FOS Technologies Luminus Pole User manual

FOS Luminus Pole
User Manual
This manual contains important information.
Please read before operating fixture.

1
SECURITY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or
injury to persons, follow these important safety instructions:
Rated voltage range: AC110V-120V/60Hz or AC200V-240V /
50HZ (to be selected).
Fixtures used in ambient temperature: -15 ℃-40 ℃, the highest
temperature of the surface of the lamp: 60 ℃.
Keep away from the liquid substance and humid environment.
Before using the lights must ensure the good grounding.
Do not use the fixture, in case of an abnormal behavior.
Technical Specifications
Power Supply: AC 100-240V/50-60Hz.
Power consumption: 90W.
Light source: 9pcs LED RGBWA+UV 6in1 mixing color.
Beam Angle: 25°.
Dimmer: 0-100% dimmer.
Strobe rate:0-24HZ.
Working Environment: -20℃-40℃.
IP rate: IP20, indoor.
DMX Channels: 2 DMX modes, 6 channels mode & 10 channels mode.
Control Mode: DMX512, Master-slave, Sound, Auto, Wireless, Wi-Fi,
Remote.
Battery:
Battery type: Lithium Ion.
Battery Charge Time: 6 hours (full power).
Battery Life: (two colors) 8hours, (single Color) 24hours.

2
Battery Power: 12V, 25Ah.
Wireless effective distance: 400 meters.
Net weight: 11kg
Production function:
DMX512 console control, which can be controlled online through 2.4G
wireless mode.
Mobile Wi-Fi operation control, support Android Android 2.3 and above,
Apple iOS 4.3 and above.
Mobile APP name: LED LAMP,Language: The software automatically
recognizes Chinese or English according to the system.
Static color selection (6 colors, dimming value 0-255) + strobe function
(speed adjustable 0-20).
Macro color: 16 colors to choose.
Automatic color jump function (speed adjustable 1-20)
Color gradient function (speed adjustable 1-20)
Color Sudden function (speed adjustable 1-20)
Strobe (speed adjustable 0-20)
2.4G wireless electronic switch, you can turn on or off the 2.4G
wireless power through the menu. You can know whether to turn on or
off the wireless module through the icon in the upper left corner of the
interface. The wireless transceiver frequency can be selected through
the menu.
White balance setting, adjust the brightness of the 6 colors
appropriately (also has the function of fine-tuning the current), the
value is (127-255)
The battery icon in the upper right corner of the interface can be turned
on or off by setting. For products without battery, it can be set to off
Screen saver settings: can be set to normally open or automatically

3
turn off the display backlight after 5 seconds, 10 seconds, 15 seconds
Infrared remote control function setting: can be turned on or off
through the menu setting.
Onboard Menu
MENU UP DOWN ENTER
Operate Menu
Menu Item1 Item2 Item3
"Choose Pattern" "Static" (Color) (Dimming)
RED 0-255
GREEN 0-255
BLUE 0-255
WHITE 0-255
AMBER 0-255
PURPLE 0-255
STROBE 0-20
"Macro" 1-32
(Speed)
"Show" "AUTO" 0-20
"FADE" 0-20
"SNAP" 0-20

4
"R-STRO" 0-20
"G-STRO" 0-20
"B-STRO" 0-20
"A-STRO" 0-20
(Sensitivity)
"Sound" "SOUND1" 0-100
"SOUND2" 0-100
"SOUND3" 0-100
(Options)
"User Settings" " Channel" 006/010
(Addressed)
" DMX512" 001-512
(Mode)
" Slave" OK
" WiFi" WiFi Icon
"System Settings" "1.white Balance" (Color) (Brightness)
RED 127-255
GREEN 127-255
BLUE 127-255
WHITE 127-255
AMBER 127-255
PURPLE 127-255
"2.Show Battery Icon" YES/NO
"3.Display Sleep" Open/5Sec/10S
ec/15Sec
"4.Autolock" YES/NO
"5.FAN Control" Auto/High/
Medium/Low
"6.Infrared Setting" ON/OFF
"7.Wireless Setting" ON/OFF
"8.Factory Reset" Password[----]

