FOS Technologies Arena Zoom User manual

Arena Zoom 10x40 IP65
User Manual
This manual contains important information.
Please read before operating fixture.

1
1 SAFETY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or
injury to persons, follow these important safety instructions:
•non-professionals users should not disassemble the light arbitrarily
for maintenance or repairs.
•rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ
(to be selected).
•Keep the fixture at least 1 meter distance from flammable
materials.
•The fixture can be used in ambient temperature: -15 ℃-40 ℃,
the highest temperature of the surface of the lamp: 60 ℃.
•before using the fixture, must ensure the good grounding.
•the installation of fixtures, must be fixed screw fasteners with
additional security cable and regular inspection.
•Fixtures movable parts require regular maintenance and inspection
depending on the frequency of use.
•The air vents, airpaths, fans, should be inspected and cleared
regularly.

2
2 TECHNICAL SPECIFICATIONS
Input Voltage: AC100-240V 50/60Hz
Power: 400W
Light Source: 10pcs LED each 40 W, RGBW 4in1.
Led Feature: Individual control of each LED.
Led life: 50,000 hours life expectancy.
Zoom Angle: 5.8~60°
DMX Channels: 33CH / 19CH / 34CH / 28CH / 29CH / 48CH / 49CH
Control mode: DMX 512, master-slave, sound, Auto
Dimmer: 0-100% electronic
Shutter: Max 10Hz electronically
Display: Colored LCD display
Cooling: Efficient low noise fan cooling system
Tilt movement: 240o
Power connector: PowerCON IN / OUT
DMX connector: 3-pin XLR connectors IN / OUT
IP rate: IP65
Dimension: 607 x 122.3 x 350.9 mm
N.W.: 15.67KG

3
Product Dimensions(mm):
3 DISPLAY MENU LAYOUT
DMX MODE 001-512
RUN DMX512
Auto1
Auto 2
DMX MODE
33CH
19CH
34CH
28CH

4
29CH
48CH
49CH
TEST
ALL
Pan&Tilt
Lamp Test
SET Display Shutoff time ON
OFF
Flip display ON
OFF
Key lock
ON
OFF
Disp flash
ON
OFF
Tilt Reverse ON
OFF
No DMX Status Black
Hold
Language English
中文
INFO
Time info
Total
0000:00
Power on
0000:00
Version
SX- V1.01
Manual
Zoom
000-255
Tilt 000-255
Fuction 000-255
Dimmer 000-255
Strobe 000-255
Macro 000-255
Red 000-255
Green
000-255
Blue
000-255

5
White
000-255
Chase
000-255
Speed
000-255
Reset
All Reset
No
Yes
4 DMX CHANNEL SHEET
33CH
Channel DMX value Function
1
0-255
Tilt
2
0-255
Tilt fine
3
0-255
Zoom,wide(flood)-Narrow(spot)
4
0-7
Reserved
8-255
Reserved
5
Set 1 color(fixed)
0-7
Colors adjustable via RGB
8-15 Color 01-red
16-23 Color 02- amber
24-31 Color 03-warm yellow
32-39 Color 04-yellow
40-47 Color 05-green
48-55 Color 06-Turquoise
56-63
Color 07-cyan
64-71
Color 08-blue
72-79
Color 09-lavender
80-87
Color 10-malve
88-95 Color 11-magenta
96-103 Color 12-Pink
104-111 White-CTO (3200K)
112-119 White (5600K)

6
120-127
White-CTB (7200K)
128-255
Rainbow effect
6
0-255
Set 1 red, color mixing system
7 0-255 Set 1 green, color mixing system
8 0-255 Set 1 blue, color mixing system
9 0-255 Set 1 white, color mixing system
10
0-255
Set 1 intensity
11 Shutter
0-9 Shutter closed
10-109 Shutter pulse random, slow to fast
110-239 Strobe effect, slow to fast
240-255 Shutter closed
12 0-255 intensity
13
0-250
No function
251-255
Reset
14
Set 2 color :Values see channel 5
15
0-255
Set 2 red, color mixing system
16 0-255 Set 2 green, color mixing system
17 0-255 Set 2 blue, color mixing system
18 0-255 Set 2 white, color mixing system
19 0-255 Set 2 intensity
20 Set 3 color: values se channel 5
21
0-255
Set 3 red, color mixing system
22
0-255
Set 3 green, color mixing system
23
0-255
Set 3 blue, color mixing system
24
0-255
Set 3 white, color mixing system
25
0-255
Set 3 intensity
26 0-255 Reserved
27 0-255 Reserved
28 0-255 Set 1 pattern select

