FOTRIC TD3 Series
Quick Start Manual

I II
Symbols
For the symbols that appear in the documentation, the
descriptions are listed below.
Warning Caution
Potential death or serious
injury inducing hazards
Potential danger of injury or
property damage.
Safety information
The purpose of this section is to ensure that the user uses the
product properly to avoid danger or property damage.
Before using this product, please read this instruction manual
carefully and keep it in a safe place for future reference.
Warning
• Do not disassemble or modify the camera battery. The battery
is equipped with safety and protection devices, which, if
tampered with, may cause the battery to overheat.
• If the battery leaks and gets into your eyes, do not rub, wash
with water and get immediate medical attention.
• Do not disassemble or modify the equipment in any way
(unauthorized modications or repairs will cause problems at

I II
your own risk).
Caution
• Protect the acoustic sensor array from stains, dust, and liquids
that could aect the performance of the acoustic imaging
camera or even cause permanent damage.
• Avoid using the product in humid, dusty, extremely hot, or cold
environments. For humidity requirements see the product
parameters table.
• It is strongly recommended to use the original power adapter.
The power adapter requirements are listed in the product
specication sheet.
• To prevent the potential risk of data loss, always copy (backup)
data to the computer.
• When storing the acoustic camera, it is strongly recommended
to use the original box and store it in a cool, dry, well-
ventilated environment free from strong electromagnetic
elds.
• When shipping the camera, it is strongly recommended that it
be shipped in the factory packaging for protection.

Contents
Acoustic Imaging Camera ������������������������������������������1
Front view ������������������������������������������������������������������������������������������������� 1
Rear view ��������������������������������������������������������������������������������������������������� 2
Side view ��������������������������������������������������������������������������������������������������� 3
Top view ���������������������������������������������������������������������������������������������������� 4
Interface Introduction �����������������������������������������������5
Main interface ������������������������������������������������������������������������������������������� 5
Save interface ������������������������������������������������������������������������������������������� 6
Gallery ������������������������������������������������������������������������������������������������������� 7
Settings ����������������������������������������������������������������������������������������������������� 9
Quick Start ��������������������������������������������������������������11
Operational Tips �����������������������������������������������������13
Frequency ltering ��������������������������������������������������������������������������������� 13
Gas leakage evaluation �������������������������������������������������������������������������� 14
Partial discharge detection ������������������������������������������������������������������� 16
About This Manual ��������������������������������������������������17
How to Contact FOTRIC �������������������������������������������19

FOTRIC TD3 Series Quick Start Manual 丨 1
Acoustic Imaging Camera
Front view

2丨FOTRIC TD3 Series Quick Start Manual
Rear view

FOTRIC TD3 Series Quick Start Manual 丨 3
Side view

4丨FOTRIC TD3 Series Quick Start Manual
Top view

FOTRIC TD3 Series Quick Start Manual 丨 5
Interface Introduction
Main interface
① Menu bar: Capture mode, signal lter mode, gallery, display
mode, Settings.
② Status bar: Display time, recording status, Wi-Fi, hotspot, power,
etc.
③ PRPD graph: Displays PRPD chart to help diagnose the type of
local play. (Only applicable under partial discharge mode)
④ Frequency display: Fast Fourier Transformation graph (sound
frequency spectrum) and enable users to select sound frequency
range.

6丨FOTRIC TD3 Series Quick Start Manual
⑤ Sound and video displays area: Displays visible light screen and
sound with palette-color overlay.
⑥ Photo/Video button: Switching between photo or video
recording function according to the capture mode.
⑦ Sound intensity trend graph: Displays the current maximum
sound intensity and sound intensity trend.
Save interface
① File name: Displays the le name, and you can modify the le
naming manually.
② Text annotation: Users can insert text annotation here.

