Frigidaire FAA063P7 User manual

Product No. FAA063P7A1 FAA063P7A2 FAA063P7A3 FAA063P7A4
Series MS II MS II MS II MS II
Color N/A N/A N/A N/A
Volts 115 115 115 115
BTU-Cooling 6000 6000 6000 6000
Owner's Guide 220204d031 220204d031 220204d031 220204d031
Installation Instructions msinstalleng msinstalleng msinstalleng msinstalleng
Market North America North America North America North America
M40L0001.eps M40C0001.eps M40M0001.eps 2202049172.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995438396
05/06/02
(EN/SERVICE/WC)
099
ROOM AIR
CONDITIONER
Model No.
FAA063P7
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995438396 FAA063P7
06/05 2
CABINET, FRONT, CONTROLS

FAA063P7 Publication No: 5995438396
# Functional Parts 3 06/05
* Non-Illustrated Parts
CABINET, FRONT, CONTROLS
Model Index: AFAA063P7A (FAA063P7A1)
BFAA063P7A (FAA063P7A2)
CFAA063P7A (FAA063P7A3)
DFAA063P7A (FAA063P7A4)
POS. NO PART NO. DESCRIPTION
1 5304446364 A - - D Base, unit chassis
1 5304446365 - B C - Base, unit chassis
2 5304437068 A B C D Rail, shutter track, bottom
3 5304437055 A B C D Frame, shutter panel, LH
4 5304437052 A B C D Retainer, shutter lock
5 5304437053 A B C D Shutter, accordion panel
6 5304437057 A B C D Retainer, shutter mount, cabinet sides
7 5304446348 A B C D Cabinet, wrapper/sleeve
8 5304437069 A B C D Rail, shutter track, top
9 5304437054 A B C D Frame, shutter panel, RH
10 5304437063 A B C D Front Assembly, complete panel, includes
11 5304437059 A B C D Panel, front grille, tilt-out
12 5304437062 A B C D Filter, air, plastic frame
13 5304437058 A B C D Frame, front assembly
14 5304437061 A B C D Louver, horizontal
15 5304437060 A B C D Louver, vertical
16 5304437050 A B C D Knob, rotary control
17 5304437051 A B C D Enclosure, control, switch box
17* 5304446347 A B C D DIAL PLATE, DISPLAY PANEL
18 5304446345 A B C D SWITCH-SELECTOR, MAIN, 9 #
19 5304446346 A B C D Panel, ctrl mtg board
20 # 5304437106 A B C D Control, temperature
23 5304436530 A B C D Strap, capacitor mtg.
24 # 5304437111 A B C D Capacitor
25 5304437070 A B C D Control Box

Publication No: 5995438396 FAA063P7
06/05 4
COOLING & AIR FLOW SYSTEMS

FAA063P7 Publication No: 5995438396
# Functional Parts 5 06/05
* Non-Illustrated Parts
COOLING & AIR FLOW SYSTEMS
Model Index: AFAA063P7A (FAA063P7A1)
BFAA063P7A (FAA063P7A2)
CFAA063P7A (FAA063P7A3)
DFAA063P7A (FAA063P7A4)
POS. NO PART NO. DESCRIPTION
1 5304446349 A B C D Scroll, blower housing, bottom
2 # 5304446350 A B C D Blower Wheel, centrifugal fan
3 5304446351 A B C D Scroll, blower housing, top
6 5304446355 A B C D Cover, blower scroll, top
7 # 5304437049 A B C D Fan Blade, propeller, axial flow
8 # 5304447863 A B C D Shroud, fan housing
9 # 5304446353 A - C - Motor, fan
9 # 5304446352 - B - D Motor, fan
11 # 5304446356 A B C D Evaporator
12 # 5304446360 A B C D Capillary Tube
13 # 5304446368 A - - D Discharge Tube
13 # 5304437099 - B C - Discharge Tube
14 # 5304446367 A - - D CompressorAssy
14 # 5304437079 - B C - Compressor Assy
15 # 5304437089 A B C D Condenser
16 # 5304446366 A - - D Suction Tube
16 # 5304437098 - B C - Suction Tube
* # 5304446361 A B C D Power Cord, electric, 115 V

Publication No: 5995438396 FAA063P7
06/05 6
WIRING DIAGRAM
2202019172
