Forest garden Oakley Summer House 8 x 6 User manual

Oakley
Summer House
8' x 6'
258cm
223cm
193cm
187cm 240cm

IMPORTANT, RETAIN FOR FUTURE
REFERENCE: READ CAREFULLY.
Check all parts are present prior to assembly.
The timber in this product is pressure treated to
ensure longevity and protection against rot. This
may leave a colour variation but these will even out
as the moisture content stabilises.
- Timber is a natural material and will shrink and
swell as a result of varying moisture content.
- Keep all plastic bags and parts away from
children.
In line with your statutory rights, please check all
parts prior to assembly, as assembly of damaged
parts may be deemed to be acceptance and this
may affect the remedies you are entitled to. The
manufacturer does not accept any liability for injury
or damage to property caused by this product not
being constructed in accordance with our
instructions or being altered in any way.
Technical Help line: 0333 7777 089
8:30am - 5.00pm Monday to Friday
Important:
Assembly of
this product
requires a
minimum of
two adults.
This article contains biocidal products to give protection against
wood destroying insects & wood rotting fungi. Contents may
vary.
May contain : Basic copper carbonate (Copper (II) carbonate –
Copper (II) hydroxide (1:1), Cupric oxide, Copper hydroxide
carbonate, oxyethyl, ammoniumpropionate, Copper HDO,
Propiconazole, Tebuconazole, Boric acid, Benzalkonium
chloride.
Wear gloves when handling freshly treated wood. Avoid
breathing dust when cutting treated or untreated wood. Dispose
of off-cuts responsibly – do not burn.
Pre-drill for
each screw
used.
- For Domes$c Use Only.
- Must be built on a solid and
level base.
- Regularly check that all fixing are
$ght and secure.
- Regularly check the felt for
damage.
Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
GLAZING
DO NOT remove the
protective film on any
of the glazing until the
building is completed.
Issue 0417
Hammer
Drill/Pozi Drive
Screwdriver
Tape Measure
Tools Required
Not Supplied
Spirit Level
Sharp Knife
AB
60mm Screw Qty 4
O
4.0 x 50mm Screw Qty 27
30mm Nail Qty 53
Felt Nail Qty 120
D
J
F
K
Tower Bolt Qty 1
(supplied with 6 x 20mm screws)
Barrel Bolt Qty 2
(supplied with own fixings)
Z’ bracket
Qty 8
Hinge
Qty 6
Panel Pin Qty 68
Turn Button
Qty 3
3.5 x 30mm Screw Qty 3
(Silver)
I
L
3.5 x 40mm Screw Qty 12
MM
Hammer
Spirit Level
Sharp Knife
B
4.0 x25mm Screw Qty 6
I
D
K
F
L
Tower Bolt Qty 1
(supplied with 6 x 20mm screws)
Barrel Bolt Qty 2
(supplied with own fixings)
J
M
M
N
FIXING PACK (OPA86DDSUMFP) Not to scale
3.5 x 25mm Screw Qty 56
3.5 x 30mm Screw Qty 32
C
E
G
H
Drill/Pozi Drive
Screwdriver
Tape Measure
A
C
E
G
H
Tools Required
Not Supplied
Item
Number Part Code Description Quantity
1WS12X8BRDFLV2 12x8 WORKSHOP BOARDED FLOOR 2
2OPA8SUMDDE OPA86SUM DOOR END 1
4OPA8PE 10'x8' O/LAP WORKSHOP PLAIN END PTREAT 1
560151710PT CORNER STRIP 60x15x1710mm PTREAT 4
745281775PTR BATTEN 45x28x1775mm PTREAT 4
813409478 OSB 1340x947x8mm 4
945281895PTR BATTEN 45x28x1895mm PTREAT 2
12 FIN20010512PT FINIAL 200x105x12mm PTREAT 1
13 59121650PPT STRIP 59x12x1650mm PAR, PTREAT 2
14 XT5501150 XT ACRYLIC 550x1150x2mm 4
15 SDR553X1645PTBI SUMMER HOUSE DOOR 1645mm PTREAT BI 2
17 56120590PPT STRIP 56x12x590mm PAR PTREAT 2
18 69121667PPT STRIP 69x12x1667mm PAR PTREAT 2
19 40150747PPT STRIP 40x15x747mm PAR PTREAT 2
25 85009 PLASTIC Z-STRIP 610mm 4
27 15120500PPT BEAD 15x12x500mm PAR PTREAT 2
28 28121125PPT BATTEN 28x12x1125mm PAR PTREAT 8
29 28281200PBNPT BATTEN 28x28x1200mm PAR, BULLNOSED, 1
30 SUMBARGE1355PT SHAPED SUMMER HOUSE BARGE 1355mm 4
31 44121142PPT STRIP 44x12x1142mm PAR PTREAT 1
32 28120555PPT BATTEN 28x12x555mm PAR, PTREAT 4
33 74462400PT BETTEN 74x46x2400mm PTREAT 1
34 OPASUM86RHWS ODASUM86 RIGHT HAND WINDOW SIDE 1
35 OPASUM86LHWS OPASUM86 LEFT HAND WINDOW SIDE 1
36 15120475PPT BEAD 15x12x475mm PAR PTREAT 2
37 85008 GREEN MINERAL FELT 4 x 1 METER 2
PARTS LIST

