FOR-A USF-111DDA-12G User manual

USF-111DDA-12G
Digital Distribution Amplifier
1st Edition
OPERATION
MANUAL

2
Precautions
Important Safety Warnings
[Power]
Stop
Do not place or drop heavy or sharp-edged objects on the power cord. A damaged
cord can cause fire or electrical shock hazards. Regularly check the power cord for
excessive wear or damage to avoid possible fire / electrical hazards.
[Circuitry Access]
Stop
Do not touch any parts / circuitry with a high heat factor.
Capacitors can retain enough electric charge to cause mild to serious shock, even after
the power has been disconnected. Capacitors associated with the power supply are
especially hazardous.
Hazard
Unit should not be operated or stored with cover, panels, and / or casing removed.
Operating the unit with circuitry exposed could result in electric shock / fire hazards or
a unit malfunction.
[Potential Hazards]
Caution
If abnormal odors or noises are noticed coming from the unit, immediately turn the
power off and disconnect the power cord to avoid potentially hazardous conditions. If
problems similar to the above occur, contact an authorized service representative
before attempting to operate the unit again.
[Consumables]
Caution
Consumable items that are used in the unit must be periodically replaced. For further
details on which parts are consumables and when they should be replaced, refer to the
specifications at the end of the Operation Manual. Since the service life of the
consumables varies greatly depending on the environment in which they are used,
such items should be replaced at an early date. For details on replacing consumable
items, contact your dealer.

3
Upon Receipt
Congratulations! By purchasing a USF-111DDA-12G Digital Distribution Amplifier, you have entered
the world of FOR-A and its many innovative products.
Check your received items against the packing list below. Check to ensure no damage has occurred
during shipment. If damage has occurred, or items are missing, inform your supplier immediately.
USF-111DDA-12G
ITEM
QTY
REMARKS
USF-111DDA-12G
1
USF-111DDA-12G Front Module
USF-111DDA-12G Rear Module
DVD-ROM
1
Operation Manual (PDF)
Screw (for Rear Module Installation)
4
* This Product can be installed into the following frame:
USF-212AS
USF-105AS

4
Table of Contents
1. Prior to Starting.....................................................................................................................................5
1-1. Overview .....................................................................................................................................5
1-2. Features......................................................................................................................................5
2. Panel Descriptions................................................................................................................................6
2-1. Front Panel..................................................................................................................................6
2-2. Rear Panel ..................................................................................................................................6
3. Switch Settings.....................................................................................................................................7
4. Web GUI...............................................................................................................................................8
4-1. WEB Display Information............................................................................................................8
4-2. syslog Functions .........................................................................................................................9
5. About SNMP.......................................................................................................................................10
6. Specifications and Dimensions ..........................................................................................................11
6-1. Specifications............................................................................................................................11
6-2. External Dimensions.................................................................................................................11

5
1. Prior to Starting
1-1. Overview
The USF-111DDA-12G is a multi-bit rate video distribution amplifier that can be installed in a USF
frame. The USF-111DDA-12G supports 12G-SDI, 3G-SDI, HD-SDI, SD-SDI and DVB-ASI, and is
capable of producing up to 11 outputs from 1 input.
1-2. Features
Installs into a USF-212AS/ USF-105AS frame.
1 input 11 distribution outputs.
Supports SDI 12Gbps, 3Gbps, 1.5Gbps, 270Mbps signals. (Automatic)
12G/3G/HD/SD-SDI equalizer and re-clock functions.
Detection of input signal and identification of 12Gbps/3Gbps/1.5Gbps/270Mbps.
Supports DVB-ASI (270Mbps) signal.
SNMP monitoring and syslog supported.

6
2. Panel Descriptions
2-1. Front Panel
USF-111DDA-12G
No.
Name
Description
(1)
OPERATE LED
Lights green when power is supplied by USF frame.
(2)
12.0Gb/s LED
Lights green when input SDI signal is 12G b/s.
(3)
3.0Gb/s LED
Lights green when input SDI signal is 3G b/s.
(4)
1.5Gb/s LED
Lights green when input SDI signal is 1.5G b/s.
(5)
270Mb/s LED
Lights green when input SDI signal is 270M b/s.
(6)
DIP switch
Sets Reclock settings.
(7)
USB connector
Used to upgrade USF-111DDA-12G software.
(Do not connect USB devices.)
2-2. Rear Panel
USF-111DDA-12G
6
1 2 3
SDI OUT
SDI OUT
4 5 SDI IN
78910 11
Name
Description
SDI IN
SDI signal input.
Accepts an SD/HD/3G/12G-SDI signal.
SDI OUT 1 –11
SDI signal outputs.
Distributes the SDI IN input to 11 outputs.
(1)
(2)
(3)
(4)
(5)
(6)
(7)