5
"Informations" "1.LED" (Temperature) 0-99℃
"2.WORK" (Hours) 001-999
"3.SOFT" (Version) 001
"4.LEVEL" (Percent) 10-100
1. 3-inch OLed display: display menu functions and parameters;
2.Button definition
MENU
Main menu function selection/exit submenu
UP
Select the previous menu/parameter
increment
DOWN
Select the next menu/parameter decreasing
ENTER
Recognize the selected function / enter the
next menu
Switch machine operation:
When the power is off, press and hold the MENU button, after 3 seconds,
the display will light up and be in the power-on state, and you can perform
the required function operations.

6
When the power is on, press and hold the MENU button, after 3 seconds,
the display will turn off and the power will be cut off.
"Choose Pattern" selection pattern
Select “Choose Pattern” and press the ENTER button to confirm. The
display will show the corresponding function menu. Such as static color,
macro function color mixing, performance mode, voice control mode. Use
the UP/DOWN button to select among the functions. If you press the
ENTER button, the display will enter the next menu item, and if you press
the Menu button, you will exit to the previous menu mode. The parameters
will be automatically saved after selection.
"User Settings" user settings
Select "User Settings" (user console mode setting), press the ENTER
button to confirm, the display will enter the channel options, use the
UP/DOWN button to select "6Ch" (6 channel mode), "10Ch" (10CH
channel mode), When you press the ENTER button again, the menu will
automatically jump to the "DMX512" address setting mode. With the
UP/DOWN button, you can adjust the address code you need to set
between 1 and 512. After you select it, the parameters will be automatically
saved. If you press the ENTER key again, it will return to the main interface.
When DMX512 signal is received, the interface will display "Connection"
prompt. If the DMX512 signal is disconnected, the interface will display
"Disconnect" prompt. If you press the ENTER or MENU button, the display
will exit to the previous menu mode.
"Slave" slave mode
Select "Slave" (slave mode), press the ENTER button to confirm, "Slave
Mode!" will be displayed. Indicates that it has entered the slave receiving

7
mode state. After selection, the parameters will be automatically saved.
When the host signal is received, the interface will display "Connection"
prompt, if the host signal is disconnected, the interface will display
"Disconnect" prompt, if you press ENTER Or press the MENU button, the
display will exit to the previous menu mode.
"System Settings" system settings mode
Select "System Settings" (system settings mode), press the ENTER button
to enter the next menu, use the UP/DOWN button to select different
settings among the setting functions, press the ENTER or MENU button,
the display will exit to the previous Level menu mode.
DMX512 console control mode
In the "User Settings" interface, press the ENTER button to confirm.
"Channel" (channel mode) is displayed on the screen, use the UP/DOWN
button to select "6Ch" (6 channel mode) or "10Ch" (10CH channel mode) as
needed, press the ENTER button to automatically jump to "DMX512"
(DMX512 address) Code setting), use the UP/DOWN button to adjust the
address code you need to set between 1 and 512, and then you can receive
the DMX512 console control signal.
If you want to use this function, please refer to the following diagram to set
the DMX512 addresses of the first 4 fixtures:
6CH mode: 1: A001, 2: A007, 3: A015, 4: A022
10CH mode: 1: A001, 2: A011, 3: A023, 4: A035