7
29
0-255
Pattern movement
30
0-255
Set 2 pattern select
31
0-255
29ch pattern movement Speed, fast to slow
32
0-255
Reserved
33 0-255 Reserved
19CH
Channel
DMX value
Function
1
Reserved
2
Reserved
3
0-255
Tilt
4
0-255
Tilt fine
5
Set 1 color(fixed)
0-7
Colors adjustable via RGB
8-15
Color 01-red
16-23 Color 02- amber
24-31 Color 03-warm yellow
32-39 Color 04-yellow
40-47 Color 05-green
48-55 Color 06-Turquoise
56-63
Color 07-cyan
64-71
Color 08-blue
72-79
Color 09-lavender
80-87
Color 10-malve
88-95 Color 11-magenta
96-103 Color 12-Pink
104-111 White-CTO (3200K)
112-119 White (5600K)
120-127 White-CTB (7200K)
128-255
Rainbow effect

8
6
0-255
Set 1 red, color mixing system
7
0-255
Set 1 green, color mixing system
8 0-255 Set 1 blue, color mixing system
9 0-255 Set 1 white, color mixing system
10
Shutter
0-9
Shutter closed
10-109
Shutter pulse random, slow to fast
110-239
Strobe effect, slow to fast
240-255 Shutter closed
11 0-255 Intensity
12 0-7 Reserved
8-255 Reserved
13 0-250 No function
251-255
Reset
14
0-255
Reserved
15
0-255
Pattern movement
16
0-255
Zoom,wide(flood)-Narrow(spot)
17
0-255
Set 1 pattern select
18 0-255 Reserved
19 0-255 Reserved
34CH
Channel DMX value Function
1
0-255
Tilt
2
0-255
Tilt fine
3 0-255 Zoom,wide(flood)-Narrow(spot)
4
0-7
Reserved
8-255 Reserved
5 Set 1 color(fixed)
0-7 Colors adjustable via RGB

9
8-15
Color 01-red
16-23
Color 02- amber
24-31
Color 03-warm yellow
32-39
Color 04-yellow
40-47 Color 05-green
48-55 Color 06-Turquoise
56-63 Color 07-cyan
64-71 Color 08-blue
72-79 Color 09-lavender
80-87 Color 10-malve
88-95
Color 11-magenta
96-103
Color 12-Pink
104-111
White-CTO (3200K)
112-119
White (5600K)
120-127 White-CTB (7200K)
128-255 Rainbow effect
6 0-255 Set 1 red, color mixing system
7 0-255 Set 1 green, color mixing system
8 0-255 Set 1 blue, color mixing system
9
0-255
Set 1 white, color mixing system
10 0-255 Set 1 intensity
11 Shutter
0-9 Shutter closed
10-109 Shutter pulse random, slow to fast
110-239
Strobe effect, slow to fast
240-255
Shutter closed
12
0-255
Intensity
13
0-255
Reserved
14 0-250 No function
251-255 Reset

10
15
Set 2 color :Values see channel 5
16
0-255
Set 2 red, color mixing system
17
0-255
Set 2 green, color mixing system
18
0-255
Set 2 blue, color mixing system
19 0-255 Set 2 white, color mixing system
20 0-255 Set 2 intensity
21 Set 3 color: values se channel 5
22 0-255 Set 3 red, color mixing system
23 0-255 Set 3 green, color mixing system
24 0-255 Set 3 blue, color mixing system
25
0-255
Set 3 white, color mixing system
26
0-255
Set 3 intensity
27
0-255
Reserved
28
0-255
Reserved
29 0-255 Set 1 pattern select
30 0-255 Pattern movement
31 0-255 Set 2 pattern select
32 0-255 30ch pattern movement speed, fast to slow
33 0-255 Reserved
34 0-255 Reserved
28CH
Channel
DMX value
Function
1
0-255
Tilt
2
0-255
Tilt fine
3
Shutter
0-9
Shutter closed
10-109
Shutter pulse random, slow to fast
110-239 Strobe effect, slow to fast
240-255 Shutter closed
4 0-255 Intensity
5 0-7 Reserved

