Franke FDF 9146 XS ECS Operation manual

Instructions for use and installation
Cooker Hood
Vejledning for installation brug og vedligeholdelse
Emhætte
Handbok för installation användning och underhăll
Köksfläkt
Håndbok for installasjon bruk og vedlikehold
Kjøkkenvifte
Asennu
s
-
, k
äyttö
-
ja hoito
-
opas
Liesituuletin
FDF 6146 XS ECS
FDF 9146 XS ECS
GB
DK
SE
NO
FI

EN
2
2
Instructions Manual
INDEX
RECOMMENDATIONS AND SUGGESTIONS......................................................................................................................7
CHARACTERISTICS..............................................................................................................................................................8
INSTALLATION......................................................................................................................................................................9
USE.......................................................................................................................................................................................12
MAINTENANCE....................................................................................................................................................................13
EASYCLEANINGTM............................................................................................................................................................14

DK
3
3
Brugsvejledning
INDHOLD
RÅD OG ANVISNINGER......................................................................................................................................................17
APPARATBESKRIVELSE....................................................................................................................................................18
INSTALLATION....................................................................................................................................................................19
BRUG....................................................................................................................................................................................22
VEDLIGEHOLDELSE...........................................................................................................................................................23
EASYCLEANINGTM............................................................................................................................................................24

SE
4
4
Bruksanvisning
INNEHÅLL
REKOMMENDATIONER OCH TIPS....................................................................................................................................27
EGENSKAPER.....................................................................................................................................................................28
INSTALLATION....................................................................................................................................................................29
ANVÄNDING.........................................................................................................................................................................32
UNDERHÅLL........................................................................................................................................................................33
EASYCLEANINGTM............................................................................................................................................................34

NO
5
5
Bruksanvisning
INNHOLD
ANBEFALINGER OG FORSLAG.........................................................................................................................................37
EGENSKAPER.....................................................................................................................................................................38
INSTALLASJON...................................................................................................................................................................39
BRUK....................................................................................................................................................................................42
VEDLIKEHOLD.....................................................................................................................................................................43
EASYCLEANINGTM............................................................................................................................................................44

FI
6
6
Käyttöopas
SISÄLTÖ
SUOSITUKSET JA EHDOTUKSET .....................................................................................................................................47
MITAT JA OSAT...................................................................................................................................................................48
ASENNUS.............................................................................................................................................................................49
KÄYTTÖ................................................................................................................................................................................52
HUOLTO...............................................................................................................................................................................53
EASYCLEANINGTM............................................................................................................................................................54

EN
7
7
RECOMMENDATIONS AND SUGGESTIONS
INSTALLATION
• The manufacturer will not be held liable for any damages resulting
from incorrect or improper installation.
• The minimum safety distance between the cooker top and the extrac-
tor hood is 650 mm.
• Check that the mains voltage corresponds to that indicated on the
rating plate fixed to the inside of the hood.
• For Class I appliances, check that the domestic power supply guaran-
tees adequate earthing.
Connect the extractor to the exhaust flue through a pipe of minimum
diameter 120 mm. The route of the flue must be as short as possible.
• Do not connect the extractor hood to exhaust ducts carrying combus-
tion fumes (boilers, fireplaces, etc.).
• If the extractor is used in conjunction with non-electrical appliances
(e.g. gas burning appliances), a sufficient degree of aeration must be
guaranteed in the room in order to prevent the backflow of exhaust
gas. The kitchen must have an opening communicating directly with
the open air in order to guarantee the entry of clean air.
USE
• The extractor hood has been designed exclusively for domestic use to
eliminate kitchen smells.
• Never use the hood for purposes other than for which it has ben de-
signed.
• Never leave high naked flames under the hood when it is in operation.
• Adjust the flame intensity to direct it onto the bottom of the pan only,
making sure that it does not engulf the sides.
• Deep fat fryers must be continuously monitored during use: over-
heated oil can burst into flames.
• Do not flambè under the range hood; risk of fire
• The hood should not be used by children or persons not instructed in
its correct use.
MAINTENANCE
• Switch off or unplug the appliance from the mains supply before carry-
ing out any maintenance work.
• Clean and/or replace the Filters after the specified time period.
• Clean the hood using a damp cloth and a neutral liquid detergent.
650 mm min.

