Frigidaire FAS296P2A1 User manual

USE & CARE MANUAL
THIS AIR CONDITIONER IS EQUIPPED WITH A NEW INDUSTRY
STANDARD POWER SUPPLY CORD WITH ATEST-RESET FUNCTION
READ AND SAVE THESE INSTRUCTIONS
AIR CONDITIONER
MULTI-STEP SPEED ELECTRONIC CONTROLS
P/N819042060-01

2
ROOM AIR CONDITIONER WARRANTY
Your product is protected by this warranty
Frigidaire
P.O. Box 212378
Augusta, GA30917
800-444-4944
*NORMAL
RESPONSIBILITIES
OF THE CONSUMER
EXCLUSIONS
IF YOU NEED SERVICE
FULL ONE-YEAR
WARRANTY
LIMITED 2-5 YEAR
WARRANTY (Sealed
LIMITED WARRANTY
(Applicable to the
WARRANTY THE CONSUMER WILLBE
RESPONSIBLE FOR:
Costs of servicecalls that arelisted under
NORMAL RESPONSIBILITIES OF THE
CONSUMER.*
Diagnostic costs and any removal,
transportation and reinstallation costs
which are requiredbecause of service.
Costs for labor, parts and transportation
other than with respect to the Sealed
Refrigeration System.
Costs of the technician’s travel to the
home and any costs for pick up and
delivery of the appliance required
because of service.
One year fromoriginal
purchase date.
Second through fifth
years from original
Time periods listed
above.
Pay all costs for repairing or replacing
parts of thisappliance which proveto be
defective in materials or workmanship.
Repair or replaceany parts inthe Sealed
Refrigeration System (compressor,
condenser,evaporator and tubing)
proves to be defective in materials or
All of theprovisions of thefull and limited
warranties above and the exclusions
listed below apply.
FRIGIDAIRE, THROUGH ITS
AUTHORIZED SERVICERS, WILL
This warranty applies only to products in ordinary household use, and the consumer is
responsible for theitems listed below.
1. Proper useof the appliancein accordance withinstructions provided withthe product.
2. Proper installation by an authorized servicer in accordance with instructions provided with the
appliance and inaccordance with alllocal plumbing, electricaland/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blownfuses,
repair of loose connections or defects in house wiring.
4. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards,
shelves, etc., whichare not apart of theappliance when itwas shipped fromthe factory.
5. Damages tofinish after installation.
This warranty doesnot cover thefollowing:
1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL
EXPENSES RESULTING FROMANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
Note: Some statesdo not allowthe exclusion orlimitation of incidentalor consequential damages,so
this limitation orexclusion may notapply to you.
2. Service callswhich do notinvolve malfunction ordefects in workmanshipor material, orfor appliances
not in ordinaryhousehold use. The consumer shallpay for suchservice calls.
3. Damages causedby services performedby persons other than authorized Frigidaireservicers; use
of parts other than Frigidaire Genuine Renewal Parts; obtained from persons other than such
servicers; or externalcauses such asabuse, misuse, inadequatepower supply oracts of God.
4. Products with original serial numbers that have been removed or altered and cannot be readily
determined.
Keep your bill of sale, delivery slip, or some other appropriate paymentrecord. The date on thebill
establishes the warranty period should service be required. If service is performed, it is in your best
interest to obtain and keep allreceipts. This written warranty gives you specific legal rights. You may
also have other rights that vary from state to state. Service under this warranty mustbe obtained by
following these steps,in order:
1. Contact FrigidaireConsumer Services oran authorized Frigidaireservicer.
2. If thereis a questionas to whereto obtain service,contact our ConsumerRelations Department at::
Product features orspecifications as describedor illustrated aresubject to changewithout notice.All warranties aremade by Electrolux.
This warranty appliesonly in the50 states ofthe U.S.A., PuertoRico and Canada.
Your appliance is warranted by Electrolux. Electrolux has authorized Frigidaire Consumer Services andtheir authorized servicersto
perform service under this warranty. Electrolux authorizes no one else to change or add to any of these obligations under this
warranty. Any obligations for service and parts under this warranty must be performed by Frigidaire Consumer Services or an
authorized Frigidaire servicer.
system)
State of Alaska)
purchase date.
workmanship.