11
8-255
Reserved
6
0-250
No function
251-255
Reset
7
0-255
Reserved
8 0-255 Zoom,wide(flood)-Narrow(spot)
9 0-255 Set 1&2 red, color mixing system
10 0-255 Set 1&2 green, color mixing system
11
0-255
Set 1&2 blue, color mixing system
12
0-255
Set 1&2 white, color mixing system
13 0-255 Set 3&4 red, color mixing system
14 0-255 Set 3&4 green, color mixing system
15 0-255 Set 3&4 blue, color mixing system
16 0-255 Set 3&4 white, color mixing system
17
0-255
Set 5&6 red, color mixing system
18
0-255
Set 5&6 green, color mixing system
19
0-255
Set 5&6 blue, color mixing system
20
0-255
Set 5&6white, color mixing system
21 0-255 Set 7&8 blue, color mixing system
22 0-255 Set 7&8 red, color mixing system
23 0-255 Set 7&8 green, color mixing system
24 0-255 Set 7&8 blue, color mixing system
25 0-255 Set 9&10 white, color mixing system
26
0-255
Set 9&10 red, color mixing system
27
0-255
Set 9&10 green, color mixing system
28
0-255
Set 9&10 blue, color mixing system
29CH
Channel DMX value Function
1 0-255 Tilt

12
2
0-255
Tilt fine
3
Shutter
0-9
Shutter closed
10-109
Shutter pulse random, slow to fast
110-239
Strobe effect, slow to fast
240-255 Shutter closed
4 0-255 Intensity
5 0-255 Reserved
6 0-7 Reserved
8-255 Reserved
7 0-250 No function
251-255 Reset
8 0-255 Reserved
9
0-255
Zoom,wide(flood)-Narrow(spot)
10
0-255
Set 1&2 red, color mixing system
11 0-255 Set 1&2 green, color mixing system
12 0-255 Set 1&2 blue, color mixing system
13 0-255 Set 1&2 white, color mixing system
14
0-255
Set 3&4 red, color mixing system
15
0-255
Set 3&4 green, color mixing system
16 0-255 Set 3&4 blue, color mixing system
17 0-255 Set 3&4 white, color mixing system
18 0-255 Set 5&6 red, color mixing system
19 0-255 Set 5&6 green, color mixing system
20 0-255 Set 5&6 blue, color mixing system
21
0-255
Set 5&6white, color mixing system
22
0-255
Set 7&8 blue, color mixing system
23
0-255
Set 7&8 red, color mixing system
24
0-255
Set 7&8 green, color mixing system
25 0-255 Set 7&8 blue, color mixing system

13
26
0-255
Set 9&10 white, color mixing system
27
0-255
Set 9&10 red, color mixing system
28
0-255
Set 9&10 green, color mixing system
29
0-255
Set 9&10 blue, color mixing system
48CH
Channel
DMX value
Function
1
0-255
Tilt
2
0-255
Tilt fine
3
Shutter
0-9
Shutter closed
10-109
Shutter pulse random, slow to fast
110-239 Strobe effect, slow to fast
240-255 Shutter closed
4 0-255 Intensity
5 0-7 Reserved
8-255 Reserved
6 0-250 No function
251-255
Reset
7
0-255
Reserved
8
0-255
Zoom,wide(flood)-Narrow(spot)
9
0-255
Set 1 red, color mixing system
10 0-255 Set 1 green, color mixing system
11 0-255 Set 1 blue, color mixing system
12
0-255
Set 1 white, color mixing system
13
0-255
Set 2 red, color mixing system
14 0-255 Set 2 green, color mixing system
15 0-255 Set 2 blue, color mixing system
16 0-255 Set 2 white, color mixing system

14
17
0-255
Set 3 red, color mixing system
18
0-255
Set 3 green, color mixing system
19
0-255
Set 3 blue, color mixing system
20
0-255
Set 3 white, color mixing system
21 0-255 Set 4 red, color mixing system
22 0-255 Set 4 green, color mixing system
23 0-255 Set 4 blue, color mixing system
24 0-255 Set 4 white, color mixing system
25 0-255 Set 5 red, color mixing system
26 0-255 Set 5 green, color mixing system
27
0-255
Set 5 blue, color mixing system
28
0-255
Set 5 white, color mixing system
29
0-255
Set 6 red, color mixing system
30
0-255
Set 6 green, color mixing system
31 0-255 Set 6 blue, color mixing system
32 0-255 Set 6 white, color mixing system
33 0-255 Set 7 red, color mixing system
34 0-255 Set 7 green, color mixing system
35 0-255 Set 7 blue, color mixing system
36 0-255 Set 7 white, color mixing system
37
0-255
Set 8 red, color mixing system
38
0-255
Set 8 green, color mixing system
39
0-255
Set 8 blue, color mixing system
40
0-255
Set 8 white, color mixing system
41 0-255 Set 9red, color mixing system
42 0-255 Set 9 green, color mixing system
43 0-255 Set 9 blue, color mixing system
44 0-255 Set 9 white, color mixing system
45 0-255 Set 10 red, color mixing system
46
0-255
Set 10 green, color mixing system
47
0-255
Set 10 blue, color mixing system
48
0-255
Set 10 white, color mixing system

