FOR-A DDA-106 User manual

DDA-106
HD/SD Digital Distribution Amp
1st Edition
OPERATION
MANUAL

Edition Revision History
Edit. Rev. Date Description Section/Page
1 2012/07/11

Precautions
Important Safety Warnings
[Power]
Operate unit only on the specified supply voltage.
Disconnect power cord by connector only. Do not pull on cable portion.
Do not place or drop heavy or sharp-edged objects on power cord. A damaged cord
can cause fire or electrical shock hazards.
Regularly check power cord for
excessive wear or damage to avoid possible fire / electrical hazards.
[Grounding]
Ensure unit is properly grounded at all times to prevent electrical shock hazard.
Do not ground the unit to gas lines, units, or fixtures of an explosive or dangerous
nature.
Ensure power cord is firmly plugged into AC outlet.
[Operation]
Do not operate unit in hazardous or potentially explosive atmospheres. Doing so
could result in fire, explosion, or other dangerous results.
Do not allow liquids, metal pieces, or other foreign materials to enter the unit. Doing
so could result in fire, other hazards, or unit malfunction.
If foreign material does enter the unit, turn power off and disconnect power cord
immediately. Remove material and contact authorized service representative if
damage has occurred.
[Transportation]
Handle with care to avoid shocks in transit. Shocks may cause malfunction. When
you need to transport the unit, use the original packing materials or alternate
adequate packing.
Stop
Caution
Hazard
Hazard
Caution
Hazard
Caution
Caution

[Circuitry Access]
Do not remove covers, panels, casing, or access circuitry with power applied to the
unit! Turn power off and disconnect power cord prior to removal. Internal servicing /
adjustment of unit should only be performed by qualified personnel.
Do not touch any parts / circuitry with a high heat factor.
Capacitors can retain enough electric charge to cause mild to serious shock, even
after power is disconnected. Capacitors associated with the power supply are
especially hazardous. Avoid contact with any capacitors.
Unit should not be operated or stored with cover, panels, and / or casing removed.
Operating unit with circuitry exposed could result in electric shock / fire hazards or
unit malfunction.
[Potential Hazards]
If abnormal smells or noises are noticed coming from the unit, turn power off
immediately and disconnect power cord to avoid potentially hazardous conditions. If
problems similar to above occur, contact authorized service representative before
attempting to again operate unit.
[Rack Mount Brackets, Ground Terminal, and Rubber Feet]
To rack mount or ground the unit, or to install rubber feet, do not use screws or
materials other than those supplied. Otherwise, it may cause damage to the internal
circuits or components of the unit. If you remove the rubber feet attached on the unit,
do not reinsert the screws securing the rubber feet.
[Consumables]
The consumables used in unit must be replaced periodically. For further details on
which parts are consumables and when they should be replaced, refer to the
specifications at the end of the Operation Manual. Since the service life of the
consumables varies greatly depending on the environment in which they are used,
they should be replaced at an early date. For details on replacing the consumables,
contact your dealer.
Caution
Hazard
Stop
Caution
Caution

Upon Receipt
Unpacking
DDA-106 units and their accessories are fully inspected and adjusted prior to shipment.
Operation can be performed immediately upon completing all required connections and
operational settings.
Check your received items against the packing lists below.
ITEM QTY REMARKS
DDA-106 1
AC Cord 1 set (Including ladder strap/retaining clip assembly)
Operation Manual 1
Option Items
ITEM QTY REMARKS
Rack mount bracket set
(Type 1) 1 set Mounts single unit to an EIA 1RU rack space.
Rack mount bracket set
(Type 2) 1 set Mounts two units to an EIA 1RU rack space.
Check
Check to ensure no damage has occurred during shipment. If damage has occurred, or items
are missing, inform your supplier immediately.

