FOR-A UFM-14DADA User manual

UFM-14DADA
Digital Audio Distribution Amplifier
UFM-18DADA
Digital Audio Distribution Amplifier
1st Edition - Rev. 2
OPERATION
MANUAL

Precautions
Important Safety Warnings
[Power]
Do not place or drop heavy or sharp-edged objects on power cord. A damaged cord
can cause fire or electrical shock hazards. Regularly check power cord for
excessive wear or damage to avoid possible fire / electrical hazards.
[Circuitry Access]
Do not touch any parts / circuitry with a high heat factor.
Capacitors can retain enough electric charge to cause mild to serious shock, even
after power is disconnected. Capacitors associated with the power supply are
especially hazardous. Avoid contact with any capacitors.
Unit should not be operated or stored with cover, panels, and / or casing removed.
Operating unit with circuitry exposed could result in electric shock / fire hazards or
unit malfunction.
[Potential Hazards]
If abnormal smells or noises are noticed coming from the unit, turn power off
immediately and disconnect power cord to avoid potentially hazardous conditions. If
problems similar to above occur, contact authorized service representative before
attempting to again operate unit.
[Consumables]
The consumables used in unit must be replaced periodically. For further details on
which parts are consumables and when they should be replaced, refer to the
specifications at the end of the Operation Manual. Since the service life of the
consumables varies greatly depending on the environment in which they are used,
they should be replaced at an early date. For details on replacing the consumables,
contact your dealer.
Caution
Stop
Hazard
Stop
Caution

Upon Receipt
Unpacking
UFM-14DADA/18DADA units and their accessories are fully inspected and adjusted prior to
shipment. Operation can be performed immediately upon completing all required connections
and operational settings.
Check your received items against the packing lists below.
ITEM
QTY
REMARKS
UFM-14DADA
or
UFM-18DADA
1
1 front module
1 rear module
CD-ROM
1
User manual
Check
Check to ensure no damage has occurred during shipment. If damage has occurred, or items
are missing, inform your supplier immediately.

Table of Contents
1. Prior to Starting..............................................................................................................................1
1-1. Welcome ...............................................................................................................................1
1-2.About the UFM-14DADA/18DADA........................................................................................1
1-3.About This Manual ................................................................................................................1
2. Panel Descriptions........................................................................................................................2
2-1. Front Panel............................................................................................................................2
2-2. Rear Panel ............................................................................................................................3
3. Connection....................................................................................................................................5
4. Internal Settings ............................................................................................................................7
4-1. Operation Mode (SW1).........................................................................................................7
4-2. Other Settings (SW2)............................................................................................................8
5. Specifications and Dimensions.....................................................................................................9
5-1. Specifications........................................................................................................................9
5-2. Dimensions..........................................................................................................................10

1
1. Prior to Starting
1-1. Welcome
Congratulations! By purchasing UFM-14DADA/18DADA Digital Audio Distribution Amplifier you
have entered the world of FOR-A and its many innovative products. Thank you for your
patronage and we hope you will turn to FOR-A products again and again to satisfy your video
and audio needs.
FOR-A provides a wide range of products, from basic support units to complex system
controllers, which have been increasingly joined by products for computer video based systems.
Whatever your needs, talk to your FOR-Arepresentative. We will do our best to be of continuing
service to you.
1-2. About the UFM-14DADA/18DADA
UFM-14DDADA/18ADA AES/EBU format digital audio distribution amplifier is specifically
designed for use with FOR-A’s Universal Frames UF-106B or UF-112.
Module
Mode
Distribution
UFM-14DADA
Single channel
Input 1 to four outputs
Dual channel
Input 1 to two outputs
Input 2 to two outputs
UFM-18DADA
Single channel
Input 1 to eight outputs
Dual channel
Input 1 to four outputs
Input 2 to three outputs
Features
Input signal indication on the front panel
The internal settings can be modified to set to single channel mode (1 way) or dual channel
mode (2 ways)
Mute data output (48kHz, 24bit) available when no audio signal is present (the following
serial number range only)
UFM-14DADA: Up to 10770159
UFM-18DADA: 10940001-10940008, 10940010-10940020, 10940027-10940036
10940038-10940040
1-3. About This Manual
This manual is intended to help the user easily operate the UFM-14DADA/18DADA and make
full use of its functions during operations. Before connecting or operating your unit, read this
operation manual thoroughly to ensure you understand the product.After reading, it is important
to keep this manual in a safe place and available for reference.