15
49CH
Channel DMX value Function
1 0-255 Tilt
2 0-255 Tilt fine
3 Shutter
0-9
Shutter closed
10-109
Shutter pulse random, slow to fast
110-239
Strobe effect, slow to fast
240-255
Shutter closed
4
0-255
Intensity
5 0-255 Reserved
6
0-7
Reserved
8-255
Reserved
7
0-250
No function
251-255
Reset
8
0-255
Reserved
9 0-255 Zoom,wide(flood)-Narrow(spot)
10 0-255 Set 1 red, color mixing system
11 0-255 Set 1 green, color mixing system
12
0-255
Set 1 blue, color mixing system
13
0-255
Set 1 white, color mixing system
14 0-255 Set 2 red, color mixing system
15 0-255 Set 2 green, color mixing system
16
0-255
Set 2 blue, color mixing system
17
0-255
Set 2 white, color mixing system
18
0-255
Set 3 red, color mixing system
19
0-255
Set 3 green, color mixing system

16
20
0-255
Set 3 blue, color mixing system
21
0-255
Set 3 white, color mixing system
22
0-255
Set 4 red, color mixing system
23
0-255
Set 4 green, color mixing system
24 0-255 Set 4 blue, color mixing system
25 0-255 Set 4 white, color mixing system
26 0-255 Set 5 red, color mixing system
27 0-255 Set 5 green, color mixing system
28 0-255 Set 5 blue, color mixing system
29 0-255 Set 5 white, color mixing system
30
0-255
Set 6 red, color mixing system
31
0-255
Set 6 green, color mixing system
32
0-255
Set 6 blue, color mixing system
33
0-255
Set 6 white, color mixing system
34 0-255 Set 7 red, color mixing system
35 0-255 Set 7 green, color mixing system
36 0-255 Set 7 blue, color mixing system
37 0-255 Set 7 white, color mixing system
38 0-255 Set 8 red, color mixing system
39 0-255 Set 8 green, color mixing system
40
0-255
Set 8 blue, color mixing system
41
0-255
Set 8 white, color mixing system
42
0-255
Set 9red, color mixing system
43
0-255
Set 9 green, color mixing system
44 0-255 Set 9 blue, color mixing system
45 0-255 Set 9 white, color mixing system
46 0-255 Set 10 red, color mixing system
47 0-255 Set 10 green, color mixing system
48 0-255 Set 10 blue, color mixing system
49
0-255
Set 10 white, color mixing system

17
5 FIXED EQUIPMENT
Please fasten the fixture clamp before hanging. The clamp can be
fastened by the little hole in the middle of the bracket, then tie with a
safety belt. The loading capacity of the safety belt should be 10 times
than the weight of the fixture itself.
6 XLR CONNECTION LAYOUT
Please connect XLR-XLR control wire with every light from the output
of DMX.
XLR connection :
ATTENTION: Please do remember to connect one circle circuit plug on
the output signal of last equipment. And this circle circuit plug was
connected a 120ohm resistance between terminals 2 and 3 of the
CANON plug, connect this circle circuit plug can avoid the signal flash
phenomena of signal DMX512 during the transmission.

18
7 Maintenance / Troubleshooting
Problems
Check list
Trouble Shooting
The fixture
does not work.
1. If your power as same as the input
of the machine.
2. If the fuse was broken.
1. Make sure the voltage.
2. Replace the same fuse.
LED dimmed. If your power us same as the input
of the machine
Make sure the voltage
input.
No DMX
input.
1. If the polarity is reversed in the
DMX controller.
2. If it is in DMX mode.
3. If there are 2 Master in a loop.
1. Correct the DMX
polarity.
2. Change to the DMX
mode.
3. Set one piece into
Slave mode.
Par Light Set
works
abnormality.
1. Check if the serial is correct on
the Par Light display
1. Set the right serial No
on the single Par
Light
Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the
warranty will not work (warranty period and terms, see the following)
warranty period：one year since purchase warranty terms：1、If fail when using the product
in normal state, you can made under the provisions of the warranty, show the warranty card
and purchase bills(copy), and enjoy free maintenance service in a specific service center or
the manufacturer.
2. The following will be the implementation of paid service:
(1)Without the effective warranty card
(2)There’s blank, alter and no point-of-sale name
(3)Fail caused by unresistance
(4)Fail caused by transportation or unloading
(5)Fail caused by not operate by manual
(6)Fail caused by disassemble without unauthorized
(7)Fail caused by using the unauthorized control system

19
Note:
The manufacturer continues to improve the product, and all
specifications are subject to change without notice. Consult the online
user manual for an updated version in such case. Thank you for your
understanding.
