Forest garden Large Apex Out Door Store OPAOSFP User manual

Forest Garden Ltd. | Unit 288 | Oak Drive | Hartlebury Trading Estate | Hartlebury | Worcestershire | DY10 4JB
Pre-drill
for each screw
used.
This article contains biocidal products to give protection against
wood destroying insects & wood rotting fungi. Contents may vary.
May contain : Basic copper carbonate (Copper (II) carbonate –
Copper (II) hydroxide (1:1), Cupric oxide, Copper hydroxide
carbonate, oxyethyl, ammoniumpropionate, Copper HDO,
Propiconazole, Tebuconazole, Boric acid, Benzalkonium chloride.
Wear gloves when handling freshly treated wood. Avoid breathing
dust when cutting treated or untreated wood. Dispose of off-cuts
responsibly – do not burn.
Drill/Pozi Drive
Screwdriver
Tape Measure
Tools Required
Not Supplied
Spirit Level
Hammer
Sharp Knife
Fixing Pack Code = OPAOSFP
a
b
c
aad
ae
f
g
h
50mm Screw Qty 16 25mm Screw Qty 75
30mm Nail Qty36
Hasp And Staple Qty 1
Flush Hinge Qty 4
Turn Button Qty 2
Issue 0118
Large Apex Out Door Store
OPAOSFP
This fixing pack covers multiple products. Please make sure you quote from the relevant parts list in the event you need to order missing or damaged parts.
SPALOS (Shiplap) PARTS LIST
Item Part Code Part Description Quantity
1 OPOSBP OLAP PTR OUTDOOR STORAGE BACK PANEL 1
2 POSFP OLAP PTR OUTDOOR STORE FRONT PANEL 1
3 OPOSSP OLAP PTR OUDOOR STORAGE SIDE PANEL 2
4 POSDR PTR OUTDOOR STORE DOOR 2
5 AOSRF OLAP APEX OUTDOOR STORE ROOF 2
6 121120907PAII83PT BOARD 121x12x907mm PAR ANGLED PTREAT 4
7 45281183PT BATTEN 45x28x1183mm PTREAT 1
8 44121372PPT STRIP 44x12x1372mm PAR PTREAT 2
9 121121010PAII83PT BOARD 121x12x1010mm PAR ANGLED PTREAT 4
10 121120784PPT BOARD 121x12x784mm PAR PTREAT 2
11 18287508 OSB 1828x750x8mm 1
12 28281828PT BATTEN 28x28x1828mm PTREAT 3
13 28280070PT BATTEN 28x28x70mm PTREAT 4
14 44161372PT STRIP 44x16x1372mm PTREAT 2
15 85063 BLACK FELT 2.5 x 1 METRE 1
Item Part Code Part Description Quantity
1 SPOSBP SLAP PTR OUTDOOR STORAGE BACK PANEL 1
2 POSFP OLAP PTR OUTDOOR STORE FRONT PANEL 1
3 SPOSSP SLAP PTR OUDOOR STORAGE SIDE PANEL 2
4 POSDR PTR OUTDOOR STORE DOOR 2
5 AOSRF OLAP APEX OUTDOOR STORE ROOF 2
6 121120907PAII83PT BOARD 121x12x907mm PAR ANGLED PTREAT 4
7 45281183PT BATTEN 45x28x1183mm PTREAT 1
8 44121372PPT STRIP 44x12x1372mm PAR PTREAT 4
9 121121010PAII83PT BOARD 121x12x1010mm PAR ANGLED 4
10 121120784PPT BOARD 121x12x784mm PAR PTREAT 2
11 18287508 OSB 1828x750x8mm 1
12 28281828PT BATTEN 28x28x1828mm PTREAT 3
13 28280070PT BATTEN 28x28x70mm PTREAT 4
15 85602 GREEN FELT 2.5 x 1 METRE 1
Help line: 08:30 to 17:00 Monday to Friday0333 7777 089
Important:
Assembly of this product requires a
minimum of two adults.
Attention:
nFor Domestic Use Only.
nMust be built on a andsolid level
base.
nRegularly check that all fixing are
tight and secure.
nRegularly check the felt for damage.
This product is pressure totreated
ensure longevity of all timber
components and to protect against rot.
This may leave a colour difference on
some parts that will even out as the
moisture content stabilises This will not.
need additional treatment.
nPlease keep all plastic bags and
small parts away from children.
nThe roof of this product is not a load
bearing structure.
nTimber is a natural material and will
shrink and swell as a result of
varying moisture content.
Assembly of damaged parts may be
deemed to be acceptance and this may
affect the remedies you are entitled to.
If the product is not constructed in
accordance with the instructions, or is
altered in anyway (e.g. painted), the
manufacturer cannot be held liable for
any resulting damage.
Please check all parts prior to
assembly.
30mm Screw Qty 2
Felt Tacks Qty 40
OPALOS (Pressure Treated Overlap ) PARTS LIST