Installing the Ladder Strap/Retaining Clip Assembly
Secure the AC cord with the supplied ladder strap/retaining clip assembly to prevent accidental
removal from the DDA-106.
Installing the clip
1) Wrap the retaining clip around the AC cord (with the anchor of the ladder strap toward the unit.)
2) Insert the anchor into the insertion hole next to the AC IN socket.
3) Lightly fasten the clip around the AC cord.
4) Plug in the power cord.
5) Slide the clip on the ladder strap toward the plug.
6) Fasten the clip tightly.
7) Gently pull on the AC cord to ensure it is secured.
Unpluging the AC cord
1) Push the tab on the retaining clip up to unfasten the clip.
2) Push the tab on the ladder strap up and slide the clip back.
3) Unplug the AC cord.
2)
4) 3)
5) 6)
1) 2)

Table of Contents
1. Prior to Starting.........................................................................................................................1
1-1. Welcome............................................................................................................................1
1-2. Features.............................................................................................................................1
1-3. About This Manual.............................................................................................................1
2. Panel Descriptions....................................................................................................................2
2-1. Front Panel ........................................................................................................................2
2-2. Rear Panel.........................................................................................................................2
3. Connection................................................................................................................................3
4. Specifications and Dimensions .................................................................................................4
4-1. Unit Specifications .............................................................................................................4
4-2. External Dimensions..........................................................................................................5

1
1. Prior to Starting
1-1. Welcome
Congratulations! By purchasing DDA-106 HD/SD Digital Distribution Amp you have entered the
world of FOR-A and its many innovative products. Thank you for your patronage and we hope
you will turn to FOR-A products again and again to satisfy your video and audio needs.
FOR-A provides a wide range of products, from basic support units to complex system
controllers, which have been increasingly joined by products for computer video based systems.
Whatever your needs, talk to your FOR-A representative. We will do our best to be of continuing
service to you.
1-2. Features
The DDA-106 is a half-1U-size HD/SD-SDI signal distributor. It accepts HD-SDI, SD-SDI, or
DVB-ASI signal and distributes the input into six outputs.
Accepts and distributes digital component signals in both SD and HD. (Auto switching)
Cable compensation function allows the input-side cable length to be as long as 200 meters
when BNC 5C-2V or equivalent cable is used for SD-SDI, and 100 meters when BNC 5C-FB
or equivalent cable is used for HD-SDI.
Reclock function minimizes signal jitter.
HD and SD Input Signal Auto Detection/Auto Switching
Bypasses signal input when unit power is off.
DVB-ASI signal format supported.
Can be mounted into 1RU EIA racks using an optional rack mount bracket set.
1-3. About This Manual
This manual is intended to help the user easily operate this product and make full use of its
functions during operations. Before connecting or operating your unit, read this operation
manual thoroughly to ensure you understand the product. After reading, it is important to keep
this manual in a safe place and available for reference.

2
2. Panel Descriptions
2-1. Front Panel
No. Name Description
1 POWER switch Switch used to turn the unit power ON/OFF.
2 POWER LED Lights whenever power is applied to the unit.
3 LOCK LED Lights whenever an input signal is properly input.
4 HD LED Lights whenever an HD-SDI signal is input.
2-2. Rear Panel
No. Name Description
1 HD/SD-SDI IN HD/SD-SDI signal input connector.
(Can bypass input signal to HD/SD-SDI OUT1.)
2 HD/SD-SDI
OUT1
HD/SD-SDI signal output connector.
Bypasses HD/SD-SDI IN signal input when unit power is off.
3 HD/SD-SDI
OUT2 to 6 Outputs HD/SD-SDI signals.
4 AC IN Used to connect to AC power source via supplied accessory
cord (100 to 240 VAC, 50/60 Hz).
5 Ladder strap
insertion hole Insertion hole for ladder strap assembly.
6 Ground terminal Used to protect operators from static electricity and / or
electrical shock.
HD/SD DIGITAL DISTRIBUTION AMP
DDA-106
HD
LOCK
POWER
OFF
ON
(1) (2)(3)(4)
SER. NO.
6
AC100-240V 50/60Hz IN
4
3
215
HD/SD-SDI OUT
HD/SD-SDI IN
(1) (2) (3) (4) (5) (6)

