Argos Malvern 395/5152 User manual

MADE IN
BRITAIN
Dimensions
Malvern - 3 Drawer 3 Door Robe
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Issue 1 - 11/05/15
Important - Please read these instructions fully before starting assembly
ALR3205
395/5152
380/4629
Width - 119cm
Depth - 49.5cm
Height - 180cm

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 79kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 1, 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: It is
recommended that this unit is
secured to a wall using the
overbalance protector kit
supplied or, an alternative fixing
method of your choice.
• Dispose of all packaging
carefully and responsibly.
Bottom Left Drawer
Side (W370-165LH)
(370 x 165mm)
Drawer Base (T713-367)
(713 x 367mm) x 3
Bottom Right Drawer
Side (W370-165RH)
(370 x 165mm)
Bottom Drawer
Back (W702-165)
(702 x 165mm)
Top Drawer
Back (W702-124)
(702 x 124mm) x 2
Top Left Drawer
Side (W370-124LH)
(370 x 124mm) x 2
Top Right Drawer
Side (W370-124RH)
(370 x 124mm) x 2
Components - Panels
Please check you have all the panels listed below
1
If you have damaged or missing components, call the
Customer Helpline: 03456 400800 quoting the reference
numbers below
2 3 4
5 6 7 8
9
Top Drawer
Front (DF4049)
(778 x 195mm) x 2
Bottom Drawer
Front (DF105)
(778 x 243mm)

Components - Panels
Please check you have all the panels listed below
2
10 11 12
80%
x 3
If you have damaged or missing components, call the
Customer Helpline: 03456 400800 quoting the reference
numbers below
17
Left Side (DF3950)
(1739 x 474mm)
Right Side (DF3951)
(1739 x 474mm)
Divider (DF4052)
(1739 x 474mm)
Top (DF4047)
(1187 x 492mm)
Base (DF4048)
(1179 x 474mm)
Cross Rail (DF106)
(753 x 78mm)
16 Large Shelf (DF107)
(753 x 473mm)
Small Shelf (DF4053)
(377 x 473mm)
Small Back (X1772-396)
(1772 x 396mm)
Large Back (X1772-772)
(1772 x 772mm)
13
14
15
21
22
20 23 24
Large Hanging Rail (FHR745)
(745mm long)
18 Small Hanging Rail (FHR369)
(369mm long)
19
Left Door (DF4050)
(1107 x 387mm)
Middle Door (DF3952)
(1107 x 387mm)
Right Door (DF4051)
(1749 x 387mm)

Please check you have all the fittings listed below
3
Components - Fittings If you have damaged or missing components, call the
Customer Helpline: 03456 400800 quoting the reference
numbers below
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A B
D E F
R S
C
Metal dowel (F901) x 22
Wooden dowel (F22) x 22
Small locking
nut (F3) x 6 Large locking
nut (F900) x 16
40mm Screw (F910) x 6
UR Runner (F160) x 3
b
L Runner (F161) x 3
Uc
L Runner (F159) x 3
Ua
R Runner (F162) x 3
Ud
350mm long
N
Knock-in Peg (F171GY) x 12
M
Wedgefix (F639) x 12
TStrap
Screw Washer x 2
Overbalance protector kit (F269) x 1
P
Hinge plate
(F523) x 9 Hinge (F518) x 9
38mm Screw (F81) x 12
Rail Holder
(F891) x 4
Q
Foot
(F233) x 6
O
Handle (FBARHANDLE ) x 6
L
Back holder (F276) x 8
*These can also be round
K
Nail screw (F277) x 8
G H I
13mm Screw (F63) x 44 9mm Screw (F73) x 18
19mm Screw (F461) x 12
J
Nail (F51) x 40
A B
D E F
R S
C
Metal dowel (F901) x 22
Wooden dowel (F22) x 22
Small locking
nut (F3) x 6 Large locking
nut (F900) x 16
40mm Screw (F910) x 6
UR Runner (F160) x 3
b
L Runner (F161) x 3
Uc
L Runner (F159) x 3
Ua
R Runner (F162) x 3
Ud
350mm long
N
Knock-in Peg (F171GY) x 12
M
Wedgefix (F639) x 12
T
VStrap
Screw Washer x 2
Overbalance protector kit (F269) x 1
P
Hinge plate
(F523) x 9 Hinge (F518) x 9
38mm Screw (F81) x 10
Rail Holder
(F891) x 4
Q
Foot
(F233) x 5
Large Handle
(FBARH224 ) x 3
O
Small Handle
(FBARHANDLE ) x 3
L
Back holder (F276) x 12
*These can also be round
K
Nail screw (F277) x 12
G H I
13mm Screw (F63) x 40 9mm Screw (F73) x 18
19mm Screw (F461) x 12
J
Nail (F51) x 40

