1 Introduction
This document describes the Qorivva MPC5746R
evaluation board (EVB) for the 176LQFP, the
252MAPBGA, and the 144LQFP packages. The EVB is
targeted at providing a platform for the evaluation and
development of the MPC5746R automotive MCU,
facilitating hardware and software development as well
as debugging. Settings for switches, jumpers, LEDs, and
push-buttons are shown for basic operation of the
prototype version of the EVB.
This document is preliminary and is subject to change
without notice.
2Features
The EVB provides the following primary features listed
below:
• Standalone operation or use with the optional
MPC57XXXMB main board
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
3 Modular concept . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
4 EVB configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4.1 Methods of operation. . . . . . . . . . . . . . . . . . . . . . . . 3
4.2 Power source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4.3 Clock Configuration Options . . . . . . . . . . . . . . . . . . 5
4.4 Micro Second Channel Connections . . . . . . . . . . . . 5
4.5 ADC Channel Filters . . . . . . . . . . . . . . . . . . . . . . . . 6
4.6 SIPI Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.7 JTAG Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.8 I/O Connectivity and Port Routing . . . . . . . . . . . . . . 9
5 Reset switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7 Test points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8 EVB Top View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
9 Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
10 EVB Errata. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
11 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Qorivva MPC5746R-176DS/252DS
Evaluation Board (EVB)
User’s Guide
by: Bill Terry
32-bit Automotive Applications

Modular concept
Freescale Semiconductor2
• Socketed MPC5746R in 176-pin LQFP package, 144-pin LQFP package, or 252MAPBGA
package
•Power options
— Power supplied via the two interface connectors when using the EVB with the optional
MPC57XXXMMB main board
— Power supplied via terminal block when using the EVB in standalone configuration
•Debug and trace
— debug via JTAG connector
— Trace using internal trace memory
•Clocks
— 20 MHz crystal
— SMA connector for external clock
— Oscillator
• MicroSecond Channel
— SAMTECH connector providing easy connection to microsecond channel pins
•I/O connectivity
— Access to all port pins when using the EVB with the optional MPC57XXXMB main
board— Access to SCI, CAN, LIN, and UARTphysical interfaces when using the EVB with
the optional MPC57XXXMB main board
• Switches
— Power-on reset
• LEDs for power indication
• Test points
3 Modular concept
The MPC5746R-176DS/252DS/144DSis part of a modular EVB hardware system that consists of:
• A common main board that provides power and access to common communication interfaces and
the MCU I/O port pins. The MPC5746R-176DS/252DS/144DSis compatible with the
MPC57XXXMB main board.
•Apackage-specific EVB to support all available production package types of the MPC5746R1.
NOTE
The MPC57XXXMB User Guide should be obtained to provide additional
configuration information when used with the MPC5746-xxxDS.
See Figure 1., “MPC5746R EVB and main board system” for an illustration of the modular EVB
hardware system concept.
1.The MPC5746R Emulation Device (ED) requires separate hardware that may beordered through your Freescale
Salesperson or Representative.
Qorivva MPC5746R-176DS/252DSEvaluation Board (EVB) User’s Guide, Rev. 1.6

EVB configuration
Qorivva MPC5746R-176DS/252DSEvaluation Board (EVB) User’s Guide, Rev. 1.6
Freescale Semiconductor 3
Figure 1. MPC5746R EVB and main board system
4 EVB configuration
This section provides information on how to configure the jumper settings on the EVB. Default settings
are marked as such.
4.1 Methods of operation
Power to the EVB is supplied by one of two options:
1. The MPC57XXXMB main board generates the 5 V/3.3 V/1.25 V supplies and provides these to
the EVB via the interface connectors.
2. In standalone configuration, external 5 V/3.3 V/1.25 V supplies are provided to the EVB via the
terminal block. (This option provides minimal access to I/O)
4.2 Power source
The default jumper settings are configured for using the EVB with the MPC57XXXMB main board.
Power is supplied from the main board to the EVB via the two interface connectors.
The EVB can also operate as a standalone device, where power can be supplied from an external power
source.
Table 1summarizes the jumper settings for the available power options.
Table 1. Jumper Settings — Power Options
Jumper Setting Description
J23 Choose one:
1-2 ON
2-3 ON
Main IO Voltage Supply - VDD_HV_IO_MAIN
5V supply from motherboard (default)
5V supply from external source
MPC57XXXMB
MPC5746R-176DS/252DS