AB
CD
PRE-DRILL PRE-DRILL PRE-DRILL
4
7af
af
af
af
f
f
f
f
af
Place and fix the corner strips using 4 x
nails. Make sure these are flush on all
sides before fixing.
A11
12
flush
flush
flush af
af
af
af
af
afaf
13
10 ad
ad
Floor and Barge Board assembly
centre line
Place the panels on top of the floor. Make
sure they are tight and flush before fixing
them to each other using 2 x 50mm
screws at each corner.
3
2
1
ae
ae e
ae
Fix the panels to the
floor using 3 x 50mm
screws to the front and
back and 1 x 50mm
screw for the sides.
Make sure the screws
locate into the floor
bearers.
e
e
e
13
6
14
8
d
d
ad
ad
Place the board onto the blocks. The
blocks should be flush on the narrow
side and offset 10mm from the long
side. Fix each in place screwing
through the board with 2 x 25mm
screws for each.
Repeat with the other boards and
remaining blocks.
These are the side barge boards for
the roof.
113mm
Place the angled boards against the
front and back panels as shown to
create an apex. Fix each board in
place using 2 x 25mm screws.
14 is for the
Overlap Garden
Store only. Offset 21mm
at the top.
The batten should be fixed so it is
tight against the horizontal battens
on the reverse of the door and offset
12mm from the top.
Front Corner Strip
28mm
The top point of the
board should be offset
113mm from the panel

EF
GH
PRE-DRILL PRE-DRILL PRE-DRILL
9
d
d
d
d
d
d
Place the front and
back barge boards
against the roof so that
they are in line with the
top of the roof and
meet at the apex. Fix
each in place using 2 x
25mm screws
positioned as shown.
Position and fix the
side barge boards
against the ends of the
roof using 2 x 25mm
screws.
Further secure the
barge board at the
corner screwing into
each of the blocks at
the ends using 2 x
25mm screws for each.
flush
h
h
Take care when
trimming the roof
felt.
Forest Garden Ltd. | Unit 288 | Oak Drive | Hartlebury Trading Estate | Hartlebury | Worcestershire | DY10 4JB Issue 0118
7
Place a turn
button on the
top and bottom
of the batten.
ag ab
ac
d
x 6
Fix the smaller piece of
the hinge to the door.
5
d
dPlace the roof sections so that they
line up at the apex. Fix these from
the inside screwing through the apex
boards into the battens using 4 x
25mm screws for each roof section.
Apex Boards
9
Block
d
x 7
Position and line up the hasp
and staple with framing on the
inside of the door.
The top of the hinge
should be in line with the
horizontal batten
Place the felt over the roof so
that there is approximately a
45mm overhang on all sides.
Secure the felt to the roof,
nailing into the ba! ens from
the sides using felt tacks
placed in 150mm intervals.
Cut and fold the felt at the
corners as shown.
h