1
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 03456 400800 quoting the reference
numbers below
Step 1
x 2
x 2
x 2
x 2
A
A
B
B
B
B
23
2
3
A
A
Step 2
Prepare the 2 top
drawer fronts
Screw 2 metal dowels
into each of the top
drawer fronts .
Note: Tighten the metal
dowels up fully against
the panels.
A
1
Prepare the top
drawer sides
Insert a small locking
nut into the hole
shown on the top left
drawer side and the
top right drawer side .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Step 3
B
2
3
Attach the top drawer
sides to the top
drawer fronts
Push the top left drawer
sides . and top right
drawer sides . onto
the back of the top
drawer fronts .
Turn the small locking
nuts on the top left
drawer side and top
right drawer side .
Note: Turn the locking
nuts clockwise to
secure panels - more
than 1/2 a turn.
2
3
1
B
B
2
3
1

1
Assembly Instructions
5
Step 4
N
N
x 2
x 2
x 2
x 2
N
N
M
9
2
4
2
3
9
3
Fit the drawer base
Slide the drawer base
down the grooves in the
top drawer sides and
. and down into the
groove in the top drawer
front .
Step 5
Fit the top drawer back
Fit the top drawer back
. between the top
drawer sides and .
Make sure that the
drawer base fits into
the groove in the top
drawer back .
Hold the top drawer
back in position and
tap the knock-in pegs
through the holes in the
top drawer sides and
. .
Step 6
9
2
3
1
4
2 3
9
4
4
N
Attach the handles
Attach a handle to
each of the top drawer
fronts using screws
. .
O
G
1
2
3
Step 7
Fit the wedgefixes
Turn the 2 top drawer
assemblies over and
slide 4 wedgefixes
into the front and back
grooves, as shown, and
tighten up the screws.
M
M
M
M
M
G
G
O
1

Assembly Instructions
6
Step 8
Step 9
Prepare the bottom
drawer front
Screw 2 metal dowels
into the bottom drawer
front .
A
5
Prepare the bottom
drawer sides
Insert a small locking
nut into the hole
shown on the bottom left
drawer side and the
bottom right drawer side
. .
Step 10
B
6
7
Attach the bottom
drawer sides to the
bottom drawer front
Push the bottom left
drawer side . and
bottom right drawer side
. onto the back of the
bottom drawer front .
Turn the small locking
nuts on the bottom
left drawer side and
bottom right drawer side
. .
6
7
5
B
6
7
5
A
B
A
B
B
BB
67
7
6
A
A
5

Assembly Instructions
5
Step 11
N
N
5
9
6
7
N
N
M
M
M
M
M
9
8
6
7
5
Fit the wedgefixes
Turn the drawer
assembly over and slide
4 wedgefixes into the
front and back grooves,
as shown, and tighten up
the screws.
Fit the drawer base
Slide the drawer base
down the grooves in the
bottom drawer sides
and and down into
the groove in the bottom
drawer front .
Step 12
Step 13
9
6
7
5
Attach the handle
Attach the handle to
the bottom drawer front
. using screws .
G
5
O
Fit the bottom drawer
back
Fit the bottom drawer
back between the
bottom drawer sides
and .
Make sure that the
drawer base fits into
the groove in the bottom
drawer back .
Hold the bottom drawer
back in position and
tap the knock-in pegs
through the holes in the
bottom drawer sides
and .
8
6
7
9
8
8
N
6
7
Step 14
M
G
G
O

Assembly Instructions
8
Step 15
Fit runners to the 2
top drawers
Fit runner , marked
with ‘R’, to the bottom
edge of the top right
drawer side , as
shown, making sure that
it is pushed up against
the back of the top
drawer front . Use a
bradawl to mark the
fixing positions, then
secure with 2 screws .
Fit runner , marked
‘L’, to the bottom edge
of the top left drawer
side using the same
method.
2
U d
3
1
H
U c
Step 16
H
H
H
H
U d
R
R
Fit runners to the
bottom drawer
Fit a runner ,
marked with ‘R’, to the
bottom edge of the
bottom right drawer side
. , as shown, making
sure that it is pushed up
against the back of the
bottom drawer front .
Use a bradawl to mark
the fixing positions, then
secure with 2 screws .
Fit runner , marked
‘L’, to the bottom edge
of the bottom left drawer
side using the same
method.
6
U d
7
5
H
U c
L
U c
L
Runners must be
pushed up against
the drawer front
7
6
5
H
H
H
H
U d
R
R
L
U c
L
Runners must be
pushed up against
the drawer front
3
2
1
x 2

