Installation and Operation Manual
Room Air Conditioners
115-Volt:
Q Chassis Models
SQ05, SQ06, SQ08
115-Volt: EQ08
PM
FAN SPEEDSCHEDULE
SYSTEM FAN MODE
POWER
ROOMTEMP
SETPOINT
AM
F
AUTOFA N
CONTINUOUS
AUTOSPEED
88C
ONOFF
AUTO
SCHEDULE
CHECK $MART
FILTER
93001008_00

2
Model information can be found on the name
plate behind the front cover.
Please complete and mail the owner
registration card furnished with this product,
or register online at www.friedrich.com. For
your future convenience, record the model
information here.
MODEL NUMBER
SERIAL NUMBER
PURCHASE DATE
Register your air conditioner
Thank you for your decision to purchase the Friedrich High Efciency Air Conditioner. Your new Friedrich has been carefully engineered and manufactured to
give you many years of dependable, efcient operation, maintaining a comfortable temperature and humidity level. Many extra features have been built into
your unit to assure quiet operation, the greatest circulation of cool, dry air, and the most economic operation.
THANK YOU, on behalf of our entire company,
for making such a wise purchase.
FRIEDRICH
AIRCONDITIONING CO.
SANANTONIO, TX
MODELNUMBER
SERIALNUMBER
VOLTS60 HZ/ 1PH
115
103 VOLT MIN.
COOLING:
BTU/HR
HEATING:
BTU/HR
7500
EER
9.8
AMPS
6.9
4000
EER
AMPS
11.2
MAX AMPS:
23.5 OZS.
DESIGNPRESSURES
600 PSIG HS
300 PSIG LS
U.S. PATENTS
D458, 229 S
5,634,346
IFCONNECTED TO
AFUSE PROTECTED
CIRCUIT, USEA 12 A
TIMEDELAY FUSE
LISTED 183H
AALY00219
EQ08N11-A
ROOM AIR
CONDITIONER
FRIEDRICH
Assembled in Mexico
MODEL NUMBER
AIR CONDITIONING CO.
SAN ANTONIO, TX
SERIAL NUMBER
VOLTS60 HZ/ 1PH
AALY00219
EQ08N11-A

3
Table of Contents...................................................................................................................................................................................................................................................................................... 3
Safety Precautions ................................................................................................................................................................................................................................................................................... 4
WARNING: Before Operating Your Unit .............................................................................................................................................................................................................................................. 5
Standard Filter Cleaning / Installation Instructions.............................................................................................................................................................................................................................. 6
Premium Carbon Filter Installation Instructions................................................................................................................................................................................................................................... 6
Control Panel Operation Instructions.................................................................................................................................................................................................................................................... 7
Remote Control Operation.................................................................................................................................................................................................................................................................... 12
Remote Effectiveness............................................................................................................................................................................................................................................................................ 12
Airow Selection and Adjustment........................................................................................................................................................................................................................................................ 14
Installation Instructions & Precautions................................................................................................................................................................................................................................................14
Items required for installation ................................................................................................................................................................................................................................................................ 15
Standard Window Installation...............................................................................................................................................................................................................................................................16
Replacement Installation Instructions................................................................................................................................................................................................................................................. 19
Cord Routing Options............................................................................................................................................................................................................................................................................ 19
Cord Routing Change............................................................................................................................................................................................................................................................................20
EntryGuard Security Lock.....................................................................................................................................................................................................................................................................21
Thru-the-wall Installation .......................................................................................................................................................................................................................................................................22
Final Inspection & Start-up Checklist ..................................................................................................................................................................................................................................................24
Routine Maintenance.............................................................................................................................................................................................................................................................................25
Service and Assistance.........................................................................................................................................................................................................................................................................25
Available Accessories............................................................................................................................................................................................................................................................................25
Troubleshooting Tips..............................................................................................................................................................................................................................................................................26
Addendum 1............................................................................................................................................................................................................................................................................................28
Table of Contents
Performance Testing Installation and Test Method (for testing laboratory use)..................................................................................................................................................................... 60

4
Safety Precautions
NOTICE
CAUTION
WARNING
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all
safety messages.
This is a safety Alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol with the word “WARNING”
or “CAUTION”. These words mean:
Indicates a hazard which, if not avoided, can result in severe personal injury or
death and damage to product or other property.
Indicates a hazard which, if not avoided, can result in personal injury and
damage to product or other property.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you
what will happen if the instructions are not followed.
Indicates property damage can occur if instructions are not followed.
WARNING
Refrigeration system
under high pressure
Do not puncture, heat, expose to flame or
incinerate.
Only certified refrigeration technicians should
service this equipment.
Only use gauge sets designed for use with
R410A. Do not use standard R22 gauge sets.
R410A systems operate at higher pressures
than R22 equipment. Appropriate safe
service and handling practices must be used.