Record Your Model and Serial Numbers
Record in thespace provided belowthe model andserial numbers. Onall models, theserial
plate is locatedon the outsideof the interiorbulkhead left side.
Model Number
Serial Number
Register Your Product
The self-addressed PRODUCT REGISTRATION CARD should be filled in completely,
signed and returnedto the FrigidaireCompany.
2 Warranty
3 Product Registration
3 Normal Sounds
4 Important SafetyInstructions
4 Energy Saving Ideas
5 Operation of Current Device
5-10 Air Conditioner Features
11 Care and Cleaning
12 Avoid Service Checklist
Normal Sounds
Product Registration
3
Gurgle/Hiss
“Gurgling or hissing” noise may be heard
due to refrigerant passing through the
evaporator during normaloperation.
High Pitched Chatter
Today'shigh efficiency compressors
may have a high pitched chatter
during the coolingcycle.
Sound of Rushing Air
At the frontof the unit,you may
hear the sound of rushing air
being moved bythe fan.
Pinging or Swishing
Droplets of water hitting the
condenser during normal
operation may cause“pinging
or swishing” sounds.
Vibration
Unit may vibrate and make noise
because of poor wall or window
construction or incorrectinstallation.
Contents
NOTE: This USE & CARE MANUAL
provides specific operatinginstructions
for your model. Use the room air
conditioner only as instructed in this
USE & CARE MANUAL. These
instructions are not meant to cover
every possible condition and situation
that may occur. Common sense and
caution must be practiced when
installing, operating, and maintaining
any appliance.

4
Important Safety
Instructions
The power supplycord with
this air conditioner contains a current
detection device designed to reduce the
risk of fire.
Please refer to the section ‘Operation of
Current Device’ for details.
In the event that the power supply cord is
damaged, it cannot be repaired it must be
replaced with a cord from the Product
Manufacturer.
Energy Saving Ideas
Read all instructionsbefore using this air conditioner.
For Your Safety
Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance. Read product labels for
flammability and otherwarnings.
Prevent Accidents
To reduce the risk of fire, electrical shock, or injury to persons when
using your air conditioner, follow basic precautions, including the
following:
Be sure the electrical service is adequate for the model you have
chosen. This information can be found on the serial plate, which is
located on the side of the cabinet and behind the grille.
If the air conditioner is to be installed in a window, you will probably
want to clean both sides of the glass first. If the window is a triple-track
type with a screen panel included, remove the screen completely
before installation.
Be sure the air conditioner has been securely and correctly installed
according to the separate installation instructions provided with this
manual. Save this manual and the installation instructions for
possible future use in removing orreinstalling this unit.
When handling theair conditioner, be careful toavoid cuts fromsharp
metal fins onfront and rear coils.
Electrical Information
The complete electricalrating of your new room airconditioner is stated
on the serial plate. Refer to the rating when checking the electrical
requirements.
Be sure the air conditioner is properly grounded. To minimize shock
and fire hazards, proper grounding is important. The power cord is
equipped with a three-prong grounding plug and a current leakage
detection device forprotection against shock & firehazards.
Your air conditioner must be used in a properly grounded wall
receptacle. If the wall receptacle you intend to useis not adequately
grounded or protected by a time delay fuse or circuit breaker, have a
qualified electrician install the proper receptacle.
Do not run air conditioner with outside protective cover in place. This
could result in mechanical damage within the air conditioner.
Do not usean extension cord or an adapter plug.
Do not block inside air flowwith blinds, curtainsor furniture; or
outside with shrubs,enclosures, or other buildings.
The capacity of the room air conditioner must fit the room size for
efficient and satisfactory operation.
Install the room air conditioner on the shady side of your home. A
window that faces north is best because it is shaded most of the day.
Close the fireplace damper, floor and wall registers so cool air does
not escape upthe chimney and into the ductwork.
Keep blinds and drapes in other windows closed during the sunniest
part of the day.
Clean the air filter as recommended in the section “Care and Cleaning”
Proper insulation and weather stripping in your home will help keep
warm air out and cool air in.
External house shadingwith trees, plants or awnings will help reduce
the air conditioner work load.
Operate heat producing appliances such as ranges, washers, dryers
and dishwashers during the coolest part of the day.
WARNINGWARNING
!
WARNINGWARNING
!
NOTENOTE
!
Do not, under any
circumstances, cut,
remove, or bypass
the grounding prong.
Power supply cord
with 3-prong grounding
plug and current
detection device
Grounding type wall
receptacle
WARNINGWARNING
!
Avoid fire hazard or
electric shock. Do not use an extension
cord or an adaptor plug. Do not remove
any prong from the power cord.
WARNINGWARNING
!
N
E
E
R
E
G
V
A
Y
S
S
Y
A
E
V
N
E
O
M

AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
Operation of Current
Device
To reduce therisk of fire,electric shock, orinjury to persons,read the
IMPORTANTSAFETY INSTRUCTIONS before operating this appliance.
WARNING
!
The power supplycord contains acurrent device thatsenses damage tothe power cord.To
test your powersupply cord dothe following:
1. Plug inthe AirConditioner.
2. The power supply cord will have TWO buttons onthe plug head.Press the TEST button.
Youwill notice aclick as theRESET button pops out.
3. Press theRESET button. Again youwill notice aclick as thebutton engages.
4. The power supply cordis now supplyingelectricity to theunit. (On someproducts this is
also indicated bya light onthe plug head).
NOTES:
Do not usethis device toturn the unit on or off.
Always make surethe RESET button is pushedin for correctoperation.
The power supplycord must bereplaced if itfails to resetwhen either theTEST button is
pushed, or itcannot be reset.Anew one canbe obtained fromthe product manufacturer.
If power supply cord is damaged, it CANNOT be repaired. It MUST be replaced by one
obtained from theproduct manufacturer.
ELECTRONIC CONTROL OPERATING INSTRUCTIONS
Before you begin, thoroughly familiarize yourself with the control panel and remote as
shown below and all its functions, then follow the symbol for thefunctions you desire.
The unit canbe controlled bythe control panelalone or withthe remote.
Air Conditioner
Features
TURNS UNIT
ON OR OFF
ACTIVATES
TIMER
SETS FAN
SPEEDS
CHECK FILTER
RESET BUTTON
SETS
MODE
SLEEP
MODE
Control panel Remote with digital display &
remote sensing feature
AUTO COOL
FEATURE
ADJUSTS
TEMPERATURE
OR TIME
CLEAN AIR
FEATURE
(SOME MODELS)
REMOTE TEMP.
SENSING
INDICATOR
(SOME MODELS)
TURNS UNIT
ON OR OFF
SETS
MODE
ACTIVATES
REMOTE
THERMOSTAT
(some models)
ADJUSTS
TEMPERATURE
OR TIME
SETS
FAN
SPEEDS
5
ACTIVATES
TIMER
LIGHT
TURNS UNIT
ON OR OFF
SETS
MODE
ADJUSTS
TEMPERATURE
OR TIME SETS
FAN
SPEEDS
ACTIVATES
TIMER
LIGHT
Standard
remote
Remote for
HEAT models
Heat
HEAT
MODE
SETS
MODE
ADJUSTS
TEMPERATURE
OR TIME
TURNS UNIT
ON OR OFF
SETS
FAN
SPEEDS
ACTIVATES
TIMER
LIGHT
Battery Size: AA
WARNING: Do Not Mix Old And New Batteries. Do Not Mix Alkaline, Standard (Carbon-Zinc), Or
Rechargeable (Nickel-Cadmium) Batteries.

AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
Air Conditioner Features
(continued)
NOTE: The followinginstructions represent theControl Panel, thesame
instructions can beused for theRemote Control.
TO TURN UNIT ON: YOU WILL SEE:
DO THIS:
PRESS ON/
OFF PAD
TO CHANGE TEMPERATURE
SETTING:
YOU WILL SEE:
DO THIS:
PRESS TO
RAISE
PRESS TO
LOWER
NOTE: Tap or hold either up( ) or down ( ) button until the
desired temperature is seen on the display. This temperature
will be automatically maintained anywhere between 60 F(15 )
and 90 F(32 ). If you want the display to read the actual room
temperature. See “ To Operate on Fan Only”section on Page
7.
TO ADJUST FAN SPEEDS: YOU WILL SEE:
DO THIS:
PRESS TO
SELECT:
FASTER
SLOWER
A 2 Digit Display is used to indicate the Fan Speed setting, from
10 through 99. When the “SLOW”button is pressed, the motor
speed will slowdown at multiple intervals (90 distinct settings),
to a minimum setting of 10. To speed the motor up, press the
“ FASTER” button. The speed will increase at multiple intervals
to a maximum setting of 99. After 5 seconds the control will
automatically change back to displaying the set temperature.
6
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer

AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
Air Conditioner Features
(continued)
TO USE AUTO COOL FEATURE: YOU WILL SEE:
DO THIS:
PRESS AUTO
COOL
TO OPERATE ON FAN ONLY: YOU WILL SEE:
DO THIS:
PRESS
MODE
BUTTON
CHOOSE
FAN
NOTE: Use this function only when cooling is not desired, such
as for room air circulation or to exhaust stale air. (Rememberto
open vent during this function, but keep it closed during cooling
for maximum cooling efficiency.) You can choose any fan speed
TO USE THE ENERGY SAVER FEATURE: YOU WILL SEE:
DO THIS:
PRESS MODE BUTTON
CHOOSE ENERGY SAVER
NOTE: In this mode, the fan will continue to run for 3minutes
after the compressor shuts off. The fan then cycles on for 2
minutes at 10 minute intervals until the room temperature is
above the set temperature, at which time the compressor
NOTE: Fan starts at High Speed and adjusts to a slower speed
as the room temperature dictates. For example if the room does
not get too warm, it will stay at the slowest speed. If the room
temperature rises quickly, such as a door being opened, it will
automatically go to the highest speed. The fan speeds will
re-adjust back to the slowest speed as the room returns to the
original set temperature. Press either the fan slower or fan
LIGHT
ON
LIGHT ON
LIGHT ON
7
faster button to adjust the fan speed manually.
you prefer.
During this function, the display will show the actual room
temperature, not the set temperature as in the cooling mode.
During this function, the display will show the actual room
temperature, not the set temperature as in the cooling mode.
turns back onand cooling starts.

AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
Air Conditioner Features
(continued)
TIMER: DELAY STOP/START FEATURE: YOU WILL SEE:
DO THIS:
PRESS TIMER
BUTTON
SLEEP FEATURE: YOU WILL SEE:
DO THIS:
PRESS
SLEEP
BUTTON
NOTE: In this “ MODE “the selected temperature will increase by 2 F 30
minutes after the mode isselected. The temperature will then increase by
another 2 F after an additional 30 minutes. This new temperature will be
maintained for 7 hours before it returns to the originally selected
temperature. This ends the “ Sleep “MODE and the unit will continue to
operate as originally programmed. The “Sleep”MODE program can be
cancelled at any time during operation by again pressing the “ Sleep”
button.
CHECK FILTER FEATURE: YOU WILL SEE:
NOTE: This feature is a reminder to clean the Air Filter (See Care and
Cleaning) for moreefficient operation. The LED (light) will illuminate after
250 hours of operation. To reset after cleaning the filter, press the“Check
NOTE: For Delay Stop, the unit must be in the ON position.
THEN DO THIS:
PRESS UP ( ) OR
DOWN ( )BUTTON
LIGHT ON
LIGHT ON
LIGHT ON
8
NOTE: For Delay Start, the unit must be in the OFF position. To adjust
timer setting, tap or hold the UP arrow ( ) or the DOWN arrow ( ) to
change delay timer at .5 hour increments, up to 10 hours, then at 1 hour
increments up to 24 hours. The control will count down the time
remaining until start (8, 7.5, 7,etc.). The Delay Start mode automatically
selects cooling at High Fan Speed. The temperature maintained will be
the same as previously set. To change the set temperature, press
"COOL " then Up or Down arrows until the desired temperature is
indicated on the display. After 5 seconds, the control will automatically
change the displayback to the hours remaining untilthe unit willstart/stop.
Turning the unit "ON" or "OFF" at any time will cancel the Delay Start/Stop
function.
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
Filter ”button and the light will go off.

