it is
neccessary to assign the computer an IP address within the same range as the devices in the installation.
Follow the steps below:
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 6

- In your computer click on Start/Control Panel/Network and shared resources centre.
- Select the option Change configuration of the adapter and then select the ethernet network card. With the
righthand button open the options menu and select Properties.
- Select the option Internet Protocol version4 (TCP/IPv4). Click on the option Properties and then assign the
IP address to the value 192.168.168.1 (for example) and the subnet mask to the value 255.255.255.0.
Finally, click on Accept to save the configuration.
EN
- 7-
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 7

2.- CHANGE HE IP AND MAC ADDRESSES OF HE RANSMI ERS AND RECEIVERS
If several FO-455M transmitters and several FO-456MR receivers are connected through a switch, the IP
and MAC addresses which are assigned by default to each device must be changed. These IP and MAC
addresses must be different to each of the extra transmitters and receivers which are added to the
installation. The IP and MAC addresses of the original transmitter and receiver can be maintained, which
are as follows:
Follow the steps described below to change the IP and MAC addresses of the transmitters and receivers:
-Step 1: connect the device (transmitter or receiver) to the computer using the Cat 5e/6 cable and powering
the device using the mains adapter provided.
-Step 2: modification of the IP and MAC addresses of each device.
Open the internet browser and enter the the IP address that is to be modified (transmitter or receiver) in
order to access the device’s configuration menu.
In this example, a receiver is being modified (http://192.168.168.56):
Click on the System button and modify the device’s IP and MAC address. Assign a value between 1and
255 to the last interval of the IP address and a value between 00 and ff to the last interval of the MAC
address.
Note: remember that these addresses must be different for each of the transmitters and receivers in the
installation.
- 8-
EN
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 8

Click on Apply to save the changes. Take a note of this new IP address. From this moment onwards the
IP address assigned to this device must be entered in order to make any adjustments in your IP or MAC
address.
Step 3: return to the network configuration your computer had.
ECHNICAL SPECIFICA IONS
FO-455M
CHARAC ERIS ICS HDMI extension matrix through TCP/IP ethernet (transmitter and
receiver).
Transmission distance up to 120 m for a 1080p resolution.
Connection through ethernet with switch with IGMP Snooping
function or direct connection with cable cat 5e/6.
According to IEEE-568B standard.
Allows up to 16 transmission channels and 237 receivers.
Ethernet bandwidth 70 Mbps.
Video compression format M-JPEG.
Remote control for channel selection.
RANSMI ER Input: 1 female HDMI
Output: 1 RJ-45 ethernet HDMI extension through cable Cat 5e/6
Controls: channel selection
RECEIVER Input: 1 RJ-45 ethernet HDMI extension through cable Cat 5e/6
Output: 1 female HDMI
Controls: channel selection
POWER SUPPLY Transmitter and receiver: 5 V DC, 1 A with adapter included
DIMENSIONS Transmitter and receiver: 130 x 24 x 85 mm depth
ACCESSORIES Remote controlled cable extender
- 9-
EN
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 9

FO-456MR
CHARAC ERIS ICS HDMI matrix receiver through TCP/IP ethernet.
For extension or replacement of FO-455M.
Possibility of using up to 237 receivers through a switch with IGMP
Snooping function.
Remote control for channel selection.
RECEIVER Input: 1 RJ-45 HDMI ethernet extension via cable Cat 5e/6
Output: 1 female HDMI
Controls: channel selection
POWER SUPPLY 5 V DC, 1 A with adapter included
DIMENSIONS 130 x 24 x 85 mm depth
ACCESSORIES Remote controlled cable extender
- 10 -
EN
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 10

DECLARA ION OF CONFORMI Y
FONES AR SIS EMAS S.A.
Polígono de Trascueto s/n
39600 Revilla de Camargo, Cantabria (Spain)
Declares, under its responsibility that the following equipment:
Description: HDMI extension matrix via TCP/IP ethernet
Brand: FONESTAR
Model: FO-455M, FO-456MR
complies with the European Community directives 2004/108/EC on Electromagnetic Compatibility,
2006/95/EC on Low Voltage and 2011/65/EU on the restriction on the use of certain dangerous
substances in electrical and electronic appliances (RoHS).
Santander, 23rd October 2015
Juan Vallejo
Technical Engineer, Sales Department
WARRAN Y
This product has been tested and has passed the corresponding quality control prior to being put on the market.
FONES AR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date
and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los
Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.
The lack of conformity in the first six months after purchase, due to a manufacturing defect, will be rectified with no more
than showing the proof of purchase. After six months FONES AR reserves the right to demand proof of the product being
sold with that problem.
This warranty does not include damage produced by: inappropriate use or negligence, accidents, worn out parts due to use,
breakages, burns, spilt liquids or other substances, excessive humidity, battery deterioration and internal manipulation of the
device, the software or its components by unauthorized persons, and in general any use that is unrelated to the nature and
purpose of the product.
If any service is needed during the warranty period because of lack of conformity, please contact the business or distributor
where the product was purchased in no more than 2 months after being conscious of the problem. It is only necessary to
contact FONES AR if it is impossible or imposes an undue burden for them to solve it..
To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections
or crossing out
This document adds information, and never decreases the consumers’ rights, which in all cases are protected by the Spanish
law ‘La Ley General para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.
FONES AR is a member of ECOEMBALAJES ESPAÑA, S.A. “ECOEMBES”, with number 03497 and all our products
carry the symbol, backed by our membership and subscription to the above mentioned organization with the recycling
and subsequent management of our packaging.
FONESTAR, S.A. - NIF: A28780443 - Apartado 191 - 39080 Santander, Cantabria (SPAIN)
www.fonestar.com
- 11 -
EN
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 11

www.fonestar.com
160311_FO-455M_FO-456MR_MANUAL_(EN)_Maqueta ión 1 14/3/16 8:31 Página 12
