Instructions Manual
INDEX
RECOMMENDATIONS AND SUGGESTIONS......................................................................................................................7
CHARACTERISTICS..............................................................................................................................................................8
INSTALLATION......................................................................................................................................................................9
USE.......................................................................................................................................................................................13
MAINTENANCE....................................................................................................................................................................14
EASY CLEANING TM...........................................................................................................................................................15

DK
3
3
Brugsvejledning
INDHOLD
RÅD OG ANVISNINGER......................................................................................................................................................18
APPARATBESKRIVELSE....................................................................................................................................................19
INSTALLATION....................................................................................................................................................................20
BRUG....................................................................................................................................................................................24
VEDLIGEHOLDELSE...........................................................................................................................................................25
EASY CLEANING TM...........................................................................................................................................................26

SE
4
4
Bruksanvisning
INNEHÅLL
REKOMMENDATIONER OCH TIPS....................................................................................................................................29
EGENSKAPER.....................................................................................................................................................................30
INSTALLATION....................................................................................................................................................................31
ANVÄNDING.........................................................................................................................................................................35
UNDERHÅLL........................................................................................................................................................................36
EASY CLEANING TM...........................................................................................................................................................37

NO
5
5
Bruksanvisning
INNHOLD
ANBEFALINGER OG FORSLAG.........................................................................................................................................40
EGENSKAPER.....................................................................................................................................................................41
INSTALLASJON...................................................................................................................................................................42
BRUK....................................................................................................................................................................................46
VEDLIKEHOLD.....................................................................................................................................................................47
EASY CLEANING TM...........................................................................................................................................................48

FI
6
6
Käyttöopas
SISÄLTÖ
OHJEET JA SUOSITUKSET................................................................................................................................................51
MITAT JA OSAT...................................................................................................................................................................52
ASENNUS.............................................................................................................................................................................53
KÄYTTÖ................................................................................................................................................................................57
HUOLTO...............................................................................................................................................................................58
EASY CLEANING TM...........................................................................................................................................................59

EN
7
7
RECOMMENDATIONS AND SUGGESTIONS
The Instructions for Use apply to several versions of this appliance. Accor
d-
ingly, you may find descriptions of individual features that do not apply to
your specific appliance.
INSTALLATION
• The manufacturer will not be held liable for any damages resulting from in-
correctorimproperinstallation.
• The minimum safety distance between the cooker top and the extractor
hood is 650 mm.
• Check that the mains voltage corresponds to that indicated on the rating
plate fixed to the inside of the hood.
• For Class I appliances, check that the domestic power supply guarantees
adequate earthing.
Connect the extractor to the exhaust flue through a pipe of minimum diame-
ter 120 mm. The route of the flue must be as short as possible.
• Do not connect the extractor hood to exhaust ducts carrying combustion
fumes (boilers, fireplaces, etc.).
• If the extractor is used in conjunction with non-electrical appliances (e.g. gas
burning appliances), a sufficient degree of aeration must be guaranteed in
the room in order to prevent the backflow of exhaust gas. The kitchen must
have an opening communicating directly with the open air in order to guar-
antee the entry of clean air.
USE
• The extractor hood has been designed exclusively for domestic use to elimi-
nate kitchen smells.
• Never use the hood for purposes other than for which it has ben designed.
• Neverleave highnaked flames under the hoodwhenit isin operation.
• Adjust the flame intensity to direct it onto the bottom of the pan only, making
sure that it does not engulf the sides.
• Deep fat fryers must be continuously monitored during use: overheated oil
can burst into flames.
• Do not flambè under the range hood; risk of fire
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concern-
ing use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appli-
ance.
MAINTENANCE
• Switch off or unplug the appliance from the mains supply before carrying out
anymaintenance work.
• Clean and/or replace the Filters after the specified time period.
• Clean the hood using a damp cloth and a neutral liquid detergent.
The symbol on the product or on its packaging indicates that this product may not be treated
as household waste. Instead it shall be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this product. For more
detailed information about recycling of this product, please contact your local city office, your
household waste disposal service or the shop where you purchased the product.
650 mm min.