Qorivva MPC5746R-176DS/252DSEvaluation Board (EVB) User’s Guide, Rev. 1.6
EVB configuration
Freescale Semiconductor4
J19 Choose one:
1-3 ON
7-9 ON
3-4 ON
7-8 ON
Low voltage power select - VDD_LV_SELECT
3.3V mother board supply (default)
5.0V mother board supply
3.3V external supply
5.0V external supply
J18 Choose one:
3-5 ON
3-4 ON
1-3 ON
Low voltage core select - VDD_LV
1.25V external supply 1.25V
internal regulator supply 1.25V
mother board supply (default)
J22 Choose one:
1-2 ON
2-3 ON
SAR ADC Voltage Supply - VDD_HV_ADV_SAR
5.0V mother board supply (default)
5.0V external supply
J8 Choose one:
1-2 ON
2-3 ON
SD ADC Voltage Supply - VDD_HV_ADV_SD
5.0V mother board supply (default)
5.0V external supply
J3 Choose one:
7-9 ON
1-3 ON
7-8 ON
3-4 ON
High voltage JTAG power - VDD_HV_IO_JTAG
5.0V mother board supply
3.3V mother board supply (default)
5.0V external supply
3.3V external supply
J5 Choose one:
7-9 ON
1-3 ON
3-4 ON
7-8 ON
Microsecond Channel I/O Segment Voltage Supply - VDD_HV_IO_MSC
5.0V mother board supply (default)
3.3V mother board supply
3.3V external supply
5.0V external supply
J20 Choose one
7-9 ON
1-3 ON
3-4 ON
7-8 ON
Ethernet I/O Segment Voltage Supply - VDD_HV_IO_FEC
5.0V mother board supply
3.3V mother board supply (default)
3.3V external supply
5.0V external supply
J14 Choose one:
1-2 ON
2-3 ON
High voltage PMC supply - VDD_HV_PMC
5.0V motherboard supply (default)
5.0V external supply
J4 Choose one:
7-9 ON
1-3 ON
3-4 ON
7-8 ON
3-5 ON
Standby RAM Supply Input - VDDSTBY
5.0V mother board supply
3.3V mother board supply (default)
3.3V external supply
5.0V external supply
GND (default)
J17 Choose one:
Installed
Removed
BCTRL - On-chip regulator pass transistor control
Control enabled
Control disabled
J12 Choose one:
1-2
2-3
Oscillator Power - OSC_PWR
3.3V mother board supply (default)
3.3V external supply
Table 1. Jumper Settings — Power Options (continued)
Jumper Setting Description

EVB configuration
Freescale Semiconductor 5
If stand alone operation is desired, the following power supplies connections should be made on J6 (see
Table 2). If using the external supplies option, the user should reference the MPC5746R Data Sheet to
ensure that IDD requirements for each supply are met.
4.3 Clock Configuration Options
The EVB provides three clocking options that are controlled by jumpers:
• On board 20 MHz crystal oscillator
• On board oscillator
• SMA connector for external clock source
Table 3 summarizes the jumper settings for the available clock options. Note that some of these jumpers
are ‘non-populated’ by default and the clock source is configured by default for crystal oscillator
operation.
Table 2. External power input
J6 Description
Pin 1 1.25 V
Pin 2 3.3 V
Pin 3 5 V
Pin 4 GND
Table 3. Jumper Settings - Clock Configuration
Jumpers Selected Clock Source
Reference
Designator Description Crystal (default) Oscillator SMA
JP2 Shunt to terminate EXTAL with 49.9 ohm resistor to GND Remove Remove Install
JP3 Shunt to connect EXTAL to crystal Install Remove Remove
JP4 Shunt to connect EXTAL to oscillator Remove Install Remove
JP5 Shunt to connect EXTAL to SMA connector Remove Remove Install
JP6 Shunt to connect XTAL to GND Remove Install Install
J10 Oscillator enable Remove Install1
1 If the oscillator is selected as the clock source, check that J12 (see Table 1) is usedto select the desired oscillator power.
4.4 Micro Second Channel Connections
The microsecond channel signals on MSC1 are grouped at a SAMTECH ERF-8 connector on the EVB to
provide easier user access. This also allows better trace routing of the differential pair signals. The
connections of MSC1 on the connector are shown in Figure 2.
Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
Remove