D
D
Assembly Instructions
9
Step 17
II
I
U b
H
H
P
R
R
R
R
Finished
front edge
Finished
front edge
U b
II 1st
screw
2nd
screw
I3rd
screw
II
I
U b
II
I
U b
Finished
front edge
C
A
A
D
D
Finished
front edge
U b
H
A
C
Prepare the divider
a: Fit 3 runners to
the divider .
The 1st screw uses
the 1st hole in from the
front of the runner.
The 2nd and 3rd screws
. use the holes that line
up with the other panel
holes.
Fit 3 hinge plates onto
the divider , making
sure that the slot is
facing towards the
finished front edge.
To fit the rail holder ,
screw through the top
hole with screw and
into the mark hole drilled
in the divider . Make
sure that it is fitted
straight, in line with the
panel edges and then fit
another screw using
the lower hole.
b: Fit a screw into
the 2nd hole in at the top
of the runners .
Insert 2 large locking
nuts into the divider
. .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Tap 4 wooden dowels
into the divider .
Screw 3 metal dowels
into the divider .
U b
12
I
I
H
A
12
C
12
D
12
U b
H
H
12
R
12
H
P
H
P
C
Note: Wooden
dowels must not
stick out from the
edge by more than
10mm or they may
damage other panels.
10mm
A
P
H
H
H
12
12
a:
b:

Finished
front edge
Finished
front edge
Assembly Instructions
10
Step 18
Finish preparing the
divider
Turn the divider over
To fit the rail holder ,
screw through the top
hole with screw and
into the mark hole drilled
in the divider . Make
sure that it is fitted
straight, in line with the
panel edges and then fit
another screw using
the lower hole.
Screw 2 metal dowels
into the divider .
H
H
12
P
Turn the
divider over
12
D
Step 19
Prepare the large shelf
Tap 4 wooden dowels
into the large shelf .
Insert 4 large locking
nuts into the large
shelf .
C
16
C
C
C
C
Finished
front edge
D
D
D
D
16
Fit the large shelf to
the divider
Push the large shelf
onto the divider .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the large shelf .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
16
12
C
16
C
Step 20
Finished
front edge
16
16
12
A
C
A
Prepare the divider
a: Fit 3 runners to
the divider .
The 1st screw uses
the 1st hole in from the
front of the runner.
The 2nd and 3rd screws
. use the holes that line
up with the other panel
holes.
Fit 3 hinge plates onto
the divider , making
sure that the slot is
facing towards the
finished front edge.
To fit the rail holder ,
screw through the top
hole with screw and
into the mark hole drilled
in the divider . Make
sure that it is fitted
straight, in line with the
panel edges and then fit
another screw using
the lower hole.
b: Fit a screw into
the 2nd hole in at the top
of the runners .
Insert 2 large locking
nuts into the divider
. .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Tap 4 wooden dowels
into the divider .
Screw 3 metal dowels
into the divider .
A
12
A
H
H
P
A
12

D
Finished
front edge
Assembly Instructions
Step 21
Finished
front edge
R
a:
b:
U a
H
Finished
front edge
U a
I I
1st
screw
2nd
screw I
3rd
screw
Finished
front edge
Prepare the left side
a: Fit 3 runners to
the left side .
The 1st screw uses
the 1st hole in from the
front of the runner.
The 2nd and 3rd screws
. use the holes that line
up with the other panel
holes.
Fit 3 hinge plates onto
the left side , making
sure that the slot is
facing towards the
finished front edge.
To fit the rail holder ,
screw through the top
hole with screw and
into the mark hole drilled
in the left side . Make
sure that it is fitted
straight, in line with the
panel edges and then fit
another screw using
the lower hole.
b: Fit a screw into
the 2nd hole in at the top
of the runners .
Insert 2 large locking
nuts into the left side
. .
Tap 4 wooden dowels
into the left side .
Screw 3 metal dowels
into the left side .
U a
10
I
I
H
A
10
C
10
D
10
U a
P
H
H
10
R
10
11
R
R
R
I
U a
I
I
I
U a
II
I
U a
II
H
H
P
H
H
H
A
A
A
D
C
C
D
D
10
10