EN
8
8
CHARACTERISTICS
Dimensions
Components
Ref. Q.ty Product Components
11 Hood Body, complete with: Controls, Light, Blower,
Filters
21 Telescopic Chimney comprising:
2.1 1 Upper Section
2.2 1 Lower Section
91 Reducer Flange ø150-120 mm
10 1 Damper ø 150
14.1 2 Air Outlet Connection Extension
15 1 Air Outlet Connection
30 1 Lower corner spacer
Ref. Q.ty Installation Components
7.1 1 Hood BodyFixing Bracket
7.2.1 4 Upper Chimney Section Fixing Brackets
7.3 1 Air Outlet Connection Support
11 18 Wall Plugs
12a 18 Screws 4,2 x 44,4
12c 6 Screws 2,9 x 9,5
12e 6 Screws 2,9 x 9,5
Q.ty Documentation
1 Instruction Manual
7.2.1
2.1
2.2
12c
2
97.1
12a
11
7.3
12e
1
15
14.1
12e
10
30

EN
9
9
INSTALLATION Wall drilling and bracket fixing
• Rest Bracket 7.1 as shown, 960 mm above the cooker top, taking care that the bracket is le-
vel.
• Mark the wall at the centres of the holes in the bracket.
• Rest a Bracket 7.2.1 as shown, 1-2 mm from the ceiling or top limit, and 347 mm from the
corner of the wall.
• Mark the wall at the centres of the holes in the bracket.
• Place bracket 7.2.1 on the wall as shown at X mm below the first bracket (X = height of the
upper
chimney section supplied), and 347 mm from the corner of the wall.
• Repeat this operation on the other side, checking that it is level.
• Drill ø 8 mm holes at all the centre points marked.
• Insert the wall plugs 11 in the holes.
• Fix the brackets and the Support using the 12a (4,2 x 44,4) screws supplied.
To install the hood in recycling version it is necessary to follow the instructions described
in the part concerning Recirculation version Air Outlet.
960
7.1
7.2.1
X
347 347
1÷2
7.1
12a
11
7.2.1

EN
1
0
10
Fitting the Hood Canopy
Before fixing the Hood to the wall, Lower corner spacer 30 must
be connected to the Hood Canopy as follows:
• Loosen the 2 Screws that join the elements making up a Lower
corner spacer 30.
• Fasten the Lower corner spacer 30 to the Hood using 3 Screws
(2.9 x 9.5) provided.
• Adjust the Screws Vr, located on the Hood Canopy connection
points, so that they are at the half-way point.
• Hook the Hood Canopy to the Bracket provided.
• It is now possible to level the hood canopy, using the screws
Vr.
• Lock the 2 Screws in the Lower corner spacer, loosened as
above, after moving the mobile part until it is in the right posi-
tion.
• If necessary, it is possible to fasten the hood to the wall using
two more screws with wall plugs, which can be positioned
from inside the hood canopy.
Vr
30
Connections
DUCTED VERSION AIR EXHAUST SYSTEM
When installing the ducted version, connect the hood to the
chimney using either a flexible or rigid pipe ø 150 or 120mm, the
choice of which is left to the installer.
To install a ø 150
• To install the dumper 10
• Fix the pipe in position using sufficient pipe clamps (not sup-
plied).
To install a ø 120
• To install a ø 120 mm air exhaust connection, insert the re-
ducer flange 9on the dumper 10.
• Fix the pipe in position using sufficient pipe clamps (not sup-
plied).
• Remove any activated charcoal filters.
ø 120
ø 150
9
10
10

