Forest garden FGHFV2FP User manual

Thank you for choosing this garden building
manufactured by the UK's largest manufacturer of
timber garden products. In order to gain the most
benefit from it, please note the following:
- This building is pressure treated to ensure the
longevity of all timber components and protect
against rot. This may leave a colour difference on
some parts that will even out as the moisture
contents stabilize.
- In line with your statutory rights, please check all
parts prior to assembly, as assembly of damaged
parts may be deemed to be acceptance and this
may affect the remedies you are entitled to.
-If the product is not constructed in accordance
with the instructions, or is altered in anyway (e.g.
painted), the manufacturer cannot be held liable
for any resulting damage.
- Timber is a natural material. It will shrink and
swell as a result of varying moisture content.
- Please keep all plastic bags and small parts
away from children in order to reduce the risk of
suffocation.
- Important Note : Do not lean or stand on roof
during assembly. The roof is not load bearing.
- If there are any technical queries with the
product, please contact our customer help line on
0333 7777 089 between the hours of 8.30 am and
5.00 pm Monday to Friday.
BASE PLAN
FGHFV2FP
Fixing pack code
FGHFV2RF
roof panel
Qty 6
FGHFV2P
full panel
Qty 2
FGHFV2DPC
door panel
Qty1
FGHFV2WPC
window panel
Qty 3
WBLB
work bench long brace
Qty 5
WBSB
work bench small brace
Qty 5
profile
TRADSUMWBLEG
work bench leg
Qty 20
Tack
Silicon Gun Qty 1
120mm Screws Qty 7
45mm Screws Qty 300
Small Handle
Lock & Keys
Hook & Eye Qty 2
70mm Screws Qty 84
Silicon Tube Qty 1
Handle & Catch Plate
POZI DRIVE SCREWDRIVER
TAPE MEASURE DRILL HAMMER
REQUIRED TOOLS : (NOT SUPPLIED)
TRADSUMV2PLUG
plug
Qty 1
TRADSUMV2UP
post Qty 6
TRADSUMV2FS
floor section
Qty 6
TRADSUMV2SB (qty 20)
bench side brace 330mm
TRADSUMV2BB (qty 5)
bench back brace 1078mm
TRADSUMSLAT830
bench slat 830mm(qty 5)
TRADSUMV2FB (qty 5)
bench front brace 735mm
TRADSUMV2SLAT1080
bench slat 1080mm (qty 5)
TRADSUMV2SLAT955
bench slat 955mm (qty 5)
TRADSUMV2FIN
finial
Qty 1
TRADSUMV2RAF
rafter Qty 6
RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
230cm
199cm
115cm
Issue 0214
Important : Assembly of this
arbour requires a minimum
of three adults.

MUST PRE DRILL
WINDOW PANEL
UPRIGHT
DOOR PANEL UPRIGHT
FULL PANEL
PLUG
Fix the uprights to the panels using
4x70mm screws for each side.
Place all panels onto the floor so that
everything is flush (Pre- drill).
Position the floor section together, face
down, as shown and fix together using
4 x 70mm screws. (Pre- drill)
A
C
Forest Garden Ltd, Unit 288, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
Place the floor sections together and so
that they are tight. Place the floor plug in
the centre. (Pre- drill)
B

FINIAL
ROOF PANEL
RAFTER
Use the silicon to seal along the
edges of the roof panels
Fix each panel to the floor sections
using 4x70mm screws, screwing
through the panel framing. (Pre- drill)
Slot the rafters into the finial
and fix using 1x120mm screw
for each rafter as shown.
(Pre- drill)
Place the rafter assembly on
to the building so that the
rafters sit in the top of the
uprights. Further secure the
rafters by using 2x70mm
screws for each. (Pre- drill)
Place the roof sections so that
they sit in the grooves of the
rafters. Fix each in place using
4x45mm screws for each side,
screwing through the framing into
the rafter. (Pre- drill)
D
F
E
G
MUST PRE DRILL
Issue 0214

SIDE BRACE
Assemble each work bench as
shown. Fix each board using
2x45mm screws for each end.
(Pre- drill)
Fix the lock and
handle as shown
using the fixings
supplied. (Pre- drill)
Place and fix the hook to the post so that is in
line with the door. Fix the eye to the door at the
desired position. Repeat for the opposite door.
(Pre- drill)
DOOR PANEL
BENCH LEG
FRONT
BRACE
BACK BRACE
LONG BRACE
SHORT
BRACE
955 SLAT
1080 SLAT
830 SLAT
H
I
J
MUST PRE DRILL
This article contains biocidal products to give protection against wood destroying insects & wood rotting fungi. Contents may vary.
May contain : Basic copper carbonate (Copper (II) carbonate – Copper (II) hydroxide (1:1), Cupric oxide, Copper hydroxide carbonate, oxyethyl, ammoniumpropionate, Copper HDO, Propiconazole, Tebuconazole, Boric acid, Benzalkonium chloride.
Wear gloves when handling freshly treated wood. Avoid breathing dust when cutting treated or untreated wood. Dispose of off- cuts responsibly – do not burn.
Forest Garden Ltd, Unit 288, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