EN
8
8
CHARACTERISTICS
Dimensions
650 min.
490 60
108 259
150
min. 730
max. 1000
545
260
300
63
41
126
81
Components
Ref. Q.ty Product Components
11 Hood Body, complete with: Controls, Light, Blower,
Filters
21 Telescopic Chimney comprising:
2.1 1 Upper Section
2.2 1 Lower Section
91 Reducer Flange ø150-120 mm
10 1 Damper ø 150
14.1 2 Air Outlet ConnectionExtension
15 1 Air Outlet Connection
Ref. Q.ty Installation Components
7.2.1 2 Upper Chimney Section Fixing Brackets
7.3 1 Air Outlet Connection Support
11 6 Wall Plugs
12a 6 Screws 4,2 x 44,4
12c 6 Screws 2,9 x 9,5
Q.ty Documentation
1 Instruction Manual
2.1
2.2
2
12c
12a 7.2.1 11
11
12a
1
9
7.3
14.1
15
10

EN
9
9
INSTALLATION Wall drilling and bracket fixing
11
12a
320 X
116
1÷2
116
650 min.
7.2.1
Wall marking:
• Draw a vertical line on the supporting wall up to the ceiling, or as high as practical, at the
centre of the area in which the hood will be installed.
• Draw a horizontal line at 650 mm above the hob.
• Place bracket 7.2.1 on the wall as shown about 1-2 mm from the ceiling or upper limit align-
ing the centre (notch) with the vertical reference line.
• Mark the wall at the centres of the holes in the bracket.
• Place bracket 7.2.1 on the wall as shown at X mm below the first bracket (X = height of the
upper chimney section supplied), aligning the centre (notch) with the vertical line.
• Mark the wall at the centres of the holes in the bracket.
• Mark a reference point as indicated at 116 mm from the vertical reference line and 320 mm
above the horizontal reference line.
• Repeat this operation on the other side.
• Drill ø 8 mm holes at all the centre points marked.
• Insert the wall plugs 11 in the holes.
• Fix the lower bracket 7.2.1 using the 12a screws (4,2 x 44,4) supplied.
• Fix the upper bracket 7.2.1 and the air outlet connection support 7.3 together using the 2
screws 12a (4,2 x 44,4) supplied.
• Insert the two screws 12a (4,2 x 44,4) supplied in the hood body fixing holes, leaving a gap
of 5-6 mm between the wall and the head of the screw.

EN
1
0
10
Mounting the hood body
• Before attaching the hood body, tighten the two screws Vr lo-
cated on the hood body mounting points.
• Hook the hood body onto the screws 12a.
• Fully tighten support screws 12a.
• Adjust screws Vr to level the hood body.
12a
Vr
Connections
DUCTED VERSION AIR EXHAUST SYSTEM
When installing the ducted version, connect the hood to the
chimney using either a flexible or rigid pipe ø 150 or 120mm, the
choice of which is left to the installer.
To install a ø 150
• To install the dumper 10
• Fix the pipe in position using sufficient pipe clamps (not sup-
plied).
To install a ø 120
• To install a ø 120 mm air exhaust connection, insert the re-
ducer flange 9on the dumper 10.
• Fix the pipe in position using sufficient pipe clamps (not sup-
plied).
• Remove any activated charcoal filters.
9
ø 120ø 150
10
10
RECIRCULATION VERSION AIR OUTLET
• Put connection 15 into the connection support 7.3.
• Insert the connection extension pieces laterally 14.1 in connec-
tion 15.
• Make sure that the outlet of the extension pieces 14.1 is hori-
zontally and vertically aligned with the chimney outlets.
• Connect the air outlet connection 15 to the hood body outlet
using either a flexible or rigid pipe ø 150 mm, the choice of
which is left to the installer.
• Ensure that the activated charcoal filters have been inserted.
ø 150
14.1
15