5
Make sure the wiring is adequate for your unit.
If you have fuses, they should be of the time delay HACR type. Before you
install or relocate this unit, be sure that the amperage rating of the circuit
breaker or time delay fuse does not exceed the amp rating listed in Table 1.
DO NOT use an extension cord.
The cord provided will carry the proper amount of electrical power to the
unit; an extension cord may not.
Make sure that the receptacle is compatible with the air
conditioner cord plug provided.
This insures proper grounding. If you have a two prong receptacle you
will need to have it replaced with a grounded receptacle by a certied
electrician. The grounded receptacle should meet all national and local
codes and ordinances. Under no circumstances should you remove the
ground prong from the plug. You must use the three prong plug furnished
with the air conditioner.
Test the power cord
All Friedrich room air conditioners are shipped from the factory with a
Leakage Current Detection Interrupter (LCDI) equipped power cord. The
LCDI device meets the UL and NEC requirements for cord connected air
conditioners effective August 2004.
To test your power supply cord:
1. Plug power supply cord into a grounded 3 prong outlet.
2. Press RESET (See Figure 1).
3. Press TEST, listen for click; the RESET button trips and pops out.
4. Press and release RESET (Listen for click; RESET button latches
and remains in). The power cord is ready for use.
Once plugged in, the unit will operate normally without the need to reset
the LCDI device.
If the LCDI device fails to trip when tested or if the power supply cord is
damaged, it must be replaced with a new power supply cord from the
manufacturer. Contact our Technical Assistance Line at [phone].
To expedite service, please have your model number available.
WARNING: Before Operating Your Unit
MODEL
CIRCUIT RATING
OR TIME DELAY
FUSE
REQUIRED WALL
RECEPTACLE
AMP VOLT NEMA NO.
SQ05 • SQ06
SQ08 •EQ08 15 125 5-15P
Table 1.
WARNING
Electrical Shock Hazard
Make sure your electrical receptacle has the
same configuration as your air conditioner’s
plug. If different, consult a Licensed Electrician.
Do not use plug adapters.
Do not use an extension cord.
Do not remove ground prong.
Unplug unit prior to performing any service.
Always plug into a grounded 3 prong oulet.
Failure to follow these instructions can result in
death, fire, or electrical shock.
NOTICE
Do not use the LCDI device as an ON/OFF switch.
Failure to adhere to this precaution may cause
premature equipment malfunction.
Figure 1
FRR072
WARNING:
TEST BEFORE EACH USE!
1. PRESS REST BUTTON.
2. PLUG LCDI INTO POWER
RECEPTACLE.
3. PRESS TEST BUTTON,
RESET BUTTON SHOULD
POP UP.
4. PRESS RESET BUTTON
FOR USE.
DO NOT USE IF ABOVE TEST
FAILS.
WHEN GREEN LIGHT IS ON.
IT IS WORKING
PROPERLY!
RESET
TEST

6
Standard Filter Cleaning / Installation Instructions
STEP 1. Open front cover and remove permanent/washable mesh
lter by grasping the lter grip and pushing the lter holder
up and outward.
STEP 2. Clean the front mesh frame by washing the dirt from the lter.
Use a mild soap solution if necessary. Allow lter to dry.
STEP 3. Install lter back into the unit. See also “Filter Removal
Procedure” on the inside of the front door.
Figure 2 Figure 3
STEP 1. Remove the black plastic lter frame from the unit following the
instructions above or on the inside of the front cover.
STEP 2. Lay the black plastic lter frame on a at surface, with the 6
lter frame hooks facing upward.
Please follow the instructions below to install the Friedrich carbon lter. The carbon
lter should be replaced after 300 hours of operation, 3 months, or more often if
needed for maximum effectiveness.
When you replace the carbon lter, clean the washable mesh lter if dirty. Allow
mesh lter to dry before reinserting.
Premium Carbon Filter Installation Instructions
Place the carbon lter over the lter frame so that the carbon
lter’s 6 installation holes align with the 6 lter frame hooks.
(Figure 4)
Secure the carbon lter to the lter frame. Make sure that
all 6 lter frame hooks are inserted through all 6 installation
holes of the carbon lter. The installation hooks will hold the
lter securely.
STEP 3. Place the black plastic filter frame with the carbon filter
installed (Figure 5) back into the front of the unit, following
the instructions on the inside of the lter door.
Carbon lter is now ready for use!
Figure 4 Figure 5
FRR075
FILTER
DOOR
FRR076
FILTER FRAME
INSTRUCTIONS
FILTER
DOOR
FRR077
FILTER FRAME
HOOKS (6)
FRR078