2
2. Panel Descriptions
2-1. Front Panel
UFM-14DADA
UFM-18DADA
(1)
Power indicator
The power indicator is lit whenever the supply curcuit on the board
is operating properly.
(2)
INPUT 1
This indicator lights whenever the proper digital audio signal is
input to IN 1.
(3)
INPUT 2
This indicator lights whenever the proper digital audio signal is
input to IN 2.
(4)
INTERFACE
Not used.
(1)
(3)
(2)
(4)
(OPTION)21
POWER
INPUT
UFM-14DADA INTERFACE
(1)
(3)
(2)
(4)
POWER 1 2 (OPTION)
INPUT
UFM-18DADA INTERFACE

3
2-2. Rear Panel
UFM-14DADA
Single channel mode
(1)
DIGITALAUDIO IN
IN 1
IN 2
Used for digital audio input connection.
IN 1 is used to input digital audio signals.
IN 2 is not used.
(2)
OUT 1
OUT 2
OUT 3
OUT 4
Used for digital audio output connection.
Digital audio signals input to IN 1 are output from OUT 1,
OUT 2, OUT 3, and OUT 4 (one input to four outputs).
Dual channel mode
(1)
DIGITALAUDIO IN
IN 1
IN 2
Used for digital audio input connection.
IN 1 and IN 2 are used to input digital audio signals.
(2)
OUT 1-1
OUT 1-2
OUT 2-1
OUT 2-2
Used for digital audio output connection.
Digital audio signals input to IN 1 are output from OUT1-1
and OUT1-2 (one input to two outputs).
Digital audio signals input to IN 2 are output from OUT2-1
and OUT2-2 (one input to two outputs).
OUT 2-2
OUT 2-1
OUT 1-2
OUT 1-1
DIGITAL AUDIO IN OUT 1 OUT 2 OUT 3 OUT 4
IN1 IN 2 UFM-14DADA
(2)
(1)

4
UFM-18DADA
Single channel mode
(1)
DIGITALAUDIO IN
IN 1
Used for digital audio input connection.
(3)
DIGITALAUDIO OUT
1 –8
Used for digital audio output connection.
Digital audio signals input to IN 1 are output from DIGITAL
AUDIO OUT 1 –8 (one input to eight outputs).
Dual channel mode
(1)
DIGITALAUDIO IN
IN 1
Used for digital audio input connection.
(2)
IN 2
Used for digital audio input connection in dual channel
mode.
(3)
OUT 1-1
OUT 1-2
OUT 1-3
OUT 1-4
OUT 2-1
OUT 2-2
OUT 2-3
Used for digital audio output connection.
Digital audio signals input to IN 1 are output from OUT1-1,
OUT1-2, OUT1-3, and OUT1-4 (one input to four outputs).
Digital audio signals input to IN 2 are output from OUT2-1,
OUT2-2 and OUT2-3 (one input to three outputs).
56 7 8
1 2 3 4
OUT 2-3OUT 2-2OUT 2-1
IN 2
OUT 1-4OUT 1-3OUT 1-2OUT 1-1
DIGITAL AUDIO OUT
DIGITAL AUDIO
IN
IN 1
UFM-18DADA
(1)
(2)
(3)

5
3. Connection
Refer to figure below for connecting the UFM-14DADA/18DADA to other devices.
Note that before installing the UFM-14DADA/18DADA into the universal frame, you should
thoroughly read the operation manual for the Universal Frame where you will be installing.
UFM-14DADA
(1) Single channel mode (one input to four outputs)
(2) Dual channel mode (one input to two outputs in two ways)
UFM-14DADA module
DIGITAL
AUDIO IN
OUT 1
Digital Audio
Input Device
1-4
Input
Detection
OUT 2
OUT 3
OUT 4
Digital
Audio
Device
Universal frame
IN 1
OUT 1-1
OUT 1-2
Universal frame
Digital
Audio
Device
Digital
Audio
Device
IN 2
OUT 2-1
OUT 2-2
Digital Audio
Input Device
1-2
Input
Detection
Input
Detection
UFM-14DADA module
Digital Audio
Input Device
3-4