EN
1
1
11
ELECTRICAL CONNECTION
• Connect the hood to the mains through a two-pole switch hav-
ing a contact gap of at least 3 mm.
• Remove the grease filters (see paragraph Maintenance) being
sure that the connector of the feeding cable is correctly inserted
in the socket placed on the side of the fan.
Flue assembly
Upper exhaust flue
• Slightly widen the two sides of the upper flue and hook them
behind the brackets 7.2.1, making sure that they are well
seated.
• Secure the sides to the brackets using the 4 screws 12c (2,9 x
9,5) supplied.
• Make sure that the outlet of the extensions pieces is aligned
with the chimney outlets.
Lower exhaust flue
• Slightly widen the two sides of the flue and hook them be-
tween the upper flue and the wall,
making sure that they are well seated.
• Fix the lower part laterally to the hood body using the 2 screws
12c (2,9 x 9,5) supplied.
12c
2.1
2.2
2
7.2.1
12c

EN
1
2
12
USE
SV1V1V1V1V1V1V1V1V1V1V1V1V1V1V1V1V1V1 V2 V3 L
LLight Switches the lighting system on and off.
SLed Motor running led.
V1 Motor Switches the extractor motor on and off at low speed. Used to provide a
contin-uos and silent air change in the presence of light cooking vapours.
V2 Speed Medium speed, suitable for most operating conditions given the optimum
treated air flox/noise level ratio.
V3 Intensive Maximum speed, used for eliminating the highest cooking vapour emission,
including long periods.

EN
1
3
13
MAINTENANCE
Grease filters
CLEANING METAL SELF- SUPPORTING GREASE FILTERS
• The filters must be cleaned every 2 months of op-
eration, or more frequently for particularly heavy
usage, and can be washed in a dishwasher.
• Remove the filters one at a time by pushing them
towards the back of the group and pulling down at
the same time.
• Wash the filters, taking care not to bend them. Al-
low them to dry before refitting.
• When refitting the filters, make sure that the han-
dle is visible on the outside.
Activated charcoal filter (Recirculation version)
REPLACING THE ACTIVATED CHARCOAL FILTER
• The filter is not washable and cannot be regener-
ated, and must be replaced approximately every 4
months of operation, or more frequently for par-
ticularly heavy usage.
• Remove the metal grease filters
• Remove the saturated activated carbon filter by
releasing the fixing hooks
• Fit the new filter by hooking it into its seating
• Replace the metal grease filters.
Lighting
LIGHT REPLACEMENT
40 W incandescent light.
• Remove the screw fixing the Lighting support.
• Pull the Lighting support down.
• Extract the lamp and replace with another of the
same type.
• Replace the lighting support in reverse order.

EN
1
4
14
EASY CLEANING TM
Removing the Grease Filters
Before carrying out Maintenance on the E-
ASY CLEANING Suction Unit:
• Disconnect the hood by switching off the
twopole switch on the mains power supply
line, or by switching off the main power
switch.
• Remove the grease filters from the hood.
• If the hood is of the recirculation type, re-
move the odour filters:
• For hoods with a flat cartridge (A): turn the
fastening elements provided;
• For hoods with a bayonet cartridge (B):
turn as indicated and extract.
Disconnecting the EASY CLEANING Suction Unit
• Disconnect the power connector Ca and the
control and lighting connector Cmd on the
sides of the unit.
• For wall-mounted hoods and free-standing
hoods with square chimney, turn the levers
Lb locking the suction unit, so that they di-
sconnect from the pins.
• For free-standing hoods with round chim-
ney, unscrew the plugs Vb locking the suc-
tion unit.
• Pull the suction unit forwards so that it un-
hooks from the support pins, and remove it
downwards through the air outlet.
CmdCa
Lb
Vb
A
B

EN
1
5
15
Dismantling Washable Parts
• To remove the side grilles protecting the
fans, lift up the stop tooth using a knife or
screwdriver and turn the grilles in the direc-
tion indicated by the arrow.
• Grasp the fans in the holes provided and
pull to extract.
CLEANING
• Wash the fans and the protection grilles,
using normal washing-up liquid. These e-
lements can also be washed in the dish-
washer.
• Using a damp cloth and a suitable deter-
gent, clean the body of the suction device,
taking great care not to allow any water to
leak into the inside of the unit or into the
connector housings.
• Leave until completely dry bifore reassem-
bling.
• Using a brush, clean the air outlet pipe as
far as you can reach.
FREE
LOCK
O
P
E
N