7
FRR079
2 DIGIT DISPLAY
Shows Setting for:
- Set Point Temperature (default)
- Room Te mperature
- Clock (AM/PM)
ON / OFF:
Turns unit on/off
SYSTEM
Cycles between:
- COOL
- HEAT (if available)
- FAN ONLY
FAN MODE
Sets fan to either:
- AUTOFAN
-- Cycles automatically
- CONTINUOUS
-- Runs continuously
FAN SPEED
Sets fan speed:
- LOW
- MED
- HIGH
- AUTO
HEAT
FILTER
Check / Clean
AUTO SPEED
Automatically selects
best fan cooling speed
DEMAND RESPONSE EVENT
(optional)
FAN SPEED
Selected fan speed
ROOM TEMP
SET POINT
AM
PM
F
AUTO FAN
CONTINUOUS
AUTO SPEED
88 C
ON OFF
SCHEDULE
CHECK$MART
FILT ER
COOL
FAN
ONLY
CONTROL
LOCKED WI-FI
CONNECTED (optional)
WAIT
TEMPERATURE
UP
TEMPERATURE
DOWN
SCHEDULE ON
TIMER / SCHEDULE
Turns ON or OFF
TIMER ON
IR WINDOW
Do not block
All of the control panel function buttons and mode icons are shown below in Figure 6.
The display backlight has an automatic two (2) step dim function. After 15 seconds of inactivity, the display dims to 20% intensity. After an additional 120
seconds, the display switches off. Touching any button automatically changes the display to full brightness.
Control Panel Operation
Figure 6
SYSTEM SYSTEM allows you to select three modes of operation:
COOL
HEAT (if available)
FAN ONLY
FRR095
4 Speed
AUTO
LOW MEDIUM HIGH AUTO*
FAN SPEED FAN
SPEED allows you to select between four fan speeds:
FAN MODE
FAN
MODE allows you to select between
AUTO FA N
and CONTINUOUS modes.
must be in COOL or HEAT operation modes)
AUTOFAN
AUTO FA N
: fan cycles on or off with compressor
CONTINUOUS
C
ONTINUOUS : fan operates all the time.
UP and DOWN – changes the system's set point (desired room
temperature). Press once to change 1 degree at a time or hold down to
change at a faster pace. The factory preset lower and upper limits are 60°F
(16°C) and 99°F (37°C) (These buttons are also used for other functions
explained later in this section).
TIMER SCHEDULE allows you to select between the 24-Hour
Timer (default) or one of the pre-programmed energy management
SCHEDULE SCHEDULE options. Pressing this button will activate the selected
TIMER or SCHEDULE. Details are explained in the next section.
* AUTO selects fan speed needed to satisfy desire set point.
Basic Functions

8
Advanced Functions.
Set TIME and DAY - To adjust the unit's time press and hold the HOUR and
the MIN buttons together for three seconds (Refer to Figure 7).
The unit's current hour displays. Use the or buttons to adjust the
hour from 1 - 12, AM or PM. The example shown below is set for 11 AM.
Press TIMER SET (Refer to Figure 7) button to save the hour setting and
display the unit's current minutes.
Figure 7
FRR097
FRIEDRICH
AIR CONDITIONING CO.
SAN ANTONIO, TX
Use the or buttons to adjust the minutes. The example shown
below is now set for 11:25 AM. Press TIMER SET button to display the
unit's day setting.
Use the or buttons to adjust the day from 1 to 7, 1 = Sunday, 2
= Monday, 3 = Tuesday, and so on. The example shown below is set to
4 = Wednesday. Both pre-programmed schedules and customizable
schedules (discussed next) operate off of this setting. It is crucial to set
the day correctly if any schedule is to be used.
24-HOUR TIMER
The default program for your TIMER SCHEDULE button is a 24-Hour
Timer. (scheduler options explained later in this section)
It allows you to set daily ON and OFF times. For example, you can program
the unit to turn ON at 8:15 am and turn OFF at 1:30 pm everyday. The start
and stop time can be dened, but the unit's system mode, fan speed and
set point cannot and will default to the last setting used.
In order to use advanced functions, such as the timer or scheduler, you
must rst set the time and day on your unit.
25
FRR129
Press TIMER SET button to exit and save the SET TIME and DAY. The
TIMER SET button must be pressed within 15 seconds or the display will
time out and return to the normal operating display.
4
FRR130
AM
11
FRR128
Set Timer: Setting the Start Time
Press and hold the HOUR button (Figure 7) for 3 seconds. The icon
and "ON" will appear on the display
Press the or button to adjust the hour. Press the TIMER SET button
(Figure 7) to save hour setting and go to minutes. The example below is
showing a starting hour of 4 AM.
AM
4ON
FRR141
21ON
FRR142
Use the or button to adjust the minutes. Press the TIMER SET
button (Figure 7) within 15 seconds to exit and save the setting. The example
below has been set to turn on at 4:21 AM, once the Timer is activated..
The display will return to normal once the settings are saved.
NOTE: Setting the Timer's start and stop times do not activate the timer.
To activate the timer, you must press the button.

