Frico IRCF15L User manual

....7
SE ....9 NO ....11 GB ....13 DE ....15 FR
Infrared heater IRCF
Original instructions
....17
RU

IRCF
2
Fig. 1
Fig. 2

IRCF
3
Fig. 3

IRCF
4
3000 W
Technical specifications | Infrared heater IRCF 3
Type Heat
output (1)
[W]
Voltage (2)
[V]
Amperage (3)
[A]
Dimensions (4)
LxHxW
[mm]
Number of
lamps (5)
Weight
(6)
[kg]
Min cable area
(7)
[mm²]
IRCF1500/IRCF15L 1500 230 V~ 7 490x230x140 1 1,7 3x1,5
IRCF3000/IRCF30L 3000 230 V~ 13 490x375x140 2 2,4 3x2,5
IRCF4500/IRCF45L 4500 400 V3~ 6,5 490x515x140 3 3,0 5x1,5
IRCF6000 6000 400 V3~ 9 490x515x140 3 3,0 5x1,5
Protection class Infrared heater IRCF 1500-4500: IP20
Protection class Infrared heater IRCF 6000: IP55
CE compliant.
Dimensions
Type Height
[mm]
Length
[mm]
IRCF1500 230 490
IRCF3000 375 490
IRCF4500 515 490
IRCF6000 515 490
IRCF can be angled
(1)
SE: Effekt
GB: Output
NO: Effekt
DE: Abgabe
FR: Puissance
RU: Мощность [Вт]
(2)
SE: Spänning
GB: Voltage
NO: Spenning
DE: Spannung
FR: Tension
RU: Напряжение [В]
(3)
SE: Ström
GB: Amperage
NO: Strøm
DE: Strom
FR: Intensité
RU: Сила тока
(4)
SE: Mått
GB: Dimensions
NO: Mål
DE: Abmessungen
FR: Dimensions
RU: Габариты LxHxW [мм]
(5)
SE: Antal lampor
GB: Number of lamps
NO: Antall lamper
DE: Anzahl der Lampen
FR: Nombre de lampes
RU: Количество ламп
(6)
SE: Vikt
GB: Weight
NO: Vekt
DE: Gewicht
FR: Poids
RU: Вес [кг]
(7)
SE: Min kabelarea
GB: Min. cable area
NO: Min. areal
DE: Min. Kabelfläche
FR: Surface mini
RU: Min сечение кабеля [мм2]

IRCF
5
Accessories
Controls and other accessories
Type Description E-nr
(SE)
EL-nr
(NO)
HxWxD
[mm]
CBT Timer 87 511 87 54 312 02 155x87x43
S123 Manual switch for 1-2-3 output steps 19 346 40 54 019 23 72x64x46
T10S Electronic thermostat with concealed knob 85 809 33 54 911 12 80x80x31
TK10S Electronic thermostat with visible knob 85 809 37 54 911 51 80x80x31
KRT1900 Capillary room thermostat, IP55 85 810 12 54 910 50 165x57x60
LIRCF Extra lamp 85 701 32
IRCG1 Protection grille for IRCF1500. IRCF3000
require 2 pcs, IRCF4500/6000 require 3 pcs.
85 701 31
KRT1900
T10S TKS16
20
25
30
15
10
5
0
1
2
S123
CBT
1h
2
1
2h
4h
CBT IRCG1

IRCF
6
IRCF
123
CBT IRCF
230V~
230V~
LN
Max load 3500W
230V~
N
230V~
P
Thermostat
IRCF
IRCF
123
CBT
230V~
LN
L1
L2
L3
N
L
N
400V~
IRCF
400V~ IRCF
400V~ IRCF
400V~
0
XX
X
X
X
X
3
2
1
1/3
3/3
2/3
S123
IRCF
400V~ IRCF
400V~ IRCF
400V~
L
230V~
N
L1
L2
L3
N
0
XX
X
X
X
X
3
2
1
1/3
3/3
2/3
S123
Thermostat
400V~
Wiring diagrams IRCF
Internal wiring diagrams
Control with timer
Control by thermostat, contactor and switch (triphase)
Control by timer, contactor and switch (triphase)
6000
20 20 20