EN
1
6
16
REASSEMBLY
N.B. To avoid reassembling the wrong way
round, the two fans have different couplings.
• Reassemble the fans on the corresponding
pins, pressing them until they snap into
place.
• Fit the protection grilles so that the teeth
coincide in the “FREE” position and when
turned to “LOCK”.
• Replace the EASY CLEANING suction
unit on the hood, inserting it in position and
connecting it to the support pins.
• Turn the lock levers, or screw in the lock
plugs.
• Connect the power connector and the
command connector to the sockets on the
sides of the suction device.
• Replace any activated charcoal odour fil-
ters.
• Replace the grease filters.
• Connect the hood to the power supply sys-
tem, by turning the two-pole switch on the
mains power line to on, or by turning the
main switch on.
• Check that the hood is working properly,
by turning the motor and lighting on.
LOCK
O
P
E
N
FREE

DK
1
7
17
RÅD OG ANVISNINGER
INSTALLATION
• Producenten kan ikke holdes ansvarlig for eventuelle skader, der
skyldes ukorrekt ellerforkert installation.
• Den mindst tilladelige sikkerhedsafstand mellem komfurets top og
emhættens underside er 650 mm.
• Kontrollér, at lysnetspændingen er den samme som den spænding,
der er angivet mærkepladen, der sidder på inde i emhætten.
• For Klasse I apparater skal det også kontrolleres, at elforsyningen er
forsynet med jord.
• Emhætten kobles til aftrækskanalen ved hjælp af et rør med en min.-
diameter på 120 mm. Afstanden fra emhætten til kanalen skal være
så kort som mulig.
• Emhætten må ikke tilsluttes en kanal, der fører forbrændingsgasser
ud i det fri (oliefyr, brændeovne etc.).
• Hvis emhætten skal anvendes i forbindelse med ikke-elektriske appa-
rater (f.eks. gaskomfur, gaskogeblus), skal det sikres, at lufttilgangen
til rummet er tilstrækkelig, så aftræksgasserne ikke slår tilbage. Køk-
kenet skal have en åbning, der har direkte forbindelse til det fri, så der
er sikret en tilstrækkelig mængde ren luft.
ANVENDELSE
• Emhætten er udelukkende beregnet til at fjerne em og lugte i køkke-
ner i private husholdninger.
• Emhætten må kun anvendes til det formål, hvortil den er konstrueret.
• Der må ikke forekomme høj åben ild under emhætten, mens den an-
vendes.
• Justér brænderen, så flammerne er rettet direkte mod bunden af pan-
den/gryden – de må ikke nå ud over kanten af bunden.
• Frituregryder skal under brug holdes under konstant opsyn: kogende
varm olie kan sprøjte ind i flammerne.
• Emhætten må ikke anvendes af børn og personer, som ikke ved,
hvordan den betjenes.
• Apparatet er ikke beregnet til at skulle anvendes af mindre børn eller
svækkede personer uden opsyn.
• Undlad at flambere retter under emhætten; der opstår ellers brandfa-
re.
• Mindre børn skal holdes under opsyn for at sikre, at de ikke leger med
apparatet.
VEDLIGEHOLDELSE
• Inden apparatet skal vedligeholdes eller rengøres, skal der slukkes for
det eller stikket skal tages ud af stikkontakten.
• Rengør og/eller udskift filtrene iht. det angivne tidinterval.
• Rengør emhætten ved hjælp af en fugtig klud og et neutralt flydende
rengøringsmiddel.
650 mm min.