9
AM
11 OFF
FRR145
55 OFF
FRR146
Press and hold the MIN button (Figure 7) for 3 seconds. The icon and
"OFF" will appear on the display
Press the or button to adjust the hour. Press the TIMER SET button
(Figure 7) to save hour setting and go to minutes. The example below is
showing a stop hour of 11 AM.
Use the or button to adjust the minutes. Press the TIMER SET button
(Figure 7) within 15 seconds to exit and save the setting. The example below
is now set to turn off at 11:55 AM, once the Timer is activated.
The display will return to normal once the settings are saved.
NOTE: Setting the Timer's start and stop times do not activate the timer.
To activate the timer, you must press the button.
Timer Activated Scenarios
FRR157
Once the Timer's Start and Stop times have been saved, you can activate
the Timer by pressing the button..
Set Timer: Setting the Stop Time
SET POINT
F
AUTO FA N79
FRR159
If the Timer function is activated during the ON time, the Timer icon
illuminates and the unit will continue to run in the existing mode (system
mode, fan mode, fan speed, set temperature, etc.) until the set OFF time
occurs. See the example below:
When the set OFF time occurs or the Timer function is activated during
the OFF time, the unit will turn off, but the icon will remain illuminated,
as shown below.
To deactivate and shut off the Timer, press the button again. Whether
in the ON or OFF times, the icon disappears. If the unit was in an ON
time, the unit will stay in the current state. If the unit was in an OFF time,
the unit will turn back on in the last state operated.
TIMER and PRE-PROGRAMMED SCHEDULING
The TIMER SCHEDULE has three options:
24-Hour Timer - System default. (already covered)
Residential Schedule (option 1) – 40 Hr. Work Week:
This option causes your unit to raise temperatures to 85°F during the typical
work day, lower them again to 78°F prior to the time when most people will
return home, and raise slightly to 82°F overnight.
Commercial Schedule (option 2) - 5-Day Business Week
This option causes your unit to raise temperature to 84°F after typical
working hours and on weekends when commercial spaces are typically
unoccupied.
(Refer to Addendum 1 in the back of this manual for both Residential and
Commercial Schedule Tables.)
To select between these 3 options, press and hold the button
for 3 seconds. You will then be able to toggle between Timer (default),
Residential Schedule (1) and Commercial Schedule (2) by pressing the
or buttons. See below for images of each option.
FRR139
24-Hour Timer (system default).
Timer/Schedule Select

10
The $MART icon illuminates to indicate that the system is being controlled
remotely for a Demand Response event.
SET POINT
F
AUTO FA N79
FRR125
$MART
The FriedrichLink Wireless Adapter Accessory (sold separately) allows
you to unlock the full control potential of your Kuhl unit.
You can control, create customized schedules, group units for zone cooling,
and many other options remotely from a smartphone, tablet or computer.
When FriedrichLink is in use, the icon illuminates to indicate that the
system is receiving a Wi-Fi connection.
SET POINT
F
AUTO FA N79
FRR126
To select/save an option, press the TIMER SET button (Figure 7) while
on the desired selection. If there is no button activity for 15 seconds, the
function will time out and leave the original selection.
Once the selection is saved (or timed out), the display reverts to the
normal display.
Residential Schedule (option 1).
1
SCHEDULE
FRR137
Commercial Schedule (option 2).
2
SCHEDULE
FRR138
To activate the selected timer or schedule, press the button
If the Schedule function is activated during normal operation, the SCHEDULE
and Timer icons illuminates and the unit immediately runs the current
period schedule parameters, as shown below..
Scheduler Activated Scenarios
SET POINT
F
AUTO FA N79
SCHEDULE
FRR155
SET POINT
F
AUTO FA N79
FRR161
To deactivate and shut off the Schedule, press the button again.
The
SCHEDULE
and Timer icons will disappear and the unit will stay in
the current state. See example below.
Timer - Scheduler Control Block
If the unit is operating in the TIMER or SCHEDULE mode, all buttons are
locked out except the button. If any other button is pressed, the Timer
icon begins to blink for 3 seconds. In order to make any changes, you
must rst deactivate the Timer or Schedule by pressing the button.
FRIEDRICHLINK WI-FI CONTROL
EXTERNAL CONTROL STATUS
