FRENGER systems EIR3000 Guide

EnergoInfra Industry
Electric Infrared Heater
EIR3000
EIR4500
EIR6000
Mounng and Installaon

CG
W
L
D
H
C/C
FB
Type Output Voltage Current L W H C/C Kg
EIR3000 3000W 400V3N~ 4.33A 1030 300 80 650 5.5
EIR4500 4500W 400V3N~ 6.50A 1360 300 80 820 7.0
EIR6000 6000W 400V3N~ 8.66A 1680 300 80 1030 8.5
45°
30°
300
110
D = 80
1
400V3~
23456
L1 L2 L3 PE
400V3N~
123456
L1 L2 L3 PEN
2300
300
500
1000
200
Fig.4a Fig.4b
Fig.2 Fig.3
Fig.1 Millimeter

EnergoInfra Industry EIR3000, EIR4500 and
EIR6000, 400V3N~, are intended for permanent
installation by an authorized electrician and in
accordance with existing national regulations. The
appliance must be preceded by an all-pole switch,
min. 3mm contact gap.Appliance and protection
class: Class I - IP44.
1. The EIR Industry can be mounted to the ceiling or
on the wall, horizontally, where the lowest installa-
tion height is 2.3m from the oor level. Respect and
follow the minimum distances to the surrounding
surfaces, according to g.1.
NOTE! Do not cover the heater or direct it towards
combustible items. Fixed heater must not be mount-
ed in front of a socket outlet.
2. The supplied ceiling/wall brackets should be
mounted with a C/C distance, see g.2 and table.
The brackets can be angled in different positions,
when wall mounted. There are two mounting holes
per ceiling bracket, where “D” is the distance be-
tween the holes, g.3. The xing brackets “FB”, on
top of the heater, is to be hung up and xed to the
ceiling/wall brackets.
3. Alternative suspension kits are available to ease
installation using wall wire mount or chains.
4. On top of the heater there are two cable grom-
mets “CG”, g.2, allowing multiple connections.
Connection according to g.4a, to a 16mm² terminal
block. Using this connection, one heating element
at a time can be connected (for three output steps).
Protect the supply cable, if it comes in contact with
hot parts!
5. When starting-up the heater for the rst time or
after a long period of disuse, smoke or odor may
result from grease, dust or dirt that has collected on
the element. This is normal and disappears after a
short period of time.
6. Like in all electrical heating appliances, clicks
can occur during expansion and contraction of the
material, due to movement when the temperature
changes.
7. The heater may undergo a colour variation fol-
lowing being energized for the rst time and during
its life span. The extent is relevant to the operating
environment and is normal behaviour.
Aerosols, paint, solvents, dust and lth etc... may
adhere to the heater and can potentially cause
discolouration. The performance of the heater is un-
affected by discolouration.As a precaution, always
switch off the heater while painting and drying!
8. When cleaning the heater, make sure that the
heater is switched off. Let the heater cool down.
Use a soft cloth to clean the body of the heater. For
cleaning the reector, use a clean soft brush.
9. If ret is needed, the heating elements can be
replaced in site without having to take down the
heater. Unscrew lid and wires. Pull out the part in
question and replace with a new one.
10. Information about energy consumption
In combination with an Ecodesign-compliant
thermostat, the product data complies with the EU
regulations on the Ecodesign Directive (2009/125/
EC) for energy-related products (ErP).
11. Safety
• When the installation is protected by an RCD, a
300mA residual current device has to be used.
• Warning - Hot surface! Do not touch the heater
when in use!
• Do not cover the heater! Risk of re!
• This appliance shall not be used by children less
than 8 years or persons with reduced physical,
sensorial or mental disability or lack of experi-
ence and knowledge, unless they are supervised
or were instructed how to use the appliance in a
safe way, and understand the hazards involved.
Children shall not play with the appliance. Clean-
ing and user maintenance shall not be made by
children without supervision.
ENGLISH
ErP✔

19.01.07-01EN