DK
1
8
18
APPARATBESKRIVELSE
Dimensioner
650 min.
490 60
108 259
150
min. 730
max. 1000
545
260
300
63
41
126
81
Komponenter
Ref. Stk. Produktets komponenter
11 Emhættens hoveddel inkl.: Betjeningsanordninger, lys,
ventilatorenhed, filtre
21 Teleskopaftræk bestående af:
2.1 1 Øverste aftræk
2.2 1 Nedersteaftræk
91 Passtykke ø 150-120 mm
10 1 Sidestykke med ventil
14.1 2 Forlænger til luftudstrømnings overgangsstykke
15 1 Luftudstrømnings overgangsstykke
Ref. Stk. Installationsdele
7.2.1 2 Beslag til befæstigelse aføverste aftræk
7.3 1 Støttebeslag til overgangsstykket
11 6 Forankringer
12a 6 Skruer 4,2 x 44,4
12c 6 Skruer 2,9 x 9,5
Stk. Dokumentation
1 Brugerhåndbog
2.1
2.2
2
12c
12a 7.2.1 11
11
12a
1
9
7.3
14.1
15
10

DK
1
9
19
INSTALLATION
Boring i væg og befæstigelse af beslag
På væggen skal der afmærkes:
• en lodret linje op til loftet eller den øverste grænse, i midten af emhættens monteringsområ-
de;
• en vandret linje mindst 650 mm over kogepladen.
• Placér beslaget 7.2.1 som vist, d.v.s. 1-2 mm fra loftet eller den øverste grænse, og stil dets
midte (indskæringer) på lige linje med den lodrette referencelinje.
• Afmærk midten af hullerne i beslaget.
• Placér beslaget 7.2.1 som vist, X mm under det første beslag (X=højden på det øverste af-
træk, der følger med), og stil dets midte (indskæringer) på lige linje med den lodrette refe-
rencelinje.
• Afmærk midten af hullerne i beslaget.
• Afmærk som vist en reference 116 mm fra den lodrette referencelinje, 320 mm over den
vandrette referencelinje.
• Gør det samme på den anden side.
• Bor et hul med ø 8 mm på de afmærkede steder.
• Sæt forankringerne 11 i hullerne.
• Fastgør det nederste beslag 7.2.1 ved hjælp af de medfølgende skruer 12a (4,2 x 44,4 ).
• Fastgør det øverste beslag 7.2.1 og overgangsstykkets støttebeslag 7.3 ved hjælp af de 2
medfølgende skruer 12a (4,2 x 44,4).
• Skru de 2 medfølgende skruer 12a (4,2 x 44,4) fast i hullerne til fastgøring af emhættens
hoveddel, hvorved der skal sikres en afstand på 5-6 mm mellem væggen og skruens hoved.
11
12a
320 X
116
1÷2
116
650 min.
7.2.1

DK
2
0
20
Montering af emhætte
• Inden man hænger emhætten op, skal man stramme de to
skruer Vr, som sidder i hættens ophængningspunkter.
• Hæng emhætten op på de forberedte skruer 12a.
• Stram ophængningsskruerne 12a helt til.
• Ved at dreje på skruerne Vr nivelleres emhætten.
12a
Vr
Tilslutninger
VERSION FORBUNDET TIL AFTRÆKSKANAL
Når aftrækskanal-versionen opsættes, forbindes emhætteenheden
til kanalen med en flexslange eller et hårdt rør, Ø150 eller 120
mm – valget er op til den, der opsætter emhætten.
Tilslutning af rør på ø 150
• Indsæt studsen på ø 150 10 på emhættens udsugningshul.
• Spænd røret fast med specielle rørklemmer. Disse medleveres
ikke.
Tilslutning af rør på ø 120
• Ved tilslutning af rør på ø120 mm, indsættes reduktionsstudsen
9på studsen ø 150, som er monteret tidligere.
• Spænd røret fast med specielle rørklemmer. Disse medleveres
ikke.
• I begge tilfælde skal man fjerne eventuelle lugtabsorberende
kulfiltre.
9
ø 120ø 150
10
10
LUFTUDSTRØMNING PÅ FILTRERENDE VERSION
• Før overgangsstykket 15 ind i støttebeslaget 7.3.
• Før overgangsstykkets forlængere 14.1 ind på siden af over-
gangsstykket 15.
• Sørg for at udgangen på overgangsstykkets forlængere 14.1
befinder sig ud for aftrækkets mundinger, både vandret og lod-
ret.
• Forbind overgangsstykket 15 til emhættens hoveddels udgang
ved hjælp af et rør eller en flexslange med ø150, som det på-
hviler installatøren at vælge.
• Sørg for, at lugtfiltret med aktivt kul er monteret.
ø 150
14.1
15