3
3. Connection
Refer to the figure below and connect the DDA-106 and other devices.
HD-SDI,
SD-SDI,
or
DVB-ASI signal
DDA-106
HD-SDI,
SD-SDI,
or
DVB-ASI signa l
HD/SD-SDI
IN
HD/SD
OUT1
HD/SD
OUT2
HD/SD
OUT3
HD/SD
OUT4
HD/SD
OUT5
HD/SD
OUT6

4
4. Specifications and Dimensions
4-1. Unit Specifications
Video Input HD-SDI: 1.485/1.001Gbps or 1.485Gbps
SD-SDI: 270Mbps
DVB-ASI: 270Mbps
75ΩBNC x 1
(Can bypass input signal to HD/SD-SDI OUT1.)
Video Output HD-SDI: 1.485/1.001Gbps or 1.485Gbps
SD-SDI: 270Mbps
DVB-ASI: 270Mbps
75ΩBNC x 6
Cable Equalization Auto cable equalization
HD-SDI: Max. 100m (5C-FB or equivalent)
SD-SDI: Max. 200m (5C-2V or equivalent)
Temperature 5ºC to 40ºC
*1
Humidity Lower than 85% (no condensation)
Power 100 VAC to 240 VAC ±10%, 50/60 Hz
Power Consumption 15VA (7W)
Dimensions 212 (W) × 44 (H)× 161.5 (D) mm, EIA 1RU (excluding protruding parts)
Weight 1.0 kg
*1
To ensure the product is used under specified conditions, do not stack the
DDA-106 on or under other equipment.

5
4-2. External Dimensions
(All dimensions in mm.)
SER. NO.
20
161.5
212
44±0.4
ON
OFF
POWER
LOCK
HD
DDA-106
HD/SD DI G ITAL DISTR IBU TION AMP
6
AC100-240V 50/60Hz IN
43215
HD/SD-SDI OUT
HD/SD-SDI IN

Warning
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in
which case the user will be required to correct the interference at his own
expense.

07/11/2012 Printed in Japan
FOR-A COMPANY LIMITED
Head Office 3-8-1 Ebisu, Shibuya-ku, Tokyo 150-0013, Japan
Overseas Division Phone: [phone], Fax: [phone]
Japan Branch Offices Osaka/Okinawa/Fukuoka/Hiroshima/Nagoya/Sendai/Sapporo
R&D/Production Sakura Center/Sapporo Center
FOR-A America Corporate Office
11155 Knott Ave., Suite G&H, Cypress, CA 90630, USA
Phone: [phone] Fax: [phone]
FOR-A America East Coast Office
2 Executive Drive, Suite 670, Fort Lee Executive Park, Fort Lee, NJ 07024, USA
Phone: [phone] Fax : [phone]
FOR-A America Distribution & Service Center
2400 N.E. Waldo Road, Gainesville, FL 32609, USA
Phone: [phone] Fax: [phone]
FOR-A Corporation of Canada
346A Queen Street West, Toronto, Ontario M5V 2A2, Canada
Phone: [phone] Fax: [phone]
FOR-A Latin America & the Caribbean
5200 Blue Lagoon Drive, Suite 760, Miami, FL 33126, USA
Phone: [phone] Fax: [phone]
FOR-A UK Limited
UNIT C71, Barwell Business Park, Leatherhead Road, Chessington Surrey, KT9 2NY, UK
Phone: [phone] Fax: [phone]
FOR-A Italia S.r.l.
Via Volturno 37, 20047 Brugherio MB, Italy
Phone: [phone] Fax: [phone]
FOR-A Corporation of Korea
1007, 57-5,Yangsan-ro,Yeongdeungpo-gu, Seoul 150-103, Korea
Phone: [phone] Fax: [phone]
FOR-A China Limited
708B Huateng Bldg., No. 302, 3 District, Jinsong, Chaoyang, Beijing 100021, China
Phone: [phone] Fax: [phone]
FOR-A Middle East-Africa Office
Jebel Ali Free Zone, LOB-16, Office 619, P. O. Box: 261914 Dubai, UAE
Phone: [phone] Fax: [phone]
*The contents of this manual are subject to change without notice.