6
UFM-18DADA
(1) Single channel mode (one input to eight outputs)
(2) Dual channel mode (one input to four outputs and one input to three outputs)
DIGITAL
AUDIO IN
OUT 1
UFM-18DADA module
Universal frame
Digital
Audio
Device
Digital Audio
Input Device
1-8
OUT 2
OUT 3
OUT 4
OUT 5
OUT 6
OUT 7
OUT 8
Input
Detection
IN 1
UFM-18DADA module
Universal frame
Digital
Audio
Device
Digital
Audio
Device
IN 2
Digital Audio
Input Device
1-4
Digital Audio
Input Device
5-7
OUT 1-2
OUT 2-1
OUT 2-2
OUT 1-1
OUT1-4
OUT 1-3
OUT 2-3
Input
Detection
Input
Detection

7
4. Internal Settings
The following settings can be made via the front module of the UFM-14DADA/18DADA.
Switch settings must be made prior to installing any module to the universal frame.
4-1. Operation Mode (SW1)
SW1 is used to select between single channel mode (one way) and dual channel mode (two
ways).
Factory default setting is single channel mode ( A position).
Jumper Setting
Operation Mode
A position
Single channel mode
A/B position
Dual channel mode
SW 1
Single channel mode/dual channel mode
toggle switch
SW2
SW1
A/B
A
Single
SW1
A/B
A
Dual

8
4-2. Other Settings (SW2)
SW2 is for maintenance use only. If these settings are changed by mistake, refer to the table
below to return them to the default settings.
Switch No.
Factory Default
Description
1
OFF
For maintenance use only. Do not
change this setting.
2
OFF
For maintenance use only. Do not
change this setting.
3
OFF
For maintenance use only. Do not
change this setting.
4
OFF
For maintenance use only. Do not
change this setting.
5
OFF
For maintenance use only. Do not
change this setting.
6
OFF
For maintenance use only. Do not
change this setting.
7
OFF
For maintenance use only. Do not
change this setting.
8
OFF
For maintenance use only. Do not
change this setting.
1
2
3
4
ON
5
4
6
7
8
SW2

9
5. Specifications and Dimensions
5-1. Specifications
UFM-14DADA
UFM-18DADA
Distribution
Single channel mode
Input 1 to four outputs
Input 1 to eight outputs
Dual channel mode
Input 1 to two outputs
Input 2 to two outputs
Input 1 to four outputs
Input 2 to three outputs
Audio input
Digital audio 1.0V(p-p) 75ΩBNC
Audio output
Digital audio 1.0V(p-p) 75ΩBNC
Digital Audio Format
AES/EBU
Sampling Frequency
32kHz –96kHz
Temperature
10°C –40°C
Humidity
30% –90%(no condensation)
Power Source
+ 12VDC to + 24VDC (supplied with universal frame)
Power Consumption
Approx.150mA
Approx.160mA
Weight
Approx. 0.5 kg
Dimensions
Front module
106 (W) x 303 (D)mm
Rear module
108.5 (W) x 20 (H) x
66.1(D)mm
108.5 (W) x 40.6 (H) x
66.1(D)mm
Required slot
1 slot
2 slots
Consumables
No consumables are used in these products.