571mm
17mm
offset
59mm
offset
7
K
Fix the panels to each other using 3 x 50mm screws for each join. Make sure that they are
all square before fixing the panels to the floor using 3 x 50mm screws for each.
(Take care to screw into the bearers underneath.)
Place the roof sheets on top of the ba# ens, posi$oned as shown. The two 1775mm ba# ens must have a 59mm offset at
each end and the outer one of these should also be offset 17mm from the edge of the roof sheet.
Use 6 x 30mm nails for each ba# en.
Turn the roof over and fix a Z bracket to each end of the shorter ba# ens using a 25mm screw
668mm
Panel overhangs Posi$on each of the corner strips so that they are
$ght and cover up the joint between panels.
Fix using 3 x 30mm screws for each.
Place each roof onto the building making sure that they are posi$oned
squarely and meet at the apex.
Fix in place using 30mm screws.
33
1
4
5
H
H
H
G
E
Fix the bearer to the back of the so that it
lines up on all sides. Fix using 4 x 60mm
screws.
H
H
H
H
H
2
35
34
8
9
O
O
O
O
K
K
K
K
L
L
L
H
L
L
L
L
L
L
45mm
1 2 3
4 5 6

12
29
18
17
G
L
X2
Place the strips to
the le& and right
hand side of the
entrance so they are
flush with the
window side and
overhang the
entrance
Fix each strip with
30mm nails.
Place the shaped
ba# en centrally
above the entrance
and fix in place using
3 x 50mm screws
making sure you are
screwing into the
framework behind.
Place the 1650mm strip inside the
entrance and against the framing. This
should also be flush with the framing on
the inside. Fix each strip with 3 x 30mm
screws
Fix the 1142mm strip at the
bo# om of the door entrance and
flush with the framing using 4 x
30mm nails.
Place the barge boards against the outside of the summer house making sure
that they meet at the apex and fix using 3 x 40mm screws.
Place the finial against the front and fix using 2 x 30mm nails.
Unroll the felt into three equal lengths and posi$on them on the building as
shown and that there is at least a 50mm overhang on all sides. Fix the felt in
place using the felt tacks provided and in 150mm intervals. Make sure the
tacks locate into the ba# ens behind.
Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
M
N
M
N
K
13
30
13
13
31
H
X3
L
X4
L
X2
M
N
K
K
K
L
X3
Cut and fold the
corners securing
with a single tack.
9
78
10

28
32
14
M
X3
M
X4
M
X3
HC
G
X2
G
X3
DJ
B
From outside place a Z strip so that it sits against
and on top of the overlap board as shown below.
Fix with panel pins.
GLAZING
DO NOT remove the
protec"ve film on any of the
glazing un"l the building is
completed.
From outside posi$on the
bolt against horizontal bar on the
door making sure that it will hold
the doors closed in the locked
posi$on.
(Use 25mm screws)
Place a turn bu# on at the top and
bo# om of the le& hand door and
fix using the silver 30mm screws
Fix the hinges to the door, fixing the
smaller part of the hinge, using 2 x 25mm
screws.
Posi$on the doors inside the entrance
and fix the hinge to the frame using
25mm screws.
Fix to door
Fix to door end
From inside place the glazing against the window fame and so that it sits in
the Z strip.
Place the glazing strips against the glazing at the bo# om and sides fixing them
to the framing using the panel pins.
From outside fix a glazing strip against the bo# om of the glazing and the Z strip
using 3 x panel pins.
14
27
M
X3
Measure and cut each
Z’ strip to size using a
pair of scissors.
Take care
InsideOutside
25
I
M
M
32
11 12
13 14

Top of door
141mm
19
29
Posi$on and fix each strip to the back of the le&
hand door using 3 x 25mm screws for each.
The bo# om strip should be 100mm from the floor
and there should be a gap between them of 70mm.
Both strips should overhang the door by 20mm.
Top View
20mm overhang
From inside posi$on one of the bolts against
the top strip you have previously fixed on the
reverse of the door.
Posi$on and fix the second smaller bolt in the gap
at the bo# om of the door.
Fix the turn bu# on to the inside of the opening
door using a single 30mm screw.
DJ
A
A
GLAZING
Lightly score around the
edges of each sheet with a
pair of scissors or a sharp
knife and peel off the
protec"ve film.
Take care
Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
G
X3
G
X3
19
15
16