EVB configuration
Freescale Semiconductor6
Note that by default these signals are not routed to the motherboard via the motherboard interface
connectors. However, zero ohm resistors may be installed at the reference designators listed in Figure 2 if
the signals need to be routed to the motherboard for use as GPIO or other purposes.
Figure 2. Samtech ERF8 - MSC1 Connections (20-pin)
The following table lists the port and pins associated with each of the MSC channel signals.
4.5 ADC Channel Filters
For convenience, the EVB implements analog RC filters on one differential ADC channel pair, and two
single ended ADC channels. The single ended filter configuration is shown in Figure 3, and the differential
pair filter configuration is shown in Figure 4. The user may modify these component values for the desired
application.
Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
Table 4. MSC Signal Mapping
Signal Name Device
Port
Pin Assignment
176LQFP 252MAPBGA
MSC1 MSC1_SOUTN PA7 165 C6
MSC1_SOUTP PA8 164 A6
MSC1_CLKN PA9 161 A7
MSC1_CLKP PA10 160 B7
MSC1_RX PA11 159 C7
MSC1_CS1 PA12 158 B8
MSC1_CS0 PA13 157 A8
12
19 20
VSS
MSC1_SOUTN PA[7]
MSC1_SOUTP PA[8]
MSC1_CLKN PA[9]
MSC1_CLKP PA[10]
MSC1_RX PA[11]
MSC1_CS1 PA[12]
MSC1_CS0 PA[13]
VSS
VSS
VSS
VSS
Motherboard Connector
0
0
0
0000
Not populated
R2 R3 R4 R5 R15
R14 R16

EVB configuration
Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
Freescale Semiconductor 7
Figure 3. Single Ended ADC Channel Filters
Figure 4. Differential ADC Channel Filter
4.6 SIPI Interface
A SIPI interface is provided on the EVB for high speed interprocessor communications. The SIPI interface
connections are shown in Figure 5 and listed in Table 5.
PZ14 20K
PZ15 20K
0.01μF0.01μF
C39
0.01μF
C38
0.01μF
C48 C47
J11
12
34
R19
R21
PY0 20K
PY1
20K
C62
100pF
C61
100pF
J15
1
2
R23
R24

Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
EVB configuration
Freescale Semiconductor8
Figure 5. SIPI Interface
4.7 JTAG Interface
A standard JTAG interface is provided on the EVB for debug connections. Note that the Aurora high speed
debug interface is only available with the MPC5746R BD trace adapter board provided as part of the
Freescale calibration solution. The JTAG interface connections are shown in Figure 6 and listed in Table 6.
Table 5. SIPI connector (J1)
Pin Signal Pin Signal
1 SIPI TXP 2 GND
3 SIPI TXN 4 GND
5GND 6SIPI_CLK
7 SIPI RXN 8 GND
9 SIPI RXP 10 GND

EVB configuration
Freescale Semiconductor 9
Figure 6. JTAG Interface
4.8 I/O Connectivity and Port Routing
Most of the MCU’s I/Os are routed to the main mother board. These include the pins associated with the
FlexCAN, Ethernet, and LinFlex interfaces and other normal GPIO pins. The MPC57XXXMB provides
physical layer drivers for these communication protocols. See the MPC57XXXMB User Guide for the
correct jumper settings to enable and configure these drivers and associated circuits.
Table 7lists the mapping from the MPC5746R device ports to the existing headers/ports on the
MPC57XXXMB motherboard, and to the FlexCAN, Ethernet, UARTand LinFlex drivers.
Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
Table 6. JTAG connector (J7)
Pin Signal Pin Signal
1TDI 2GND
3TDO 4GND
5TCK 6GND
7 EVTI0 8 PORST_B
9 RESET_B 10 TMS
11 VDD_HV_IO_JTAG 12 GND
13 EVTO0 14 JCOMP

Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
EVB configuration
Freescale Semiconductor10
Table 7. Port to Motherboard Mapping — 144LQFP, 176LQFP and 252MAPBGA
MPC5746R Pin Number MPC57XXXMB Motherboard
Port
Function
144LQFP 176LQFP 252MAPBGA
144LQFP 176LQFP
252MAPBGA 144LQFP 176LQFP 252MAPBGA
PA[0] MSC0_CS0 — 142 174 A3 PP[7]2PA[0]
PA[1] MSC0_CS1/SIPI_RXN SIPI_RXN 141 173 B3 PP[8]2no connect1
PA[2] MSC0_RX/SIPI_RXP SIPI_RXP 140 172 A4 PP[9]2no connect1
PA[3] MSC0_CLKN — 139 171 B4 PP[10]2PA[3]
PA[4] MSC0_CLKP/SIPI_CLK SIPI_CLK 138 170 C4 PP[11]2no connect1
PA[5] MSC0_SOUTN/SIPI_TXN SIPI_TXN 137 169 C5 PP[12]2no connect1
PA[6] MSC0_SOUTP/SIPI_TXP SIPI_TXP 136 168 B5 PP[13]2no connect1
PA[7] n/a MSC1_SOUTN 165 C6 n/a PP[7]2
PA[8] n/a MSC1_SOUTP 164 C7 n/a PP[8]2
PA[9] n/a MSC1_CLKN 161 A6 n/a PP[92]
PA[10] n/a MSC1_CLKP 160 A7 n/a PP[10]2
PA[11] n/a MSC1_RX 159 B7 n/a PP[11]2
PA[12] n/a MSC1_CS1 158 B8 n/a PP[12]2
PA[13] n/a MSC1_CS0 157 A8 n/a PP[13]2
PB[0] TDO 143 175 D1 no connect3
PB[1] TDI 144 176 E3 no connect3
PC[0] FEC_REF_CLK 45 56 Y9 PA[15]
PC[1] FEC_TXCLK 46 57 W9 PK[14]
PC[2] FEC_TXEN 47 58 V9 PC[14]
PC[3] FEC_TXD3 48 59 U9 PM[5]
PC[4] FEC_TXD2 49 60 W10 PM[4]
PC[5] FEC_TXD1 50 61 V10 PE[12]
PC[6] FEC_TXD0 51 62 U10 PC[15]
PC[7] FEC_RXD0 54 65 Y11 PC[12]
PC[8] FEC_RXD1 55 66 V11 PC[13]
PC[9] FEC_RXD2 56 67 U11 PM[1]
PC[10] FEC_RXD3 57 68 Y12 PK[15]
PC[11] FEC_RXER 58 69 W12 PM[3]
PC[12] FEC_RXCLK 59 70 V12 PC[10]
PC[13] FEC_RXDV 60 71 U12 PM[0]
PD[0] — 37 45 Y3 PL[0]
PD[1] — 38 46 W3 PL[1]
PD[2] — Y4 PL[2]
PD[3] — W4 PL[3]
PD[4] — 47 V4 PL[4]

EVB configuration
Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
Freescale Semiconductor 11
PD[5] — Y5 PL[5]
PD[6] — W5 PL[6]
PD[7] — 39 48 V5 PL[7]
PD[8] FEC_MDC 40 49 V6 PC[3]
PD[9] — Y7 PL[9]
PD[10] — 52 W7 PL[10]
PD[11] — 53 V7 PL[11]
PD[12] — U7 PL[12]
PD[13] FEC_MDIO 43 54 Y8 PC[2]
PD[14] — 44 55 W8 PL[14]
PD[15] — V8 PL[15]
PE[0] — U8 PE[0]
PF[0] LIN2TX 126 G20 PD[14]
PF[1] LIN2RX 127 G19 PD[15]
PF[2] LIN3TX G18 PF[2]
PF[3] LIN3RX G17 PF[3]
PF[4] CAN0TX F19 PF[4]
PF[5] CAN0RX D19 PF[5]
PF[6] CAN1TX E20 PF[6]
PF[7] CAN1RX E18 PF[7]
PF[8] — D20 PF[8]
PF[9] — D19 PF[9]
PF[10] CAN1TX D18 PF[10]
PF[11] CAN0RX/CAN1RX 106 130 C20 PF[11]
PF[12] CAN0TX 107 131 C19 PC[9]
PF[13] CAN0RX 108 132 B20 PC[8]
PG[1] CAN2RX 109 133 A18 PG[14]
PG[2] CAN2TX 110 134 A17 PE[5]
PG[3] — B17 PG[3]
PG[4] — C18 PG[4]
PG[5] LIN1RX 111 135 B16 PE[6]
PG[6] LIN1TX 112 136 A16 PE[7]
PG[7] — C17 PG[7]
PG[9] CAN3RX 113 137 C16 PA[11]
PG[10] — 138 A15 PG[10]
PG[11] CAN3TX 115 140 B15 PA[10]
PG[12] — 116 141 B14 PG[12]
PG[13] — 117 142 A14 PG[13]
Table 7. Port to Motherboard Mapping — 144LQFP, 176LQFP and 252MAPBGA
MPC5746R Pin Number MPC57XXXMB Motherboard
Port
Function
144LQFP 176LQFP 252MAPBGA
144LQFP 176LQFP
252MAPBGA 144LQFP 176LQFP 252MAPBGA

Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
EVB configuration
Freescale Semiconductor12
PG[14] — C15 PE[14]
PG[15] — C14 PE[15]
PH[0] — 118 143 D14 PH[0]
PH[1] — A13 PH[1]
PH[2] — B13 PH[2]
PH[3] — 119 144 C13 PH[3]
PH[4] — D14 PH[4]
PH[5] — A12 PH[5]
PH[6] — C12 PH[6]
PH[7] — 120 145 D12 PH[7]
PH[8] — 121 146 B11 PH[8]
PH[9] — C11 PH[9]
PH[10] — D11 PH[10]
PH[11] — 125 150 A10 PH[11]
PH[12] — 126 151 B10 PH[12]
PH[13] — C10 PH[13]
PH[14] — 127 152 D10 PH[14]
PH[15] — 128 153 A9 PH[15]
PI[0] — 129 154 B9 PI[0]
PI[1] — 130 155 C9 PI[1]
PI[2] — D9 PI[2]
PI[3] — 131 156 C8 PI[3]
PI[4] — D8 PI[4]
PI[5] — D7 PI[5]
PJ[0] — 10 10 H1 PJ[0]
PJ[1] — 11 11 G4 PJ[1]
PJ[2] — H2 PJ[2]
PJ[3] — 12 H3 PJ[3]
PJ[4] EVTI_0 12 13 H4 no connect3
PJ[5] — 17 18 J2 PJ[5]
PJ[6] — J3 PJ[6]
PJ[7] EVTO_0 18 19 J4 no connect3
PJ[8] — K2 PJ[8]
PJ[9] — K3 PJ[9]
PJ[10] — K4 PJ[10]
PJ[11] — 24 25 L3 PJ[11]
PJ[12] — 26 L4 PJ[12]
PJ[13] — 27 M3 PJ[13]
Table 7. Port to Motherboard Mapping — 144LQFP, 176LQFP and 252MAPBGA
MPC5746R Pin Number MPC57XXXMB Motherboard
Port
Function
144LQFP 176LQFP 252MAPBGA
144LQFP 176LQFP
252MAPBGA 144LQFP 176LQFP 252MAPBGA

EVB configuration
Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
Freescale Semiconductor 13
PJ[14] — 25 28 M4 PJ[14]
PJ[15] — 29 N2 PJ[15]
PK[0] — 30 N3 PS[0]
PK[1] — 26 31 N4 PS[1]
PK[2] — 27 32 P1 PS[2]
PK[4] — 33 P2 PS[4]
PK[5] — 28 34 P3 PS[5]
PK[7] — 31 37 P4 PS[7]
PK[8] — 32 38 R1 PS[8]
PK[9] — 39 R3 PS[9]
PK[10] — 33 40 T2 PS[10]
PK[11] — 34 41 T3 PS[11]
PK[12] — 42 U1 PS[12]
PK[13] — 35 43 U2 PS[13]
PK[14] — 36 44 V1 PS[14]
PW[0] — Y13 PW[0]
PW[1] — 64 76 W13 PW[1]
PW[2] — 75 V13 PW[2]
PW[3] — 63 74 U13 PW[3]
PX[0] — U19 PX[0]
PX[1] — 73 89 U18 PX[1]
PX[2] — 72 88 V18 PX[2]
PX[3] — 71 87 Y17 PX[3]
PX[4] — W17 PX[4]
PX[5] — 68 84 V17 PX[5]
PX[6] — Y16 PX[6]
PX[7] — 67 83 W16 PX[7]
PX[8] — U14 PX[8]
PX[9] — 82 Y15 PX[9]
PX[10] — 66 81 W15 PX[10]
PX[11] — V15 PX[11]
PX[12] — 80 Y14 PX[12]
PX[13] — 79 W14 PX[13]
PX[14] — 65 78 V14 PX[14]
PX[15] — 77 V16 PX[15]
PY[0] SD2_0 101 N20 n/a no connect4
PY[1] SD2_1 80 100 N19 no connect6no connect5
Table 7. Port to Motherboard Mapping — 144LQFP, 176LQFP and 252MAPBGA
MPC5746R Pin Number MPC57XXXMB Motherboard
Port
Function
144LQFP 176LQFP 252MAPBGA
144LQFP 176LQFP
252MAPBGA 144LQFP 176LQFP 252MAPBGA

Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
Reset switches
Freescale Semiconductor14
5 Reset switches
The push-button switch SW1 provides a power-on-reset signal to the MCU.
PY[2] — 99 N18 PT[2]
PY[3] — N17 PT[3]
PY[4] — 98 P20 PT[4]
PY[5] — P19 PT[5]
PY[6] — 79 97 P18 PT[6]
PY[7] — 96 P17 PT[7]
PY[8] — R20 PT[8]
PY[9] — 78 95 R19 PT[9]
PY[10] — 94 R18 PT[10]
PY[11] — T20 PT[11]
PY[12] — T19 PT[12]
PY[13] — 77 93 T18 PT[13]
PY[14] — U20 PT[14]
PY[15] — 74 90 V20 PT[15]
PZ[0] — 102 123 H20 PN[0]
PZ[1] — 101 122 H19 PN[1]
PZ[2] — 100 121 H18 PN[2]
PZ[3] — 99 120 H17 PN[3]
PZ[4] — 98 119 J20 PN[4]
PZ[5] — 97 118 J19 PN[5]
PZ[6] — 96 117 J18 PN[6]
PZ[7] — 95 116 J17 PN[7]
PZ[8] — 90 111 K18 PB[0]
PZ[9] — 89 110 K17 PB[1]
PZ[10] — 88 109 L18 PB[2]
PZ[11] — 87 108 L17 PB[3]
PZ[12] — 86 107 M18 PB[4]
PZ[13] — 85 106 M17 PB[5]
PZ[14] — 84 105 M20 no connect5no connect6
PZ[15] — 83 104 M19 no connect4no connect6
1Routed to Samtech connector 1 on daughter card.
2Routed to Samtech connector 2 on daughter card and to this port number on MB via a zero ohm resistor..
3Routed to JTAG connector on daughter card
4Routed to N side of differential PI-filter on daughter card
5Routed to P side of differential PI-filter on daughter card
6Routed to Pi-filter on daughter card
Table 7. Port to Motherboard Mapping — 144LQFP, 176LQFP and 252MAPBGA
MPC5746R Pin Number MPC57XXXMB Motherboard
Port
Function
144LQFP 176LQFP 252MAPBGA
144LQFP 176LQFP
252MAPBGA 144LQFP 176LQFP 252MAPBGA

LEDs
Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
Freescale Semiconductor 15
6LEDs
LEDs shown in Table 8 provide indicators for:
• Power from external 5.0 V supply
• Reset states
7Testpoints
Test points shown in Table 9 are available to allow probing of various voltages and signals.
Table 8. LEDs
LED Description
D1 5V External Supply
D2 RESET_B
D3 PORST_B
Table 9. Test points
Test Point Description
TP1 SIPI_CLK
TP2 VDD_HV_MSC
TP3 VDD_STBY
TP4 VDD_HV_IO_JTAG
TP5 SIPI_TXP
TP6 SIPI_TXN
TP7 SIPI_RXN
TP8 SIPI_RXP
TP9 GND
TP10 GND
TP11 VSSA_JTAG
TP12 VDD_HV_ADV_SD
TP13 VSSA_ADC
TP14 VDD_HV_PMC
TP15 VDD_HV_FLA
TP16 VDD_LV_CORE
TP17 GND
TP18 GND
TP19 VDD_HV_IO_FEC
TP20 VDD_HV_ADV_SAR

Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
Schematics
Freescale Semiconductor16
8 Schematics
The MPC5746R-176DS, MPC5746R-252DS and MPC5746R-144DSschematics are available as an
attachment in this PDF document. To access the schematic open the bookmark window and click on the
paper clip icon on the left side of the page.
9 EVB Errata
EVB errata are listed in the following table.
TP21 VDD_HV_IO_MAIN
Errata List
Errata Description
Affected
Workaround
176DS252DS144DS
1
Port pin PG[9] (CAN3RX) on the MPC5746R was
routed to motherboard port pin PA[13] instead of
PA[11]. PA[11] is also routed on the motherboard to
J38, which is a selectable RX pin for the CAN
transceiver. This prevents the CAN RX signal from
being connected directly via motherboard trace to
the PG[9] pin on the MPC5746R for the CAN3RX
function.
Yes No No
To connect the RX signal from
the CAN bus interface (J6) to the
CAN3RX signal on the
MPC5746R device at pin PG[9],
place a wire jumper from PA[13]
on the motherboard to pin 3 on
J38.
Table 9. Test points (continued)
Test Point Description

Revision history
Qorivva MPC5746R-176DS/252DS Evaluation Board (EVB) User’s Guide, Rev. 1.6
Freescale Semiconductor 17
10 Revision history
Table 10. Revision history
Revision number Date Description
1.0 04/24/2013 Initial version.
1.1 04/25/2013 Updated from review comments.
1.2 04/25/2013 Added EVB Errata section and updated
with current known errata.
1.3 09/09/2013 Updated Table 7 to include port
mappings from 252MAPBGA pins. Other
minimal modifications to various sections
so that User Guide supports both 176
and 252 packages.
1.4 09/11/2013 Removed Top View section. Updated
Errata list to included affected DS
1.5 04/23/2014 Updated Table 7to include port
mappings from 144LQFP pins. Other
minimal modifications to various sections
so that User Guide supports the 176,
252, and 144 packages.
1.6 09/01/2015 Changed all instances of MPC5746M
to MPC57XXX.

Document Number: MPC5746REVB176UG
Rev. 1.6
9/2015
Information in this document is provided solely to enable system and software
implementers to use Freescale products. There are no express or implied copyright
licenses granted hereunder to design or fabricate any integrated circuits based on the
information in this document.
Freescale reserves the right to make changes without further notice to any products
herein. Freescale makes no warranty, representation, or guarantee regarding the
suitability of its products for any particular purpose, nor does Freescale assume any
liability arising out of the application or use of any product or circuit, and specifically
disclaims any and all liability, including without limitation consequential or incidental
damages. “Typical” parameters that may be provided in Freescale data sheets and/or
specifications can and do vary in different applications, and actual performance may
vary over time. All operating parameters, including “typicals,” must be validated for
each customer application by customer’s technical experts. Freescale does not convey
any license under its patent rights nor the rights of others. Freescale sells products
pursuant to standard terms and conditions of sale, which can be found at the following
address: http://www.reg.net/v2/webservices/Freescale/Docs/TermsandConditions.htm
How to Reach Us:
Home Page:
freescale.com
Web Support:
freescale.com/support
Freescale, the Freescale logo, AltiVec, C-5, CodeTest, CodeWarrior, ColdFire,
C-Ware, Energy Efficient Solutions logo, Kinetis, mobileGT, PowerQUICC, Processor
Expert, QorIQ, Qorivva, StarCore, Symphony, and VortiQa are trademarks of
Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. Airfast, BeeKit, BeeStack,
ColdFire+, CoreNet, Flexis, MagniV, MXC, Platform in a Package, QorIQ Qonverge,
QUICC Engine, Ready Play, SafeAssure, SMARTMOS, TurboLink, Vybrid, and Xtrinsic
are trademarks of Freescale Semiconductor, Inc. All other product or service names
are the property of their respective owners. The Power Architecture and
Power.org word marks and the Power and Power.org logos and related
marks are trademarks and service marks licensed by Power.org.
© 2012 Freescale Semiconductor, Inc.

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
NXP:
MPC5746R-252DS MPC5746R-144DS MPC5746R-176DS