EN
1
1
11
RECIRCULATION VERSION AIR OUTLET
• Insert the extension pieces 14.1 laterally on the air outlet con-
nection piece 15.
• Fix the connection piece with the extension pieces onto the
support 7.3 using the two screws 12e (2,9 x 9,5) provided.
• Place the assembled unit on the wall corner at 110 mm from
the ceiling or upper limit.
• Mark the centre of the bracket holes.
• Drill the marks ø 8 mm.
• Insert wall plugs 11 into the holes.
• Fix the connection piece using the screws 12a (4,2 x 44,4) pro-
vided.
• Make sure that the charcoal filter has been mounted inside the
hood.
12e
110 mm
110 mm
ELECTRICAL CONNECTION
• Connect the hood to the mains through a two-pole switch hav-
ing a contact gap of at least 3 mm.
• Remove the grease filters (see paragraph Maintenance) being
sure that the connector of the feeding cable is correctly inserted
in the socket placed on the side of the fan.

EN
1
2
12
Chimney assembly
Upper exhaust Chimney
• Slightly widen the two sides of the upper chimney
and hook them behind the brackets 7.2.1, making
sure that they are well seated.
• Secure the sides to the brackets using the 4 screws
12c (2,9 x 9,5) supplied.
Lower exhaust Chimney
• Slightly widen the two sides of the chimney and hook
them between the upper chimney and the wall, mak-
ing sure that they are well seated.
• Fix the lower part laterally to the hood body using
the 2 screws 12c (2,9 x 9,5) supplied.
7.2.1
2.1
12c
2.2

EN
1
3
13
USE
SV1V1V1V1V1V1V1V1V1V1V1V1V1V1V1V1V1V1 V2 V3 L
LLight Switches the lighting system on and off.
SLed Motor running led.
V1 Motor Switches the extractor motor on and off at low speed. Used to provide a
contin-uos and silent air change in the presence of light cooking vapours.
V2 Speed Medium speed, suitable for most operating conditions given the optimum
treated air flox/noise level ratio.
V3 Intensive Maximum speed, used for eliminating the highest cooking vapour emission,
including long periods.

EN
1
4
14
MAINTENANCE
Grease filters
CLEANING METAL SELF- SUPPORTING GREASE FILTERS
• The filters must be cleaned every 2 months of operation, or
more frequently for particularly heavy usage, and can be
washed in a dishwasher.
• Remove the filters one at a time holding them up with one
hand and pulling the handle downwards with the other hand at
the same time.
• Wash the filters, taking care not to bend them. Allow them to
dry before refitting.
• When refitting the filters, make sure that the handle is visible
on the outside.
Activated charcoal filter (Recirculation version)
These filters are not washable and cannot be regenerated, and
must be replaced approximately every 4 months of operation, or
more frequently with heavy usage.
REPLACING THE ACTIVATED CHARCOAL FILTER
• Remove the metal grease filters
• Remove the saturated activated charcoal filter as shown (A).
• Fit the new filters (B).
• Replace the metal grease filters.
A
B
Lighting
LIGHT REPLACEMENT
20 W halogen light.
• Remove the snap-on lamp cover by levering it from under the
metal ring, supporting it with one hand.
• Remove the halogen lamp from the lamp holder by pulling
gently.
• Replace the lamp with a new one of the same type, making
sure that you insert the two pins properly into the housings on
the lamp holder.
• Replace the snap-on lamp cover.

EN
1
5
15
EASY CLEANING TM
Removing the Grease Filters
Before carrying out Maintenance on the E-
ASY CLEANING Suction Unit:
• Disconnect the hood by switching off the
twopole switch on the mains power supply
line, or by switching off the main power
switch.
• Remove the grease filters from the hood.
• If the hood is of the recirculation type, re-
move the odour filters:
• For hoods with a flat cartridge (A): turn the
fastening elements provided;
• For hoods with a bayonet cartridge (B):
turn as indicated and extract.
Disconnecting the EASY CLEANING Suction Unit
• Disconnect the power connector Ca and the
control and lighting connector Cmd on the
sides of the unit.
• For wall-mounted hoods and free-standing
hoods with square chimney, turn the levers
Lb locking the suction unit, so that they
disconnect from the pins.
• For free-standing hoods with round chim-
ney, unscrew the plugs Vb locking the suc-
tion unit.
• Pull the suction unit forwards so that it un-
hooks from the support pins, and remove it
downwards through the air outlet.
CmdCa
Lb
Vb
A
B