IRCF
11
GB
General instructions
Read these instructions carefully before
installation and use. Keep this manual for
future reference. During installation and
maintenance and when replacing the lamp
the heater should always be disconnected
from the power supply.
The element of IRCF is a halogen quartz
lamp that is operating at about 2200 ºC.
The guarantee is only valid if the heater is
installed and used in a way that is described
in this instruction.
Application area
IRCF is especially designed for spot heating
of premises with large air volumes, such as
churches, aircraft hangars, industries and
warehouses.This infrared heater is tested and
approved according to the EMC- and LVD
regulations and is CE compliant.
Normally IRCF is used to give comfort for
people in the area in front of or under the
heater.
With its high efficiency and compact size it
is perfect for many difficult applications.
Mounting
After unpacking make sure that the appliance
is complete and shows no signs of visible
damage.
Make sure that the voltage is the same as
indicated on the rating label.
IRCF must be mounted at least 2,3 m above
the floor.
Normally the heater is mounted at 3 – 6 m
height, for spotheating the appliance should
not be mounted higher than 5 m. The best
comfort is experienced when a person is
heated from two directions.
Enclosed in the package there is a wall
bracket. Make sure that the wall is firm and
that proper screws are used.
Make sure that the appliance is directed
at the surface that shall be heated, for
adjustments se fig. 2.
Fig. 3 shows other mounting alternatives,
chains and S-hooks needed for such
installations are to be purchased separately.
Following important notes must be followed:
- The heater should always be installed
horizontally and only by using the brackets
provided.
- The heater must not be located directly
below a wall socket.
- Make sure that the power supplying cable
does not come in contact with the lamps or
is reached by the thermal heat.
- The minimum distances according to page
2 must be kept.
- Do not use the heater directly near a
bathtub, a shower or a swimming pool.
- The heater must be installed so that a
person standing in a shower can reach
neither the switch nor the heater.
- The heater must not be installed in areas
where hazardous vapours may be present.
Electrical installation
The electrical installation should be
carried out by a qualified electrician and in
conformity with prevailing regulations. When
fixed an all-pole switch with at least 3 mm
breaking gap should precede the appliance.
If a cable connects the heater it should be of
type H05 RN-F or similar.
N.B: The cable glands must be classified as
the heater.
Start up (E)
When the unit is used for the first time or
after a long period of disuse, smoke or odour
may result from dust or dirt that has collected
on the element. This is completely normal
and disappears after a short time.
Residual current circuit breaker (E)
When the installation is protected by means
of a residual current circuit breaker, which
trips when the appliance is connected,
this may be due to moisture in the heating
element. When an appliance containing a
heater element has not been used for a long
period or stored in a damp environment,
moisture can enter the element.
This should not be seen as a fault, but is
simply rectified by connecting the appliance
to the mains supply via a socket without a
Mounting and operating instructions

IRCF
12
GB
safety cut-out, so that the moisture can be
eliminated from the element. The drying
time can vary from a few hours to a few days.
As a preventive measure, the unit should
occasionally be run for a short time when it is
not being used for extended periods of time.
Maintenance
During maintenance the heater must be
disconnected from the power supply.
The heater contains no moving parts
and therefore very little maintenance is
required other than to ensure that there is no
excessive build-up of dust/dirt on the reflector
or lamp as this can cause overheating and
premature lamp failure.
To clean the appliance, wipe off with a damp
cloth. Wait until the unit is completely dry
before connecting it to the power supply.
When cleaning the appliance a mild soap
solution can be used. (N.B. Dishing- or
washing detergents can do damage to the
reflectors)
Replacement of lamp
A qualified person shall replace the lamp and
the gaskets.
The lamp is robust and if knocks and shock
vibrations are avoided it will run for a long
time. The expected lifetime of the lamp is
depending on the ambient temperature and
where the heater is installed.
Safety
• For all installations of electrically heated
products should a residual current
circuit breaker 300 mA for fire protection
be used.
• During installation, cleaning and service
the heater must be disconnected from the
power supply.
• All users should be made aware of all
aspects of operation and safety mentioned
in this instruction.
• The appliance is only to be used
according to these instructions.
• This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
• During operation the surfaces of the unit
are hot!
• The unit must not be covered fully
or partially with clothes, or similar
materials, as overheating can result in a
fire risk!
• Ensure that there is no excessive build-
up of dust/dirt on or around the heater as
this can cause overheating.
• A safety distance of not less than 1 m to
inflammable substances should always
be left in front of the heater.

2015-09-08 HH
Main office
Frico AB Tel: [phone]
Box 102
SE-433 22 Partille [email protected]
Sweden www.frico.se
For latest updated information and information
about your local contact: www.frico.se
