FREEWAY MT400-24T Assembly instructions

INTRODUCTION
Thank you for acquiring Freeway Med-Tech’s Medical-Grade Integrated LCD System. With a 23.8-
inch TFT display and powered by the Intel®Core™ i processor, the Medical-Grade Integrated LCD System
offers optimal combinations of performance and power savings. With fully-integrated point-of-care modules
within an elegant, space-saving design, the Medical-Grade Integrated LCD System is the optimum solution to
enhance work ow and service.
Please take a few moments to review the contents of this document to ensure that the setup and startup
proceed smoothly. The Medical-Grade Integrated LCD System is ready for use, out of the box, in its default
con guration when powered by the power source provided. The following documentation offers guidance
on the hardware elements and features of the computer. Please refer to your device provider for information
pertaining to the software operating system or software applications.
The MT400-24T supports VESA standard (100x100mm) mounting brackets and arms. Attach the bracket or
the arm to the back of MT400-24T, then use screws (4 x M8x12mm) to fi x the VESA bracket or arm.
BASIC
OPERATION
GUIDE
MT4 0 0 -2 4T
Medical-Grade Integrated LCD System
Package contents
1 MT400-24T Mains
Powered 24in Touch
Screen Monitor
1 Medical Grade AC-DC
power adapter with
orange curly power cord
1 Basic Operation Guide

BASIC FEATURES
The Medical-Grade Integrated LCD System integrates a bright 23.8” display with a high performance system
and USB ports for a comprehensive point-of-care solution.
Attach The Tabletop Stand (Optional)
1. Insert the top two tabs of the tabletop stand into the top two open slots on the MT400-24T back panel.
2. Push the latch to pivot the two lower tabs of the tabletop stand.
3. Push the two lower tabs into the two lower slots on the MT400-24T back panel. Make sure the latch locks
back into position so the stand is securely attached.
Detach the Tabletop Stand (Optional)
1. Push the latch to pivot the two lower tabs.
2. Pull out the two lower tabs, then the two upper tabs from the MT400-24T back panel.
PRECAUTIONS
• Always exercise care when operating and handling
the Medical-Grade Integrated LCD System.
• Never disassemble any portion of the enclosure, as
this will void any product warranty on the Medical-
Grade Integrated LCD System.
• Do not use any AC/DC adapter other than the
one provided with the device or a replacement
acquired from the manufacturer.
• In the unlikely event that smoke, abnormal noise or
strange odour is present, immediately power down
the Medical-Grade Integrated LCD System and
disconnect all power sources. Please report the
problem to your device provider immediately.
Powering ON and OFF
Please use the AC-DC adapter with the Medical-Grade Integrated LCD System for the power supply. To
activate the Medical-Grade Integrated LCD System, push and quickly release the Power Button and the
display will come on in a few seconds. To put in Standby mode, push and quickly release the Power Button.
To turn off for extended storage, power off the device safely using any software function that “shuts down
computer” provided in the software operating system.
Wireless Networking
Wireless LAN
The Medical-Grade Integrated LCD System is often delivered with an embedded (user- inaccessible) 802.11ac
WLAN adapter equipped with a hidden custom antenna.
• Through the support of typical WLAN adapters, the Medical-Grade Integrated LCD System should be
able to detect all 802.11 access points in the vicinity for you to select the access point of your choice for
connection.
• The SSID and WEP/WPA/WPA2 (if enabled) parameters on the Medical-Grade Integrated LCD System
and the access points have to match. The SSID is case-sensitive and it is recommended that you enable
WEP/WPA/WPA2 encryption (or advanced alternatives) for secure access.
• When WEP/WPA/WPA2 is enabled, you may need to consult your network administrator or your
networking equipment literature to properly congure associated settings such as Authentication mode, etc.
• Refer to the access point operating manuals for setting up the 802.11 access points.
IMPORTANT NOTES
1. To conserve power, use (push and quick release) the Power Button to put the device in “Standby” mode
while not in use. Pushing briey on the same button will wake up the system within seconds.
2. Avoid using the Power Button (“hold 4+ seconds” feature) to turn off the device — this form of hardware
shutdown is intended to be a means of recovery from device lockups, and not as normal operation.
freewaymedtech.com MT400-24T Basic operation guide
1
1
2
2
3
MEDICAL – GENERAL MEDICAL EQUIPMENT
AS TO ELECTRICAL SHOCK, FIRE AND MECHANICAL
HAZARDS ONLY IN ACCORDANCE WITH ANSI/AAMI
ES60601-1 (2005) + AMD (2012) & “CAN/CSA-C22.2
No. 6060-1 (2008) + (2014)

CLEANING THE MT400-24T
The screen
• A screen cleaning solution that is alcohol-free and non-abrasive can be used to clean the touch screen.
• Cleaning with a micro- ber cloth is recommended.
• Please spread the solution onto the cloth and then clean the touch screen.
The anti-microbial enclosure
• Use a soft/non-abrasive cloth moistened with water to clean the enclosure.
• If using a cleaner, an alcohol-free and oxide-free cleaning liquid is recommended.
• To prevent scratching the anti-microbial coating, please wipe gently.
TOUCH
SCREEN
E I J
CA B CG
H
K
D F
FRONT
LOWER I/O
REAR
100x100 VESA mounting
I/O PORTS
The MT400-24T Monitor has a comprehensive set of I/O ports. The following ports are located along
the bottom side of the unit.
v1.0 0 422freewaymedtech.com
APower button GEthernet ports (RJ45)
BProgrammable buttons HAudio jack
CSpeakers IUSB 2.0 ports
DDC-in JCOM ports
EHDMI output KPotential equalization conductor (optional)
FUSB 3.0 ports