8
Master and Slave machine built-in program control
When multiple fixtures are connected in the main and auxiliary mode,
except for the first one, select "Slave" (slave mode) for the other fixtures
behind, press the ENTER button to confirm, and "OK!" will be displayed.
Indicates that it has entered the slave receiving mode state. After selection,
the parameters will be automatically saved. When the host signal is
received, the interface will display a "Connection" prompt. If the DMX512
signal is disconnected, the interface will display a "Disconnect" prompt. If
you press ENTER Or press the MENU button, the display will exit to the
previous menu mode. The first light fixture is used as the host, and all
performance modes can be selected, and the auxiliary unit will be
controlled by the host to perform the same actions.
WIFI Operation mode
In the "User Settings" interface, press the ENTER button, use the
UP/DOWN button to select "Wi-Fi Mode" (WIFI mode), press the ENTER
button, the Wi-Fi icon will appear, indicating that the Wi-Fi module has
been turned on, and you can use your mobile phone at this time Set up for
connection control. Open the phone settings function, find the wireless and
network WLAN items, connect the device with the name of LED_xxx, as
shown in the figure

9
When the connection is successful, exit the mobile phone function settings
and open the “Led LAMP” application software, then the corresponding
mode operation can be carried out. App interface and mobile phone
operating system may be different.
DMX CHANNEL SHEET
6CH mode
CH
Value
Function
1 0-255 Red
2 0-255 Green
3 0-255 Blue
4 0-255 White

10
5
0-255
Amber
6 0-255 UV
10CH mode
CH
Value
Function
1
0-255
Master dimmer, CH9(0~9)
2 0-9 Strobe close
10-255 Strobe open, from slow to fast
3 0-255 Red
4 0-255 Green
5 0-255 Blue
6
0-255
White
7
0-255
Amber
8
0-255
UV
9
0-9
Dimmer mode
10-29 Choose color: CH10 choose color
30-49 Jump change: CH10 control speed
50-69 Gradual change: CH10 control speed
70-89 Pulse change: CH10 control speed
90-109 Red On + Strobe: CH10 control speed
110-129 Green On + Strobe: CH10 control speed
130-149
Blue On + Strobe: CH10 control speed
150-169
Amber On + Strobe: CH10 control speed
170-189
Purple On + Strobe: CH10 control speed
190-209
Sound Jump change
210-229
Sound Jump change + Gradual change
230-255 Sound Strobe
10 0-255
CH10 function decided by CH9
When CH9 on 10-29, CH10 will choose
When CH9 on 30-189, CH10 will control speed, from
slow to fast

11
FIXED EQUIPMENT
Please fasten the fixture clamp before hanging. The clamp can be
fastened by the little hole in the middle of the bracket, then tie with a
safety belt. The loading capacity of the safety belt should be 10 times
than the weight of the fixture itself.
CONNECTION OF DMX-512 AND CONNETION WITH
THE LIGHT EQUIPMENT
Please connect XLR-XLR control wire with every light from the
output of DMX.
XLR connection:
ATTENTION: Please do remember to connect one circle circuit
plug on the output signal of last equipment. And this circle circuit
plug was connected a 120ohm resistance between terminals 2
and 3 of the CANON plug, connect this circle circuit plug can
avoid the signal flash phenomena of signal DMX512 during the
transmission.

12
Maintenance
Problems
Check list
Trouble Shooting
The fixture do
not work
1. If your power as same as the
input of the machine.
2. If the fuse was broken.
1. Make sure the
voltage.
2. Replace the same
fuse.
LED dimmed
If your power us same as the
input of the machine
Make sure t
he voltage
input.
No DMX input
1. If the polarity is opposite in the
DMX controller.
2. If it is in DMX mode.
3. If there are 2 Master in a loop.
1. Correct the DMX
polarity.
2. Change to the DMX
mode.
3. Set one piece into
Slave mode.
Par Light Set
works
abnormality
1. Check if the serial is correct on
the Par Light display
1. Set the right serial
No on the single Par
Light
AFTER SERVICE
1. Our company offer technical consultation to customers for
ever.
2. If the machine is wrong and need repairmen, please truthfully
fill in the related content and feedback us the problems timely,

13
as well as we must improve the product.
Note:
Based on our company continue to improve the product, the
statement containing data may have changed, and will not notice
the change. Company retains its right to change specifications
related when product is improved. Thanks for your
understanding.