EN
1
6
16
Dismantling Washable Parts
• To remove the side grilles protecting the
fans, lift up the stop tooth using a knife or
screwdriver and turn the grilles in the direc-
tion indicated by the arrow.
• Grasp the fans in the holes provided and
pull to extract.
CLEANING
• Wash the fans and the protection grilles,
using normal washing-up liquid. These
elements can also be washed in the dish-
washer.
• Using a damp cloth and a suitable deter-
gent, clean the body of the suction device,
taking great care not to allow any water to
leak into the inside of the unit or into the
connector housings.
• Leave until completely dry bifore reassem-
bling.
• Using a brush, clean the air outlet pipe as
far as you can reach.
FREE
LOCK
O
P
E
N

EN
1
7
17
REASSEMBLY
N.B. To avoid reassembling the wrong way
round, the two fans have different couplings.
• Reassemble the fans on the corresponding
pins, pressing them until they snap into
place.
• Fit the protection grilles so that the teeth
coincide in the “FREE” position and when
turned to “LOCK”.
• Replace the EASY CLEANING suction
unit on the hood, inserting it in position and
connecting it to the support pins.
• Turn the lock levers, or screw in the lock
plugs.
• Connect the power connector and the
command connector to the sockets on the
sides of the suction device.
• Replace any activated charcoal odour fil-
ters.
• Replace the grease filters.
• Connect the hood to the power supply sys-
tem, by turning the two-pole switch on the
mains power line to on, or by turning the
main switch on.
• Check that the hood is working properly,
by turning the motor and lighting on.
LOCK
O
P
E
N
FREE

DK
1
8
18
RÅD OG ANVISNINGER
Denne brugervejledning gælder for flere versioner af apparatet.
Der fremstilles muligvis enkelte dele af tilbehøret, der ikke vedrører jeres apparat.
INSTALLATION
• Producenten kan ikke holdes ansvarlig for eventuelle skader, der skyldes ukorrekt
eller forkert installation.
• Den mindst tilladelige sikkerhedsafstand mellem komfurets top og emhættens un-
derside er 650 mm.
• Kontrollér, at lysnetspændingen er den samme som den spænding, der er angivet
mærkepladen, der sidder på inde i emhætten.
• For Klasse I apparater skal det også kontrolleres, at elforsyningen er forsynet med
jord.
• Emhætten kobles til aftrækskanalen ved hjælp af et rør med en min.-diameter på
120 mm. Afstanden fra emhætten til kanalen skalvære så kort som mulig.
• Emhætten må ikke tilsluttes enkanal,der fører forbrændingsgasserud i detfri (olie-
fyr, brændeovne etc.).
• Hvis emhætten skal anvendes i forbindelse med ikke-elektriske apparater (f.eks.
gaskomfur, gaskogeblus), skal det sikres, at lufttilgangen til rummet er tilstrækkelig,
så aftræksgasserne ikke slår tilbage. Køkkenet skalhave en åbning, der har direkte
forbindelse til det fri, så der er sikret en tilstrækkelig mængde ren luft.
ANVENDELSE
• Emhætten er udelukkende beregnet til at fjerne em og lugte i køkkener i private
husholdninger.
• Emhætten må kun anvendes til det formål, hvortil den erkonstrueret.
• Der må ikke forekomme højåben ild underemhætten, mens den anvendes.
• Justér brænderen, så flammerne er rettet direkte mod bunden af panden/gryden –
de må ikke nå ud over kanten afbunden.
• Frituregryder skal under brug holdes under konstant opsyn: kogende varm olie kan
sprøjte ind i flammerne.
• Emhætten må ikke anvendes af børn og personer, som ikke ved, hvordan den be-
tjenes.
• Apparatet er ikke beregnet til at skulle anvendes af mindre børn eller svækkede
personer udenopsyn.
• Undlad at flambere retter under emhætten; der opstår ellers brandfare.
• Dette apparat må ikke anvendes af personer (derunder børn) med nedsatte psyki-
ske, sensoriske eller sindsmæssige evner, eller personer uden erfaring eller til-
strækkeligt kendskab, med mindre de overvåges eller oplæres i brugaf apparatet af
personer, der er ansvarlige for deres sikkerhed.
• Børn skal overvåges for at undgå, at de leger med apparatet.
VEDLIGEHOLDELSE
• Inden apparatet skal vedligeholdes eller rengøres, skal der slukkes for det eller
stikket skal tages ud af stikkontakten.
• Rengør og/eller udskift filtrene iht. det angivne tidinterval.
• Rengør emhætten ved hjælp af en fugtig klud og et neutralt flydende rengørings-
middel.
Symbolet på produktet eller på pakken angiver, at dette produkt ikke må behandles som hus-
holdningsaffald. Det skal i stedet overgives til en affaldsstation for behandling afelektrisk og elektro-
nisk udstyr. Ved at sørge for at dette produktbliver bortskaffet på den rette måde, hjælper du med til
at forebygge eventuelle negative påvirkninger af miljøet og af personers helbred, der ellers kunne
forårsages af forkert bortskaffelse af dette produkt. Kontakt det lokale kommunekontor, affaldssel-
skab ellerden forretning,hvor produkt er købt, for yderligere oplysninger om genanvendelse afdette
produkt.
650 mm min.