10
5-2. Dimensions
(All dimensions in mm.)
UFM-14DADA
UFM-18DADA
(OPTION)21
66.1 20
303 13.5
PO WER
UFM-14DADA INPU T IN TER FAC E
OUT 2-2
OUT 2-1
OUT 1-2
OUT 1-1
DIGITAL AUDIO IN OUT 1 OUT 2 OUT 3 OUT 4
IN1 IN 2 UFM-14DADA
108.5
106
17.2
66.1 40.6
5678
1234
303
OUT 2-3
OUT 2-2
OUT 2-1
IN 2
OUT 1-4
OUT 1-3
OUT 1-2
OUT 1-1
DIGITAL AUDIO OUT
DIGITAL AUDIO
IN
IN 1
UFM-18DADA
PO WE R
UFM-18DADA 1 2
INP UT
(OPTION )
INT ERF AC E
108.5
106

Warning
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in
which case the user will be required to correct the interference at his own
expense.

FOR-A COMPANY LIMITED
Head Office 3-8-1 Ebisu, Shibuya-ku, Tokyo 150-0013, Japan
Overseas Division Tel: +81(0)3 3446 3936 Fax: +81(0)3 3446 1470
Japan Branch Offices Osaka/Okinawa/Fukuoka/Hiroshima/Nagoya/Sendai/Sapporo
R&D/Production Sakura Center/Sapporo Center
FOR-A Corporation of America
11155 Knott Ave., Suite G&H, Cypress, CA 90630, USA.
Tel: +1 714 894 3311 Fax: +1 714 894 5399
FOR-A Corporation of America East Coast Office
2 Executive Drive, Suite 670, Fort Lee Executive Park, Fort Lee, NJ 07024, USA
Tel: +1 201 944 1120 Fax: +1 201 944 1132
FOR-A Corporation of America Distribution & Service Center
2400 N.E. Waldo Road, Gainesville, FL 32609, USA
Tel: +1 352 371 1505 Fax: +1 352 378 5320
FOR-A Corporation of America Miami Office
5200 Blue Lagoon Drive, Suite 760, Miami, FL 33126, USA
Tel: +1 305 931 1700 Fax: +1 305 264 7890
FOR-A Corporation of Canada
1131A, Leslie Street Suite 209, Toronto, Ontario M3C 2J6, Canada
Tel: +1 416 977 0343 Fax: +1 416 977 0657
FOR-A Europe S.r.l.
Via Volturno 37, 20861 Brugherio MB, Italy
Tel: +39 039 879 778 Fax: +39 039 878 140
FOR A UK Limited
Trident Court, 1 Oakcroft Road, Chessington, KT9 1BD, UK
Tel: +44 (0)20 3044 2935 Fax: +44(0)20 3044 2936
FOR-A Italia S.r.l.
Via Volturno 37, 20861 Brugherio MB, Italy
Tel: +39 039 881 086/103 Fax: +39 039 878 140
FOR-A Corporation of Korea
1007, 57-5, Yangsan-ro, Yeongdeungpo-gu, Seoul 150-103, Korea
Tel: +82 (0)2 2637 0761 Fax: +82 (0)2 2637 0760
FOR-A China Limited
708B Huateng Building, No. 302, 3 District, Jinsong, Chaoyang, Beijing 100021, China
Tel: +86 (0)10 8721 6023 Fax: +86 (0)10 8721 6033
FOR-A Middle East-Africa Office
Dubai Media City, Aurora Tower, Office 1407, P.O. Box 502688, Dubai, UAE
Tel: +971 (0)4 551 5830 Fax: +971 (0)4 551 5832
Agiv (India) Private Limited (FOR-A India)
85, V.N. Purav Marg Sion-Chunabhatti (E) Mumbai - 400 022
Tel: +91 22 2405 1258 Fax: +91 22 2405 0007
2015/03/27 Printed in Japan
http://www.for-a.com/
This manual suits for next models
1
Table of contents
Other FOR-A Amplifier manuals

FOR-A
FOR-A USF-1053DDA User manual

FOR-A
FOR-A USF-105DADA User manual

FOR-A
FOR-A UFH-70ADA User manual

FOR-A
FOR-A DDA-106 User manual

FOR-A
FOR-A ADA+205A User manual

FOR-A
FOR-A USF-105DDA-12G User manual

FOR-A
FOR-A UFM-15VDA User manual

FOR-A
FOR-A USF-1053DDA User manual

FOR-A
FOR-A UFH-DDAEX User manual

FOR-A
FOR-A USF-111DDA-12G User manual