7
3. Switch Settings
SW No.
Function
S1
Reboot Switch (Do not change settings in normal operation.)
S2
CPU Reset Switch (Do not change settings in normal operation.)
DS1
SW No.
Function
Setting
Factory Setting
OFF
ON
1
-
－
－
OFF (Do not change the setting.)
2
-
－
－
OFF (Do not change the setting.)
3
-
－
－
OFF (Do not change the setting.)
4
-
－
－
OFF (Do not change the setting.)
5
Reclock
Reclock Bypass
Reclock
ON（Normal use setting.）
6
-
－
－
ON (Do not change the setting.)
7
-
－
－
OFF (Do not change the setting.)
8
-
－
－
OFF (Do not change the setting.)
DS2
SW No.
Function
Setting
Factory Setting
OFF
ON
1
-
－
－
OFF (Do not change the setting.)
2
-
－
－
OFF (Do not change the setting.)
3
-
－
－
OFF (Do not change the setting.)
4
-
－
－
OFF (Do not change the setting.)
5
-
－
－
OFF (Do not change the setting.)
6
-
－
－
OFF (Do not change the setting.)
7
-
－
－
OFF (Do not change the setting.)
8
-
－
－
OFF (Do not change the setting.)
DS1
DS2
S1
S2

8
4. Web GUI
Status parameters of USF-111DDA-12G can be displayed on the Web display if the module is installed
in a USF-212AS/USF-105AS frame. SNMP monitoring is also available. Refer to the
USF-212AS/USF-105AS Operation Manual for details on displaying the Web GUI window.
NOTE
USF-111DDA-12G does not support simultaneous Web GUI access from multiple PCs. Use the
SNMP function to simultaneously monitor a USF-111DDA-12G from multiple PCs.
4-1. WEB Display Information
Start the Web GUI and click on a USF-111DDA-12G from slot 1 to 12 of USF-212AS/USF-105AS to
open the window as shown below.
Module Information
Item
Description
Slot
Slot no. of the USF-212AS/USF-105AS in which USF-111DDA-12G is
installed.
S/N
Serial number of the USF-111DDA-12G.
MAC Address
MAC address of the USF-111DDA-12G.
Firmware
Firmware version of the USF-111DDA-12G.
FPGA
FPGA of the USF-111DDA-12G.
IP Address
IP address of the USF-111DDA-12G.
CPU Temperature
Temperature of the CPU on the USF-111DDA-12G front card.
Video Input
Displays video input status.
Detected: Normal video input.
Not Detected: No video input, or input level is low.
Input Status Trap
Sets the SNMP trap setting when monitoring USF-111DDA-12G via SNMP
Manager.
Enable: Sends input status traps.
Disable: Sends no traps.
Input Signal
(SD/HD/3G/12G)
Displays the bit rate of SDI input: SD (270Mbit/sec), HD (1.5Gbit/sec),
3G (3.0Gbit/sec), 12G (12.0Gbit/sec)
Not Detected: No input signal
Mode
Displays the re-clock function mode.
Output 1-11 Mute
If not connecting video output signal via SDI OUT1-11, set Enable for
unused ports. (Recommended use)

9
Downloading MIB files
(1) Click to download the MIB (Management Information Base) for your
SNMP manager.
(2) Select Save (S) from the opened dialog box.
(3) FORA-USF111DDA12G-MIB.zip File is downloaded.
(4) Unzip the file and load it into your SNMP manager.
4-2. syslog Functions
The USF-111DDA-12G supports log monitoring and message transmission using syslog protocol.
Clicking the syslog tab opens a window shown as below.
Item
Description
Send Syslog
Select Enable to send syslog messages to the management terminal.
Send Address
Check the IP address to send syslog messages. The IP address is the
same as the SNMP trap address. Refer to the USF-212AS/USF-105AS
Operation Manual for details on setting the SNMP trap address.
Facility
Sets syslog logging facilities in Local 0 through Local 7.
Header Message
Sets syslog header messages up to a maximum of 63 alphanumeric
characters.
Factory setting: USF-111DDA-12G
Input Video Detect
Sets detection messages for video input into USF-111DDA-12G.
Maximum of 63 alphanumeric characters. Sets priority in 9 steps.
Factory setting: Notice
Input Video Loss
Sets detection messages for video input into USF-111DDA-12G being
lost. Maximum of 63 alphanumeric characters. Sets priority in 9 steps.
Factory setting: Warning
* Click Apply when settings are changed.