DK
1
9
19
APPARATBESKRIVELSE
Dimensioner
Komponenter
Ref. Stk. Produktets komponenter
11 Emhættens hoveddel inkl.: Betjeningsanordninger, lys,
ventilatorenhed, filtre
21 Teleskopaftræk bestående af:
2.1 1 Nedersteaftræk
2.2 1 Øverste aftræk
91 Passtykke ø 150-120 mm
10a 1 Sidestykke med ventil
14.1 2 Forlænger til luftudstrømnings overgangsstykke
15 1 Luftudstrømnings overgangsstykke
30 1 Hjørnedæksel forneden
Ref. Stk. Installationsdele
7.1 1 Beslag til befæstigelse af emhættens hoveddel
7.2.1 4 Beslag til befæstigelse aføverste aftræk
7.3 1 Beslag til befæstigelse af filtrerende overgangsstykke
11 18 Forankringer ø 8
12a 18 Skruer 4,2 x 44,4
12c 6 Skruer 2,9 x 9,5
12e 6 Skruer 2,9 x 9,5
Stk. Dokumentation
1 Brugerhåndbog
7.2.1
2.1
2.2
12c
2
97.1
12a
11
7.3
12e
1
15
14.1
12e
10
30

DK
2
0
20
INSTALLATION Boring i væg og befæstigelse af beslag
• Placér beslaget 7.1 som vist, d.v.s. 960 mm over kogepladen, hvorved man skal passe på, at
beslaget er nivelleret.
• Afmærk midten af hullerne i beslaget.
• Placér beslaget 7.2.1 som vist, d.v.s. 1-2 mm fra loftet eller den øverste grænse og 347 mm
fra væggens hjørne.
• Afmærk midten af hullerne i beslaget.
• Placér beslaget 7.2.1 som vist, X mm under det første beslag (X=højden på det øverste af-
træk, der følger med) og 347 mm fra væggens hjørne.
• Gør det samme på den anden side, og kontrollér nivelleringen.
• Bor et hul med ø 8 mm på de afmærkede steder.
• Sæt forankringerne 11 i hullerne.
• Fastgør beslagene ved hjælp af de medfølgende skruer 12a (4,2 x 44,4 ).
Ved installation som filtrerende version skal man straks foretage proceduren, der er
fremstillet i afsnittet Luftudledning på Filtrerende Version
960
7.1
7.2.1
X
347 347
1÷2
7.1
12a
11
7.2.1
