FourStarGroup 12504043 User manual

MODEL: 12504043
KID’S POOL GAZEBO

2
NO
1
2
3
4
5
6
7
TUBE 1
TUBE 2
TUBE 3
TUBE 4
TUBE 5
TUBE 6
TUBE 7
8 PCS
8 PCS
4 PCS
4 PCS
4 PCS
4 PCS
4 PCS
A
B
C
D
E
F
G
FOOT CAP
3 WAY CONNECTOR
4 WAY BASE CONNECTOR
4 WAY UPPER CONNECTOR
ROOF CONNECTOR
PVC POOL
PE CANOPY
8 PCS
4 PCS
4 PCS
4 PCS
1 PC
1 PC
1 PC
HARDWARE LIST QTY
PARTS LIST AND HARDWARE

ASSEMBLY INSTRUCTIONS
3
PRECAUTIONS:
1. CHECK ALL PARTS AND HARDWARE LISTED ON THE PARTS
LIST. LAY THEM ON A CLEAR AND LEVEL SURFACE PRIOR
TO ASSEMBLY.
2. IT IS RECOMMENDED TO HAVE 2 PEOPLE FOR ASSEMBLY.
FIG. 1
STEP 1
CONNECT ALL THE 8 PCS OF TUBE 1 TO FOOT CAP (A) AS WELL
AS 3 WAY CONNECTOR (B) AND 4 WAY CONNECTOR (C).
SPREAD OUT PVC POOL (F). MAKE TUBE 2 THROUGH THE
SEWING EDGE ON THE PVC POOL (F) AND CONNECT THEM TO
THE 3 WAY CONNECTOR (B) AND 4 WAY CONNECTOR (C).
REFER TO FIG 1 TO FINISH THE ASSEMBLY OF THE POOL BASE.
C
11
1
1
1
1
1
A
A
A
A
A
AF
B

4
FIG. 2
STEP 2
CONNECT THE REST TUBES AS THE FIGURE BELOW SHOWS
TO FINISH THE MAIN FRAME OF THE ITEM.
B
C
3
3
3
4
4
46
7
5
5
5
3
D
D
D
E
A
6
7

5
FIG. 3
STEP 3
COVER THE PE CANOPY (G). FASTEN THE HOOK ON THE PE
CANOPY TO THE FOOT CAP, AND FIX THE PE CANOPY TO THE
POLE AS FIG 3.
NOW THE ASSEMBLY OF THIS ITEM IS FINISHED.

8
Do you have any questions? Missing small parts or hardware?
If you need assistance with the assembly of your KID’S POOL
GAZEBO please e-mail our Customer Service Department at:
[email protected]
or call us at [phone]
or [phone]
Please include the following information in your email:
• Where item was purchased
• Item, model, style or SKU number listed on instructions
or box
• Part number, description of the part and quantity needed
This information will help us get the proper part to you faster
!
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY
FROM THIS TENT FABRIC.
This tent meets the flammability requirements of CPAI-84. The fabric may
burn if left in continuous contact with any flame source. The application of
any foreign substance to the tent fabric may render the flame-resistant
properties ineffective.
Children should be supervised to play in or near this item in any cases.
Make sure the item is completely finished its assembly before using.