FOTRIC TD3 Series Quick Start Manual 丨 7
③ Favorite:Apply ‘favorite’ to help lter important images
④ Cancel:Do not save the changes made on the le
⑤ OK: Conrm to save the changes
⑥ Defect diagnosis:Select among defect severity level,also
used in ltering images.
Gallery
① Return: Return to the main interface;
② Filter: Filter the list le according to the favorite status or
severity level diagnosis;
③ Data export: The icon lights up after the device is connected to

8丨FOTRIC TD3 Series Quick Start Manual
an external hard drive. It enables user to export all data;
④ Image information: Display sound pressure level, test distance,
frequency range, defect level;
⑤ Favorite: Add and cancel ‘favorite’ status;
⑥ Text annotation: Add or edit text annotation;
⑦ Spectrum: Display the frequency spectrum;
⑧ Delete: Delete the selected le;
⑨ Image list: Display the list of les, users can long press to delete
multiple selections;
⑩ Image display area: display the current selected le screen,
graphs and other information.

FOTRIC TD3 Series Quick Start Manual 丨 9
Settings
① Shooting mode: snap photo, recording, naming rules - default,
custom;
② Display: Brightness, sound, dynamic range;
③ Detection mode: Partial discharge mode and leakage mode;
④ Distance: Select the distance between 0.1~130 m
⑤ WLAN:Connect to a Wi-Fi;
⑥ Hot spot:On/o, hot spot’s name and password;
⑦ Time & Date:Set up the time for the system

10 丨 FOTRIC TD3 Series Quick Start Manual
⑧ System: Model, language, serial number, version information,
IP, power remaining, capacity remaining;
⑨ Reset: Reset parameters to factory default settings, delete all
saved les.

FOTRIC TD3 Series Quick Start Manual 丨 11
Quick Start
Follow these steps:
1. Place the battery in the battery compartment of the sound
camera.
2. Charge the battery to full capacity before starting the camera
for the rst time.
3. Press the power button to turn on the camera.
4. Select the detection mode according to user's need. (for more
details, see the next section)
5. Aim the camera at the target object.
6. Press the Photo button once to freeze the image. In this state,
users can modify the le name, add text notes, bookmark, or
select the diagnostic label.
7. Click the OK button, and the modied le will be saved
automatically.
8. Image or video les can be viewed by clicking on the gallery.
9. Insert a U disk in the Type-C port of the sound camera.
10. Click the in gallery interface to export the les
11. Install the SonicLab software on your PC.

12 丨 FOTRIC TD3 Series Quick Start Manual
12. Start the SonicLab professional analysis software.
13. Copy the exported data to the PC using a USB ash drive.
14. Bind the copied folder by SonicLab.
15. See the exported les in SonicLab. Double-click the selected
les to open them for analysis.
16. Select the le you want to export the report from the list and
click ‘Generate Report’ to export the Word report.

FOTRIC TD3 Series Quick Start Manual 丨 13
Operational Tips
Frequency ltering
The Fast Fourier Transformation (FFT) graph on the right presents
the frequency and amplitude of current sound signals. Users can
rene the analysis by adjusting the red box on the graph, isolating
the target signal and minimizing interference from other noise.

14 丨 FOTRIC TD3 Series Quick Start Manual
Gas leakage evaluation
To initiate leakage detection mode, navigate to Settings ->
Detection and select ‘Leakage Mode.’
For precise leakage assessment, accurately complete the
‘Parameters Cong’ table with the relevant details.
The correction factor is used to reconcile any dierences between
the calculated and the actual measured leakage rates, which may
arise from variables such as leakage shape, ambient humidity, and
background noise.
The power ratio reects the energy required to compress a unit
volume of the specied gas, which is essential for a comprehensive
evaluation.
The ‘Evaluation’ option within the display mode is accessible
only after selecting ‘Leakage Mode.’

FOTRIC TD3 Series Quick Start Manual 丨 15
Within the ‘Evaluation’ interface, the camera provides an
estimate of the annual cost associated with the detected leakage.

16 丨 FOTRIC TD3 Series Quick Start Manual
Partial discharge detection
To engage the partial discharge detection mode, navigate to
Settings -> Detection and choose ‘Partial Discharge Mode.’
In this mode, the Phase Resolved Partial Discharge (PRPD) graph is
displayed in the top right corner of the screen. Click on the graph
for an expanded view. When partial discharges are detected, the
PRPD graph will plot the pulses in a sinusoidal pattern, indicating
the phase angle and magnitude of each discharge occurrence.
The PRPD graph is a powerful diagnostic tool in acoustic cameras,
as it allows for the visualization of discharge patterns over time.
This visual representation helps to distinguish between dierent
types of discharges and to identify problematic insulation in
electrical equipment.
