Forest garden OPA77DD User manual

Overlap Apex Shed
7' x 7'
Important :
Assembly of this
shed requires a
minimum of two
adults.
B
OPA7PE
PLAIN END
OPA7WS
WINDOW PANEL
207012358
ROOF SHEET
QTY 2
DEF
A
OPA77DD PARTS LIST
BRDFL37
FLOOR QTY 2
DDRPT
DOOR
QTY 2
OPA7DDE
DOOR END
44161570PT
1570mm C/STRIP QTY 4
H
M
J
45281630PT
1630mm BATTEN QTY 1
G
2
11
C
OPA7PS
PLAIN PANEL
3
REQUIRED TOOLS :
(NOT SUPPLIED)
HAMMER
59121273PAII62PT
1273mm BARGE BOARD QTY 4
K
H
Must Pre-drill for
each screw used.
37282070PT
2070mm BATTEN QTY 2
O
L
FELT QTY 1
FELT4BLROSE
Place the panels on top of the floor. Make sure that all the panels are tight and flush before fixing
them to each other using 3x50mm screws.
Make sure that the panels are tight and are sitting flush before fixing each panel to the floor using 3 x
50mm screws making sure that all of the screws are locating into the bearers underneath.
Fixing Pack (OPA77DDFP)
This fixing pack is used for several products.
There may be additional fixings.
Not to Scale
Flush Hinge
Qty 4
50mm Screw Qty 28
30mm Nail Qty 80
25mm Screw Qty 39
Hasp & Staple
30mm Screw Qty 22
10mm Felt tacks
Qty 120
Place the hinges against the batten on the side of the door in line
with the battens on the back. Fix the inner/smaller part of the hinge
to the door using 25mm screws.
Place the Door into the Door End ensuring that the door is square
and fix the outer part of each hinge to the framing of the door end
using 25mm screws.
I FIN20010512PTR
FINIAL
QTY 1
SHARP KNIFE
IMPORTANT, RETAIN FOR FUTURE REFERENCE; READ
CAREFULLY
Check all parts prior to assembly
This building is pressure treated to ensure longevity of all
timber components and to protect against rot. This may leave
a colour difference on some parts that will even out as the
moisture content stabilises. This will not need additional
treatment.
- This product must be built on a solid level base.
- The roof of this building is not a load bearing structure.
- Please keep all plastic bags and small parts away from
children
- Timber is a natural material. It will shrink and swell as a
result of varying moisture content.
- Due to the nature of the material the doors may need some
trimming for a neater fit.
Technical Helpline: 0333 7777 089 8.30 am and 5.00
pm Monday to Friday.
In line with your statutory rights, please check all parts prior
to assembly, as assembly of damaged parts may be deemed
to be acceptance and this may affect the remedies you are
entitled to.
If the product is not constructed in accordance with the
instructions, or is altered in any way (e.g. painted), the
manufacturer cannot be held liable for any resulting damage.
37281982PT
1982mm BATTEN QTY 4
Z’ bracket Qty 8
Ridge Plate
60mm Screw Qty 3
PCWIN1
WINDOW QTY 2
45120675PPT
675mm STRIP QTY 1
P
Fix the two floor sections together
using 3 x 50mm screws.
Top View
E
B
C
D
A
STEP LADDER
40mm Screw Qty 12
Turn Button
Qty 2
84996
PLASTIC L’ STRIP QTY 4
N
The windows are packed
together tightly, separate
before assembly.
Place the corner strips so that they cover the joins between
the panels. Fix each in place using 3 x 30mm screws.
L
4
Place the 1630mm batten against the inside of the door so that
it is tight against the battens on the reverse of the door and
leaves a small gap at the top and bottom. Fix the batten in
place with 3 x 60mm screws.
Fix a turn button to the top and bottom of the batten so that the
door will be held closed when fixed. Use a 30mm screw for
each turn button.
5
flush
J
SCISSORS
FLAT HEAD
SCREWDRIVER
POZI DRIVE
SCREWDRIVER
TAPE MEASURE
25mm Security Screws
Screws Qty 14
F

Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
Biocidal Product Regulation (EU 528/2012) Article 58 Information
This article contains timber treated with Celcure AC-500, incorporating biocidal products to give protection against wood destroying insects & wood rotting fungi.
Contains: Basic copper carbonate (Copper (II) carbonate – Copper (II) hydroxide (1:1)), Boric acid, Benzalkonium chloride.
Wear gloves when handling freshly treated wood. Avoid breathing dust when cutting treated or untreated wood. Dispose of off-cuts responsibly – do not burn.
9
Place the barge boards against the front and back of the shed. Make
sure that these are in line with the roof sheet and meet at the apex.
Fix each in place using 3 x 40mm screws.
Place the finial over the top of where the barge boards meet to cover
the join and fix it in place using 2 x 30mm screws.
10
7
11
6
Unroll the felt and cut it into three equal lengths. Place a section on each
eaves so that there is a 50mm overhang on each edge as shown. Fix this
to the roof using felt nails spaced in 150mm intervals. Cut and fold the
corners securing with a single felt nail for each.
Place the remaining section as shown making sure that the it overlaps the
others. Again secure each sheet in place using felt nails spaced in 150mm
intervals.
8
Before fixing the Hasp to the door, make sure that it is in line with the framing
on the reverse of the door and that it closes over the Staple. Fix this in place
using 2 x 25mm screws.
Position the Staple opposite, again making sure that it is in line with the
framing behind and fix it in place using 3 x 25mm screws.
Fix the ridge plate from inside the shed so that it bridges the two battens at
the apex together. Fix using 2 x 25mm screws
K
I
K
I
Maintenance.
Regularly check that all fixings are secure.
The roofing felt has no holes or tears.
There are no splits in the wood and any large splinters removed.
ISSUE 0115
P
Place the window from the outside so that the lip sits on the bottom board as
shown.
Place the plastic strips at the top and bottom of the window so that one side butts
up against the cladding. Fix each strip in place using 2 x security screws.
Place one 675mm wooden strip in the middle, so that it overlaps the window
equally on both sides. Place the remaining strips either side of the windows. Again
fix each wooden strip in place using 2 x 25mm security screws.
Attention:
Take care when
placing the
screws. These
can not be
backed out.
N
Board
P
Lift the roof sections into place making sure that they are in line with the
apex and the front and back panels of the shed.
Fix the roof in place using 30mm nails spaced in approximately 300mm
intervals. (Make sure the nails locate into the framework of the panels)
Attention
Take care when cutting
and trimming the roof
felt.
Nailing through the roof sheet (G) in to the battens. Position the battens as shown.
1.The 2070mm batten (M) should be flush on all sides.
2.Place a 1982mm batten (O) so that it is offset 45mm on either side and has a 15mm offset on
the long side.
3.Place another 1982mm batten (O) in between, again with a 45mm offset on both sides.
Fix each batten in place using 30mm nails spaced in 300mm intervals.
Fix a Z’ bracket to
each end of the
1982mm battens
using a 25mm
screw for each.
B
K15mm Offset
M
G
O
45mm Offset
G
pencil line
Lip