Air Conditioner Features
(continued)
9
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
HEATING FEATURE(on some models):YOU WILL SEE:
NOTE: This feature can be used with any combination of FAN Speeds,
Timer, or Sleep Modes. When in the Heat Mode, the fan will run continuously
while heat is needed. The temperature will automatically be maintained
anywhere between 60F(15 ) and 90F(32 ). When the room settemperature
is satisfied, the fan will cycle off and on to circulate and sample the room
air.
DO THIS:
PRESS MODE BUTTON
SELECT HEAT
LIGHT ON
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
CLEAN AIR FEATURE(on some models):YOU WILL SEE:
NOTE: When this feature is “ON”, the electronic air purifier is energized to
remove pollen and impurities from the air. To cancel this feature, press the
Clean Airbutton (the LIGHT will turn off).
NOTE: This feature can beactivated on the unit control panelONLY.
DO THIS:
PRESS CLEAN AIR
BUTTON
LIGHT ON
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
REMOTE SENSING FEATURE
(on some models):
YOU WILL SEE:
NOTE: This feature can beactivated from the remote control ONLY, the unit
must be in a cooling mode.
DO THIS:
PRESS REMOTE
SENSING
BUTTON ON
LIGHT ON
To activate the remote sensing feature, point the remote control towards the
unit and press the remote sensing button. Next, use the buttons to set
the desired temperature at the remote. (Note that the set temperature will
only be displayed on the unit itself). The LIGHT on the remote control will
pulse to indicate it received the signal. The LIGHT on the remote control will
pulse each time it sends a signal. It will continue to send this signal until the
feature is deactivatedby pressing the remote sensing button.If the unitdoes
not receive the remote sensing signal during any 3 minute interval, The unit
will beep to indicate the remote sensing mode has ended. The
display on the remote control indicates the temperature at the remote ONLY.

10
TO TURN UNIT OFF:
DO THIS:
PRESS ON/
OFF BUTTON
ADDITIONAL THINGS YOU SHOULD KNOW
Now that youhave mastered the operating procedure, here are more features in your controlthat you should become
The “Cool”circuit has an automatic 3 minutetime delayed startif the unit is turned off and onquickly. This prevents
overheating of thecompressor and possible circuit breaker tripping. The fan will continue torun during thistime.
The control willmaintain the set temperature within 2 F,between 60 Fand 90 F degrees.
The control iscapable of displaying temperature in degreesFahrenheit or degreesCelsius. To convert fromone to the
other and back, press and hold the “TEMP/TIMER”Up ( )and Down ( ) buttons together for 3 seconds.
Fresh Air Vent Control
Fresh Air Vent Control
The Fresh Air Vent allows the air conditioner to:
1.Recirculate inside air - Vent Closed (See Fig.1)
2.Draw fresh air into the room - Vent Open(See Fig.2)
3.Exchange air from the room and draws fresh air into the room - Vent
and Exhaust Open (See Fig.3)
YOU WILL SEE:
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Energy Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
Fan SlowerFan Slower
Fan FasterFan Faster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
familiar with.
Figure 1 (VENT CLOSED) Figure 2 (VENT OPEN) Figure 3 (VENT &
EXHAUST OPEN)
4-Way Louvers Air directional louvers control air flow direction. You air conditioner
has the louver type described below.
Auger Type
The louvers will allow you to direct the air flow Up or Down and Left or
Right throughout the room as needed. Rotate the Auger Wheel until
the desired Left/Rightdirection is obtained. Pivot horizontal louvers
until the desired Up/Down direction is obtained.
AUTOAUTO
Auto
Cool
Auto
Cool
Clean
Air
Clean
Air
Cool
Saver
Fan
Heat
ModeMode
Temp /TimerTemp /Timer
Temp /TimerTemp /Timer
FanSlowerFanSlower
FanFasterFanFaster
On/OffOn/Off
SleepSleep Check
Filter
Check
Filter
Remote
Sensing
TimerTimer
Air Conditioner Features
(continued)