10
5. About SNMP
The USF-111DDA-12G can be monitored using an external SNMP monitoring system that supports
SNMPv2C. MIB (Management Information Base) files that are required for SNMP monitoring systems
can be downloaded from the Web GUI. (Refer to the prior page “Downloading MIB files” for details.)
Refer to the USF-212AS/USF-105AS Operation Manual for details on SNMP settings.
GET List
Object
group
Item Name
Object name in MIB file
Value
OID
Type
TRAP
Function
OID : 1.3.6.1.4.1.20175.1.340.1.
Unit
Status
Product Name
usf111Dda12gProductName
USF-111DDA-12G
1
OCTET STRING
Product Code
usf111Dda12gProductCode
1023850
2
INTEGER
Serial Number
usf111Dda12gSerialNumber
1757****
3
INTEGER
Soft Version
usf111Dda12gFirmwareVersion
R**.**
4
OCTET STRING
FPGA Version
usf111Dda12gFpgaVersion
R**.**
5
OCTET STRING
Slot Number
usf111Dda12gSlotNumber
1-12
6
INTEGER
CPU Temperature
usf111Dda12gCpuTemperature
** degree Celsius
7
INTEGER
Input Video Status
usf111Dda12gInputStatus
-1:cannotDetect
0: not Detected
1: detected
8
INTEGER

Input SDI Bit Rate
usf111Dda12gSdiRate
-1:cannotDetect
0: not Detected
1: sdi SD
2: sdi HD
3: sdi 3G
4: sdi 6G
5: sdi 12G
9
INTEGER
Reclock Bypass Setting
usf111Dda12gReclockBypass
0:reclocking
1:reclock Bypass
10
INTEGER
Output 1-11 Mute
usf111Dda12gOutput1Mute
0:disable
1:enable
11
INTEGER
usf111Dda12gOutput2Mute
- ditto -
12
INTEGER
usf111Dda12gOutput3Mute
- ditto -
13
INTEGER
usf111Dda12gOutput4Mute
- ditto -
14
INTEGER
usf111Dda12gOutput5Mute
- ditto -
15
INTEGER
usf111Dda12gOutput6Mute
- ditto -
16
INTEGER
usf111Dda12gOutput7Mute
- ditto -
17
INTEGER
usf111Dda12gOutput8Mute
- ditto -
18
INTEGER
usf111Dda12gOutput9Mute
- ditto -
19
INTEGER
usf111Dda12gOutput10Mute
- ditto -
20
INTEGER
usf111Dda12gOutput11Mute
- ditto -
21
INTEGER
* No item can be set from SNMP.
TRAP List
Object
Group
Item Name
Object name in MIB file
OID
Reference object
Type
OID : 1.3.6.1.4.1.20175.1.340.0.
TRAP
SDI Input
usf111Dda12gInputStatusChanged
1
usf111Dda12gSlotNumber
INTEGER
usf111Dda12gInputStatus
INTEGER

11
6. Specifications and Dimensions
6-1. Specifications
Video Input
12G-SDI: 12Gbps
3G-SDI: 3Gbps
HD-SDI: 1.5Gbps
SD-SDI: 270Mbps
DVB-ASI: 270Mbps
75Ω BNC x 1
Video Output
12G-SDI: 12Gbps
3G-SDI: 3Gbps
HD-SDI: 1.5Gbps
SD-SDI: 270Mbps
DVB-ASI: 270Mbps
75Ω BNC x 11
Cable
Compensation
Automatic Cable Compensation
12G-SDI: Max. 70m (L-5.5 UHDC-equivalent cable)
3G-SDI: Max. 100m (5C-FB-equivalent cable)
HD-SDI: Max. 100m (5C-FB-equivalent cable)
SD-SDI: Max. 200m (5C-2V-equivalent cable)
SNMP
SNMP Monitoring available
SNMP version v2C
Temperature
0°C to 40°C
Humidity
30% to 90% (no condensation)
Power
+12V DC (Supplied by a USF frame)
Power Consumption
12.7 VA (12.7W)
Dimensions
Front module:106 (W) x 356 (D) mm
Rear module: 114 (W) x 40.7 (H) mm
Weight
280 g
Required Slots
2 Slots
6-2. External Dimensions
（All dimensions in mm）
334
106
3.2
13.5
16.7
114
356
USF-111DDA-12G
40.7
USF-111DDA-12G
6 123
SDI OUT
SDI OUT
45SDI IN
78910 11
