foxunhd SX-EX11 User manual

Operating Instructions
2) Servicing Personnel: Do not attempt to service the unit beyond that described in
these operating instructions.Refer all other servicing to authorized servicing
personnel.
3) Replacement parts: When parts need replacing ensure the servicer uses parts
specified by the manufacturer or parts that have the same characteristics as the
original parts. Unauthorized substitutes may result in fire, electric shock, or other
hazards.
4) Safety check: After repairs or service, ask the servicer to perform safety checks
to confirm that the unit is in proper working condition.
WARRANTY
If your product does not work properly because of a defect in materials or
workmanship, our Company (referred to as "the warrantor" ) will, for the length of the
period indicated as below, (Parts(2)Year, Labor(90) Days) which starts with the
date of original purchase ("Limited Warranty period"), at its option either(a) repair
your product with new or refurbished parts, or (b) replace it with a new of a
refurbished product. The decision to repair or replace will be made by the warrantor.
During the "Labor" Limited Warranty period there will be no charge for labor.
During the "Parts" warranty period, there will be no charge for parts. You must
mail-in your product during the warranty period. This Limited Warranty is extended
only to the original purchaser and only covers product purchased as new. A
purchase receipt or other proof of original purchase date is required for Limited
Warranty service.
MAIL-IN SERVICE
When shipping the unit carefully pack and send it prepaid, adequately insured and
preferably in the original carton. Include a letter detailing the complaint and provide a
day time phone and/or email address where you can be reached.
LIMITED WARRANTY LIMITS AND EXCLUSIONS
1) This Limited Warranty ONLY COVERS failures due to defects in materials or
workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage.
The Limited Warranty ALSO DOES NOT COVER damages which occurred in
shipment,
or failures which are caused by products not supplied by warrantor, or failures which
result from accidents, misuse, abuse, neglect, mishandling, misapplication,
alteration, faulty installation, set-up adjustments, misadjustment of consumer
controls, improper maintenance, power line surge, lightning damage, modification,
or service by anyone other than a Factory Service center or other Authorized
Servicer, or damage that is attributable to acts of God.
2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
"LIMITED WARRANTY COVERAGE". THE WARRANTOR IS NOT LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF
THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRNTY. (As
examples, this excludes damages for lost time, cost of having someone remove or
re-install an installed unit if applicable,
travel to and from the service, loss of or damage to media or images, data or other
recorded content. The items listed are not exclusive, but are for illustration only.)
3) PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.
4
Operating Instructions
50m HDMI Extender over Single Cat5e/6, support 3D
Model: SX-EX11
Operating Instructions
Dear Customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
FEATURES
Each set includes one transmitter and one receiver.
Easy installation, no need setting.
Transmission Over 50m single CAT5e/6 without signal loss.
Supports Deep Color up to 24 bits.
Supports 3D.
Supports lossless compressed digital audio: Dolby TrueHD, DTS-HD Master
Audio.
DC 5V power supply.
EDID copy function.
NOTICE
Our company reserves the right to make changes in the hardware, packaging and
any accompanying documentation without prior written notice.
1

Operating Instructions
TABLE OF CONTENTS
Specifications
Package Contents
Panel Descriptions
Connecting and Operating
Maintenance
Product Service
Warranty
SPECIFICATIONS
Operating Temperature Range -5 to +35℃(+23 to +95℉)
Operating Humidity Range 5 to 90%RH (No Condensation)
Input Video Signal 0.5-1.0 Volts P-P
Input DDC Signal 5 volts p-p(TTL)
Support Video Format DTV/HDTV:576i/480P/576P/720P/1080i/1080P
3D video①
Video Output HDMI
Support Audio Format DTS-HD Master Audio、Dolby true-HD etc.
Transmission Distance 1080P 8-bit 50m(Maximum) over single CAT5E/6 /24AWG/Solid
Power consumption 5watts(Maximum)
Dimension (L×W×H) 83x48x25mm
Net Weight 250g(Pair)
Note1: Specifications are subject to change without notice. Mass and dimensions
are approximate.
① Sink must support 3D video when sources is 3D device
PACKING CONTENTS
1) Main Unit: Transmitter & Receiver
2) DC 5V 1A x2PCS
3) Operating Instructions
PANEL DESCRIPTIONS
Transmitter Panel
1. Status of signal connection 2.HDMI input 3.EDID copy button
4. CAT-5E/6 output 5.Power input
2
Operating Instructions
Receiver Panel
1. Status of signal connection 2. HDMI output 3. Status of power
input
4. CAT-5E/6 input 5. Power input
*Note: When the sink can’t display the signal, try to connect HDMI transmitter to
the display device. Plug the power supply into Transmitter, press the “EDID copy
button” and the light flashes, the EDID data has been copied from the display
device successfully, at least press ”EDID copy button” for 3 seconds, The EDID will
be reset to the default setting.
CONNECTING AND OPERATING
1) Connect the HDMI signal sources (Such as PS3, STB etc) to HDMI Transmitter.
2) Connect CAT5e/6 cable to both the output of the transmitter and input of the
Receiver. (The cables must follow the standard of EIA-TIA 568B).
3) Connect the HDMI display (Such as HD-LCD, HD-DLP) into the Receiver.
Attention: Insert/Extract cables gently.
Connection Diagram
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to
clean this unit.
PRODUCT SERVICE
1) Damage requiring service:
The unit should be serviced by qualified service personnel if:
(a) The DC power supply cord or AC adaptor has been damaged;
(b) Objects or liquids have gotten into the unit;
(c) The unit has been exposed to rain;
(d) The unit does not operate normally or exhibits a marked change in performance;
(e) The unit has been dropped or the cabinet damaged.
3