Care and Cleaning
Clean your air conditioner occasionally to keep it looking new. Be
sure to unplug the unit beforecleaning to prevent shock or fire
hazards:
Air Filter Cleaning
The air filter should be checked at least once a month to see if
cleaning is necessary.
Trapped particles in the filter can build up and cause an accumulation
of frost on the cooling coils.
Open the front panel.
Grasp the filterby the center and pull up and out.
Wash the filter using liquid dishwashing detergent and warm
water. Rinse filter thoroughly. Gently shake excess water from the
filter. Be sure filteris thoroughly dry before replacing.
Or, instead of washing you may vacuum the filter clean.
Cabinet Cleaning
Be sure to unplug the air conditioner to prevent shock or fire
hazard. The cabinet and frontmay be dusted with an oil-free cloth
or washed with a cloth dampened in a solution of warm water and
mild liquid dishwashingdetergent. Rinse thoroughly and wipe dry.
Never use harshcleaner, wax or polish on the cabinet front.
Be sure to wring excess water from the cloth before wiping
around the controls. Excess water in or around the controls may
cause damage to the air conditioner.
Plug in air conditioner.
Winter Storage
If you plan to store the air conditioner during the winter, remove
it carefully from the window according to the installation
instructions. Cover itwith plastic or return it to the original carton.
NOTE: To prevent rust or electrical connections from being
damaged, store air conditioner in an upright position andin a
dry place.
Air Filter
11

Avoid Service Checklist Before calling forservice, review this list. It may save you time and expense. This list
includes common occurrences that are not the result of defective workmanship or
OCCURRENCE SOLUTION
Air conditioner will not operate. Wall plug disconnected. Push plugfirmly into walloutlet.
House fuse blown or circuit breaker tripped. Replace fuse with time delay type or reset
circuit breaker.
Control is OFF. Turncontrol On andset to desired FAN orCOOL setting.
Unit turned off and thenon too quickly. Turnunit off and wait 3minutes before restarting.
Air from unit does not feel cold
enough.
Room temperature below60 F (15 C). Coolingmay not occur until room temperature
rises above 60F (15 C).
Temperaturesensor touching cold coil, located behindair filter.Straighten away from
coil.
Air conditioner cooling,but
room is toowarm- ice forming
on cooling coilbehind
decorative front.
Outdoor temperature below 60 F (15 C). To defrost thecoil, set selector to FAN
position. Then, set thermostat to warmer position.
Air filter may be dirty. Clean filter. Refer to Care and Cleaning section. Todefrost, set
selector to FAN ONLY mode.
Temperature is too low for night-time cooling. To defrost the coil, set to FAN ONLY
mode. Then, set temperature to a higher number.
Air conditioner cooling,but
room is too warm-NO ice
forming on coolingcoil
behind decorative front.
Dirty air filter-airrestricted. Clean air filter. Referto Care andCleaning section.
Temperature is too high. Set temperature to a lower number.
Current device tripped. Preset RESET button.
Reset to a lower temperature.
Compressor shut-off by changing modes. Wait approximately 3 minutes, and listen for
compressor to restartwhen set inthe COOL mode.
Vent set at OPEN position. Set vent at CLOSED position for maximum cooling.
Air direction louverspositioned improperly. Position louversfor better airdistribution.
Front of unitis blocked by drapes, blinds, furniture, etc.-restricts air distribution.Clear
blockage in frontof unit.
Doors, windows, registers, etc, open- cold air escapes. Close doors, windows,
registers, etc.
Unit recently turned on in hot room, allow additional time to remove “ stored heat”
from walls, ceiling, floor and furniture.
Air conditioner turnson and
off rapidly.
Dirty air filter-air restricted. Clean air filter.
Outside temperature extremely hot. Set FAN speed to a faster setting to bring air
past cooling coils more frequently.
Noise when unitis cooling Air movement sound.This is normal. If too loud, set to a slower FAN setting.
Sound of fan hitting water-moisture removal system. This is normal when humidity
is high. Closedoors windows and registers.
Window vibration- poor installation. Refer to installation instructions orcheck with
installer.
Water dripping INSIDE when
unit is cooling.
Improper installation. Tilt air conditioner slightly to the outside to allow water
drainage. Refer toinstallation instructions - check with installer.
Water dripping OUTSIDE when
unit is cooling.
Unit removing large quantity of moisture from humid room. This is normal during
excessively humid days.
Room too cold
Not in HEAT mode. Change mode.(On HEAT models only)
Setting too low. Increase temperaturesetting.
12
materials in thisappliance
Remote sensing deactivating
prematurely(some models).
Remote control notlocated within range. Place remote control within 20 feet& 180 ,
radius of thefront of the unit.
Remote control obstructed. Remove obstruction.
Remote sensing activated (on some models) and remote control located in Hot
Spot-Relocate remote controlor deactivate remote sensing.