Finished
front edge
Assembly Instructions
12
Step 22
Finished
front edge
Prepare the cross rail
Tap 2 wooden dowels
into the cross rail .
Insert 2 large locking
nuts into the cross rail
. .
Step 23
D
C
15
15
D
D
C
C
15
Note: Support the
cross rail until the left
side has been fitted
in the next step.
Fit the cross rail
Push the cross rail
onto the divider .
Use a screwdriver to
tighten the large locking
nut fitted to the cross
rail .
15
12
C
15
Step 24
15
12
15
10
16
Fit the left side
Push the left side
onto the assembly.
Use a screwdriver to
tighten the 3 large
locking nuts fitted to
the large shelf and
the cross rail .
C
16
10
15

17
Assembly Instructions
Step 25
13
D
Prepare the small shelf
Tap 4 wooden dowels
into the small shelf .
Insert 4 large locking
nuts into the small
shelf .
C
17
C
C
C
C
Finished
front edge D
D
D
D
17
17
Fit the small shelf to
the divider
Push the small shelf
onto the divider .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the small shelf .
17
12
C
17
Step 26
12
H
U a
H
Unfinished
back edge

Prepare the right side
Fit 3 hinge plates onto
the right side , making
sure that the slot is
facing towards the
finished front edge.
To fit the rail holder ,
screw through the top
hole with screw and
into the mark hole drilled
in the right side .
Make sure that it is fitted
straight, in line with the
panel edges and then fit
another screw using
the lower hole.
Insert 2 large locking
nuts into the right
side .
Tap 4 wooden dowels
into the right side .
Screw 2 metal dowels
into the right side .
Assembly Instructions
14
Step 27
R
R
R
RFinished
front edge
D
AD
C
A
D
A
H
H
P
C
D
11
C
11
D
11
P
H
11
R
11
H
11
11
17
Fit the right side to
the small shelf
Push the right side
onto the small shelf .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the small shelf .
11
17
C
17
Step 28

Assembly Instructions
Step 29
15
H
U a
H
Fit the base
Attach the base to
the left side , right
side and divider
using 6 screws .
14
10
11 12
E
E
E
E
EE
E
14
10
11
12
A
AA
A
A
A
Step 30
Prepare the top
Screw 6 metal dowels
into the top .
A
13
13
Finished
front edge

Assembly Instructions
16
Step 31
Fit the top
Push the top onto
the assembly.
Use a screwdriver to
tighten the 6 large
locking nuts fitted to
the left side , right
side and divider .
C
10
11 12
13
13
10
11
12
Note: To make it easier
to fit the top panel, place
polystyrene blocks from
the packaging underneath
the side and divider
panels to raise the
assembly.
Step 32
F
F
Q
F
F
Q
Fit the feet
Fit the feet to the
base using screws .
F
Q
14
F
F
Q
F
F
QF
F
Q
F
F
Q
14

y
y
x
y
x
Assembly Instructions
Step 33
17
H
U a
H
Fit the back panels
a: Square up the unit by
making sure that
measurement x:x equals
y:y.
Place the small back
and large back ,
coloured surface facing
down, onto the unit as
shown.
Make sure that the 2
backs are pushed up
tight against each other
and that they meet in the
centre of the divider’s
back edge.
b: Nail around the
outside edges of the 2
backs.
Note: Do not nail where
the 2 backs meet.
c: Push the nail screws
. through the back
holders and tap them
down between the small
back and large back
. and into the back
edge of the divider .
Keep tapping the nail
screws in until the
back holders dig into
the small and large back.
Stand the unit up for
the next step.
23
24
J
K
L
23
24
12
K
L
Warning: The
unit is heavy.
Lift with care.
Note: If ever you need to take
the backs off to dismantle the
unit, the nail screws can be
taken out using a screwdriver.
K
L
b:
J
Note: These can
also be round
LK +
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
c:
K
L
23
24
L
23
24

Assembly Instructions
18
Step 34
Step 35
Fit the drawers
Slide the wheels of the
runners fitted to the
drawers, over the wheels
of the runners fitted to
the side panel and push
the drawers into position.
Side
panel Drawer
18
18 19
P
Fit the hanging rail
Push the hanging rails
and into the rail
holders fitted to the
panels.
18
19
P19
Top drawer
Top drawer
Bottom drawer

Assembly Instructions
Step 36
19
H
U a
H
Prepare the 3 doors
Push fit 3 hinges into
each of the 3 doors ,
. and .
Secure each hinge with
2 screws .
Note: Before securing
with the screws, make
sure that the hinges are
positioned at 90 degrees
with the edge of the
door.
H
S
20
2221
90
S
Left Door (DF4050)
(1107 x 389mm)
Middle Door (DF3952)
(1107 x 389mm)
Right Door (DF4051)
(1749 x 389mm)
S
H
H
S
H
H
S
H
H
S
H
H
S
H
H
S
H
H
S
H
H
S
H
H
S
H
H
20
22
21
